LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 1
Thank you for buying a Bunning spreader. For your 3 year Bunning guarantee please fill
in the form below and return it to G.T. Bunning Ltd.
Customer Name
Post Code
Telephone
Fax
Email
Machine ID Number
Date of delivery
LOWLANDER WARRANTY REGISTRATION FORM
Company Name
ID No. Example 01/17/9999/U/MSL75
Dealer
Address
Important Data Protection Information.
We or our business partners may contract you by mail, telephone, e-mail or other electronic messaging services with offers of goods
and services or information that may be of interest to you.
By providing us with your telephone number or e-mail address you consent to being contacted by these methods.
If you do not wish to receive marketing information by these methods from GT Bunning or our business partners please tick this box.
GT Bunning & Sons Ltd
The Green
Gressenhall, Dereham
Norfolk
NR20 4DT ENGLAND

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 2
Pre-Delivery Inspection sheet
The purpose of this document is to ensure that the operator, hirer or owner is fully appraised of all safey
guidelines and operating and maintenance methods before taking possession of the machine.
Bunning Lowlander Mk4
5
LIGHTING
12
Check operation of lights
13
1
2
Draw attention to the safety decals
located on the machine.
GENERAL
Ensure the operator receives a copy of the
instruction & spares manual.
OPERATOR
DEALER
I have received a copy of the instruction & spares manual and
understand the method of operation, the safety requirements
and the maintenance methods.
I have given basic instruction in the method of operation, the
position of safety stickers and methods of maintenance, and
ensured that the owner/operator is in possession of the
Manual.
3
Explain the functions of the machine.
Check hydraulic cylinder for leaks and
damage.
SIGNATURE
DATE:
19
Check wheel nut torque. (Check daily for first
week of use)
7
Check operation of parking brake.
8
Check operation of service brake.
Check condition of cabling & 7 pin connector.
HYDRAULICS & PNUEMATICS
14
Check hydraulic hose condition especially
brake hoses & connectors.
16
Check oil level of floor drive gearbox and
auger drive gearbox.
4
Locate, identify & explain spreader to
towing vehicle air ,hydraulic and electric
connectors.
STRUCTURE
9
Check condition of body, drawbar & augers
15
Check air system hose condition and
connectors. (Option).
WHEELS & TYRES
17
Check condition of tyres.
6
Explain how to cut the PTO guard to size and
where to fit the safety chains.
BRAKING
11
Grease all points if necessary.(see
manual).
10
Check condition of all cylinders & pins.
18
Ensure tyre pressures are correct for speed &
load.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 3
CHASSIS SERIAL NUMBER................................................................................
SECTION & CONTENTS PAGE
Preface. 7
How to use this manual. 7
Operating on public roads. 7
Introduction. 8
Disposal. 8
EC Declaration of Conformity. 9
Machine over view. 10
1. OPERATING INSTRUCTIONS
1.1 Hitching to tractor. 11
1.2 Coupling of hydraulic hoses. 12
1.3 Hand brake. 13
1.4 Brake adjustment. 13
1.5 Floor adjustment. 13
1.6 Method of operation. 13
1.7 Slurry door. 13
1.8 Installation and gerenal use of detachable spinner deck. 14
1.9 Horizontal beaters operation. 16
2. MAINTENANCE
2.1 Lubrication of spreader. 17
2.2 Servicing intervals. 17
2.3 Amount of oil required to fill gearboxes. 20
2.4 Service record. 21
2.5 Shearbolt protection. 22
2.6 Key greasing points. 22
2.7 Jack points. 22
DRAWINGS AND PARTS LISTS
3. FLOOR DRIVE
3.1 Hydraulic circuit for floor drive. 23
3.2 Floor speed control unit. 24
3.3 Floor drive relief valves. 26
3.4 Floor drive gearbox MK4 75/85/90/105/105C/120 B3105. 27
3.5 Floor drive gearbox MK4 150 B3122. 29
3.6 Rear floor shaft assembly MK4. 31
3.7 Front shaft and chains MK4. 33

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 4
4 AUGERS AND DRIVES
4.1 Shredding augers MK4. 35
4.2 Shredding augers WB for hybrid machines. 37
4.3 Horizontal beater with spinning discs. 39
4.4 Gearbox Standard 540/360 - B3172. 41
4.5 Gearbox Standard 1000/420 - B3170. 43
4.6 Gearbox Widebody augers 1000/350 - B3180. 45
4.7 Gearbox Spinner deck through drive 1000/420 - B3175. 47
4.8 Gearbox Detachable spinner deck 1000/520 - B3190. 49
4.9 Gearbox Horizontal beater 1000/520 - B3192. 51
4.10 Transverse drive assembly horizontal beaters. 53
5. P.T.O AND TRANSMISSION
5.1 MK4 Transmission model 75 & 105C. 54
5.2 MK4 Transmission model 85/90/105/105HY/150C. 55
5.3 MK4 Transmission model 120/120HY. 56
5.4 MK4 Transmission model 150/150HY. 57
5.5 MK4 Horizontal beater transmission. 57
5.6 Problems and possible solutions. 58
5.7 Walterscheid wide angle PTO. 60
5.8 Walterscheid torque limiter complete 6 spline wide angle. 60
5.9 Walterschied PTO shaft. 61
5.10 Walterscheid W/A PTO shaft. 62
5.11 PTO guard safety chain fixing. 64
5.12 PTO stowage. 66
6. BRAKE & AXLE ARRANGEMENTS
6.1 Model 75, 85 & 90 - Axle and hub parts. 67
6.2 Model 75, 85 & 90 –Brake parts. 68
6.3 Model 75, 85 & 90 –Brake lever parts. 69
6.4 Model 105 & 105C - Axle and hub parts. 70
6.5 Model 105 & 105C –Brake parts. 71
6.6 Model 105 & 105C –Brake lever parts. 72
6.7 Model 120 –all Axle parts. 73
6.8 Model 150 –all Axle parts. 75
6.9 Hydraulic brake ram assembly Model 75. 77
6.10 Hydraulic brake ram assembly Model 85/90/105/105C/120/150. 78
6.11 Hydraulic brake circuit –single axle. 79
6.12 Hydraulic brake circuit –rear drawbar clevis. 80

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 5
7. AXLES & SPRUNG DRAWBAR
Safety notice. 82
General information. 83
Axle maintenance and adjustment. 83
Sprung drawbar spring information. 94
Minimum program of maintenance sheet. 95
8. TYRES AND WHEELS
8.1 Tyre and wheel maintenance. 96
8.2 Pressure settings standard tyres. 97
8.3 Wheel type and torque settings. 103
9. OPTIONS
9.1 Sprung drawbar. 104
9.2 Rear clevis drawbar. 105
9.3 Guillotine slurry door MK4. 106
9.4 Guillotine slurry door MK4 horizontal beaters. 107
9.5 Guillotine slurry door hydraulic circuit drawing. 108
9.6 Support Leg. 109
9.7 Toolbox. 109
9.8 Sludge cake kit. 110
9.9 Detachable Spinner deck kit. 111
9.10 Handbrake control multi-stroke. 113
9.11 Auger deck rubbers MK4 & WB. 113
9.12 Simple canopy. 114
9.13 Hydraulic border control. 114
9.14 Automatic rear lamps. 115
9.15 Weigh cell spares. 116
10. ELECTRICS
10.1 Wiring for 12v 7 pin plug. 117
10.2 Rear lamps. 118
10.3 Marker lamp. 118

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 6
11. HEALTH AND SAFETY & POTENTIAL HAZARDS
11.1 Hazardous machinery warning. 119
11.2 Loss of control. 119
11.3 Operation around bystanders. 119
11.4 Hydraulic fluid penetration or burning. 119
11.5 Electrocution. 119
11.6 Body entry. 119
11.7 Coupling / decoupling. 119
11.8 Machinery start up. 120
11.9 Machinery shut down. 120
11.10 Additional driver protection. 120
11.11 PTO Connection and guarding. 120
11.12 Personal protective equipemnt. 120
11.13 Safety decal location. 120
11.14 Operating hazard area. 121
11.15 Warnings 122
12. WARRANTY 122
13. IMPORTANT INFORMATION 123
14. NOTES 124
15. IDENTIFICATION PLATE 125
16. TECHNICAL DATA & SPECIFICATIONS 126
17. MACHINE DIMENSIONS 127
** THIS MANUAL IS THE ORIGINAL INSTRUCTIONS **

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 7
PREFACE
The instructions in the manual must be read carefully and followed by all persons concerned
with the operation, maintenance, repair or inspection of this machine in order to prevent
accidents.
Especially read sections relating to safety, operating instructions and maintenance.
The use of spare parts, accessories and additional equipment which is not originally
manufactured checked and release by GT Bunning Ltd can have a negative effect on specific
design features of the machine and on its operability. This may impair its operating safety, as
well as safety at work for the operator and could invalidate warranty.
GT Bunning will in no way be liable for damage or personal injury caused by the use of other
than original GT Bunning parts, accessories and additional equipment.
Technical specifications, dimensions and weights are given with the usual tolerances (+ or -2%).
GT Bunning Ltd operates a policy of continual improvement; as such some items in this manual
may differ slightly from that of your machine. GT Bunning reserves the right to make changes to
the machine or manual without notice. If in any doubt regarding any aspect of the design or
operation of this machine contact GT Bunning Ltd or your GT Bunning Ltd agent for clarification.
HOW TO USE THIS MANUAL
The manual contains sections that cover all of the following, Safety, Operating instructions,
Maintenance, Specifications and Technical data. Refer to the contents pages for the relevant
page number.
Before use of the machine familiarise yourself with the manual and its contents.
The machine should only be operated, serviced and repaired by persons who are familiar with
the machine and who have read and understood this manual, and are informed of the risks.
This manual should stay with the machine/operator at all times.
OPERATING ON PUBLIC ROADS (UK)
Before operating on public roads the spreader must be correctly connected to the towing
vehicle, the lights must be connected and function of the lighting equipment must be checked.
The braking system of the spreader must be correctly connected to the towing vehicle, check for
correct operation. Remember, max gross combination weight is 24390Kg and maximum gross
spreader weight is 18290kg. If your spreader is wider then 2.55m and up to 3.5m your
maximum speed is 25 mph, above 3.5m is 12 mph.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 8
INTRODUCTION
This manual provides information on the use, adjustment and servicing of the GT Bunning range
of Lowlander spreader.
Following the advice on the correct maintenance and servicing procedures will ensure maximum
performance and a long service life of your machine.
Failure to carry out maintenance work correctly or incorrect operation will result in poor
machine efficiency and loss of valuable time.
By ensuring the correct operation, and by carrying out maintenance and service work with care,
you will be able to make full use of the technical knowledge and the experience with which your
Lowlander spreader was originally designed.
DISPOSAL
Upon completion of the useful life of the machine, all parts can be disposed of at a suitable
waste disposal facility.
Care must be taken if oxy-acetylene cutting equipment is to be used.
The wheels and tyres, hydraulic cylinders, valves and hoses must be removed before using
cutting equipment.
Oil must be drained collected and disposed of in accordance with current legislation.
Electrical components must be disposed of in accordance with the relevant legislation.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page 9
G.T.BUNNING & SONS LIMITED
Manure Spreaders
Telephone: [phone] Registered Office:
Fax: [phone] Smithy House,
TheGreen
E-mail: [e-mail] Gressenhall, Dereham
www.gtbunning.co.uk Norfolk, NR20 4DT
EC MACHINERY DIRECTIVE
2006/42/EC
DECLARATION OF CONFORMITY
We hereby certify that the machinery stipulated below complies with all the relevant provisions
of the EC Machinery Directive 2006/42/EC & regulations adopting the Directive.
Modifications to this machine without prior written approval from the undersigned will render
the declaration null & void.
Machine Description: Unbalanced trailer for the
carriage & application of manure
Machine Type: Agricultural manure spreader
Model: Lowlander MSL
Serial Number: / / /U/MSL
Standards used.
BS ISO 4251-1:2005+A1:2012, BS EN ISO 12100-1:2010, BS EN ISO 4254-1:2015, BS EN 690: 2013,
BS EN 15811: 2014, BS EN ISO 13857:2008, BS EN 349:1993+A1:2008, BS EN 12965:2003+A2:2009,
BS EN 150 14120:2015, BS EN ISO 5674:2009, BS EN ISO 4413:2010, BS EN ISO 4414 2010
Signed Date :
Name: Greg Shepherd Position: Joint Managing Director

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
10
MACHINE OVER VIEW
KEY QTY DESCRIPTION
1 1 BODY
2 1 DRAWBAR
3 1 STONE GUARD
4 1 FRONT PILLAR
5 1 PTO DRIVE LINE
6 1 FINGER GUARD
7 1 SUPPORT LEG
8 1 LADDER
9 2 WHEEL & TYRE ASSEMBLY
10 1 AUGER GEARBOX
11 1 FLOOR DRIVE GEARBOX, MOTOR AND VALVE
12 2 AUGERS
13 2 AUTO LAMP ASSEMBLY
14 1 AXLE
15 1 PTO STOWAGE

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
11
1. OPERATING INSTRUCTIONS
The intended purpose of the vehicle is to tow and spread manure and other materials.
1.1 Hitching to tractor.
Attach spreader to pick-up hook or static hitch stub. Do not attach to swinging drawbar
or pick-up hook in extended position.
Remove screwjack from drawbar (if fitted) and locate in transport position provided at
the front of spreader.
Turn off the tractor and remove key before fitting PTO.
Slide the tractor end of the PTO shaft out and fit to the tractor PTO. Lay the two halves
of the PTO shaft alongside one another and mark the required lengths, allowing for
turning. Maximum pull out of 300mm (12 inches) of the 2 shafts. Cut to size and clean
burrs at each end of shaft KEEP SHAFT SLIDING SURFACES GREASED. Attach chains
fitted to PTO guard (to prevent rotation of guard) to suitable point on the tractor and
the staple on the drawbar. Ensure that the spring loaded pins in splined yokes are fully
locked in position. Always disengage the PTO when turning sharply to avoid damage to
shafts universal joints. Where a wide angle PTO is fitted attach this end to the tractor.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
12
1.2 Coupling of hydraulic hoses.
Fit the two hoses for the floor drive hydraulic motor (one to feed and one for return) to
double spool valve on tractor. Choose position of spool lever for ease of control to
obtain floor movement to rear. Reversing of floor is done by selecting the opposite
position of the hydraulic control lever. Universal quick release probes are fitted as
standard to hose ends. Mark hose as required to assist in the future coupling for correct
position of feed and return. When a slurry door is fitted connect the hydraulic hoses to
a double spool valve and select the hose positions to suit the operator to open and close
the door.
Fit hydrualic brake hose to trailer brake valve on tractor (male fitting).
A universal female brake coupling is fitted as standard to the hose ends.
N.B CHECK DIRECTION OF FLOOR BEFORE LOADING.
Do not run floor in reverse with full load. Speed of floor in reverse is at MAXIMUM.
Only reverse floor for a few seconds.
Ensure the braking system is connected and that it functions correctly before moving.
FLOOR PRESSURE
FLOOR RETURN
SLURRY DOOR CLOSE
SLURRY DOOR OPEN
SPARE RETURN
SPARE FEED
BRAKES

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
13
1.3 Hand brake.
The handbrake is a multi-stroke ratchet type. To apply the handbrake give the handle
short pumps (a clicking of the ratchet will be heard) until resistance occurs and
subsequent tightening of the cable. To release the handbrake give the handle one sharp
movement in the opposite direction This releases the ratchet mechanism.
1.4 Brake adjustment.
Brake adjustment is carried out at the hydraulic brake ram unit fitted to each wheel axle
giving independent adjustment to each wheel. To adjust, jack up the spreader, slacken
the locknut in the set screw and turn the set screw clockwise. (See section 7)
BEWARE NOT TO OVER ADJUST. Make sure the wheel can rotate freely.
1.5 Floor adjustment.
When adjusting floor chains ensure that the adjustment is carried out equally to both
sides.
DO NOT ALLOW THE CHAINS TO BECOME TOO SLACK.
ADJUST CHAINS AFTER A FEW LOADS.
KEEP CHAINS ADJUSTED CORRECTLY AT ALL TIMES, A GUIDE IS TO BE ABLE TO SEE A
WHOLE LINK BELOW FRONT SIDE OF THE SPREADER i.e. FROM CENTRE TO FRONT
POST.
Reverse floor
The floor should only be reversed for very short periods, to clear the augers.
Do not reverse if the floor chain is slack, tighten floor chain first.
1.6 Method of operation.
1) Select speed of floor required on control valve.
2) Engage PTO to power the rear augers –tractor engine revs low.
3) Raise slurry door if fitted.
4) Engage spool valve to power floor to rear.
1.7 Slurry Door
As the load height reduces lower the slurry door to cover the augers. This will help
prevent foreign objects being thrown forward.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
14
1.8 INSTALLATION AND GENERAL USE OF DETACHABLE SPINNER DECK
GENERAL USE
The detachable spinner deck is designed purely for wider spread patterns and low
application rates of between 1 and 3 tonnes per acre (2 ½ to 7 ½ tonnes per hectare). It
must NEVER be used to spread long straw based material or heavy applications beyond
5 tonnes per acre.
INSTALLATION
When fitting or removing the spinner deck assembly great care must be taken not to
endanger an assistant in any way, especially when raising or lowering the unit. Persons
must not be put at risk.
Before making any adjustments, fitting or removing attachments, the tractor that the
spreader is attached to must be switched off and the key removed.
FITTING THE SPINNER DECK –See pages 111 & 112 for parts list.
1 Remove guard from output spigots of the auger gearbox.
2Slide one half of ‘flexi coupling’ onto the shaft, through shaft of spinner gearbox.
3 Slide other half of the ‘flexi coupling’ on the input spigot of the spinner gearbox.
4 Using approved lifting apparatus lift the complete spinner deck assembly using
lower lifting eye on canopy.
5 Offer the assembly to rear of the machine and lower into position. Firstly locate
the ‘bucket hooks’ of deck into clevis’ at the top rear corners of the spreader.
6 Hinge hook bolt No. 14 into anchors and tighten.
7 Fit and tighten 4 bolts to join the two halves of the flexi coupling.
8 The machine is now ready for use with the spinner deck.
Flexi coupling
Bucket hooks
Cattle ramp fastener

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
15
REMOVING THE SPINNER DECK
1 Clean all material from spinners and decks.
2 Remove 4 bolts from the flexi coupling.
3 Loosen hook bolts No. 14 and hinge back to clear anchors.
4 Using approved lifting apparatus lift from lower lifting eye on the canopy firstly
pulling the bottom of the deck assembly away from rear of spreader to the clear
auger blades.
5Lift the assembly clear of the spreader and stand on level ground with the front
of the assembly close to, or against a wall or stable object.
6 Fit the shaft cover to the output spigot of the spreader auger gearbox.
7 The machine is now ready for use without spinner deck.
ADJUSTMENT OF CANOPY & BLADES
For the best results
1 Fix the canopy on the inner positions for light materials i.e. Poultry manure.
2For heavy material i.e. slurry or sludge adjust canopy out as far as possible so as
not to deposit material beyond the deck into gaps between the discs.
3 To increase the width of the spread pattern adjust the angle of blades forward
on the disc.
4 If the spread pattern is light immediately behind the machine adjust the angle of
the blades back.
5 It is possible to achieve an even spread by adjusting the blades, as opposing
pairs. i.e. Blade 1 and 3 position 3 and blade 2 and 4 in position 1.
LEFT HAND SPINNER
Direction of spin

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
16
1.9 OPERATING INSTRUCTIONS FOR HORIZONTAL BEATERS
General use
The horizontal beater with spinner discs is designed primarily for wider spread patterns
and lower application rates for product such as chicken and turkey manure, however
long straw based materials can be spread effectively. It must be expected that
application rates maybe slower than a vertical auger spreader.
Adjustments for spread patterns
The position of the lower section of rear canopy and the angle of the blades on the discs
will affect the spread pattern and width.
Select a hole position that places the rubber strip over the middle of the discs for a
lighter application rates and wider widths. Adjust the hole position to move the rubber
strip rearwards for higher application rates e.g. for straw based materials. Excessive
rearward adjustment will cause the material to miss the discs and hit the ground
without being spread.
Each spinning disc is supplied with 2 blades on and the others loose; it has been proven
that many materials are spread more effectively with just 2 blades per disc.
1 To increase the width of the spread pattern adjust the angle of blades forward
on the disc.
2 If the spread pattern is light immediately behind the machine adjust the angle of
the blades back.
3 With 4 blades fitted it is possible to achieve an even spread by adjusting the
blades, as opposing pairs. i.e. Blade 1 and 3 in position 3 and blade 2 and 4 in
position 1.
4 When adjusting angle use the 2nd set of holes on the blade to keep the tip of the
blade on the edge of the disc
Change angle of lower
canopy here.
Rubber strip pointing
at the centre of the
spinning discs.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
17
2. MAINTENANCE
2.1 Lubrication of spreader.
DAILY GREASE Front and rear floor shaft
Overrun clutch to front of main ‘T’ gearbox
Hitch eye
WEEKLY GREASE All sealed bearing –1/2 pump of grease gun maximum.
TAKE CARE NOT TO DAMAGE GREASE SEAL BY OVERGREASING
Sliding tube of PTO shaft.
PTO universal joints –Follow manufacturers instructions.
Screwjack top (when fitted)
Shearbolt bush
MONTHLY Check gearbox oil levels
ANNUALLY Change oil to all gearboxes
TYPE OF LUBRICATION GREASE Multi purpose
GEARBOXES EP90
2.2 Servicing intervals
The period recommended is based on normal operating conditions. Severe or unusual
conditions may require more frequent lubrication or oil changes.
IMPORTANT: ENSURE CV JOINT IS GREASED BEFORE FIRST USE!
TAKE CARE NOT TO DAMAGE SEALS BY OVERGREASING.
DAILY (8 HRS)
1. Check for hydraulic fluid leaks and damaged hoses.
2. Grease Front and Rear floor chain shaft bearings.
a. Front shaft.
• Remove front Finger Guard to access bearings.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
18
b. Rear Shaft.
• Grease both left and right bearings.
3. Grease the Overrun Clutch to front of the auger gearbox.
WEEKLY (40 HRS)
1. Check wheel nuts. Re-torque as needed.
2. Grease all sealed bearings
a. Driveline hanger bearings (2 or 3 depending on model).
b. Top auger bearings (Grease nipples access provided on right turret).
3. Grease the telescoping section of the PTO shaft.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
19
4. Grease PTO input drive system.
a. Input shaft.
b. Cross joint fittings.
c. Guard bearings.
d. Shear bolt housing.
e. Over-running clutch (5 pumps).
5. Grease the implement jack top.
6. Check gearbox oil level
a. Floor Chain Drive Gearbox
-Oil should be level with the middle of the sight glass.
-Add oil as required through the top plug.
b. Auger Gearbox
-Spreader must be unhooked from tractor and set on level ground to check oil. Oil
should be level with the middle of the sight glass.
-Add oil as required through the top plug.
-Oil may take a while to distribute in casing, recheck level after 30 –40 minutes and
repeat if necessary.
MONTHLY
1. Apply grease or heavy oil to apron chain.
2. Grease telescoping section of PTO shaft.
3. Grease the CV Joint of PTO shaft (15 pumps)
4. Grease suspension system spring bushings on each side.
5. Grease brake pivot bushings (Tandem Suspension machines).
6. Grease parking brake leaver joint.
7. Check and adjust the apron chain tension.

LOWLANDER MK4 MANURE SPREADER –INSTRUCTION & SPARES MANUAL
Page
20
ANNUALLY
1. Change oil to all gearboxes.
2. Check the condition of the frame sealing flaps. Replace if not sealing the sides or bottom.
a. Front.
b. Rear Slurry Door Auger Deck.
3. Check brake setting.
Brakes can be checked by depressing the brake petal with the engine running and the
tractor in gear; release clutch to determine brake adjustment.
4. Check condition of rotor blades and paddles. Repair when there are loose bolts, cracked
welds, chipped, bent or broken blades or paddles. Replace when any components are worn
within 25mm (1 inch) of flighting.
5. Clean machine.
6. Check general hardware/bolt tightness. Retighten if necessary.
It is recommended to apply waste oil to the floor chains periodically when spreading dry material
and particularly at the end of the spreading season. This assists in the smooth running of the
machine and prolongs the working life of the components.
7. Check bearings in gearboxes.
8. Remove the floor drive gearbox from drive shaft, clean both, add copaslip to the drive
shaft and gearbox and replace.
2.3 Amount of oil required to fill gearbox
Please use EP90 gear oil
RT500/50/25 6.7 Ltrs (TVA) - 7.75 Ltrs (HBD)
RT800/60/32 10.5 Ltrs (TVA) - 12 Ltrs (HBD)
SRT 12 13.5 Ltrs
SRT 18 13.5 Ltrs
B3183 HDB all in one g/box 16 Ltrs
