Sealey SPB57T User manual

INSTRUCTION MANUAL FOR:
BROADCAST SPREADER 57kg TOW
BEHIND
MODEL No: SPB57T
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
3. SPECIFICATION & CONTENTS
2. INTRODUCTION
4.1. Check contents against fig.1 above, if anything is missing or
damaged contact your local Sealey dealer.
4.2. Refering to fig.2, place an axle bush (18) onto the axle of the
frame tube assembly(1).
4.3. Attach the pneumatic wheel (5) then a Ø16 flat washer (17) to
the mounting tube axle. Secure with split pin (11) and repeat
procedure for the other side. Additional Ø16 flat washers (17) are
provided to adjust the spacing between the axle bushing (18)
and the pneumatic wheel (5).
4.4. Rotate one pneumatic wheel (5) so that the hole on the inside of
the wheel boss aligns with the corresponding hole in the axle
tube. Insert inner hex bolt M5x45 (10) through the axle tube and
secure with lock nut M5 (12) as shown in figure 2.
4. ASSEMBLY
Model No. ......................................SPB57T
Capacity (Weight)....................................57kg
Capacity (Volume) ...................................60ltr
Spread .........................................3-3.6mtr
Weight .......................................... 11.6kg
Dimensions (W x D x H)...................680 x 980 x 790mm
 Ensure that the spreader is in sound condition and good working
order before use.
Ensure that the operator is fully trained and competent to operate
the prime mover before attaching and using the spreader.
 Ensure that all chemical safety instructions are adhered to when
handling products for use in the spreader. A full range of personal
safety equipment is available from your Sealey dealer.
 Always distribute the load evenly.
 Ensure all non essential personnel keep a safe distance when the
spreader is in use.
 Replace or repair damaged parts. Use only recommended parts.
Unauthorised parts may be dangerous and will invalidate the
warranty.
 Keep hands and feet away from moving parts.
DO NOT overload the spreader - see Specification.
DO NOT leave unattended, especially when loaded, unless the
wheels are chocked or the spreader is otherwise secured.
DO NOT allow others to ride on the spreader.
DO NOT allow untrained personnel to use the spreader.
DO NOT use the spreader for purposes other than for which it is
designed.
DO NOT operate the spreader when you are tired or under the
influence of alcohol, drugs or intoxicating medicines.
When loaded,DO NOT operate the spreader over edges, rough
surfaces etc. where the spreader is at risk of overturning.
WARNING! Failure to comply with these instructions may result
in damage to spreader or other property and/or personal injury.
Manufactured with a strong tubular steel frame and polypropylene
dispensing hopper. Pin hitch design attaches to ride-on lawnmowers,
can be converted to ball hitch using Model No. TB36. Fitted with
aluminium gear, rain cover, pneumatic tyres and adjustable feed
system. Includes hopper screen to ease spreader flow and filter out
unwanted contaminants. Sprays in 360° motion to cover a large area.
Suitable for a variety of horticultural agents, including grit, seed, salt,
fertiliser and weed killer.
Original Language Version SPB57T Issue: 1 - 21/06/11
fig.1
fig.2

4.9. Place the hopper (6) over the frame tube assembly (1) so
that the shaft protruding from the impeller on the frame tube
assembly locates into the swivel bush on the base of the
hopper.
4.10. Align the six bolt holes in the hopper assembly with the six
bolt holes on the frame tube assembly and fit the Hex Bolts
M6x40 (9) with the big flat washers M6 (15) at the bolt heads.
Loosely attach the M6 lock nuts (13) as shown in figure 6.
Adjust the hopper assembly over the frame tube assembly
until the impeller is free to rotate without any resistance. Fully
tighten the nuts and bolts securing the hopper assembly to
the frame tube assembly.
4.11. Attach the R-pin (19) to the shaft protruding above the
impeller as shown in figure 7.
4.5. Attach the hitch tube (2) to the frame tube assembly tube (1)
using hex bolt M6x40 (9), big flat washer M6 (15) and M6 lock
nut (13) as shown in figure 3. At this stage do not fully tighten
the nut and bolt.
4.6. Attach one brace (3) to either side of the hitch tube (2)
using hex bolt M6x35 (8) and M6 lock nut (13) as shown in
figure 4. Do not fully tighten the nut at this stage
fig.3
fig.4
4.7. Attach the other ends of the braces (3) to the frame tube assembly
(1) using hex bolt M6x35 (8) and M6 lock nuts (13) as shown in
 gure5.
4.8. All nuts and bolts used for the braces (3) can now be fully
tightened
fig.5
fig.6
fig.7
4.12. Attach a Ø8 flat washer (16) over the loose end of the
adjustable connection rod and insert the rod through the
hole in the fixing plate at the base of the hopper and secure
with a M8 lock nut (14) as shown in figure 8.
4.13. Place the hopper screen (4) into the hopper (6) so that it sits
squarely on the base.
4.14. The spreader is now fully assembled and ready for use.
Original Language Version SPB57T Issue: 1 - 21/06/11

5. OPERATION
Original Language Version SPB57T Issue: 1 - 21/06/11
5.1. Read the Safety Instructions in Section 1 before operating the
spreader.
5.2. Secure the spreader onto the prime mover using the towing
pin on the hitch tube (2). Secure the towing pin with the R-pin
provided. The spreader can be converted to use a ball hitch
by fitting a Sealey Ø50mm Towing Hitch, Model No. TB36,
available from your Sealey dealer.
5.3. Load the product into the hopper, ensuring that it is evenly
distributed and the maximum capacity of the spreader is not
exceeded. When handling hazardous products it is important
to first read the safety data sheet and take necessary safety
precautions. A full range of personal safety equipment is
available from your Sealey dealer.
5.4. The towing speed will affect the rate of flow from the
spreader. It is advisable to operate the spreader at lower
speeds for a more effective flow of the product.
5.5. The adjustable feed system is controlled by movement of the
handle on the hitch tube (2). Operate the spreader at the
desired speed and adjust the handle either forwards or
backwards until a satisfactory rate of flow is achieved. A
locking device is provided on the gauge to allow the optimum
flow required to be maintained.
5.6. Clean the spreader thoroughly after use, paying particular
attention to the area around the adjustable feed system and
the impeller.
fig.8
6. MAINTENANCE
6.1 After each use clean material out of hopper.
6.1.1 Rinse/dry inside and outside of spreader after each use.
6.1.2 Before operating make sure that the tyres are inflated to the
correct pressure.
6.1.3 Periodically check all fastenings are tight.
6.1.4 Annually clean and lightly lubricate parts.
6.1.6 To avoid damaging the spreader never exceed the rated load
capacity of 57kg.
6.2 STORAGE.
6.2.1 Before storing ensure that the spreader is clean and dry.
6.2.2 Store indoors or in a protected area during severe weather and
in the winter months.
6.2.3 Never allow material to stay in the hopper for extended periods
of time.

NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our catalogue and latest promotions call us on 01284 757525 and leave your full name, address and postcode.
Original Language Version SPB57T Issue: 1 - 21/06/11
(CHART 'A') SQUARE FOOT COVERAGE PER BAG (LBS/1000 SQ.FT)
WEIGHT OF BAG (LBS) 5000 SQ.FT COVERAGE 10000 SQ.FT COVERAGE 15000 SQ.FT COVERAGE
5 1.0lb 0.5lb 0.3lb
10 2.0lb 1.0lb 0.7lb
15 3.0lb 1.5lb 1.0lb
20 4.0lb 2.0lb 1.3lb
25 5.0lb 2.5lb 1.7lb
30 6.0lb 3.0lb 2.0lb
35 7.0lb 3.5lb 2.3lb
40 8.0lb 4.0lb 2.3lb
45 9.0lb 4.5lb 3.0lb
50 10.0lb 5.0lb 3.3lb
55 11.0lb 5.5lb 3.7lb
(CHART 'B') SPREADER SETTINGS/SPREADER WIDTHS
MATERIALS TO BE
USED
LBS/1000
SQ.FT
SPREADER
SETTING
SMALL PARTICLE
SPREAD
MEDIUM PARTICLE
SPREAD
LARGE PARTICLE
SPREAD
GRIT
SEED
FERTILISER
WEED
KILLER
E.T.C.
1 5 5-6 ft 6-9 ft 9-12 ft
2 8 5-6 ft 6-9 ft 9-12 ft
3 10 5-6 ft 6-9 ft 9-12 ft
4 13 5-6 ft 6-9 ft 9-12 ft
5 15 5-6 ft 6-9 ft 9-12 ft
6 18 5-6 ft 6-9 ft 9-12 ft
7 20 5-6 ft 6-9 ft 9-12 ft
8 23 5-6 ft 6-9 ft 9-12 ft
9 25 5-6 ft 6-9 ft 9-12 ft
10 28 5-6 ft 6-9 ft 9-12 ft
11 30 5-6 ft 6-9 ft 9-12 ft
