INSTRUCTIONS FOR:
AIR HYDRAULIC PUMP 10TONNE
MODEL Nos: RE83/840.V2 & RE83/840/CWH.V2
Thank you for purchasing a Sealey product. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
1. SAFETY INSTRUCTIONS
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS.
USE THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.
WARNING! Ensure Health & Safety, local authority and general workshop practice regulations are adhered to when using this equipment.
Familiarise yourself with product application and limitations, as well as the specific hazards peculiar to the pump.
WARNING! Disconnect the hydraulic pump from the apparatus before servicing or performing any maintenance.
Maintain pump in good order. Replace/repair with genuine parts only. Unauthorised parts may be dangerous and will invalidate the warranty.
Use qualified person to lubricate and maintain the hydraulic pump. DO NOT use brake fluid to top up hydraulic unit. Use Sealey hydraulic oil only.
Keep the pump and treadle clean for best and safest performance.
WARNING! Ensure you know how much load you are pushing. Never exceed the maximum pushing capacity.
The kit accessories may be used with other popular makes of kit.
 We recommend the use of BS approved safety impact goggles and heavy duty gloves when working with this pump. Both are available from your
authorised Sealey dealer.
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
If working on an ‘off centre’ load, pump with care. If you feel undue resistance, stop and re-adjust the set-up.
Ensure any hydraulic hoses are not bent or kinked but laid out correctly. Avoid damage to hoses (e.g. crushing/cutting).
Keep non-essential persons away from the operating area. Be aware of the locations of other persons assisting you.
 DO NOT operate the pump if any parts are damaged or missing as this may cause failure and/or personal injury.
WARNING! DO NOT use for any purpose other than for which it is designed.
When not in use, place dust cap in end of hydraulic hose or cylinder and store in a safe, dry, childproof location.
Only fully trained and qualified persons should use this equipment. These instructions are not a substitute for user receiving full
supervised training by a qualified person. It is important the user understands the applications, limitations and potential hazards
of the product.
Original Language Version RE83/840.V2 & RE83/840/CWH.V2 Issue: 1 - 13/11/12
MODEL: RE83/840.V2
MODEL: RE83/840/CWH.V2
©Jack Sealey Limited
2. INTRODUCTION/SPECIFICATIONS
2.1 Suitable for use with SuperSnap hydraulic ram as supplied with Model No. DZRE92/C body straightener and all body kits.
Air Supply Oil Pressure Oil Capacity Hose
Model No. RE83/840.V2 90-120psi 10000psi 450cc not supplied
Model No. RE83/840/CWH.V2 90-120psi 10000psi 450cc supplied (loose)
R

Original Language Version
3. OPERATION
3.1 Setting up
3.1.1 Remove pipe plug from hydraulic adaptor and connect a hose (Model RE83/840.V2 only)
3.1.2 Removetheshippingplugfromtheairinletportandinserta1/4"NPTquickreleasecoupler(Ifnottted).
3.1.3 Connect an air supply to the quick release air hose coupler and connect the hydraulic hose to the ram or device coupler.
3.1.4 To operate the pump for ram/device extension/actuation, depress the treadle at the air inlet valve end.
3.1.5 To retract the ram/device to the original start position, depress treadle end marked "RELEASE". Retraction will stop with
load held, when pressure on treadle is removed. For fullest retraction continue to depress.
3.2 Operating requirements
3.2.1 For maximum performance and rated hydraulic pressure, air pressure should be 100psi minimum.
3.2.2 Toensurebestperformancetheairsupplyequipmentshouldincludeanairlter,regulatorandlubricator.Aminimum
 requirementisanairlterwiththeaircompressortankdrainedofwatereverydayandasmallquantityoflubricatingoilinto
the air inlet each week.
3.2.3 Hydraulic output pressure can be controlled by regulating the air pressure. To determine the maximum hydraulic pressure
multiply the regulated air pressure reading by 100.
4.1 Release valve adjustment
4.1.1 Attach an air supply to the pump.
4.1.2 With an allen key loosen socket headed cap screw (Fig.2.) in treadle pivot boss two or three full turns.
4.1.3 With a screwdriver turn anti-clockwise the slotted head release valve (Fig.2. and Fig.3.) two full turns.
4.1.4 Lift the treadle at the air inlet end and depress the air valve button (Fig.1.) with your thumb.
4.1.5 Actuate the pump to build up pressure in the hose by depressing the treadle on to thumb and depressed air valve.
4.1.6 Using a screwdriver turn the slotted head release valve clockwise gently until resistance of the valve seat is felt. Excessive
tightening will cause loss of pressure in hose.
4.1.7 Continuing to depress the air valve button with your thumb to obtain operating clearance between the treadle air valve and
the release valve, tighten socket headed cap screw with an allen key through treadle pivot boss.
4.1.8 Release valve should now be correctly set.
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
INFORMATION: For a copy of our latest catalogue and promotions call us on 01284 757525 and leave your full name and address, including postcode.
01284 757500
01284 703534
[e-mail]
Sole UK Distributor, Sealey Group,
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk,
IP32 7AR
www.sealey.co.uk
Web
email
4. MAINTENANCE
Fig.1.
Fig.2.
Oilllerplug(onunderside)
Release valve
Air valve button
Socket head cap screw
Fig.3.
©Jack Sealey Limited
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or phone [phone].
RE83/840.V2 & RE83/840/CWH.V2 Issue: 1 - 13/11/12
