Sealey LED360 V4 Series User manual

INSTRUCTIONS FOR
RECHARGEABLE 360°INSPECTION LAMP
10 SMD LED+3W LED LITHIUM-ION
MODEL NO: LED360.V4 SERIES
Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these
instructions, and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
1. SAFETY
9Inspect the cable and connector for wear and damage to ensure items are safe before connecting to the power supply. If worn or
damaged DO NOT use.
9Ensure the lamp is fully charged before initial use.
8DO NOT charge in damp conditions.
8DO NOT turn the lamp on when it is being charged.
8DO NOT shine directly into your, another person’s or an animal’s eyes.
8DO NOT allow children to use the lamp.
8DO NOT handle or move the lamp whilst it is being charged.
8DO NOT use the lamp if you suspect that the battery or the lamp casing is damaged.
8DO NOT leave battery in a discharged state, recharge battery immediately. Before storage, fully recharge the battery, subsequently
recharge the battery at least once every six months of non-use.
8DO NOT attempt to open, disassemble, modify or service the battery pack.
8DO NOT crush, puncture, short external contacts or dispose of in re or water.
8DO NOT expose to temperatures above 60°C (140°).
Replace only with the battery pack designated for this product.
Recycle or dispose of used battery as stipulated by local regulation.
If the electrolyte in the cells gets on your skin, thoroughly wash with soap and water. If it gets in your eyes, rinse thoroughly with cool
water and seek immediate medical attention.
2. INTRODUCTIONS
Unique and innovative 360° swivel and tilt function enables light source to be positioned in any direction. Exclusive patented design owned and
registered to Sealey. Each lamp houses 10 super bright SMD LEDs providing up to 400 lumen output with 120° spread of light, illuminating the
whole work area. Includes an additional high power 3W LED in the end for use as a directional torch. Features two swivel hooks and three rubber
covered magnets, two on the rear and one on the end, which allow hands free operation. High quality 2.2Ah Lithium-ion battery for longer life, no
memory effect and a much slower discharge than traditional Ni-MH batteries. Micro USB charging port. Supplied with high quality braided USB
charging cable.
3. SPECIFICATION
Model No..............................................................LED360.V4
Battery ........................................................3.7V 2.2Ah Li-ion
LED Quantity................................................. 10SMD + 1LED
Lumen Output Side(High/Low)Top ............... (400/200)/120lm
Operating Time Side(High/Low)/Top......................... (3/6)/8hr
Charging Time................................................................3.5hr
IP Rating .........................................................................IP54
Minimum Length......................................................... 260mm
Maximum Length........................................................ 280mm
The battery tted to this lamp is considered to be a consumable item and its ability to accept a charge will reduce over time.
We will provide warranty against mechanical and electrical defect for a period of one year - this does not cover fair wear and tear.
If the battery is not properly charged before rst use, or regularly conditioned, its capacity will diminish. Under these circumstances
we will not replace the battery regardless of whether it is less than one year old.
Note: The lithium battery does not suffer from memory effect and once fully charged may be stored for up to six months without
another charge.
LED360.V4 Series | Issue 1 04/04/17
Original Language Version
© Jack Sealey Limited
Refer to
instructions

4. OPERATION
4.1. Connect the USB lead to the socket on the rear of the lamp and into a charging socket. Turn on power supply, the charging LED on
the lamp will light RED to show that charging has commenced.
4.2. When the battery has fully charged the LED will turn GREEN.
4.3. Direct the lens away from your eyes before switching on.
4.4. Toggle the lamp between the end light and side light using the ON/OFF switch.
4.5. The lamp may be suspended by the hooks or attached to any ferrous surface by using the magnets.
4.6. When the light is hanging from the hook it can be rotated through 360° for more precise positioning.
4.7. Separate the top and bottom sections by pulling apart. When attached to a ferrous surface, using the base magnet, the lamp can
rotate to shine in any direction.
Original Language Version
© Jack Sealey Limited LED360.V4 Series | Issue 1 04/04/17
NOTE: It is our policy to continually improve products and as such we reserve the right to alter data, specications and component parts without prior notice.
IMPORTANT: No liability is accepted for incorrect use of this product.
WARRANTY: Guarantee is 12 months from purchase date, proof of which will be required for any claim.
Sole UK Distributor, Sealey Group.
Kempson Way, Suffolk Business Park,
Bury St. Edmunds, Suffolk.
IP32 7AR
www.sealey.co.uk
[e-mail]
01284 757500
01284 703534
Environmental Protection
Recycle unwanted materials instead of disposing of them as waste. All tools, accessories and packaging should be
sorted, taken to a recycling centre and disposed of in a manner which is compatible with the environment.
When the product becomes completely unserviceable and requires disposal, drain off any fluids (if applicable)
into approved containers and dispose of the product and the fluids according to local regulations.
WEEE Regulations
Dispose of this product at the end of its working life in compliance with the EU Directive on
Waste Electrical and Electronic Equipment (WEEE). When the product is no longer required, it must be disposed
of in an environmentally protective way. Contact your local solid waste authority for recycling information.
Battery Removal
Remove the 6 screws on the back of the lamp. Remove the back casing and disconnect the wiring from the
circuit board. Remove the battery. Dispose of according to local government guidelines.
Under the Waste Batteries and Accumulators Regulations 2009, Jack Sealey Ltd are required to inform potential
purchasers of products containing batteries (as dened within these regulations), that they are registered wih Valpak’s
registered compliance scheme. Jack Sealey Ltd’s Batteries Producer Registration Number (BPRN) is BPRN00705.
Parts support is available for this product. To obtain a parts listing and/or diagram,
please log on to www.sealey.co.uk, email [e-mail] or telephone [phone].
