Seametrics FT420 User manual

Page 1
The FT420 ow computer comes with factory-set parameters for K-factor, pulse output, 4-20 mA output, precision
(number of decimals) of display, and time units. These operational parameters can be changed by the operator
(except when Passcode Protection is invoked); the procedures for these main menu functions are described in
detail in the FT420 Instruction Manual and are not repeated here.
In addition to the customer-controlled operations described above, there are a series of administration menus that
can be accessed by the Seametrics dealer in order to change basic functionality of the FT420:
Operation Mode: Main Menu Function Administration Menu Functions
(Details in Instruction Manual): (Details described in this document):
SET K Adjust K-Factor numeric value Lock/unlock user access to changing the
K-Factor
SET P Set scale of pulses in pulse Three choices: pulse output, high ow alarm,
output or, low ow alarm
SET A Set high or low ow rate Three choices: pulse output, high ow alarm
at which ow alarm triggers or, low ow alarm
SET 20 Set ow range over which Rene accuracy of 4-20 mA output reading
4-20 mA output is desired using a current meter
SET D Choose number of decimals Enable or disable the resettable total function
for display
SET TIME Choose time units over Change jitter time (period of time to ignore
which ow is measured random pulses in full, non-owing pipe), lter
time (amount of display dampening or
“smoothing” of reading), and volumetric units
Procedures for Accessing Administration Menus and Adjusting Values
To move from one (main menu) operation mode to another, use the SET key.
NOTE: The internal processor scans the front panel every one second - this may cause a “lag” in
button response.
To access the administration menu behind each (main menu) operation mode, press and hold all three
buttons (SET, LEFT ARROW, UP ARROW in order) for approximately ve seconds.
To select among alternative (either/or) selections for a particular function, use the UP ARROW key.
When changing a multi-digit numeric value, select the digit to be changed by using the LEFT ARROW key.
To adjust a numeric value up or down, use UP ARROW key (see each function for specic details about
that adjustment).
IMPORTANT: No settings changes will be retained until you have completed the entire sequence,
 endingonthescreenrstdisplayedwhenpoweringup.
either/or either/or
DISTRIBUTOR USE ONLY
FT420 Administration Menus

Page 2
OPERATION MODE ADMINISTRATION MENUS
(MAIN MENU)
Display when powered up
Set K
Set P
Set A
either/or
either/or
Press to choose between Lock and Unlock K-factor resettability. (Note:
If the FT420 has been Passcode-protected you will not be able to toggle be-
tween UL and L screens. Instead, use to move to the Passcode screen.
Follow “Using the Passcode” in the FT420 Passcode Protection document to
enter your passcode. When nished, press to return to Operation Mode
(Main Menu), and to advance to the next Operation Mode.
None - Press to go to the menus.
PASSCoE
Important Note: The FT420 menus will “time out” after two
minutes’ inactivity. If this happens, you will need to begin again.
Press to choose among Pulse Output, Alarm High, and Alarm Low.
When you have made your selection, press to return to EITHER Set P
Mode (if you have chosen P (Pulse Output Mode) in the administration menu,
OR Set A (ow alarm rate) if you have chosen Alarm High or Alarm Low. In
either of these operation modes (Set P or Set A), use to adjust your
values (to choose your pulse output rate (Set P) or the ow rate above (AL
HI) or Below (AL LO) at which the alarm will trigger. NOTE: Under AL HI or AL
LO, the scaled pulse output circuit will close and maintain contact as long as
the condition meets the HI/LO perameter. Press to advance to the next
operation mode.

Set D
Page 3
Set 20
With your FT420 connected to a current meter, press to make incre-
mental adjustments in the Adj 4 screen until it reads exactly 4. (The will
increase the number incrementally to a point, and then jump below 4 again,
so if you start or move above 4, keep pressing until you reach 4 again).
Press to move to the Adj 20 screen and use to make incremetal
adjustments in the same way, until it reads exactly 20.
Press to return to Operation Mode (Main Menu) and to advance to
the next Operation Mode.
OPERATION MODE ADMINISTRATION MENUS
(MAIN MENU)
PASSCoE
Press to choose from a non-resettable total (rd = reset disabled), and a
resettable total (RE = reset enabled). When nished, press to return to
Operation Mode (Main Menu). Press again to advance to the next opera-
tion. NOTE: with reset disabled, “RESET” no longer shows on display.

LT-13247-C
7/14/09
Page 4
Set Time
Jitter Time Filter Time Units
U0 = Gallons
U1 = 1000 Gal
U2 = Acre Feet
Press to adjust Jitter Time (period of time to ignore random pulses in full,
non-owing pipe). Press to advance to Filter Time screen.
Press to adjust Filter Time (amount of display dampening, or “smoothing”
of reading) from 0-9. Press to advance to Units of Measure screen.
Press to select Units of Measure (Gallons, Gallons x 1000, acre feet)).
Press to return to Operation Mode (Main Menu). Press to return to
Starting Display. NOTE: If units of measure is changed, total should be reset
to insure changes are implemented. Selection of U1 or U2 is not indicated on
main menu.
Display when powered up Finished, or begin again.
OPERATION MODE ADMINISTRATION MENUS
(MAIN MENU)
PASSCoE
