Seconique NEVADA DRESSING TABLE SET User manual

05/20/SP
NEVADA DRESSING TABLE SET
ASSEMBLY INSTRUCTIONS
IMPORTANT
FOR DOMESTIC USE ONLY
CARE AND MAINTENANCE
PLEASE READ BEFORE YOU CONTINUE FURTHER
PAGE 1

PAGE 2
01
02
04
05
06
06
07
08
09
09
12
11
11
10
10
13
14
14
15
16
16
17
19
18
03
05/20/SP
PARTS LIST
The below highlighted parts have been number/colour coded to help identify them during assembly.
Please Note:
* Use of power tools to assemble this product will invalidate any claim and damage this
product making it unsafe !!!
* Please assemble on a clean soft surface to avoid damage.
* Please check contents and read the instructions before commencing assembly.
* Assemble this product following the enclosed instructions carefully.
* Please take care to avoid damaging panels during assembly.
!
Part Number Part Code Part Description Quantity Carton
1 100-105-017-SP1-01 Le Chest Side Panel/RED 1 1/2
2 100-105-017-SP1-02 Front Baseboard 1 1/2
3 100-105-017-SP1-03 Back Baseboard 1 1/2
4 100-105-017-SP1-04 Right Chest Side Panel/GREEN 1 1/2
5 100-105-017-SP1-05 Back Crossbar 1 1/2
6 100-105-017-SP1-06 Upper Crossbar 2 1/2
7 100-105-017-SP1-07 Right Table Side Panel/BLUE 1 1/2
8 100-105-017-SP1-08 Top Panel 1 2/2
9 100-105-017-SP1-09 Back Panel 2 1/2
10 100-105-017-SP1-10 Stool Side Panel/BLACK 2 2/2
11 100-105-017-SP1-11 Stool Crosspiece 2 2/2
12 100-105-017-SP1-12 Stool Seat 1 2/2
13 100-105-017-SP1-13 Mirror Base Panel 1 1/2
14 100-105-017-SP1-14 Mirror Side Panel 2 2/2
15 100-105-017-SP1-15 Mirror Panel 1 2/2
16 100-105-017-SP1-16 Drawer Side/BLUE 8 2/2
17 100-105-017-SP1-17 Drawer Back/RED 4 2/2
18 100-105-017-SP1-18 Drawer Front 4 1/2
19 100-105-017-SP1-19 Drawer Botom 4 2/2
RED
BLACK BLACK
RED
RED
BLUE
BLUE
BLUE
GREEN

PAGE 3
FITTINGS LIST
Glue
Flat Head Screw
Ø3,5x14mm (24x)
A
+/2
Flat Head Screw
Ø6,0 x 10mm (16x)
B
+/2
Flan Head Screw
ØM4x20mm (8x)
C
+/1
Flan Head Screw
Ø3,5 x 30mm (2x)
D
+/1
Flat Head Screw
Ø4,0x 50mm (14x)
E
+/2
Flat Head Screw
Ø4,5 x 60mm (4x)
F
+/1 Dowel Ø6,0 x 30mm (62x)
G
+/2 Nail 1,8x23 (64x)
H
+/2
Flat Head Screw
Ø3,0 x 16mm (8x)
I
+/1 Cam Bolt (18x)
J
+/2 Mirror Support (2x)
K
Cam Nut Ø15mm (10x)
L
+/2
Cam Nut Ø12mm (8x)
M
+/1 Plastic Foot (10x)
N
+/2 Hole Plugs (22x)
O
+/2 Glue (2x)
P
Strap (2x)
Q
Washer (4x)
R
+/1 +/1 Handle (4x)
S
Drawer Runners (4x)
T
Back Panel Strip (1x)
U
05/20/SP
USE
DO NOT
USE
!
TIPS FOR FITTINGS CAM-LOCKS
PO
P
O
WHEN FITTING CAM NUT. ENSURE STARTING
POSITION IS CORRECT BEFORE YOU INSERT
CONNECTING CAM BOLT TURN CLOCKWISE UNTIL
SECURE
CORRECT WRONG
Cam bolt head needs to be in centre
CAMBOLT
Tighten until shoulder in flush with
panel. Do not overtighten or
undertighten (see example below) Shoulder
Panel Panel
Flat Head Screw
Ø3,5x40 mm (8x)
V
+/2

PAGE 4
Pre-Assembly
B-Flat Head Screw
Ø6,0 x 10mm (16x)
G-Dowel
Ø6,0 x 30mm (6x) J-Cam Bolt (6x) N-Plastic Foot (6x) P-Glue (1x)
Glue
T-Drawer Runners (4x)H-Nail 1,8x23 (6x)
Detail 1
Detail 1
Detail 2
Detail 2
Detail 2
Detail 2
Detail 2
Detail 2
Detail 3
Detail 3
Detail 3
Detail 3
Detail 4
Detail 4
Detail 4
Detail 4
Detail 5
Detail 5
Detail 1
Detail 1
Detail 5
Detail 5
Detail 5
Detail 5
07
08
01
04
Detail 1
Detail 1
05/20/SP
Detail 1
G+P
Detail 5
Detail 3
H
N
T
B
Detail 4
T
B
Detail 2
J
RED
GREEN
BLUE
UP SECOND HOLE
SECOND HOLE
LAST FIFTH HOLE
T

PAGE 5
Pre-Assembly
G-Dowel
Ø6,0 x 30mm (56x) J-Cam Bolt (12x) N-Plastic Foot (4x) P-Glue (1x)
Glue
H-Nail 1,8x23 (4x)
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 2
Detail 2
Detail 2
Detail 2
Detail 5
Detail 5
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
12 10 2x
17 4x
16 8x
06 2x
05
03
02
11 2x
18 4x
Detail 2
Detail 2
05/20/SP
BLACK
RED
RED
BLUE
Detail 1
G+P
Detail 2
J
Detail 5
H
N

PAGE 6
2
Detail 6
P-Glue (1x)
Glue
L-Cam Nut
Ø15mm (6x) P-Glue (1x)
Glue
Detail 6
Detail 6
Detail 6
Detail 6
Detail 6
Detail 6
Detail 6
Detail 6
Detail 6
Detail 6
Detail 7
Detail 7
Detail 7
Detail 7
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
Detail 1
1
E-Flat Head Screw
Ø4,0 x 50mm (10x)
01 02
03
04
05
06
07
06
08
E
05/20/SP
RED
GREEN
BLUE
Detail 1
G+P
Detail 1
G+P
Detail 7
L

PAGE 7
3
Detail 8
H
H-Nail 1,8x23) U-Back Panel Strip (1x)
09
09
U
Detail 8
For your future reference
Order number should be here
Detail 8
4
V-Flat Head Screw
Ø3,5x40mm (8x)
M-Cam Nut
Ø12mm(8x)
Detail 12
1º
2º
4X
4X
O
M
Detail 12
Detail 1
Detail 1
Detail 1
16 17
16
18
V
V
Detail 1
Detail 12
O-Hole Plugs (8x) P-Glue (1x)
Glue
05/20/SP
RED
RED
BLUE
BLUE
Detail 1
G+P
X
X
X
X
X

PAGE 8
4º
5º
4X
4X
A
A
A
C
C
S
A
T
TIPS FOR FIXING
DRAWER BOTTONS
X=117mm
Y=60mm
3º 4X
YX
Y
Y
X
Y
19
H
Detail 13
Detail 13
Detail 13
H
5
A-Flat Head Screw
Ø3,5X14mm (16x)
C-Flan Head Screw
ØM4x20mm (8x) S-Handle (4x) T-Drawer Runners (4x)
T
H
H
H
H
H
H
H-Nail 1,8x23 (32x)
05/20/SP
FOURTH HOLE LAST FOURTH HOLE
T

PAGE 9
6
Detail 1
Detail 1
Detail 1
Detail 1
Detail 6
Detail 6
Detail 6
Detail 6
P-Glue (1x)
Glue
E-Flat Head Screw
Ø4,0 x 50mm (4x)
10
10
11
11
Detail 7
Detail 1
Detail 1
Detail 1
7
P-Glue (1x)
Glue
L-Cam Nut
Ø15mm (4x)
12
L
Detail 7
Detail 7
11 10
11 10
05/20/SP
Detail 1
Detail 1
G+P
G+P
Detail 6
E
BLACK
BLACK
X

PAGE 10
Detail 9 Detail 10
Detail 10.2
Detail 9
Detail 9
Detail 10 +
10.1 + 10.2
Upper
Lower
8
K-Mirror Support (2x)
F-Flat Head Screw
Ø4,5 x 60mm (4x)
I-Flat Head Screw
Ø3,0 x 16mm (4x)
14
14
13
I
I
K
K
Marking
Counterbore
F
Detail 10 +
10.1 + 10.2
Lower
Upper
35 mm 35 mm
35 mm 35 mm
Detail 10.1
K
9
Detail 11 +
11.1
10
K-Mirror Support (2x)
I-Flat Head Screw
Ø3,0 x 16mm (4x)
15
15
IK
Marking
201 mm
Detail 11 Detail 11.1
I
Marking
Detail 11 +
11.1
05/20/SP

PAGE 11
11
12
Detail 15
Drawer AdjustmentDrawer Adjustment
Drawer Lock
A-Flat Head Screw
Ø3,5X14mm (8x)
A
See last page
See last page
Detail 15
Detail 15
Detail 15
Detail 15
Detail 14
Detail 14
O-Hole Plugs (12x)
O
!
!
05/20/SP

PAGE 12
D-Flan Head Screw
Ø3,5 x 30mm (2x) Q-Strap (2x) R-Washer (4x)
D
R
Q
R
Q
