Security Brands Ascent M1 User manual

1 of 6
Model 16-M1
QUICK START GUIDE
1
2
STOP

WARNING

IMPORTANT
rr
Unpack box and make sure you have all items shown here.
(Screwdriver not shown.)
Unlock and open front panel of unit for
mounting, wiring, and setup.
This is a cellular accessory for a gate or door.
An uninterrupted cellular connection
CANNOT BE GUARANTEED!
An emergency egress or primary entry
mechanism SHOULD ALWAYS BE USED!
(transmitter, fire box, mechanical release)
Consult with your dealer, distributor, and/or
system designer for more information.
AUTOMATIC GATES CAN CAUSE SERIOUS
INJURY OR DEATH!
ALWAYS CHECK THAT THE GATE PATH IS
CLEAR BEFORE OPERATING!
REVERSING OR OTHER SAFETY DEVICES
SHOULD ALWAYS BE USED!
This Ascent unit WILL NOT WORK until the
activation process is COMPLETE!
Follow the included Activation Guide to get
this unit activated.
If you need help or have any questions, please
contact Summit Control at [phone].
Ascent Unit
Key
Carriage Bolt
( 4x )
Hex Nut
( 4x )
12-V AC/DC Adapter
(PS-12DC2)
Continued on next page...

QSG-16M1-EN Rev. A (12/2020)
© 2020 Security Brands, Inc. All rights reserved.
Model 16-M1
2 of 6
QUICK START GUIDE
IMPORTANT
rr
CAUTION

We recommend mounting the unit on a
gooseneck pedestal using the included
mounting hardware.
If using alternate mounting, the
4G LTE Antenna Extension Kit
(Model 16-ANTX-1)
should be purchased and installed.
Failure to do so may result in NO SIGNAL!
What’s what?
All important components labeled
Antenna Jacks
Antenna extension kits
connect here
Wiegand Device Terminals
For wiring to Wiegand devices
See Page 6
Ascent Camera
For automatic and on-demand
photo capture
SIM Card
Power and Relay Terminals
For wiring to power and
gate operator or door opener
See Page 3
Status and Event Terminals
For enabling gate status and
connecting request-to-exit devices
See Pages 4 and 5
Relay Status LEDs
Relay is active when lit
Inside of front panel shown.
Wiring/cabling not shown for clarity.
Mount unit to pedestal using included
mounting hardware.
(This step may be completed later.)
Use all four carriage bolts when mounting
the unit to a pedestal.
Leave the “hockey puck” antenna in place
even if using an antenna extension.
Seal all openings created in the enclosure.
Failure to follow these instructions can
damage the unit!
3

3 of 6
Model 16-M1
QUICK START GUIDE
4CAUTION

If the included 12-V AC/DC adapter will not be
used, please go to Page 5 and follow the
procedure, Using a Third-Party Power Source.
Do not exceed 24 VAC/DC! Failure to choose a
compatible power source can damage the unit!
Connect wires
Feed wires through back of unit,
and connect as shown using
included screwdriver.
Excessive force can damage unit!
RELAY A
J4
RELAY B
J5
12–24 VAC/DC
POWER
J3 J8 J9 J12
DIGITAL INPUTS
Ascent Power and Relay Terminals Gate Operator / Door Opener
POWER (+)
POWER (–)
COM
RADIO
COM
REVERSE LOOP
STOP
CLOSE
The GROUND terminal is optional
unless required by local code(s).
If using, please connect to earth
ground or equivalent. 12-V AC/DC Adapter
(Model PS-12DC2 included)
Relay B can be wired to a second device in the same manner.
FREE EXIT
COM
N/C N/C
COM
N/O
GND
# 1
GND
# 2
GND
# 3
Consult gate/door opener
manual for exact connections.
Terminals vary widely across
manufacturers and models.
If plugging into duplex outlet,
remove screw from outlet plate,
and secure with included screw.
Additional wiring diagrams can
be found on Pages 4–6.
+–
Third-Party 12–24-VAC/DC
Power Source
POS. (+)
NEG. (–)
OR
COM
N/O
COM
OPEN

© 2020 Security Brands, Inc. All rights reserved.
4 of 6
QSG-16M1-EN Rev. A (12/2020)
Model 16-M1
QUICK START GUIDE
STOP

5
ACAUTION

IMPORTANT
rr
Key in temporary code 2012 on
keypad and confirm gate opens. If it
does, close and lock front door of unit.
Before going forward, double check all
wiring and make sure the unit has power!
Wiring diagrams for connecting to accessory
devices can be found on Pages 4–6.
For connecting accessories not mentioned,
please contact Technical Support.
Make sure the gate path is clear before
completing Step 5!
Adding and deleting codes is done through
Summit Control and NOT from keypad on unit!
J7
GATE 1
J13
GATE 2 EVENT
J6
(if equipped with limit switches)
Open Limit Switch
Close Limit Switch
Optional
wire
splices
N/C
N/C
Gate Operator
Ascent Status and Event Terminals
GND
N/O
COM
N/O
COM
N/O
CLOSE
GND
OPEN
CLOSE
GND
OPEN
The Status Terminals are designed
for low voltage (3 V or less). Check
the voltage on your status wires
before connecting. If it is above 3 V,
please contact Technical Support.
Exceeding 3 V can damage the unit!
Gate Status Check WILL NOT WORK
with a decoder!
YOU MUST USE A DRY CONTACT!
Status Check
Wiring to enable Gate Status Check
2 20 1
Now follow the Activation Guide to create an
account and begin using Ascent.
INSTALLATION COMPLETE!
N

5 of 6
Model 16-M1
QUICK START GUIDE
4a
4b
IMPORTANT
rr
CAUTION

B
Verify your power source is compatible with
the unit’s electrical specifications below.
Not intended for solar applications!
Connect wires to unit as shown in
Step 4.
Connect wires to your power source,
making sure you connect positive to
positive and negative to negative.
J7
GATE 1
J13
GATE 2 EVENT
J6
Ascent Status and Event Terminals
CLOSE
GND
OPEN
CLOSE
GND
OPEN
Request-to-Exit Device
(58-RTE-P is shown)
GND
N/O
Double check that you have wired from
positive on the Ascent unit to positive on your
power source and negative on the Ascent unit
to negative on your power source.
Reverse polarity can damage the unit!
Event Input
Wiring for accessories such as a request-to-exit device
Input 12–24 VAC/DC
no more than 10% beyond this range
Current Draw less than 600 mA @ 12 VDC
less than 320 mA @ 24 VDC
Using a Third-Party
Power Source (Optional)

© 2020 Security Brands, Inc. All rights reserved.
6 of 6
Call [phone]
Email [email protected]
We are available Mon–Fri / 8am–5pm Central
QSG-16M1-EN Rev. A (12/2020)
Model 16-M1
QUICK START GUIDE
C
CAUTION

J15 J16 J19 J18
Wiegand Device
WIEGAND OUTPUTS
Ascent Wiegand Device Terminals
+12V
GND
LED 1 LED 2
DATA 0 DATA 1
GND
LED 2 LED 1
DATA 0 DATA 1 DATA 0 DATA 1
+12V
GND
LED 2 LED 1
+12V
DOOR/READER A
WIEGAND 1
DOOR/READER B
WIEGAND 2
Disconnect power to the Ascent unit
before connecting Wiegand devices.
Failure to disconnect power can
damage the unit!
Wiegand Device
Wiring for a Wiegand device such as a card reader
