V-Tec DMR18S User manual

DMR18S
User Manual
Door Station
Please read this manual carefully before using the product you purchase, and keep it well for future
use.We reserve the right to modify the specication in this manual at any time without notice.
1 2 3
654
7 8 9
#0
*
RF CARD

1.Parts and Functions
2. Terminal Descriptions
Camera Lens
Night View LED
Speaker
Adjustable Camera
Connectiong Port
With rainy cover
350 mm
128 mm
1 2 3
654
7 8 9
#0
*
LCD Screen
ID Card Window
Digital Keypad
Microphone
12
3
Touch Key
RF CARD
L1
T/R -
CN-LK
T/R+
J/KMB JP-LK
Bus
SD Card Slot
EB+ EB- N.O LK+ LK-
+12V
L2
12
3
12
3
• +12V:12VDCpoweroutput.
• LK-(GND):Powerground.
• LK+(COM):CommoncontactoftheRelay.
• NO.:NormallyopencontactoftheRelay(refertoDTtechnicalguideforLockconnection
• detailinformations).
• EB+:Exitbuttonconnectionport.
• EB-:Exitbutonconnectionport.
• JP-LK:Forelectroniclocksafetytypesetting(refertoDoorStationLockConnections).
• T/R-:USB-RS485communicationterminalnegative.
• T/R+: USB-RS485communicationterninalpositive.
• Bus(L1,L2):non-polaritybusline.
-1-

3.Door Station Mounting
1 2
4 5 6
Drill holes in the wall to match the size of
screws and attach the rainy cover to the wall.
Attach screws to fix the
metal box
Attach the unit to the rainy
cover correctlly
The last view for all mounting
The view for rainy
cover after mounted
Adjust the camera angle and attach the
metal to the panel and wire correctly.
Camera
angle
3
Surface mounting
-2-

1 2 3
4
7
5 6
Drill a hole and attach the
rainy cover to it
Attach screws to fix the
metal box
Attach the unit to the rainy
cover correctlly
Attach the baffle to protect
the unit from droping
The last view for all mounting
The view for rainy
cover after mounted
Adjust the camera angle and attach the
metal to the panel and wire correctly.
Camera
angle
147
m
m
395
m
m
4
2mm
RF CARD
Flush mounting
-3-

Code=0
OFF ON
OFF ON
DBC4A
A B C D
DBC4A
A B C D
Impedance
switch
Impedance
switch
NOTE:Here we take DT47M(the monitor) for example.
100~240VAC
BUS(IM) BUS(DS)
PC6
AC~
Code=2
Code=1
Code=3
Code=28
Code=30
Code=29
Code=31
1 2 3
654
7 8 9
#0
*
RF CARD
ID Code=0
4. System Connection
-4-

5. Door Lock Connections
1. Internal Power Supply Mode
Usethepowerofthesystemtosupplyfortheelectroniclock,sothatthelockcanbe
connectedtothedoorstationdirectly,withoutanadditionalpowersupplyfortheelectroniclock.
Notethatthedoorstationcanonlyoutput12Vdcpower,thereforethekindoflockislimited.
• Theratedpowerofthelockmustbelessthan12Vdc300mAwhenusinginternalpower
supplymode
• TheGNDmustconnecttothenegativeofthelock,andtheCOMconnecttothepositive.
• Jumpersetto1-2positionforPower-off-to-Unlocksafetytype(Normally closed mode);
setto2-3positionforPower-on-to-Unlocktype(Normally open mode).
• Ifdifferentunlockingtimeisneededtobeconfigured,changetheUnlock Timingon
doorstation.(Indebugstate,press[1#]-->[1]InstallerSetup-->[2]UnlockTiming)
JP_LK
12V 300mA
Jumper set to 2-3 position
+
-+12V
LK - (GND)
LK+(COM)
N.O.
EB+
EB -
1 2 3
set to Normally open on the
Unlock Relay mode
A. Connection for Power-on-to-Unlock type:
12V 300mA
Jumper set to 1-2 position
+12V
LK - (GND)
LK+(COM)
N.O.
EB+
EB -
+
-
set to Normally Closed on the
Unlock Relay mode
JP_LK
1 2 3
B. Connection for Power--off-to-Unlock type:
-5-

+
+
-
-
+12V
LK - (GND)
LK+(COM)
N.O.
EB+
EB -
Remove the Jumper
set to Normally Open on the
Unlock Relay mode (default)
JP_LK
1 2 3
Note: Cut off this line when
using external power supply
+12V
LK - (GND)
LK+(COM)
N.O.
EB+
EB -
Remove the Jumper
set to Normally Closed on the
Unlock Relay mode
+
+
-
-
JP_LK
1 2 3
Note: Cut off this line when
using external power supply
2. External Power Supply Mode
Whentheelectroniclockisover12Vdc,additionalpowersupplyforthelockisneeded.
• Thepowersupplyforthelockmustbelessthan48Vdc1.5A.
• TheJumpermustberemovedwhenusingexternalpowersupply.Thedefaultsettingis
Power-on-to-Unlocktype(Normally open mode),ifusePower-off-to-Unlocktype,
changetheUnlockRelaymodetoNormally closed mode.
• Ifdifferentunlockingtimeisneededtobecongured,changetheUnlock Timingon
doorstation.(Indebugstate,press[1#]-->[1]InstallerSetup-->[2]UnlockTiming)
C. Connection for Power-to-Unlock type:
D. Connection for Power--off-to-Unlock type:
-6-

6. Door Station Congurations
1. About room code(address):
RoomCode(alsocalledroomaddress)isacodeassignedtoeachmonitor,toidentifydifferent
monitors;eachmonitorhaveauniqueroomcodeinonebuidling.TheroomCodeisstoredin
eachMonitor’sinnerEEPROMmemory,anddoesnotloseeventhemonitorispoweroff.
2. About Debug State:
TheDebugStateisyourstartingpointforusingalltheapplicationsonDMR18S.
WhenDoorStationisin
standby,press'#'key
Press"2#"keytoexitoutthedebugstate.
input'9008',theninputthe
AdminCode.(66666666by
default)
DebugStatemenuislaunched
[ 9 0 0 8 ]
Please Input Password
1 2 3
654
7 8 9
#0
*
RF CARD
>> Debug State <<
1-# Tools
0-# Redial
2-# Exits
3. About Debug Tools:
DuringworkingatDebugState,press"1#"toentertoolspage,DebugToolsoverviewsis
shownasbelow:
1. Installer Setup
2. Setup
3. Card Manage
4. Online Monitors
5. Online Devices
6. Voltage Measure
Pres NO.
to select
*Back
Tools
>> Debug State <<
0-# Redial
2-# Exits
1-# Tools
-7-

Item Submenu
1. Installer Setup
1.IDCode[0]
2.UnlockTiming[01]
3.UnlockOutput[0]
4.MonitorTiming[600]
5.DoorplateMode[0]
6.WaitingTiming[040]
7.TalkingTiming[090]
8.InstallerCode...
9.Default...
2. Setup
1.Language[0]
2.ToneSelect[01]
3.ToneVolume[3]
4.UnlockCode[1111]
5.WorkMode[0]
6.Clock...
7.SetupCode...
8.About...
9.Default...
3. Card Manage
1.AddCard...
2.DeleteByCard
3.DeleteByM.code
4.CardsInformation
5.Format
4. Online Monitors Tosearchtheonlinemonitors,inputthemonitorcode
numbertosearch
5. Online Devices Tosearchtheonlinedoorstations.Max.4doorstation
canbesearched
6. Voltage Measure Tocheckthevoltageofthemonitor,notethatthe
monitormustbeonline.
Table1:
-8-

Basic Tools Detail:
Item Description Factory
set
IDCode
Ifonlyonedoorstationisinstalledinthisbuilding,set
to0;
Ifmultidoorstationsareinstalled,primarydoorstation
mustbesetto0,andotherslavedoorstationsmust
besetfrom1to3.Notethatmax.4doorstationsare
availableinonebuilding
[0]
Single
UnlockTiming Tosetthetimethathowlongthedoorkeepsopen
whendoorisreleased.Rangefrom01to99seconds.
[01]
1seconds
UnlockOutput
Tosettheunlockmodetomatchthecorresponding
lock.Rangefrom0to1.
0:Power-on-to-UnlockMode(NormallyOpenMode)
1:Power-off-to-UnlockMode(NormallyClosedMode)
0
MonitorTiming Toshowthemonitortime,Rangefrom6sto600s 600s
DoorplateMode
Tosetthecallingmode.Ifsetto0,it'stheauto
mode,thatmeansthecallingwillbeactivateddirectly
afterinputting2digitscode.Ifsetto1,it'sthemanual
mode,thatmeansyoushouldpress"#"buttonto
activatethecallingafterinputtingthecode.
[0]
Automode
WaitingTiming Toshowthecallingwaittime,Rangefrom6sto600s 40s
TalkingTiming Toshowthelimitationtimeoftalking,Rangefrom6sto
600s 90s
InstallerCode... Tochangedoorstationadministratorcode [66666666]
Default...
Notethisoperationisirreversible.Oncerestoreis
activated,allparameterswillreturntofactorydefault
settingexcepttheinformationofaccesscard.
Table2(InstallerSetup):
-9-

Item Description Factory
set
L an gu ag e reserved. 0
To n e  S e l e c t  SelectthechimeofDoorStationincallingwaitstate. 01
To n e  V o l u m e  Adjustthetonevolumefordooorstationincalling.Range
from01~15 3
 U n l o c k  C o d e  TochangeunlockcodeinCommonCodeUnlockmode,in
4-digitsformat.1111isthedefaultunlockcode. 1111
WorkMode
0:Standardworkmode;
1:DJworkmode;
2:Routerworkmode;
3.Gatewayworkmode.
0
Clock...
Tosetdateandtime.
Dateformat:ifsetto0,dateformatisDD/MM/YY,ifsetto
1,dateformatisMM/DD/YY.
Timeformat:ifsetto0,timeformatis24hourstandard.Ifset
to1,timeformatis12hourstandard.
SetupCode TochangetheProgramCode. [88888888]
About...
1.Hardwareversion---ToshowtheDoorStation(including
ACS)hardwareinformation
2.Softwareversion---ToshowtheDoorStation(including
ACS)softwareinformation
3.ManufactureDate---Toshowthemanufacturingdate
4.DialingCounts---Toshowthecalloperationcounts
5.CallsCounts---Toshowtheestablishedcallingcounts
6.UnlockCounts---Toshowtheunlockoperationcounts
Default... RestoreallSetupparameterstofactorydefaultsetting,Please
notethatthisoperationisanirreversible
Table3(Setup):
-10-

Item Description Factory
set
AddCard... Toaddtheusercard
DeleteByCard Todeletecardbyusercard
DeleteByM.code Todeletecardbyroomcode
CardsInformation Toshowtheinformationsaboutcards
Format Toformatinformationsaboutcards
Table4(CardManage):
4. How to use code unlock function:
Pleaserefertothefollowingoperations:
[ - - - - ]
Please Input Password
1 2 3
654
7 8 9
#0
*
RF CARD
1 2 3
654
7 8 9
#0
*
RF CARD
[8017 ]
iDoor Open
WhentheDoorStationisin
standby,Press“#”
Ifveriedcorrectly,
dooropen
Input4digitsUnlockCode
directly
-11

Press“#”,Input“8002”,
theninputSetupCodeor
AdminCode(88888888or
66666666bydefault)
Press“4”toenterunlock
codeitem.
5. Change Unlcok Code:
IfdoorstationrunsasDebugState,youcanpress“1#”toactivateToolsMenu,thenselect“2”
toentersetuppage,thenselect4item.IfitrunsasNormalState,followthesesteps:
[ 8002 ]
Please Input Password
1 2 3
654
7 8 9
#0
*
RF CARD
*Back
[ - - - - ]
( * * * *)
# Save
4. Unlock Code[1111]
1. Language [1]
3. Tone Volume[03]
4. Unlock Code[1111]
5. Work Mode
6. Clock
7. Setup Code
8. About
9. Default
Press No.
to select
*Back
Setup
2. Tone Select [03]
Input4digitsnumber,
thenpress“#”toupdate
6. User Card Management:
ThissectionexplainshowtocongurethekeyfobfunctiononDMR18S,Thekeyfobisused
toopenthelock.Total320keyfobscanberegisteredwithonedoorstation.Whenswipingthe
fobtothedoorstation,thedistancemustbelessthan3centimeter.
KeyFobsmustberegisteredontheDoorstationthatcanbeusedtoopenthedoor.
Register the Key Fobs:
AlltheregisteredkeyfobsarecalledUserCards/UserKeyFobs.Newfobs/cardsneedto
beregisteredonebyonetotheDoorstationtobecomeavalidUserCard/UserKeyFob;and
everyUserCard/UserKeyFobisrelatedtoacertainMonitorAddress(Flatcode).
WhentheDoorstationisstandby,press[#]-->[9008]-->Password([66666666bydefault])
togetintotheDebugModeMenu,thenPress[1#]-->[3]CardManage-->[1]AddCardtoget
intotheAddCardpage.Pleaseseethefollowings.
-12

EnterAddCardmenu,and
RoomCodeisasked.
InputRoomCode Readthecardtobe
authorized
Delete user cards:
Delete By Card:
InDebugState,Press[1#]-->[3]Card
Manage-->[2]DeleteByCardtoenter
DeletebyCardpage.asshownonthe
right,thenshowthecardsyouwantto
deleteonebyone.
RegisteredUserCards/KeyFobscanbedeletedfromtheDoorstation,oncedoingthedelete
operation,thecard/keyfobscannotopenthedooranymore.Theycanalsobere-registered
againtobecomeavalidUserCard/UserKeyFob.TherearetwowaystodeleteUserCards/
UserKeyFobs:
1.Deletebycard:showtheunwantedcard(s)whentheDoorstationisinDeleteCardMode
2.Deletebyroomnumber:deletealltheregisteredUserCardsrelatedtothatroomnumber.
1. AddCard ...
* Back # Save
Please Input Room Code
[ - - - ]
1. AddCard ...
* Back # Save
Show the card
[ 0 0 1 ]
1. AddCard ...
* Back # Save
[ 0 0 1 ]
C a r d numbs :15977131
Show The Card
User
Card
iUpdated
InDebugState,Press[1#]-->[3]Card
Manage-->[3]DeleteByM.Codetoenter
DeletebyM.Codepage.asshownonthe
right,thenInputtheRoomCode,press
“#”toconrm;allassociatedcardswillbe
deleted.
Delete by Room Number:
3. Delete By M.code
* Back # Save
Please Input Room Code
[ - - - ]
3. Delete By M.code
* Back # Save
[ 0 0 1 ]
Please Input Room Code
iUpdated
2. Delete By Card ...
* Back # Save
Show The Card
2. Delete By Card ...
* Back # Save
User
Card
C a r d numbs:15977131
Show The Card
iUpdated
-13-

Card information:
Format:
EnterCardInformationpage,andthe
screenwilldisplaytheauthorizedUser
Cardscount,andcardreadaccess
eventscount.
EnterCardFormatpage,apassword
willbeasked,input8digitsinstaller
password(66666666bydefault),then
press"#"keytosave,formatoperation
isactivated.allcardinformationwillbe
cleared.
4. Cards Information
* Back # Save
Card Count: 320
5. Format
* Back # Save
Please Input Password
[ - - - - - - - - ]
7. Specication
●Power supply: DC24V
●Camera Lens: 1/4 ACS 4T image sensor with DSP processor
●Power consumption: Standby 33mA; Working status 157mA.
●Screen: 3.5 inch TFT
●Resolution: 320(R, G, B)X240 pixels
●Video signal: CCIR/EIA Optional
●Wiring: 2 wires, non-polarity
●Dimension: 350(H)×128(W)×46(D)mm
-14-

DT-ENG-DMR18S-V1 2015S0520
