SecurityMan DigioutAir User manual

DigioutAir User’s Manual
Digital Wireless Outdoor/Indoor Color
Camera Kit with Audio and Night Vision

1
© Copyright 2012
This manual is furnished under license and may be used or copied only in
accordance with the terms of such license. Except as permitted by such license,
no part of this publication may be reproduced, stored in a retrieval system, or
transmitted, in any form or any means, electronic, mechanical, recording, or
otherwise, including translation to another language or format, without the
prior written permission of SecurityMan. The content of this manual is furnished
for informational use only, is subject to change without notice, and should not
be construed as a commitment by SecurityMan. SecurityMan Inc assumes no
responsibility or liability for any errors or inaccuracies that may appear in this book.
FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device should not cause harmful interference.
(2) This device must accept any interference received, including interference that
may cause undesired operation. Operation of this equipment in a residential area
is likely to cause interference in which case, the user at his or her own risk and
expense will be required to correct the interference.
Warranty
SecurityMan Inc warrants that this product will be free from defects in title,
materials and manufacturing workmanship for one year or otherwise specified
on the product packaging. This limited warranty shall commence from the date
of purchase. SecurityMan products warranty is not transferable and is limited
to the original purchaser. If the product is found to be defective then, as your
sole remedy and as the manufacturer’s only obligation, SecurityMan will repair
or replace the product. This warranty shall not apply to products that have been
subjected to abuse, misuse, abnormal electrical or environmental conditions,
normal wear and tear, or any condition other than what can be considered normal use.

2
Warranty Disclaimers
SecurityMan Inc, makes no other warranties, express, implied or otherwise,
regarding this product, and specifically disclaims any warranty for merchantability
or fitness for a particular purpose. The exclusion of implied warranties is not
permitted in some states and the exclusions specified herein may not apply to you.
This warranty provides you with specific legal rights. There may be other rights
that you have which vary from state to state.
Limitation of Liability
The liability of SecurityMan Inc, arising from this warranty and sale shall be limited
to a refund of the purchase price. In no event shall SecurityMan be liable for costs
of procurement of substitute products or services, or for any lost profits, or for any
consequential, incidental, direct or indirect damages, however caused and on any
theory of liability, arising from this warranty and sale. These limitations shall apply
not withstanding any failure of essential purpose of any limited remedy.
For Tech Support Call: 888-977-3777
SecurityMan
4601 E. Airport Drive
Ontario, CA, 91761, USA
Tel: [phone]
Fax: [phone]
Email: [e-mail]
Website: www.securitymaninc.com
Copyright 2012 by SecurityMan v1.0

3
Table of Contents
Introduction
Important
Restrictions
Conditions
Package Contents
Specifications
Features
Product Basics
Camera (SM-703DT)
Receiver (SM-451DR)
Quick Start
On-Screen Display
Operation
Troubleshooting
4
4
5
7
8
9
10
11
11
11
12
14
14
15

4
Introduction
Thank you for purchasing the SecurityMan DigioutAir. The DigioutAir
is a “Do-It-Yourself” Digital Wireless Security camera kit designed for
easy installation and operation. With surveillance made easy, this DIY
kit will allow you to monitor your home, business, front or back doors,
garage, backyard, or any location that you would like to keep an eye on.
In comparison to the traditional wireless technology (analog), digital
wireless provides three key features which include: Increased range of
transmission, secure signal (neighbors cannot pick up the signal) and
unlike analog, the digital signals are virtually interference-free from
crowded wireless analog devices such as: Wi-Fi routers, Bluetooth
devices, cordless phones, microwaves, and cell phones.
Important
This guide provides important information on the use and operation of
your DigioutAir. Please read all the information carefully prior to using
the product for the best performance and to prevent any damage/
injuries or misuse of the device(s). Customers are entitled to have read
through this complete user’s manual before using the DigioutAir. Any
unapproved changes or modifications will void your warranty. Please
ensure to have a complete understanding of the following restrictions.

5
Restrictions
When using this product, the safety precautions below must be taken
to avoid possible legal liabilities and damages. Retain and follow all
product safety and operating instructions. Observe all warnings in
the product operating instructions. To reduce the risk of bodily injury,
electric shock, fire, and damage to the equipment, observes the
following precautions.
PLEASE NOTE that under certain circumstances, audio/video recording
may be PROHIBITED by law. This device should be used only in
compliance with all applicable federal, state and local statutes.
• DO NOT place this product too close to medical equipments.
1. Radio waves might potentially cause breakdown of medical
electrical equipments and thus cause incidents.
2. Place the product at least 22cm from the heart pacemaker.
Radio wave potentially influences heart pacemaker and thus leads to
respiratory disturbance.
• DO NOT use this product to monitor equipments or activities that are
relevant to one’s privacy.Monitoring one’s private activities without
consent is illegal and this product is not designed and manufactured
for these purposes.
• DO NOT this product to carry out any illegal activities such as sneak
preview, and etc. SecurityMan shall not be responsible for any
consequences of illegal conducts made by users.
• DO NOT put the plastic package bags in reach of children or babies.
Young children can choke on these items if they put them into their mouths.

6
• DO NOT plug the AC adapter into the outlet in improper situations.
• Plugging in an AC adapter with wet hands might cause electric shock.
• Plugging in the AC adapter unsteadily might cause re or electric shock.
• DO NOT cover the AC adapter when it is connected to an outlet, place
the adapter near heaters, or put it on the floor which is equipped with
a heater. The above mentioned operation might cause fire or incidents.
• DO NOT use it aboard; please abide by the airway’s provision. It might
influence communication aboard and the flying apparatus if departing
from the airway’s regulation. This will result in accident, possible death
and severe physical hurt.
• DO NOT disassemble or repair the camera, receiver or other relevant
peripheral equipments by yourself. Improper disassembly might
cause damages to the product or the peripheral equipment.
• DO NOT put the camera in quaky paces. The camera may be unstable
or out of operation if installed improperly. Such installation may also
cause breakdown.
• DO NOT touch, shake or hold the antenna. Touching, shaking or holing
the antenna might influence the receiving of electromagnetic wave,
and thereby influence the receiving effect.
• DO NOT use the camera in complex environment, the obstruction of
stumbling block will affect the electromagnetic wave and influence
the receiving range. Wall, tree and other stumbling block might absorb,
reflect the electromagnetic wave, and influence the receiving range.
• DO NOT use the camera in the places which are covered with
metal.The around metal, such as elevator and cabin, might shield the
electromagnetic wave, and result in inability to receive signals.

7
Conditions
Please read the following messages to make sure your working
environment is suitable.
• The temperature should be kept between –20˚C and 50˚C (-4˚F to
122˚F). The relative humidity should be kept between 20% and 80%.
• Avoid putting the product in places where temperature or humidity
may change rapidly.
• Keep product away from heat sources such as electric heaters.
• Do not use the camera near harmful chemicals.
• Do not place product near any strong magnetic objects
• It might influence the normal operation of the product if used at the
fringe range of normal temperature. Please turn off the power when
not in use.
• Do not disassemble the product.
• Do not shake or strike the product.
• Please obey the local government’s environment protection policy.

8
Package Contents
1 x Receiver
(SM-451DR)
1 x Antenna
1 x Camera
(SM-703DT)
2 x AC Adapters
5 x Screws
1 x Bracket
1 x AV Cable
User’s Manual

9
Specifications
Image Sensor
Resolution
View Angle
Weatherproof Rating
Night Vision Range
Audio
Minimum Illumination
Pairing Button
IR LEDs
Power Supply
Dimensions (LxWxH)
Pairing Button
Channel Button
AV Output
Power Supply
Dimensions
Stand
Frequency
Transmission power
Receiver Sensitivity
Modulation
Antenna
Transmission Distance
Operating Temperature
Operating Humidity
1/4” CMOS Color
510 x 492 pixels (NTSC)
35 degree
IP65
Up to 50ft / 15m (B/W)
Microphone built-in
(audio monitoring up to 20ft)
3 Lux/F1.2 (IR off); 0 Lux (IR on)
1
24 LEDs
DC 5V / 1.5A
3.5” x 2.4” x 2.4”
1
1 CH button (Manually Select CH1~CH4)
1 x Video out (RCA); 1 x Audio out (RCA)
DC 5V / 1.5A
4.2” x 2.7” x 0.9”
1 x docking stand
ISM 2400 – 2480 MHz (CH1/CH2/CH3/CH4)
17 dBm
≤-85dBm
GFSK
Omni 3dBi
Up to 490 ft (150m) clear line of site;
up to 200ft (indoor)
-20°C to 60°C (-4°F~140°F)
20% -80% RH
SM-703DT
(Camera)
SM-451DR
(Receiver)
Wireless

10
Features
• Do-it-yourself (D.I.Y) easy to setup and use wireless camera kit
• Weatherproof camera housing for outdoor and indoor applications
• Wireless transmission up to 200ft between walls or up to 490ft in
clear line of site
• No Wi-Fi interference; no interference from crowded analog
900MHz/2.4GHz/5.8GHz/6.0GHz devices
• Built-in infrared LEDs for night vision up to 50ft (B/W)
• Built-in microphone for audible recording or monitoring up to 20ft away
• AV output RCA interface from receiver to monitor for live display
or to a recorder
• Digital wireless pairing between camera and receiver, worry free of
signal interception by neighbors
• Supports up to 4 sets of digital wireless camera/receiver (CH1~CH4)
to a location
• One receiver can support up to four digital wireless cameras
(switching one camera at a time)
• Video signal loss alert notication

11
Product Basics
Lens
Sun Visor
Light Sensor
Night Vision LED
Power Jack
Pairing Button
Bracket
Channel Button
Pairing Button
Audio Output
Video Output
Power Socket
Docking Stand
Antenna
Antenna
MIC
Camera (SM-703DT)
Receiver (SM-451DR)
LED Lights

5VDC/1.5A
5VDC/1.5A
Camera
Monitor
Receiver
12
Quick Start
1. Mount the camera in the desired position. Be sure to plug in the
power to the camera and attach the supplied antenna.
CAUTION: To prevent electric shock or damage to the camera,
please be sure to properly insolate the camera’s microphone and
power connections if being used as an outdoor application.
Microphone is for indoor use only.

AV Output to
TV/DVR/VCR
Input
or
13
2. Plug in the receivers power supply and connect the AV (audio/video)
cable from the AV output of the receiver to your TV or recording
devices (VCR or DVR) AV input.
NOTE: Make sure all cords are connected tight and that you are
following the proper color coding (Video/Yellow, Audio/White or Red)
3. Turn on your TV and set it to the appropriate input channel. The
television must be on the A/V Input that you connected the receiver to.
For example A/V 1, Input 1, Video 1 or Line 1. Once the television
is on the proper input channel and the receiver is powered ON, you
should receive your picture and be able to hear audio from the camera’s
microphone. The graphic user’s interface will display on the monitor as
shown below.
NOTE: To tune your TV to the proper input channel, you must do it
directly on the TV itself or with the original TV remote.

Channel
Signal Strength
No Signal
14
On-Screen Display
Signal Strength
The signal bars on the
on-screen display indicates
the signal strength between
the camera and the receiver.
[0~1 bars = weak/no reception;
4 bars = strong reception]
Channel
The channel number corresponds to the camera that is being monitored
or recorded. You can toggle between channels by simply pressing the
“CH” button located on the receiver.
No Signal
A “NO SIGNAL” notification will be displayed (followed by a melody)
whenever the user toggles to a channel with no camera matched to it or
if the camera and receiver are not successfully matched.
NOTE: The “Channel” and “Signal Strength” icons will turn orange during
the no signal warning.
Operation
Adding and Pairing camera to the receiver
To pair multiple cameras to your receiver (4max), simply switch the
receiver to a channel that is not in use or no signal and simultaneously
press on both Pairing button’s located on the camera and the receiver.
If it is a new add-on camera, please be sure to pair the camera close
by (within 20ft recommended) the receiver first before securing the
camera to a desire location. The camera image will immediately be
displayed on the screen after successfully being matched and paired
to the receiver. The manufacturer default setting for the camera is
channel 1.

15
NOTE: A “NO SIGNAL” notification will be displayed, followed by a melody
if the camera and receiver are not successfully paired. To remove the
camera from the receiver, simply pair another camera over the existing
channel or unplug the power from the camera.
Switching between channels
You can switch between cameras by pressing the “CH” button located on
the back of the receiver. The DigioutAir system support manual channel
switching only. It does not support automatic channel dwelling and Quad
channel view.
NOTE: A “NO SIGNAL” notification will be displayed, followed by a melody
if you switch the receiver to a channel that does not have a camera
matched to it.
Troubleshooting
Q: The power adapters are plugged in both the camera and the
receiver, but there is no picture showing on the monitor?
Check all connections to the camera and the receiver. Make sure that the
camera and receiver are both ON and that the camera(s) is in range of
the Receiver. Make sure the monitor or TV are set to the auxilary input
channel, ie. INPUT1, INPUT2, VIDEO1, VIDEO2, and etc. Else try pairing the
camera to the receiver.
Q: The image from the camera(s) is choppy and/or keeps on cutting out?
The wireless receiver may be out of range of the camera(s). Use the signal
bars on the on-screen display to observe signal strength. 0~1 bars = no/
weak reception; 4 bars = strong reception. Adjust and relocate both the
camera and the receiver to try to find better signal bars.
Q: I can’t hear any audio sound from the camera(s) on my TV?
Check the connections between the receiver and the TV, specifically the
red and/or white connector(s) are plugged in correctly. Check the volume
settings on the TV. Also, remember that the range of the microphone is
not the same as the range of the camera – the camera will detect anything
in front of it that it sufficiently lit.
