DigioutAir
Digital Wireless Outdoor/Indoor Color Camera Kit with Audio
and Night Vision
Go digital with your wireless security needs; the simplest way to secure your home and business. DigioutAir is a do-it-yourself
digital security camera kit designed for easy installation and operation. In comparison to the traditional analog wireless
technology running on 900MHz, 2.4GHz, and 5.8GHz, the 2.4GHz digital wireless technology provides three key advantages;
stronger signal strength which provides longer transmission distance (indoor/clear-line-of-site: 200ft/490ft v.s.100ft/300ft),
digital signal which is interference free from crowded wireless analog devices (Wi-Fi routers, Bluetooth devices, cordless/cell
phones, and other digital wireless band), and privacy which is worry free of signal interceptions from neighborhood.
Package Contents:
Features:
• Do-it-yourself (D.I.Y) easy to setup and use digital wireless camera kit
• Weatherproof camera housing for outdoor and indoor applications
• Wireless transmission up to 200ft between walls and up to 490ft in clear line of site
• No Wi-Fi interference; no interference from crowded analog 900MHz/2.4GHz/5.8GHz/6.0GHz devices
• Camera with built-in infrared LEDs for night vision up to 50ft (B/W)
• Built-in microphone for audible recording up to 20ft away
• AV output RCA interface from receiver to monitor for live display or to a recorder
• Digital wireless pairing camera and receiver, worry-free of signal interception
• Supports up to 4 sets of digital wireless camera/receiver (CH1~CH4) to a location
• One receiver supports up to four digital wireless cameras (switching one camera at a time)
• Video signal loss alert notication
• 1 x Digital wireless outdoor/indoor camera with antenna and sun visor
• 1 x Digital wireless receiver with antenna and docking stand
• 2 x Power adapters (for camera and receiver)
• 1 x AV cable
• 1 x Camera mounting bracket
• User’s manual and screws
NIGHT VISIONCOLOR
WEATHER
RES ISTANT
DO IT
YOURSELF
DIGITAL
WIRELESS
AUDIO

Key Specifications:
Image Sensor
Resolution
View Angle
Weatherproof Rating
Night Vision Range
Audio
Minimum Illumination
Pairing Button
IR LEDs
Power Supply
Dimensions
Pairing Button
Channel Button
AV Output
Power Supply
Dimensions
Stand
Frequency
Transmission power
Receiver Sensitivity
Modulation
Antenna
Transmission Distance
Operating Temperature
Operating Humidity
1/4” CMOS Color
510 x 492 pixels (NTSC)
35 degree
IP65
Up to 50ft / 15m (B/W)
Microphone built-in (audio monitoring up to 20ft)
3 Lux/F1.2 (IR off); 0 Lux (IR on)
1
24 LEDs
DC 5V / 1.5A
3.5” x 2.4” x 2.4”
1
1 CH button (Select CH1~CH4)
1 x Video out (RCA); 1 x Audio out (RCA)
DC 5V / 800mA
4.2” x 2.7” x 0.9”
1 x docking stand
ISM 2400 – 2480 MHz (CH1/CH2/CH3/CH4)
17 dBm
≤-85dBm
GFSK
Omni 3dBi
Up to 490 ft (150m) clear line of site; up to 150ft (indoor)
-20°C ~ 60°C/-4°F ~ 140°F
20% -80% RH
SM-703DT (Camera)
SM-451DR (Receiver)
Wireless
