SEGUE VK-1314 Manual

© 2019
Order #XXXXX
Top View
Perspective View
10’
10’
Scale: 19
VK-1314 General Layout
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2019
Order #XXXXX Grid Layout
Locked layer contains
placeholder marks.
= 1 sq foot

© 2019
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information

© 2019
Order #XXXXX
Graphic Removal
To remove the graphic
the frame, locate the fabric
pull tab.Gently pull up on the
tab to remove the fabric.
Step 1
Insert corner A. Turn edge of
graphic so silicon welt is
perpendicular to face of
graphic. Insert narrow side
of welt with fabric to outside
into the channel. Repeat for
other side of this corner.
Step 2
Repeat Step 1 for opposite
corner C, then insert corner
B, followed by corner D, to
complete the installation of
the corners.
Step 3
Once all corners are inserted,
press one silicon edge into
channel from corners and
work toward the center.
Make sure welt is fully inserted
into channel. Continue until
all sides are done. Smooth
out edges of graphic.
It is important to first insert
graphic into each alternate
corner then to the sides of
the frame. If this is not done,
graphic will not fit into the
frame correctly.
Corner A
Corner D
Corner B
Corner C
from
SEG Installation

© 2019
Case 1 of 3
Order #XXXXX Case Packing
Graphics
Lights
Setup Hardware
Top View of Each Level
Level 1 (Bottom Level) Level 2
14
13 17
16
16A 2 2A 3 3A 15 4 4A 5 5A
7,7A
8,8A
1,1A
6,6,6A,6A
Level 3

© 2019
Case 2 of 3
Order #XXXXX Case Packing
Top View of Each Level
Level 1 (Bottom Level) Level 2
Counter
9,9A
11,11
12,12
Shelf
(Qty. 2)
Shelf
(Qty. 4)
Level 3 Level 4
Canopy Pieces
Shelf
(Qty. 2)
Shelf
10,10A

© 2019
Case 3 of 3
Order #XXXXX Case Packing
Locked layer contains
placeholder marks.
Top View of Each Level
Level 2 Level 3 Level 4 Level 5
Counter Top (2) Side Panels Front Panel
Shelf
Floor
Shelf Supports
Back Panel w/ Door
Level 1 (Bottom Level)

© 2019
Step 1 of 4
Order #XXXXX VK-1314 Backwall Assembly
2
15
14
Counter
Flange
9
11
12
10 10A
9A
12
11
1
Bolt Bolt
1A
6786
7A 8A 6A
13
6A
2A
3
4
3A
Canopy
Mount
5
5A
Item
1,1A
2,2A
3,3A
4,4A
5,5A
6,6A
7,7A
8,8A
9,9A
10,10A
11
12
13
14
15
Description
Base Plate
42” S44 Vertical Extrusion w/ PR37
42.25” S44 Vertical Extrusion w/ TSP3 & PR37
42” S44 Vertical Extrusion w/ TSP3 & PR37
42” S44 Vertical Extrusion w/ PR37
14” Z45 Horizontal Extrusion
28.9725” Z45 Horizontal Extrusion w/ TSP3
28.9725” Z45 Horizontal Extrusion w/ TSP3
11.0128” Z33 Horizontal Extrusion
11.8331” Z33 Horizontal Extrusion
44.3283” Curved Vertical Extrusion
44.3283” Curved Vertical Extrusion
14” Z140 Horizontal Extrusion
19” Z45 Horizontal Counter Support
31.945“ Vertical Counter Support
Qty.
1,1
1,1
1,1
1,1
1,1
2,2
1,1
1,1
1,1
1,1
2
2
1
1
1
Steps:
1) Attach base plate [1] to vertical [2] and [15].
2) Attach base plate [1A] to vertical [5].
3) Attach all upper verticals to lower verticals.
4) Connect horizontals [7 to 8] and [7A to 8A].
5) Connect curved verticals [11] to [12].
6) Attach horizontals between vertical as shown, making sure Velcro is facing to back.
7) Attach horizontal [14] between to verticals [2] and [15].
8) Place counter on top of horizontal [14]. See Counter Attachment detail to secure.
9) Apply SEG graphic to TSP3. See SEG Installation sheet for instruction.
10) Connect graphics to Velcro on back of PR37 extrusions.
Velcro at lower
back of bar. Velcro at lower
back of bar.
Velcro at upper back of bar.
Velcro
PR37
Extrusion
Profile
Completed Assembly
Velcro at upper back of bar.
Counter Attachment
*
Wing Nut
Fixed
Screws
Flange
15
14
Counter
Attach flange to extrusion [15], using screw.
Insert fixed screws, located on underside of
counter, into holes of flange then secure
with wing nuts.
*
Keep canopy mounts attached
to [2A] and [5A], when packing.

© 2019
Step 2 of 4
Order #XXXXX
Using Your Setup Instructions
The Aero Setup Instructions are created specifically for your configuration. The instructions include an
exploded view of the frame which is sequentially labeled. We encourage you to review the instructions
before attempting to assemble your exhibit.
Connections are kept very simple; no tools required. Everything assembles with push-button connectors.
Cleaning and Packing Your Display
1) Use care when cleaning aluminum extrusion or acrylic inserts. Use only non-abrasive cleaners.
2) Retain all packing material. It will make re-packing much easier and will reduce the likelihood
of shipping damage.
Connections are made by holding the button down and
sliding the red tube into opposing tube until the connection
is made. To disassemble push button and pull or twist
extrusions apart.
Push-Button
Push-Button
66
6
6
Numbered Label
Steps:
1) Connect canopy pieces together as shown.
2) Apply pillow case graphic to assembled canopy
AA
BB
D
D
CC
Push-Button
Push button then rotate
for packing purposes
E
F
E
FG
H
G
H
Canopy Assembly

© 2019
Step 3 of 4
Order #XXXXX VK-1314 Backwall Attachments
Completed Assembly
Header Assembly
**
*
**
**
**
**
**
Canopy
Keep header assembled,
when packing.
Header
Shelves
Screw
Cap
Screw
Cap
Shelves
Shelves
16
16A
17 7A
2A 13
8A
5A
Item
16,16A
17
Description
8” Z45 Vertical Extrusion
38.5928” Z45 Curved Horizontal Extrusion
Qty.
1,1
1
Steps:
1) Attach assembled header to top horizontals [7A/8A],
making sure header Velcro faces to back.
2) Connect graphic to Velcro on back of assembled header.
3) Attach lights. See Light Attachment detail.
4) Place canopy on top of vertical [2A] and [5A] mounts.
5) Attach shelves to backwall using screw caps and
clamps. See Clamp Attachment detail.
6) Attach monitor mount to horizontal [13]. See Monitor
Mount Attachment detail.
Attach mount plate, using bolts, to Z140
extrusion then secure with wing nuts.
Attach monitor mount to mount plate.
Z140
Extrusion
Wing
Nut
Monitor
Mount
Mount
Plate
Monitor Mount Attachment
*
SEG Graphic
When desired location
is found, tighten
set screw to secure.
Slide connector, located on
back of clamp, into groove
of extrusion.
Clamp
Clamp Attachment
Keep clamps attached to verticals, when packing.
*
Knob
Set Screw
A10 Clamp
*
Slide light onto clip then lock clip
into groove of horizontal extrusion.
Clip
Light
Light Attachment
Clip
Light
Horizontal Extrusion

© 2019
Step 4 of 4
Order #XXXXX
Locked layer contains
placeholder marks.
*
Completed Pedestal Assembly
Pedestal Base Assembly
Pedestal Top Attachment
Pedestal Top
Screw
Cap
Back Panel
with Door
Side Panel
Side Panel Front Panel
Floor
Shelf Support
Shelf
Align hole with pin Rotate pin. Spring
will push pin into hole.
Pedestal Top Attachment
12
*
Pin
*
Remove pins for floor from
side panels when packing.
Setup Instructions:
1) Attach pins at bottom interior of side panels. Note: Pins are designed to be slightly angled.
2) Use screw caps to secure the side panels to front panel and back panels, making sure Velcro is facing inward.
3) Slide floor into the bottom of assembled pedestal base. The floor will sit on pins of the side panels.
4) Connect shelf supports to Velcro on panels, then place shelf on top of supports.
5) Attach pedestal top to assembled pedestal base. See Pedestal Top Attachment detail.
LTK-1001 Pedestal Assembly
