SEI MISSION SPACESAVER BE7591 User manual

SOUTHERN ENTERPRISES INC.
RELAX...If you can follow a few easy, step-by-step directions
in order .YOU CAN ASSEMBLE THIS ITEM.
STYLENO:
BE7591
MISSION SPACESAVER
PLEASE FIND HARDWARE IN RED POLYBAG BEFORE DISCARDING PACKING MATERIAL.
HARDWARE LIST
(1) METAL HANDLE
2PCS
(9) MAGNET
1PC
(2) METAL PLATE
2PCS
(10) SMALL FLAT HEAD WOOD SCREW
(Ø3X12mm)
10PCS
(3) MACHINE SCREW
4PCS
(11) PLASTIC ANCHOR
2PCS
(4) CAM-BOLT
14PCS
(12) LARGE FLAT HEAD WOOD SCREW
(Ø4X25mm)
2PCS
(5) CAM-LOCK
14PCS
(13) MIDDLE FLAT HEAD WOOD SCREW
(Ø8X22mm)
8PCS
(6) SHORT WOOD DOWEL(Ø8X30mm)
24PCS
(14) PAN HEAD WOOD SCREW
26PCS
(7) LONG WOOD DOWEL(Ø8X45mm)
4PCS
(15) SHELF SUPPORT
4PCS
(8) METAL HINGE
4PCS
(16) COVER
14PCS

PARTS LIST
(A) TOP PANEL
1PC
(I) UPPER CROSS BRACE
2PCS
(B) UPPER LEFT SIDE PANEL
1PC
(J) LOWER FIXED SHELF
1PC
(C) UPPER RIGHT SIDE PANEL
1PC
(K) LOWER CROSS BRACE
1PC
(D) BOTTOM PANEL
1PC
(L) ADJUSTABLE SHELF
1PC
(E) RIGHT DOOR
1PC
(M) UPPER BACK PANEL
1PC
(F) LEFT DOOR
1PC
(N) MIDDLE BACK PANEL
1PC
(G) LOWER LEFT SIDE FRAME
1PC
(O) LOWER BACK PANEL
1PC
(H) LOWER RIGHT SIDE FRAME
1PC

ASSEMBLY INSTRUCTION
1. SELECTA SMOOTH, SOFT SURFACE TO PREVENT SCRATCHING FINISH.
2. YOU MAY NEED A PHILIP SCREWDRIVER.
3. INSERT SMALL FLAT HEAD WOOD SCREWS (10) THROUGH METAL HINGES (8) AND TIGHTEN
INTO PREDRILLED HOLES ON CORNERS OF BACK OF LEFT DOOR (F). INSERT MACHINE SCREWS
(3) THROUGH PREDRILLED HOLES ON BACK OF LEFT DOOR (F)AND TIGHTEN INTO PREDRILLED
HOLES ON METAL HANDLESAND METAL PLATES (1, 2). ASSEMBLE RIGHT DOOR (E) IN THE
SAME MANNER. AS SHOWN IN FIGURE 1
4. INSERT SMALL FLAT HEAD WOOD SCREWS (10) THROUGH END OF MAGNET (9) AND TIGHTEN
INTO PREDRILLED HOLES ON UNDERSIDE OF TOP PANEL (A). INSERT CAM-BOLTS (4), SHORT
WOOD DOWELS (6) INTO PREDRILLED HOLES ON UNDERSIDE OF TOP PANEL (A) AND FIT INTO
CORRESPONDING HOLES ON TOP EDGES OF UPPER LEFTAND RIGHT SIDE PANELS (B, C), INSERT
CAM-LOCKS (5) INTO BIG HOLES ON INSIDE OF UPPER LEFTAND RIGHT SIDE PANELS (B, C)
WITH SLOT FOR SCREWDRIVER FACING OUTWARD. ROTATE CAM-LOCKS (5) CLOCKWISE TO
SECURE CAM-BOLTS (4). PUSH COVERS (16) INTO CAM-LOCKS (5). AS SHOWN IN FIGURE 2
FIGURE 1
FIGURE 2

5. INSERT METAL HINGES (8) EXTENDING FROM LEFTAND RIGHT DOORS (F, E) INTO PREDRILLED
HOLES ON UNDERSIDE OF TOP PANEL (A), UPSIDE OF BOTTOM PANEL (D). INSERT MEDIUM FLAT
HEAD WOOD SCREWS (13) THROUGH PREDRILLED HOLES ON BOTTOM PANEL (D)AND TIGHTEN
INTO CORRESPONDING HOLES ON BOTTOM EDGES OF UPPER LEFT AND RIGHT SIDE PANELS
(B,C). AS SHOWN IN FIGURE 3.
FIGURE 3
6. ATTACH UPPER BACK PANEL (M) INTO SLOTS ON PARTS (A, B, C). INSERT PAN HEAD WOOD
SCREWS (14) THROUGH PREDRILLED HOLES ON UPPER BACK PANEL (M)AND TIGHTEN INTO
CORRESPONDING HOLES ON REAR EDGES OF PARTS (A, B, C). ASSEMBLE LOWER BACK PANEL
(O) IN SAME MANNER. FINALLY, ATTACH MIDDLE BACK PANEL (N) ONTO UPPER AND LOWER
BACK PANELS (M, O). TIGHTEN PAN HEAD WOOD SCREWS (14) THROUGH PREDRILLED HOLES
ON MIDDLE BACK PANEL (N) INTO CORRESPONDING HOLES ON REAR EDGES OF PARTS (B, C).
AS SHOWN IN FIGURE 4.
FIGURE 4
(C)
(D)
(B)
(A)
(O)
(N)
(M)
(14)

7. INSERT CAM-BOLTS (4) AND SHORT WOOD DOWELS (6) INTO PREDRILLED HOLES ON INSIDE OF
LOWER LEFTAND RIGHT SIDE FRAMES (G, H) AND FIT INTO CORRESPONDING HOLES ON ENDS
OF UPPER CROSS BRACE (I), LOWER CROSS BRACE (K) AND LOWER FIXED SHELF (J). INSERT
CAM-LOCKS (5) INTO BIG HOLES ON UPPER CROSS BRACES (I), LOWER CROSS BRACE (K) AND
LOWER FIXED SHELF (J) WITH SLOT FOR SCREWDRIVER FACING OUTWARD. ROTATE
CAM-LOCKS (5) CLOCKWISE TO SECURE CAM-BOLTS (4). PUSH COVERS (16) INTO CAM-LOCKS
(5). AS SHOWN IN FIGURE 5.
8. PLACE THE ASSEMBLED BOTTOM HALF BEHIND THE TOILET TANK, THEN INSERT LONG WOOD
DOWELS (7) INTO PREDRILLED HOLES ON UPPER EDGES OF LOWER SIDE FRAMES (G, H), INSERT
SHORT WOOD DOWELS (6) INTO PREDRILLED HOLES ON UPPER CROSS BRACES (I). WITH AN
ASSISTANT, INSERT LONG AND SHORT WOOD DOWELS (7, 6) EXTENDING FROM UPPER EDGES
OF PARTS (G, H, I) INTO CORRESPONDING HOLES ON UNDERSIDE OF BOTTOM PANEL (D). INSERT
MEDIUM FLAT HEAD WOOD SCREWS (13) THROUGH PREDRILLED HOLES ON LOWER LEFT AND
RIGHT SIDE FRAMES (G, H) AND TIGHTEN INTO CORRESPONDING HOLES ON UNDERSIDE OF
BOTTOM PANEL (D). AS SHOWN IN FIGURE 6.
FIGURE 5
FIGURE 6

9. FOR SAFETYAND STABILITY, PLACE THE UNIT AGAINST WALL, DRILL TOW 1/4” DIAMETER
HOLES IN WALL, THE DISTANCE BETWEEN TWO HOLES SHOULD MATCH TO THE PREDRILLED
HOLES ON UPPER BACK PANEL (M). FIT PLASTIC ANCHORS (11) INTO THE HOLES ON WALL .USE
SCREWDRIVER TO SCREW LARGE FLAT HEAD WOOD SCREWS (12) THROUGH PREDRILLED
HOLES ON UPPER BACK PANEL (M) INTO PLASTIC ANCHORS (11).AS SHOWN IN FIGURE 7.
10. FIT SHELF SUPPORTS (15) INTO PREDRILLED HOLES ON INSIDE OF UPPER LEFTAND RIGHT SIDE
PANELS (B, C), PUT ADJUSTABLE SHELF (L) ON EACH SHELF SUPPORTS (15) MATCH THE
POSITION OF GROOVE ON ADJUSTABLE SHELF (L). AS SHOWN IN FIGURE 7.
FIGURE 7 READY
YOUR NEW MISSION SPACESAVER IS FINISHEDAND READY TO USE.

Please count, identify and compare parts and hardware list to be sure all parts are present. It may help to
divide parts and label them to correspond with part list. Extra hardware may be included. If any items are
missing, please contact our parts/service department at [phone] or in Dallas [phone]/ 9am –
4pm Mon-Fri Central time. Missing or damaged hardware and/ or parts will be replaced free of charge. WE
DO NOT SELL PARTS. WE DO NOT RECOMMEND MODIFYING PRODUCT(S) AND WE ARE NOT
RESPONSIBLE FOR ANY DAMAGES DUE TO PRODUCT MODIFICATION(S). If this product has not
been purchased from our retail affiliates (within 9 months), we are under no obligation to provide parts or
replacement merchandise. Parts will not be available for items arriving fully assembled.
"We will ship parts if available" "This is not a warranty"
PARTS REPLACEMENT FORM
STYLE NO: BE7591
Customer Name PARTS
LETTER PART DESCRIPTION QUANTITY NEEDED
Street, City, State, Zip
Phone#
Please indicate where you purchased this item.
Store/website/catalog
/ /
SOUTHERN ENTERPRISES INC.
P.O. Box 59996 Dallas, Texas 75229 Please indicate color/size/style number
/ /
