Seicane S018801 Mercedes-Benz SLK W171 R171 aftermarket radio dvd
gps stereo upgrade insta ation rep acement instruction
Seicane S018801 Mercedes-Benz SLK W171 R171 head unit after installation
Some tips before the insta ation:
1. lease disconnect the power before the installation.
2. lease prepare a lever and a screwdriver before the removal and the installation.
3. lease keep all the separate parts from the car. lease take great care of the dashboard to
avoid scratching it during its detachment and installation. lease keep handy any parts from
the car and make use of all the original screws from the car as much as possible. so each
related part of the unit can be fixed securely.
4. For your convenience, here’s the recommended tools for removal and installation from
Seicane, please check for more details:
http://www.seicane.com/car-dvd-dismantling-device-srd-400

www.seicane.com
Mercedes-Benz SLK W171 R171 head unit insta ation guide
1. Open the little box beneath the radio and remove the screws with a screwdriver.
2. ry the trim panel on the right side of the box with a removal tool, after that, remove it.
3. Remove the screw with a screwdriver.
4. ry the leather surrounding the brake, then pull it up, at last, remove it.

www.seicane.com
5. Remove the trim panel under the brake with your hands.
6. Disconnect the connectors behind the trim.
7. Take the box out of the dashboard.
8. Disconnect the connectors behind the box.

www.seicane.com
9. Remove the trim panel on the box with your hands.
10.Disconnect the connectors at the back of the trim panel.
11. Remove two screwdrivers inside the trim panel.
12.Take another box under the radio with your hands.

www.seicane.com
13. Disconnect all the connectors at the back of the box.
14. Remove two screws after taking away the box with a screwdriver.
15. op out the disc player.
16. Remove the screws at both sides of the disc player.

www.seicane.com
17. Take the disc player out of the dashboard.
18. Remove two screws holding the radio with a screwdriver.
19. Take the radio out of the dashboard.
20. Disconnect all the connectors at the back of the radio.

www.seicane.com
21. Check all the accessories for the new Seicane head unit.
22. Connect the harnesses to the back of the new Seicane head unit.
23. Connect the Seicane head unit to your original car radio 's plugs.
24. ut the new Seicane unit into the dashboard and turn it on to have a comprehensive check.
25. If everything works well, then install all the screws, boxes and trim panels accordingly into
their original places. If not, check carefully whether all the cables are connected or not.
P ease note:
We suggest you arrange a professional to install it. If you have any questions about installation,
please send us photos about your original car's plugs, we can make a wiring diagram for your car.
