SelectBlinds Cellular Push Button Cordless Honeycomb... User manual

1. Hold the shade up near the brackets and insert the front clip of the
bracket into the front groove of the rail.
2. Make sure the shade is centered in the window opening.
3. Push the rail back and up until the back clips of the bracket are
inserted in the back groove of the rail.
To remove shade, reverse procedure.
A few simple tools are required:
- Measuring tape
- Carpenters Level
- Power drill or Phillips head Screwdriver
- ¼” Hex head and/or Phillips driver bit
Additional fasteners other than those sent with your shading may be
required depending on the mounting surface. Wallboard and plaster
require the use of anchors such as expansion or toggle bolts. Brick,
tile or stone need special plugs and drill bits. Remember to always
pre-drill holes in wood to avoid splitting.
Getting Started
Step 1: Bracket Installation
Step 2: Hanging the Shade
Optional Extension Brackets are used to project the back of the shade
up to 2 1/2” from the mounting surface. Attach the Mounting Bracket
to the Extension Bracket with the nut and bolt provided.
Line the bracket top with the desired height
of the top of the headrail.
Mark holes for screws. Remove brackets
and drill holes.
Insert screws for keyhole slots only. Ap-
proximately 1/8” of the screw should be le
protruding.
Pull the endcap out of the headrail and slide
the bracket on as shown. Replace the endcap
and then slide the bracket all the way into the
headrail.
Install the second bracket in the same
manner as the rst bracket.
Hook one bracket onto the screw in the window frame, using the
keyhole slot. Bring the other end bracket over the screw at the other
side of the frame. Slide down, exing bracket inward until the screw
engages in the keyhole slot.
Bol t
Nut
Extension
Bracket
Mounting Bracket 1 1/4” Hex Head
Bracket Screw
Headrail Extension
Bracket
Hold Down
Bracket (optional)
INSIDE MOUNT
Shade Width # of Brackets
Up to 40” 2
>40” - 72” 3
>72”- 84” 4
>84” 5
OUTSIDE MOUNT
EXTENSION BRACKETS (optional)
SIDE MOUNT (optional)
2” minimum surface required
Step 3: Operation
Press the button on the handle to raise or
lower the moveable rails. e rails will stay
in position when the button is released.
End brackets should be located as close to
each end as possible (edge of bracket approx.
1” from end). Depending on the width of the
shade, additional brackets may be necessary
evenly spaced between the two end brackets.
Using the Installation Bracket as a template, measure and mark the
center lines. When mounting brackets, make sure they are in line and
level.
Rail
Sidemount
Bracket
3/4” minimum
2” minimum for standard rail
2 1/2” minimum for large rail
WINDOWFASHIONS
Comfortex
1 7/8”1 7/16”
Standard Rail Large Rail
1”

Step 5: Hold Down Installation (optional)
e Shade fabric is easy to care for. Regular dusting with a feather duster or
vacuum cleaner brush is recommended. Most stains can be blotted with a
damp sponge and mild detergent. Before using anything stronger than mild
detergent and lukewarm water, test an unobtrusive corner of the shade. If
you have any questions, call your dealer for advice.
Cleaning and Care
Cellular
Push Button Cordless
Installation Instructions
Our window fashions represent a design breakthrough in
style, eciency and function. Our Cellular shades feature
100% non-woven polyester fabric providing a so diused
light and high level of privacy. e unique hardware system
is designed to provide years of reliable service when properly
installed.
Please take a few minutes to read through
these instructions before beginning.
152126 Rev C. 5/4/2015
If the bottom rail or the middle moving rail of a top down/bottom up
shade is not level, it can be adjusted by following the procedure below.
Remove the right endcap from the rail that is not level.
Pull out the section labeled TOOL.
Push in on the adjustment screw with the
tool and turn to adjust the rail.
When the rail is level, replace the tool and
the endcap.
Optional Hold Down Brackets are mounted with the supplied
screws. With the shade at its proper drop, place the pin of each
Hold Down into the hole in each End Cap and mark the screw holes.
Make sure the pins are level and aligned. Remove the pins from the
endcaps. Raise the shade, then screw the Hold Down Brackets into
the mounting surface. Lower the shade. Slightly ex the holddown
brackets to insert the pins into the endcaps.
Standard
Top Down/
Bottom Up

Step 4: Level the Moving Rail (If Necessary)
