Dometic DRIVING SUPPORT PERFECTVIEW CAM44 User manual

CAM44
Rear View Video Camera
Installation and Operating Manual. . . . . . . 11
Rückfahrvideokamera
Montage- und Bedienungsanleitung . . . . .28
Caméra vidéo de recul
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . . . .45
Cámara de vídeo de marcha atrás
Instrucciones de montaje y de uso . . . . . . .63
Câmara de vídeo de marcha atrás
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Videocamera per la retromarcia
Istruzioni di montaggio e d’uso . . . . . . . . .98
Achteruitrijvideocamera
Montagehandleiding en
gebruiksaanwijzing . . . . . . . . . . . . . . . . . . 116
Bakvideokamera
Monterings- og betjeningsvejledning . . . 133
Backningsvideokamera
Monterings- och bruksanvisning . . . . . . . 149
Ryggevideokamera
Monterings- og bruksanvisning . . . . . . . .165
Peruutusvideokamera
Asennus- ja käyttöohje . . . . . . . . . . . . . . . 181
Видеокамера заднего вида
Инструкция по монтажу и эксплуатации 197
Kamera cofania
Instrukcja montażu i obsługi. . . . . . . . . . . 215
Cúvacia videokamera
Návod na montáž a uvedenie
do prevádzky. . . . . . . . . . . . . . . . . . . . . . . 233
Couvací kamera
Návod k montáži a obsluze . . . . . . . . . . . 249
Tol atóka mera
Szerelési és használati útmutató . . . . . . . 265
V2
V1
TWIN
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
DRIVING SUPPORT
PERFECTVIEW
CAM44-IO-16s.book Seite 1 Mittwoch, 5. Oktober 2016 11:38 11

CAM44-IO-16s.book Seite 2 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
3
1 2 3
4
9
6
8
5
7
10 11 12
1
CAM44-IO-16s.book Seite 3 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
4
2
3
4
5
6
7
CAM44-IO-16s.book Seite 4 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
5
Ø 16 mm
1
2
3
45
6
7
V2
V1
TWIN
8
4
3
2
1
5
9
2.
1.
1.
0
CAM44-IO-16s.book Seite 5 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
6
B
A
D
C
a
A10 mm
15 mm
B
C
D
b
A10 mm
B20 mm
C
D
c
CAM44-IO-16s.book Seite 6 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
7
90°
d
e
f
g
CAM44-IO-16s.book Seite 7 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
8
h
i
j
k
~20°
l
CAM44-IO-16s.book Seite 8 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
9
A
B
m
9102200078
V 2 V 1
TWIN
n
CAM44-IO-16s.book Seite 9 Mittwoch, 5. Oktober 2016 11:38 11

CAM44
10
AMP100
Monitor (RCA)
Camera Input
12 - 24V
o
A
B
C
p
CAM44-IO-16s.book Seite 10 Mittwoch, 5. Oktober 2016 11:38 11

EN
CAM44
11
Please read this instruction manual carefully before installation and first
use, and store it in a safe place. If you pass on the product to another
person, hand over this instruction manual along with it.
Contents
1 Explanation of symbols. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
2 Safety and installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
3 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
7 Notes on the electrical connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
8 Fitting the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
9 Using the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
10 Cleaning and caring for the camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
11 Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12 Disposal. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
CAM44-IO-16s.book Seite 11 Mittwoch, 5. Oktober 2016 11:38 11

EN
Explanation of symbols CAM44
12
1 Explanation of symbols
!
!
A
I
2 Safety and installation instructions
Pleaseobservetheprescribedsafetyinstructionsandstipulations fromthe
vehicle manufacturer and service workshops.
The manufacturer accepts no liability for damage in the following cases:
•Faulty assembly or connection
•Damage to the product resulting from mechanical influences and excess voltage
•Alterations to the product without express permission from the manufacturer
•Use for purposes other than those described in the operating manual
Please observe the following instructions:
•To prevent short circuits, always disconnect the negative terminal of the vehicle’s
electrical system before working on it.
If the vehicle has an additional battery, its negative terminal should also be dis-
connected.
•Insufficient supply line connections could result in short circuits which
–Causecablefires
– Trigger the airbags
– Damage electronic control devices
– Cause electric functions to fail (indicators, brake light, horn, ignition, lights)
WARNING!
Safety instruction: Failure to observe this instruction can cause fatal or
serious injury.
CAUTION!
Safety instruction: Failure to observe this instruction can lead to injury.
NOTICE!
Failure to observe this instruction can cause material damage and impair
the function of the product.
NOTE
Supplementary information for operating the product.
CAM44-IO-16s.book Seite 12 Mittwoch, 5. Oktober 2016 11:38 11

EN
CAM44 Safety and installation instructions
13
•When working on the following cables, only use insulated cable terminals, plugs
and flat push-on receptacles:
– 30 (direct supply from positive battery terminal)
– 15 (connected positive terminal, behind the battery)
– 31 (return cable from the battery, earth)
– 58 (reversing light)
Do not use terminal strips.
•Use a crimping tool (fig. 110, page 3) to connect the cables.
•Screw the cable for connections to cable 31 (earth)
– Screw on the cable using a cable terminal and serrated washer to one of the
vehicle's earth bolts or
– Screw the cable to the bodywork using a cable terminal and a self-tapping
screw
Make sure there is a good earth connection.
If you disconnect the negative terminal of the battery, the entire data stored in the
volatile memories will be lost.
•The following data must be reset, depending on the vehicle equipment options:
–Radiocode
– Vehicle clock
–Timer
– On-board computer
– Seat position
You can find instructions for making these settings in the corresponding
operating manual.
Observe the following installation instructions:
•Secure the parts of the camera installed in the vehicle in such a way that they
cannot become loose under any circumstances (sudden braking, accidents) or
cause injuries to the occupants of the vehicle.
•Secure any parts of the system covered by the bodywork in such a manner that
they cannot be come loose or damage other parts and cables or impair vehicle
functions (steering, pedals, etc).
•To prevent damage when drilling, make sure there is sufficient space on the other
side for the drill head to come out (fig. 2, page 4).
•Deburr all drill holes and treat them with a rust-protection agent.
CAM44-IO-16s.book Seite 13 Mittwoch, 5. Oktober 2016 11:38 11

EN
Safety and installation instructions CAM44
14
•Always follow the safety instructions of the vehicle manufacturer.
Some work (e.g. on retention systems such as the AIRBAG etc.) may only be
performed by qualified specialists.
Observe the following instructions when working with electrical parts:
•When testing the voltage in electrical cables, only use a diode test lamp
(fig. 18, page 3) or a voltmeter (fig. 19, page 3).
Test lamps with an illuminant (fig. 112, page 3) consume voltages that are too
high and can damage the vehicle's electronic system.
•When making electrical connections, ensure that:
– They are not kinked or twisted
– They do not rub on edges
– They are not laid through sharp-edged ducts without protection (fig. 3,
page 4).
•Insulate all connections.
•Protect the cables from mechanical wear (for example rubbing against existing
cables) using cable binders or insulating tape.
The camera is watertight. However, the seals on the camera cannot withstand a high-
pressure cleaner (fig. 4, page 4). Therefore, you should observe the following
instructions when handling the camera:
•Do not open the camera, as this impairs the watertightness and the function of
the camera (fig. 5, page 4).
•Do not pull on the cables, as this impairs the watertightness and the function of
the camera (fig. 6, page 4).
•The camera is not suitable for use under water (fig. 7, page 4)!
CAM44-IO-16s.book Seite 14 Mittwoch, 5. Oktober 2016 11:38 11

EN
CAM44 Scope of delivery
15
3Scopeofdelivery
4Accessories
Available as accessory (not included in scope of delivery):
5 Intended use
The CAM44 camera (item no. 9600000043) camera is designed primarily for use in
vehicles. It can be used in rear view video systems to observe the space behind the
vehicle from the driver's seat when manoeuvring or parking, for example.
!
No. in
fig. 8,
page 5
Quantity Description Ref. no.
11Camera with motorised protective
cover
22Cover
3 1 Camera guard
4 1 Camera bracket
5 1 Insulation pad
6 1 CAM44 adapter box 9102200078
7 1 Extension cables 9102200030
– 1 Fastening material
Description Ref. no.
AMP100 switch box 9600000210
WARNING!
Since rear view systems are designed merely as an additional aid for
reversing, they do not relieve you of the duty to take proper care
when reversing.
CAM44-IO-16s.book Seite 15 Mittwoch, 5. Oktober 2016 11:38 11

EN
Technical description CAM44
16
6 Technical description
The colour camera with integrated microphone is encased in an aluminium housing
and transmits image and sound to a monitor via a cable. It has a close-up lens and a
long-range lens. The infrared LEDs improve night vision.
The long-distance lens shows the space behind the vehicle as if you were looking
through a rear window. You can switch it on when you are not reversing.
The close-up lens (reversing camera) is a wide-angle lens, which shows the area
directly behind the vehicle. It is activated when you engage reverse gear.
The camera produces three distance marks in reversing mode which are shown on a
connected colour monitor as coloured lines.
The CAM44 camera is equipped with a motorised cover to protect against dirt.
I
The camera consists of the following elements:
NOTE
The cameras were equipped with a reverse display at the factory. Any
monitor that is connected therefore needs a normal picture function.
No. in
fig. 9, page 5 Description
1 6-pin connection cable
2 Long-range lens
3 Infrared LEDs
4 Close-up lens (reversing camera)
5 Microphone
CAM44-IO-16s.book Seite 16 Mittwoch, 5. Oktober 2016 11:38 11

EN
CAM44 Notes on the electrical connections
17
7 Notes on the electrical connections
7.1 Laying cables
A
Please therefore observe the following instructions:
•As far as possible, use original openings or alternative openings for the
connecting cable duct, e.g. the paneling edges, ventilation grilles or blank
panels. If no openings are available, you must drill holes for the cables. Check
beforehand that there is sufficient room for the drill head to come outon the other
side.
•Wherever possible, lay cables inside the vehicle, as they are better protected
there than outside.
If you do need to lay a cable outside the vehicle, ensure that it is well fastened
(use additional cable ties, insulating tape etc.).
•To prevent damage to the cables, when laying them, ensure that they are far
enough away from hot or moving vehicle components (exhaust pipes, drive
shafts, light systems, fans, heater etc.). Use corrugated piping or other protective
materials to protect against mechanical wear.
•Screw on the plug connections of the connecting cables to protect against water
penetration (fig. 0, page 5).
•When laying the cables, make sure:
– They are not kinked or twisted
– They do not rub on edges
– They are not laid through sharp-edged ducts without protection (fig. 3,
page 4).
•Attach the cables securely in the vehicles to prevent tripping hazards. Use cable
binders, insulating tape or glue the cables in place.
NOTICE! Risk of damage!
•To prevent damage, when drilling ensure that there is sufficient
space on the other side for the drill head to come out.
•Cables and connections which are not properly installed will cause
malfunctions or damage to components. Correct installation of
cables and connections is the basic prerequisite for lasting and
trouble-free operation of the retrofitted components.
•The cables may not be exposed for long periods to solvents such as
benzine, as the solvents can damage the cable.
CAM44-IO-16s.book Seite 17 Mittwoch, 5. Oktober 2016 11:38 11

EN
Notes on the electrical connections CAM44
18
•Protect every through-hole made in the bodywork against water penetration,
e.g. by using a cable with a sealant and by spraying the cable and the cable
sleeve with sealant.
I
7.2 Using branch connectors
To prevent loose connections in the branch connectors, it is important to ensure that
the cable cross sections fit into the branch connectors.
To use the branch connectors, proceed as follows:
➤Insert the cable to be tapped in the front groove of the cable connector
(fig. aA, page 6).
➤Insert the end of the new cable up to approx. 3/4 of the way into the rear groove
(fig. aB, page 6).
➤Use a pair of combination pliers to close the connector by pressing the metal pin
in. This creates an electrical connection (fig. aC, page 6).
➤Press down the safety cap until it snaps into place.
➤Check that the connection is secure by gently tugging the cable (fig. aD,
page 6).
NOTE
Only start sealing through-holes when you have completed all
installation work on the camera and have laid the required cable lengths.
CAM44-IO-16s.book Seite 18 Mittwoch, 5. Oktober 2016 11:38 11

EN
CAM44 Notes on the electrical connections
19
7.3 Creating clean soldering joints
Proceed as follows to solder a cable to the original cables:
➤Strip approx. 10 mm of insulation from the end of the original cable (fig. bA,
page 6).
➤Strip approx. 15 mm of insulation from the end of the cable to be connected
(fig. bB, page 6).
➤Wind the cable to be connected around the original cable and solder the two
cables together (fig. bC, page 6).
➤Insulate the two cables with insulating tape (fig. bD, page 6).
Proceed as follows to solder two cables together:
➤Strip the two cables (fig. cA, page 6).
➤Place a shrink sleeve with a length of approx. 20 mm over the cable (fig. cB,
page 6).
➤Twist the cables together and solder them (fig. cC, page 6).
➤Place a shrink sleeve over the soldered point and heat it briefly (fig. cD,
page 6).
CAM44-IO-16s.book Seite 19 Mittwoch, 5. Oktober 2016 11:38 11

EN
Fitting the camera CAM44
20
8 Fitting the camera
8.1 Tools required
For installation and assembly you will need the following tools:
•Drill bit set (fig. 11, page 3)
•Drill (fig. 12, page 3)
•Screwdriver (fig. 13, page 3)
•Set of ring or open-ended spanners (see fig. 14, page 3)
•Measuring ruler (fig. 15, page 3)
•Hammer (fig. 16, page 3)
•Centre punch (fig. 17, page 3)
To establish and test the electrical connection, the following tools are required:
•Diode test lamp (fig. 18, page 3) or voltmeter (fig. 19, page 3)
•Insulating tape (fig. 111, page 3)
•Cable bushing sleeves (optional)
To fasten the cables you may require additional cable binders.
8.2 Fitting the camera
!
I
CAUTION!
Select a location for the camera and attach it firmly enough so that it
cannot under any circumstances fall off and injure bystanders (e.g. by
being knocked off by branches brushing over the roof of the vehicle).
NOTE
If installing the camera alters the vehicle height or the length specified in
the vehicle documents, your vehicle must be inspected by the
appropriate authorities.
Make sure that you are in possession of vehicle documents verifying that
your vehicle has passed this inspection.
CAM44-IO-16s.book Seite 20 Mittwoch, 5. Oktober 2016 11:38 11
