Rexing S1 Pro User manual

1
S1 Pro
User Manual

2
Notice
1. Menu Setup Operation: The menu is to be set up in non-video mode.
If the device is in video mode, proceed after stopping the video
recording.
2. Memory card: A new card must be formatted to the machine before
use. Continuous image recording for long periods of time may
produce protected files that are not subject to long-term protection
(these files may not be overwritten during loop recording) and storage
fragments, which need to be cleared regularly in order to save stable
storage space.
3. Standard Voltage for On-board Charger: Standard input voltage is
configured at 12V. If a charge voltage greater than 12V is found,
contact your dealer or our service center to replace it with an
applicable charger. An OEM charger must be used.
4. Movement Detection (Motion Detection) and Parking Monitor: Do
not enable this function during driving. When it is enabled, repeated
start/stop recording may affect the integrity of your video.
5. Do not install the device within the range that could be impacted by
airbag or in a location that interferes with the driver’s view or other
safe operation of the vehicle. Make sure it is securely mounted.

3
6. The features described in the operation manual are available for all
products of the same type. Your model may have come with optional
or additional functions. Menu operations may vary. Please refer to the
instructions that apply to your actual product.
Warning
The battery (module or pack) must not be expose to an overheat environment
such as direct sunlight or flame.
Never remove, strike, or squeeze the battery or put it in fire. Stop using the
battery if it is ballooned, warped, leaking, or shows any other visible signs
of damage.

4
Overview
Thank you for choosing REXING! We hope you love your new
products as much as we do.
If you need assistance, or have any suggestions to improve it,
please contact us. You can reach us via [email protected] or call
us at (203) 800 - 4466. Our support team will respond you as soon
as possible.
Always a surprise in Rexing. Check us out here.
https://www.facebook.com/rexingusa/
https://www.instagram.com/rexingdashcam/
https://www.rexingusa.com/support/registration/
Facebook
Instagram
Site
Product Support

5
Table of Contents
Camera Overview..........................................................................6
Installation and Operation……………………………………………….............9
Basic Operations…………………………………………………………..……………12
Mobile Connection…………………………………………………………………….16
GPS Player………………………………………………………………………………….22
Product Specifications……………………………...……………………………….24
General Troubleshooting…………………………...………………………………25

6
Camera Overview
I. Visual Features
(For reference only)
1. Menu/Mode Button
2. Record/Up Button
3. Power Button
4. Down/Toggle Button
5. OK Button
6. Power Cord Connection Port
7. Rearview Camera Connection Port
8. Reset Pinhole
Note: GPS is an optional feature need to connect to the GPS Logger
Buttons and Description:
USB 5V Socket
Smart
Hardwire Kit
Socket
Rearview
Camera Socket
GPS Socket
Front Camera
IR light
Cabin Camera

7
Buttons
Description
M Button
(Menu/Mode
Switch)
1. In standby mode, press this button to start/stop the related
menu options such as recording mode, photography mode,
playback mode.
2. In recording mode, press and hold the button for 3 second to
enter picture-taking and playback interface. Depress it again to
exit.
Record/Up/M
IC Button
1. In standby mode, press this button to start/pause video
recording.
2. Video Mode: Depress this button to start/stop audio
recording.
3. The button is defined for page up in menu setup and playback
mode.
4. During playback, press the button shortly to play fast rewind.
Power Button
1. Press this button to start the device. Depress it for 3 seconds
to power off the device.
2. In power-on state, press the button shortly to turn off/on
screen backlight.
Down/Toggle
Button
1. This button is defined for page down in menu setup and
playback mode.
2. Press this button to switch between front/rear camera view
and PIP display.
3. During playback, press the button shortly to play fast
forward.
4. In video mode, depress the button to switch the IR light to
OFF/ON/AUTO.
OK Button
1. This button functions as a confirmation in each of the setups.
2. In video recording, press this button to start emergency
recording.
3. Depress this button to switch Wi-Fi on/off.

8
4. In photography mode or playback mode, press the button to
take a picture or play back a file.
USB Port
Power charging port/USB data cable port
Power Port
Power cable connection port
Rearview
Camera
Connection
Port
Rearview Camera Connection Port
Reset Pinhole
If the system crashes, use a pin to reset the system.

9
Installation and Operation
1. Turn off the car’s engine.
2. Place the MicroSD card into the slot.
3. Secure the dashcam to a place close to the original rearview mirror.
4. Plug the GPS module into the GPS port and secure the module to a position
close to A-pillar of the car. The antenna receiver side (the side without 3M
adhesive) faces the outside and the side with 3M adhesive faces down. It
should be properly secured.
5. Plug the charger into the car’s cigarette lighter. Connect the device to the
cigarette lighter through the car charger.
Note: The charger extension cable can be wired along the edge of the
windshield during installation. The optional rearview camera should be
mounted on the rear windshield of the car. Pay attention to its orientation
during installation. It can be wired against or above the interior’s headliner.
Plug the rearview camera connector into its rear camera port of the device once
the camera is securely mounted. Adjust the position of the lens to make sure
that it remains horizontal with the ground. Start the engine to check the video
operation of your device.
(This picture is for reference only. Listed articles should referred to your actual
device.)
6. Rearview Camera Wire Routing Illustration (as shown below)
Installation Instructions
Optimum Installation
Location
Power Cable
Wiring Location

10
For the rearview camera, there are two wiring options as shown in the above
figure. The first part of both options is characterized with concealed wire
routing against the edges of the door(s).
A: The rearview camera can be mounted directly above the rear window inside
the car.
B: The rearview camera can be mounted directly above the car’s license plate.
We recommend that you install all components beforehand according to the
above drawing and test the system by using the on-board charger power supply.
Make sure the device is good condition prior to installation. Please, contact our
service center in case of any questions.
Note: The device is configured with a streaming media rearview camera that
provides clear traffic view behind the car. To obtain clearer and more intuitive
images, it is recommended to mount the camera above the license plate (as
shown by option B).
7. Instructions for Reverse Trigger Wiring
The red wire of the car’s reverse gear wiring is connected to the positive end
of one of the car’s reverse light. Make sure that the car charger is energized
during use.
Connection to rearview camera
Re
d

11
III. Turn on the Dash Cam
Connect the dash cam to the car charger after installation. Starting the car
engine will start the device. The built-in battery will be charged at the same
time.
Note: Due to unstable voltages caused by starting the car engine, a voltage
fluctuation in some vehicles may be especially obvious. If a flashing screen or
some other unforeseeable operating problem occurs when you start the engine,
it is recommended to unplug the device from the charger before starting the
engine, and then reconnect it after the engine is running.

12
Basic Operation
Main Interface
System Setup
I. Open the Setup Menu
Press the Menu Button to open system menu setup. Select Settings. Press the
Up/Down Button to change the option and press the OK Button to confirm.
II. Video Mode - Setup
Select Record on the main menu. Press the OK Button to start/pause video
recording of the device or press the Record Button to pause/start video
recording.
Note: Please format the MicroSD card during the initial operation. Meanwhile,
perform selective setups to the primary options, such as setting the device’s
system time. Video Resolution: FHDP30+FHDP30, FHDP30+HDP30
1. Video Duration: 1, 2, or 3 minutes
2. WDR: ON/OFF
3. G-SENSOR: Off/High/Moderate/Low
After the device is started, it may sense shock/impact caused by a certain level
of force (the higher the sensitivity setting, the smaller the force required). This
function will lock the video at the time of detection and save it as a protected
video. Meanwhile an icon indicating that the device is locked will be shown
on top of the display.
4. Time-lapse Monitoring Duration: 12h, 24h, 48h
5. Exposure Compensation: +5/3, +4/3, +1.0, +2/3, +1/3, +0.0, -1/3, -2/3, -1.0,
-4/3, -5/3
6. DVR Audio: Off/On

13
7. Date Stamp: Off/On
III. System Menu Setup
1. Date/Time: Year, Month, Day, Hour, Minute, Second (RTC system time
setup). Press the OK Button to access [Date/Time] of system setup. Press the
Menu Button to shift to the next setting. Press the Up/Down Button to set the
parameters. Press the OK Button to save and exit.
Note: To obtain a valid date and time record to be used as evidence for a car
accident, please set the correct time and date before using the device.
2. Screen Backlight: Off, 1, 3, and 5 minutes. When Off is selected, the screen
remains on. Select 1/3/5 minutes. Without any operation, the screen backlight
turns off automatically after a predetermined length of time, but the device will
keep recording as normal.
3. Key Tone: Off/On
4. Language Setup: English, French, German, Spanish, Italian, Portuguese,
Simplified Chinese, Japanese, Traditional Chinese, and Russian.
5. Frequency：50HZ, 60HZ
6. IR Light Mode: Auto, On, Off
7. Formatting: Cancel/Confirm. Select Confirm to format the storage card.
Note: Formatting removes all files (including protected files) from the storage
card. Files cannot be restored after formatting. Please back up important files
before formatting.
8. Default Setup: Cancel/Confirm. When Confirm is selected, customer
settings will be changed and the system will be restored to its default values.
9. Version: Determine the current software version.
Taking Pictures
I. Taking a Picture
Depress the Menu Button to switch to the picture taking mode. Press the OK
Button once to take a picture.
II. Picture Mode Setup
When the picture taking function is in standby, press the Menu Button to access
the picture taking setup menu. Use the Record/UP button and Record/DOWN

14
button to select parameters. Press the OK Button to save your setup selections
and return to the previous menu. Press the Menu Button to exit setup when
complete.
1. Picture Taking Method: Single Shot, 2s Timer, 5s Timer, 10s Timer
2. Resolution: 12M 4032 x 3024, 10M 3648 x 2736, 8M 3264 x 2448, 5M 2592
x 1944, 3M 2048 x 1536, VGA 640 x 480
3. Continuous Capture: Off/On When continuous capture is enabled, 3 pictures
are taken consecutively.
4. Picture Quality: Optimum, Standard
5. Sharpness: Strong, Standard, Moderate
6. White Balance: Auto, Daylight, Cloudy, Tungsten, Fluorescent
7. Color: Color, Black & White, Sepia
8. ISO: Auto, 100, 200, 400
9. Exposure Compensation: +5/3, +4/3, +1.0, +2/3, +1/3, +0.0, -1/3, -2/3, -1.0,
-4/3, -5/3
10.Anti-Shock: Off, On
11.Quick Preview: Off, 2s, 5s After taking a picture, time setting will be
discontinued on the image, so as to allow you to determine if the picture is
desirable.
12.Date Stamp: Off, Date, Date/Time.
Playback and Delete a File
I. Browsing Files
Select the playback folder on the main menu or depress the Menu Button to
switch to playback mode. Press the Up/Down Button to browse your video
files and pictures.
II. Playback
When browsing files, video files are presented with an icon on screen.
Press the OK Button to play the video and quickly press it again to stop
playback.
II. Deletion and Protection

15
When browsing files in playback mode, quickly press the Menu Button to
enable the pop-up menu options. The following operations are available:
Delete: Delete a single file or all files.
Note: Locked files cannot be simply deleted. Unlock the file before you need
to delete it.
Protection
Lock: Lock and save unprotected files. A locked file cannot be overwritten
Unlock: Remove the protective feature of a protected file. Simply delete the
file once it is unlocked.
IV. Slide View
Recorded files are played automatically at a set time interval.
V. Back to homepage: Return directly to the homepage.
Playback on Computer
When using the USB cable to connect with a computer, the [UP] and [DOWN]
buttons can be used to select options in the pop-up menu. Use the [OK] button
to confirm your selection.
1. Mass Storage: Can be used to play a file in the device or copy any file to
your computer.
2. Video: Video can be used as a power source for video recording.
Parking Monitor
Note: A Smart Hardwire Kit (sold separately) is required to activate the
parking monitor feature. A USB cable cannot provide this function.
I. Power Voltage Protection
1. From the Power Voltage menu setup on the main menu, select a voltage（
11.8-12.5V）for switching off the device when the car engine is turned off for
parking. For example, 11.8V means that the device automatically switches off
when the detected vehicle battery voltage drops to less than 11.8V.

16
II. Monitoring Mode
In the monitoring mode menu setup on the main page, when a smart hardwire
connection is detected, turning on the parking monitor will enable modes:
Super Night Scene and Time-Lapse video monitoring.
1. Time-Lapse Video Monitoring: A video recorded in parking mode has only
an approximate size of about one sixth to one tenth that of a normal video. This
enables the user to save as much video as possible.
2. Super Night Vision: Time lapse photography in parking monitoring mode is
recorded at sixty frames per minute. This function allows for clearer video
during low-light or night conditions.
3. Parking Monitor: In parking mode, when a shock/impact is detected,
recording will start and last for 1 minute.
Note: Monitoring duration options include 12h, 24h, 48h
Mobile Connection
When the device is paired to a mobile phone via Wi-Fi, it can be controlled
through the Mobile App.
Basic Operations:
I. Android System
1. Open Google Play and search for LuckyCam or scan the QR code below to
quickly download and install it.
Wi-Fi
Record
Playback
Parking
Power Voltage
Settings
Power Voltage
Wi-Fi
Record
Playback
Parking Monitor
Power Voltage
Settings
Parking Mode
OFF
Parking Monitor
Super Night Scene
Time-Lapse video monitoring

17
Google Store
II. Apple iOS system
1. Open The App Store and search for LuckyCam or scan the QR code below to
quickly download and install it.
App Store QR code
2. Open the app after installation. There will be a pop-up message asking if you
will allow LuckyCam to access the photos in your phone. Click OK or Yes as
shown in the picture:
III. Wi-Fi Connection
LuckyCam wants to access
your “Photos”
Use album permissions
No
Yes
Allow LuckyCam to access your location?
GPS and WiFi information are obtained
during use
Permitted when the app is used
Just once
No
Step 1

18
For an initial connection, it is necessary to access Wi-Fi setup. Find network
and input the password. Later connections require no password input. Simply
click the link of the Wi-Fi equipment to be switched when it becomes
switchable.
1. Select Wi-Fi ON/OFF on the main menu or press the OK Button to turn on the
Wi-Fi of the device. Press it again to turn the Wi-Fi off. As shown below:
2.Open the LuckyCam app and click Switch Device; then click Wi-Fi Setup as
shown:
3. Search for Wi-Fi on your device and find SSID: E89_***. Input the
password for your connection. The default password for the device is
12345678.
4. Click to complete your connection. When successful a connection is
established between the mobile phone and camera, the Wi-Fi icon on the
AP Mode
Switch Device
Step 1:
Please turn on the device’s Wi-Fi
Step 2:
Please go to the Wi-Fi setup of
your mobile phone and select
the SSID of the device. A
connection will be established
automatically when you return
to the app.
Shortcut Menu
Switch Device
Wi-Fi Setup
Files Folder
App Setup
Record
File folder
Settings
Settings

19
device’s screen will turn from white to green. To view the camera record
images, simply return to the app.
VI. App Overview:
1. Press the button to pause/start recording.
Note: To begin a new setup, use the function menu shown below, press this
button to pause the recording before beginning a new setup.
2. Press the Setup button on the bottom and set up the parameters of the system
menu as shown in the picture:
Switch image
Audio
Current resolution
Duration
Front view
Internal view
Rear view
Start/pause recording
Photo mode
Video mode
Video file folder
Menu setup
Video
File
Setup

20
3. Click the File button on the bottom and to check the video files and pictures.
You may simply click the file to play it online or download it to your mobile
phone as shown in the picture:
4. Click the Record button on the bottom to enter video recording mode and
watch your video in real time while recording as shown in the picture:
Shortcut Menu
Shortcut Menu
Local File Folders
App Setup
Video Setup
Video Setting
Dual Recording
G-sensor
Low
Loop Recording
1 minute
Video Resolution
Enabled
MIC
Enabled
MIC
Enabled
Date label
Enabled
General
Wi-Fi ID
Date Label
Enabled
General
Wi-Fi ID
Wi-Fi Password
Exposure Compensation
System Setup
Software Version
Available Space
Format camera
Camera Language
Simplified Chinese
Date & Time Setup
Automatic Synchronization
Restore Default Values
設定
Camera File Folders
