Senix CSP4QL-L User manual

8458-A016001001-001
4-Cycle 1.62 cu in. (26.5 cc)
Engine Gasoline Powered Pole Saw
Operator’s manual
Model: CSP4QL-L
For customer support, please call 1-800-261-3981 or send email to:
[email protected]
SAVE THIS MANUAL FOR FUTURE REFERENCE.

2WWW.SENIXTOOLS.COM
• SAFETY & INTERNATIONAL SYMBOLS •
This operator’s manual describes safety and international symbols and pictographs that may appear on this product.
Read the operator’s manual for complete safety, assembly, operating and maintenance and repair information.
To reduce the risk of injury, user must read
instruction manual.
Contact of the guide bar tip with any object
should be avoided.
Tip contact can cause the guide bar to to
move suddenly upward and backward, which
can cause serious injury.
Always use two hands when voperating the
pole saw.
DO NOT USE E85 FUEL IN THIS UNIT
CAUTION: It has been proven that fuel
containing greater than 10% ethanol will
likely damage this engine and void the
warranty.
Always use clean, fresh unleaded fuel. Refer
to operator’s manual for the proper type of
oil.
Hot surface. Do not touch a hot mufer or
cylinder. You may get burned. These parts
get extremely hot from operation. They
remain hot for a short time after the unit is
turned off.
Bystander sound pressure level: 72dB(A)
Keep all bystanders at least 50 ft. away.
DANGER!
Risk of electrocution!
The chain must be continously coated with
oil to function correctly. Verify oil level before
each use.
Wear hand protection.
Wear non-slip safety footwear.
Failure to keep your hands away from the
blade will result in serious personal injury
Avoid power lines, use in dry conditions
Do not expose to rain.
Indicates danger, warning or caution.
Precautions that involve your safety
Thrown objects and loud noise can cause
severe eye injury and hearing loss. Wear
eye protection meeting current ANSI Z87.1
standards and ear protection when operating
this unit. Wear head protection when
operating this unit. Fallen objects can cause
severe head injury. Use a full face shield
when needed.
Thrown objects can ricochet and result in
personal injury or property damage.
72dB(A)
MEASURED AT 50FT. (15M)
PER ANSI B175.3

3WWW.SENIXTOOLS.COM
TABLE OF CONTENTS
SAFETY..........................................................................................3
KNOW YOUR UNIT........................................................................7
SPECIFICATIONS*.........................................................................7
ASSEMBLY......................................................................................8
OPERATION..................................................................................11
MAINTENANCE............................................................................14
TROUBLESHOOTING..................................................................17
PARTS...........................................................................................18
PARTS LIST..................................................................................19
WARRANTY...................................................................................21
1. Proper safety precautions must be observed. Like all
power equipment this unit must be handled carefully.
DO NOT EXPOSE YOURSELF OR OTHERS TO
DANGER. Follow these general rules. Do not permit
others to use this unit unless they are thoroughly
responsible and have read, and understood the string
pole saw manual and are trained in its operation.
2. Always wear safety goggles for eye protection. Dress
properly. Do not wear loose clothing or jewelry that
could become caught in moving parts of the unit.
Safe, sturdy, nonskid footwear should always be
worn. Always wear heavy, long pants, boots, gloves,
and a long-sleeve shirt. Do not wear loose clothing,
jewelry, short pants, sandals, or go barefoot. Secure
hair so it is above shoulder level. Long hair should
be tied back. It is recommended that legs and feet be
covered to protect from ying debris during operation.
3. Inspect the entire unit for loose parts (nuts, bolts,
screws, etc.) and any damage before start and
operation. Repair or replace as necessary before
using the machine.
4. Modifying your pole saw or installing non-Senix
attachments can make your pole saw unsafe. Non-
Senix attachments are usually designed for universal
applications. Although aftermarket attachments
may t on your pole saw, they may not meet factory
specications and could make your pole saw unsafe.
Do not remove the cutting head shield or modify your
pole saw in any way that would alter its design or
operation. This could make your pole saw unsafe.
Serious injury to the operator or bystanders could
result as well as damage to the machine.
5. Keep the handles free from oil and fuel.
6. Do not operate the unit in insufcient lighting
conditions.
7. Do not operate the unit when you are tired, when
your concentration is impaired and/or under the
inuence of drugs, medication, or alcohol.
8. Always use proper handles when trimming.
9. Do not smoke while lling tank.
10. Do not ll fuel in an enclosed room or near open
ames. Ensure adequte ventilation.
11. Always store fuel in a properly marked container
that is approved by local codes and ordinances for
such usage.
12. Never remove the fuel tank cap while the engine is
running.
SAFETY
Signals an EXTREME hazard. Failure to obey a safety
DANGER symbol WILL result in serious injury or death
to yourself or to others.
Crude oil, gasoline, diesel fuel and other petroleum
products can expose you to chemicals including toluene
and benzene, which are known to the State of California
to cause cancer and birth defects or other reproductive
harm. These exposures can occur in and around oil
elds, reneries, chemical plants, transport and storage
operations such as pipelines, marine terminals, tank
trucks and other facilities and equipment. For more
information go to:
www.P65Warnings.ca.gov/petroleum.
Signals a SERIOUS hazard. Failure to obey a safety
WARNING symbol CAN result in serious injury to
yourself or to others.
Signals a MODERATE hazard. Failure to obey a safety
CAUTION symbol MAY result in property damage or
injury to yourself or to others.
CALIFORNIA PROPOSITION 65
This product contains a chemical known to the state
of California to cause cancer, birth defects or other
reproductive harm.
Read the operator’s manual and follow all warnings
and safety instructions. Failure to do so can result
in serious injury to the operator and/or bystanders.
SAFETY WARNINGS
DANGER:
WARNING:
WARNING:
CAUTION:
WARNING:
NOTE: Advises you of information or instructions vital to
the operation or maintenance of the equipment.

4WWW.SENIXTOOLS.COM
RESIDUAL RISKS
• Damage to lungs if an effective dust mask is not
worn.
• Damage to hearing if effective hearing protection is
not worn.
• Health defects resulting from vibration emission if
the unit is being used over long periods of time or not
adequately managed and properly maintained.
Even when the unit is used as prescribed it is not
possible to eliminate all residual risk factors. The
following hazards may arise in connection with the unit’s
construction and design:
WARNING:
13. Never start or run the product inside a closed
room or building. Fumes from the exhaust contain
dangerous carbon monoxide.
14. Never attempt to make engine adjustments
while the unit is running. Always make engine
adjustments with the unit resting on a at, clear
surface.
15. Do not use the unit if it is damaged or poorly
adjusted. Never remove the unit’s guard. Serious
injury to the operator or bystanders could result as
well as damage to the machine.
16. Inspect the area to be cut and remove all debris that
could become entangled in the nylon cutting head.
Also remove any objects that the unit may throw
during cutting.
17. Keep children away. Onlookers should be kept
at a safe distance from the work area, at least 15
METERS (50 FEET) away.
18. Never leave the unit unattended while the engine is
running.
19. Uses other than those intended by the manufacturer
can result in injury to the operator or damage to the
pole saw and other property.
20. Do not overreach. Keep proper footing and balance
at all times. Do not use the unit while standing on a
ladder or on any other unstable footing location.
21. FOLLOW INSTRUCTIONS for assembling and
operation.
22. Do not store the unit in a closed area where fuel
vapors can reach an open ame from hot water
heaters, furnaces, etc. Store in a locked, well
ventilated area only.
23. Ensure safe and proper performance of your unit.
Please only use original accessories. The use of
any other accessories or attachments may cause a
potential hazard or injury to the user, damage to the
unit, and void the warranty.
24. If the unit will not be used for a long time, clean
the unit completely, especially the fuel/oil tank, its
surroundings, and the air lter.
25. When refueling, stop the engine and conrm that
it is cooled down. Never refuel when the engine
is running or hot. When gasoline spills, be sure to
wipe it up completely and dispose of those materials
before starting the engine.
26. Stay clear of other workers or bystanders by at least
15 meters/50 feet.attention and conrm that the
operator stops the engine. Be careful not to startle
or distract the operator which can cause an unsafe
situation.
28. The engine should be turned off when the unit is
moved between work areas.
29. Pay attention to loosening and overheating
parts. If there is any abnormality of the unit, stop
operation immediately and check the unit carefully.
If necessary, have the unit serviced by customer
support. Never continue to operate a unit which
may be malfunctioning.
30. In start-up or during operation of the engine, never
touch hot parts such as the mufer, the high voltage
wire, or the spark plug.
31. After the engine has stopped, the mufer is still hot.
Never place the unit in any places where there are
ammable materials (dry grass, etc.), combustible
gasses, or combustible liquids.
32. Pay special attention to operation in the rain or just
after the rain as the ground may be slippery.
33. If you slip or fall to the ground, release the throttle
lever immediately.
34. Be careful not to drop the unit or hit it against
obstacles.
35. Before proceeding to adjust or repair the unit, be
sure to stop the engine and detach the spark plug.
36. When the machine is placed in storage for a
long time, drain fuel/oil from the fuel/oil tank and
carburetor, clean the parts, and move the machine
to a safe place.
37. Make periodic inspections to ensure safe and
efcient operation. For a thorough inspection of
your unit, contact customer support.
38. Keep the unit away from re or sparks.
39. Keep your body warm, especially the head, neck,
feet, ankles, hands, and wrists.
40. Maintain good blood circulation by performing
vigorous arm exercises during frequent work breaks
and also by not smoking.
41. Limit the hours of operation.
42. If you experience discomfort, redness and swelling
of the ngers followed by whitening and loss of
feeling, consult your physician before further
exposing yourself to cold and vibration.
43. Always wear ear protection. Loud noises for long
periods can cause hearing loss, even permanent
deafness.
44. Wear no-slip heavy duty work gloves to improve
your grip on the handle. Gloves also reduce the
transmission of machine vibration to your hands.
45. Do not lay the machine on the side; otherwise the
fuel could spill out.
46. Fuel evaporation during refueling and exhaust
gases are harmful to the operator and people
around the unit.
47. Make sure that the fuel evaporation and exhaust
gases will not drift to the face of operator and keep
other people away from your working area.
48. Do not allow children or untrained individuals to use
this unit.

5WWW.SENIXTOOLS.COM
SPECIFIC SAFETY RULES FOR POLE
PRUNERS
ADDITIONAL SAFETY WARNINGS FOR
OPERATION
1. Wear head and eye protection and personal
protective equipment (PPE), including correct
clothing.
2. Keep bystanders, especially children at a safe
distance during operation of the saw chain pole
pruner.
3. Keep all parts of the body away from the saw chain.
Do not remove cut material or hold material to be
cut when blades are moving. Make sure the switch
is off when clearing jammed material. The saw chain
continues to move after the switch is turned off. A
moment of inattention while operating the extended-
reach pruner may result in serious personal injury.
4. Carry the extended-reach pruner by the handle with
the saw chain stopped. When transporting or storing
the extended-reach pruner, always t the saw chain
• Always disconnect the spark plug wire before
assembling, adjusting or cleaning, and before leaving
the machine unattended for any period.
• Always use the harness to carry the tool weight on
the shoulder. If you use the harness across your body,
learn how to use the quick release on the harness and
keep it in front of your body.
• It is recommended that the unexperienced user
should have practical instruction in the use of the saw
and the protective equipment from an experienced
operator.
• This tool is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a to ensure that
they do not play with the appliance.
• Children and juveniles, with the exception of
apprentices older than 16 years and under
supervision, may not operate the product. The same
applies for persons who do not or do not sufciently
know how to handle the product.
• The operating instructions should always be at hand.
Persons unt or tired must not operate the tool.
• Wait until the chain has come to a standstill
completely before placing it down.
• Any servicing should be performed by an authorized
service representative.
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
This unit produces an electromagnetic eld during
operation. This eld may, under some circumstances,
interfere with active or passive medical implants. To
reduce the risk of serious or fatal injury, we recommend
persons with medical implants to consult their physician
and the medical implant manufacturer before operating
this unit.
Inspect unit before each use.
Replace damaged parts. Check for fuel leaks. Make
sure all fasteners are in place and secure. Replace
parts that are cracked, chipped, or damaged in any way.
Make sure the cutting attachment is properly installed
and securely fastened.
Do not operate the unit inside a closed environment,
such as a room or building; breathing carbon monoxide
from exhaust fumes can kill.
Pour fuel outdoors where there are no sparks and
ames. Slowly remove the fuel cap only after stopping
the engine. Do not smoke while fueling or mixing fuel.
Wipe spilled fuel from the unit. Move at least 3 m (10 ft)
away from the fueling source and site before
starting engine.
Do not operate near electrical power lines. The unit has
not been designed to provide protection from electric
shock in the event of contact with overhead electric
lines. Consult local regulations for safe distances from
overhead electric power lines and ensure that the
operating position is safe and secure before operating
the saw chain pole pruner.
device cover. Proper handling of the extended-reach
pruner will reduce possible personal injury from the
saw chain.
5. Hold the extended-reach pruner by insulated gripping
surfaces only, because the saw chain may contact
hidden wiring. A saw chain contacting a ″live″wire
may make exposed metal parts of the extended-
reach pruner ″live″ and could give the operator an
electric shock.
6. Keep cable away from cutting area. During operation
the cable may be hidden in shrubs and can be
accidentally cut by the saw chain.
7. Do not use the extended-reach pruner in bad
weather conditions, especially when there is a risk of
lightning. This decreases the risk of being struck by
lightning.
8. To reduce the risk of electrocution, never use near
any electrical power lines.
9. Contact with or use near power lines may cause
serious injury or electric shock resulting in death.
10. Always use two hands when operating the
extended-reach pruner. Hold the extended-reach
pruner with both hands to avoid loss of control.
11. Always use head protection when operating the
extended-reach pruner overhead. Falling debris can
result in serious personal injury.

6WWW.SENIXTOOLS.COM
SAVE THESE INSTRUCTIONS
WARNING:
WARNING:
The danger of a kickback is greatest when attempting
to cut near or with the guide bar tip. Always apply the
saw as atly as possible in order avoid a loss of control
during operation.
When removing branches, hold the pole saw at an
angle ranging from 0 to 60° in order to avoid being
struck by a falling branch. The saw should never be
operated directly above head.
Pinching the saw chain along the top of the guide bar
can push the bar rapidly towards the operator. Either of
these reactions may cause a loss in control of the saw,
increasing the chances of serious personal injury. Do
not rely on the safety devices built into the saw.
Kickback is the result of tool misuse and/or incorrect
operating procedures. These conditions can be
minimized with the following steps:
Kickback can occur when the tip of the guide bar
touches an object or when the wood closes in and
pinches the saw chain inside of the cut. Tip contact can
kick the guide bar up and back towards the operator.
REDUCING KICKBACK
SAWING TECHNIQUES
1. Maintain a rm grip, with thumbs and ngers
encircling the pole saw handles. Both hands should
be on the saw with your body and arms in a position
to resist kickback forces.
2. Do not overreach and keep the work area free from
obstructions.
3. Only use replacement bars and chains specied by
Senix. Replace dull blades as necessary.
4. Do not let the tip of the guide bar contact any
surfaces.
5. Keep proper tension on the blade at all times. Check
the tension at regular intervals.
6. Cuts should only take place while the chain is moving
at full speed. Do not turn the saw ON or OFF in
the middle of a cut. Use extreme caution when re-
entering a previous cut.
7. Cut one branch at a time. Do not attempt plunge or
bore cuts. Watch for shifting logs or other external
forces that could close a cut and pinch the chain.
8. Make a precut on the opposite side of the log to
avoid the blade from being pinched during operation
as another safeguard against kickback.
• Saw off the lower branches on the tree rst. By doing
so, it is easier for the cut branches to fall to the
ground.
• At the end of the cut, the weight of the saw suddenly
increases for the user since it is no longer being
supported by a branch. There is a risk of losing
control of the saw, so make sure to stay alert during
the entire sawing operation.
• Only pull the saw out of a cut while the saw is running.
By doing so, you prevent the chain from jamming in
the wood.
• Do not saw with the tip of the guide bar. Do not saw
into the branch formations (where the tree branches
outwards). This will impede the tree’s ability to heal.
• For sawing off smaller branches, place the stop face
of the saw on the branch. This prevents unwanted
movements of the saw at the beginning of the cut.
While applying light pressure, guide the saw through
the branch from top to bottom.
• For sawing off larger branches, rst make a relief
cut. Saw through 1/3 of the branch diameter from the
bottom to top using the top side of the guide bar. Then
saw from top to bottom for the other 2/3 using the
bottom side of the guide bar.
• Saw off longer branches in sections in order to
maintain control over the location of impact.
• When working on an incline, always stand above or
to the side of the branch being sawed. Hold the tool
as close as possible to your body. By doing so, you
maximize your balance.

7WWW.SENIXTOOLS.COM
As a pole saw:
• Cutting small limbs
• General tree pruning
Engine type......................................................................................................................................Air-Cooled, 4-Cycle
Displacement...................................................................................................................................1.62 cu in. (26.5 cc)
Spark plug gap...........................................................................................................0.025 in. - 0.31 in. (0.6 - 0.8 mm)
Lubrication..................................................................................................................................................SAE 10W-30
Crankcase lubrication capacity..............................................................................................................2.01 oz. (60 ml)
Chain lubrication oil tank capacity........................................................................................................4.02 oz. (120 ml)
Fuel tank capacity................................................................................................................................9.46 oz. (280 ml)
Chain speed............................................................................................................................................59 ft/s (18 m/s)
Single shoulder harness...........................................................................................................................................Yes
Handle type......................................................................................................................................................D handle
Shaft type...........................................................................................................................................................Flexible
Chain bar.....................................................................................................................................8 in. Oregon (537042)
Saw chain.................................................................................................................................8 in. Oregon (91P033X)
Total length (with extension tube, chain, and bar) ..........................................................................105.5 in. (2680 mm)
Extension tube length.........................................................................................................................30.7 in. (780 mm)
Tube material..................................................................................................................................................Aluminum
Dimensions.........................................................................................................105.5x13x8.7 in. (2680x330x220 mm)
Weight (fully assembled, without fuel or oil).......................................................................................12.57 lbs. (5.7 kg)
* All specications are based on the latest product information available at the time of printing. We reserve the right
to make changes at any time without notice.
APPLICATIONS
KNOW YOUR UNIT
SPECIFICATIONS*
Coupler
Throttle
Lockout
On/Off
Switch
Chain
Protective
Cover
Harness Hook
Choke
Button
Harness
Throttle
Guide
Bar Tip
Extension
Tube
Lower
Drive Shaft
Coupler
Tools
Saw Chain
Guide
Bar
Guide Bar
Nut
Chain Oil
Reservoir
Air Filter Spark Plug
Muffler
Primer Bulb
Fuel Cap
Starter Grip Oil Tank
Cap

8WWW.SENIXTOOLS.COM
UNPACKING
INSTALL THE HANDLE
POWER HEAD SHAFT/LOWER SHAFT
ASSEMBLY
ASSEMBLY
INCLUDED PARTS
This product requires assembly. Carefully remove the
product and any accessories from the box. Make sure
that all items listed in the packing list are included.
Inspect the product carefully to make sure no breakage
or damage occurred during shipping.
Do not discard the packing material until you have
carefully inspected and satisfactorily operated the
product. If any parts are damaged or missing, please
call 1-800-261-3981 for assistance.
Do not use this product if any parts on the packing
list are already assembled to your product when you
unpack it. Parts on this list are not assembled to the
product by the manufacturer and require customer
installation. Use of a product that may have been
improperly assembled could result in serious personal
injury.
To prevent an accidental start that could cause serious
personal injury, always disconnect the engine spark
plug wire from the spark plug when assembling parts.
Never install, remove, or adjust any attachments while
power head is running. Failure to stop the engine can
cause serious personal injury.
Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a
second is sufcient to inict serious injury.
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
If any part of the pole saw is missing or damaged, do
not operate the pole saw until the damaged part is
repaired or replaced.
Disconnect the spark plug wire before performing
maintenance or assembly procedures.
1. Screw the handle and holder using the hex wrench
provided. The screws and holder are pre-attached to
the front handle.
2. Tighten the 4 screws until the handle is secure.
1. Set the engine assembly on a level surface. Loosen
the clamping knob.
2. Pull locator pin out and turn counter-clockwise 1/4
Screw
DO NOT discard box or packing material until all parts
are examined.
NOTE: Chain and Bar Oil is not included. You must ll
the Chain Saw with SAE30 oil BEFORE use.
NOTE: Remove the Chain/Bar/Blade Protective Cover
before use.
Quantity Item
1Operator’s manual
1Handle and mounting hardware
1Chain protective cover
1 Spark plug wrench
1 Bar nut wrench
1 Hex wrench
1 60 ml bottle
1Harness
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
Locator pin
Clamping
Knob
Shaft hole
Coupler
Extension tube

9WWW.SENIXTOOLS.COM
INSTALL THE CHAIN BAR AND CHAIN
Disconnect the spark plug wire before performing
maintenance or assembly procedures.
Cutting edges on chain are sharp.
Use protective gloves when handling chain.
ALWAYS maintain proper chain tension. A loose chain
will increase the risk of kickback. A loose chain may
jump out of chain bar groove. This may injure operator
and damage chain. A loose chain will cause chain,
chain bar, and sprocket to wear rapidly. The chain
life of the saw chain mainly depends upon sufcient
lubrication and correct tensioning. Avoid tensioning the
chain if it is hot, as this will cause the chain to become
over tensioned when it cools down.
1. Place the saw body on a rm and level surface.
2. Using the supplied wrench, turn the bar adjustment
locking nut counter-clockwise to loosen it. Remove
the locking nut and cover.
5. Turn the chain tensioning screw clockwise to
preliminarily tighten the chain bar enough that it
stays in place. While holding the bar still, place the
cover back onto the saw. Make sure the tab properly
lines up with the slot on the body of the saw. Install
the locking nut. Using the supplied wrench, turn
the locking nut clockwise to tighten it. DO NOT
overtighten.
6. Check the chain tension by pulling the saw chain
away from the chain bar. A properly tensioned chain
should have roughly 1/8 inch (3 mm) of distance
between itself and the bar guide.
3. Wearing protective gloves, wrap the saw chain
around the chain bar, making sure that the teeth are
aimed in the direction of rotation. The chain should
be properly set in the slot running along the entire
outside edge of the chain bar.
4. Place the saw chain around the sprocket while lining
up the slot in the chain bar with the internal bolt at the
base of the saw and the chain tensioning pin in the
chain bar’s pin hole. The chain tensioning pin may
need adjustment to properly align with the hole in the
chain bar. Use a at-blade screwdriver to turn the
chain tensioning screw to adjust the location of the
pin until it ts in the chain bar.
WARNING:
WARNING:
WARNING:
Cover
Bar adjustment
locking nut
Cover
Bar adjustment
locking nut
Tab
turn to lock-out position. Remove cap and cardboard
spacer, if necessary.
3. Align the hole in the extension boom with the locator
pin on the coupler.
4. Install the extension tube into the coupler. Pull the
locator pin out and turn 1/4 turn clockwise to release.
Push the drive shaft until the locator pin locks into
place.
5. Tighten the clamping knob.
6. Following steps 1 to 5, install the lower drive shaft
assembly.
Sprocket
Chain Tensioning Pin
Internal Bolt
Chain
Tensioning
Screw
1/8” (3 mm)

10 WWW.SENIXTOOLS.COM
SAW CHAIN LUBRICATION
FILLING THE OIL TANK
ADDING/CHECKING ENGINE OIL
ADD ENGINE OIL: INITIAL USE
CHECK ENGINE OIL: BEFORE EACH USE
The pole saw features automatic chain lubrication.
Never operate the pole saw without saw chain oil. The
use of the pole saw without enough saw chain oil will
damage the unit.
Only use SAE300 saw chain oil. Other oils will run the
risk of damaging the unit and voiding the warranty.
Take note of temperature conditions. Using the saw
at various temperatures requires the use of differing
oils. To ensure a sufcient layer of lubricant at lower
temperatures, use liquid oil (low viscosity).
7. If adjustments are needed, loosen the bar adjustment
locking nut one full turn.
8. To adjust the saw chain tension, turn the chain
tensioning screw. Turning the screw clockwise
increases the tension while turning it counter-
clockwise decreases tension. A properly tensioned
chain should have no sag and should only be able to
be pulled 1/8 inch (3 mm) away from the chain bar of
the saw.
9. Once the chain is properly tensioned, tighten the bar
adjustment locking nut. DO NOT over-tension the
chain: this will lead to excessive wear and reduces
the life of both the bar and chain.
1. Place the saw on a level surface. Clean the area
around the oil tank cap and then open it.
1. Unscrew the oil cap from the engine and remove.
2. Pour 60 ml of oil into the oil ll hole. Replace and
tighten the oil cap.
1. Separate the pole saw from the engine assembly.
2. Set engine assembly on a at level surface with shaft
parallel to surface.
3. Unscrew the oil cap and remove.
4. Lubricant level should fall within the top of the oil ll
hole (the top of screw thread).
5. If level is low, add engine lubricant until the uid level
rises to the top of oil ll hole (the top of screw thread).
NOTE: Do not overll.
6. Replace and tighten the oil cap.
2. Fill the oil tank with 4.02 oz. (120 ml) of saw chain
and bar oil.
3. Close the oil tank cap.
The saw chain must be tensioned properly in order to
ensure safe operation.
Make sure that no dirt gets into the oil tank to prevent
clogging in the oil nozzle.
Attempting to start the engine before it has been
properly lled with lubricant will result in equipment
failure not covered by the warranty.
Do not overll. Overlling the crankcase may cause
excessive smoke, oil loss, and engine damage.
Operation of this equipment could create sparks that
can start res around dry vegetation. A spark arrestor
may be required. The operator should contact local
re agencies for laws or regulations relating to re
prevention requirements.
Engine lubricant has a major inuence on engine
performance and service life. This unit is shipped
without engine lubricant.
Always use a 4-cycle engine lubricant that meets or
exceeds the requirements for API service classication
SJ. SAE 30, 10W30, or 10W40 are all acceptable
lubricants to use in this product. Non- detergent or
2-stroke engine lubricants will damage the engine and
should not be used. Check lubricant level before each
use.
CAUTION:
CAUTION:
CAUTION:
CAUTION:
WARNING:
MAX
Oil tank cap Oil tank

11WWW.SENIXTOOLS.COM
OPERATION
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
Gasoline is extremely ammable. Ignited vapors may
explode. Always stop the engine and allow it to cool
before lling the fuel tank. Do not smoke while lling the
tank. Keep sparks and open ames at a distance from
the area.
Remove the fuel cap slowly to avoid injury from fuel
spray. Never operate the unit without the fuel cap
securely in place.
Add fuel in a clean, well-ventilated outdoor area. Wipe
up any spilled fuel immediately. Avoid creating a source
of ignition for spilled fuel. Do not start the engine until
fuel vapors dissipate.
DO NOT USE E85 FUEL IN THIS UNIT. It has been
proven that fuel containing greater than 10% ethanol
will likely damage this engine and void the warranty.
Use a fuel additive, such as STA-BIL Fuel Stabilizer or
an equivalent, to inhibit corrosion and minimize gum
deposits. Add 0.8 oz. (23 ml) of fuel additive per gallon
of fuel, according to the instructions on the container.
NEVER add fuel additives directly to the unit’s fuel tank.
Gasoline and its vapors are highly ammable and
explosive. To prevent serious personal injury and
property damage, handle it with care. Keep away from
ignition sources and open ames, handle outdoors only.
Pour fuel outdoors where there are no sparks or ames.
Slowly remove the fuel cap after stopping the engine.
Do not smoke while fueling. Wipe spiled fuel from unit.
Move at least 3 m (10 ft) away from the fueling source
before starting engine.
Always wear heavy, long pants, boots, gloves, and a
long-sleeve shirt. Do not wear loose clothing, jewelry,
short pants, sandals, or go barefoot. Secure hair so it is
above shoulder level.
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
USING THE RIGHT FUEL
Denition of Blended Fuels
Using Blended Fuels
USING FUEL ADDITIVES
FUELING THE UNIT
The use of old fuel is the most common cause of
performance problems. Use only fresh, clean unleaded
gasoline.
This unit has a four-cycle engine. DO NOT mix oil with
gasoline.
Today’s fuels are often a blend of gasoline and
oxygenates such as ethanol, methanol or MTBE (ether).
Alcohol-blended fuel absorbs water. As little as 1%
water in the fuel can make fuel and oil separate, forming
acids when stored. ALWAYS use fresh fuel (less than
30 days old) with less than 10% ethanol. Dispose of old
fuel according to federal, state and local regulations.
If using a blended fuel:
Always use fresh unleaded gasoline.
Use the fuel additive STA-BIL®or an equivalent.
1. Remove the fuel tank cap by turning counterclockwise.
Rest the cap on a clean surface.
2. Carefully pour fuel into the tank until fuel reaches the
base of the tank spout. Avoid spillage.
3. Immediately replace fuel cap and hand tighten by
turning it clockwise. Wipe up any spilled fuel.
NOTE: Visually inspect to see if fuel level is low. If fuel is
low, rell with unleaded fuel carefully without overlling
and tighten the fuel tank cap immediately.
Engine housing can become hot during pole saw
operation. Do not rest or place your arm, hand, or any
body part against the engine housing.
Extended contact with the engine housing can result in
burns or other injuries.
WARNING:
Base of
Tank Spout
• This unit has a 4-cycle engine. Do not mix oil with
gasoline.
• The use of old fuel is the most common cause
of performance problems. Use only fresh, clean
unleaded gasoline (less than 30 days old). Dispose
of old fuel according to federal, state and local
regulations.
• Drain the tank and run the engine dry before storing
the unit.
• Do not use E15 or E85 fuel (or fuel containing greater
than 10% ethanol) in this product. It will damage the
unit and void the warranty.

12 WWW.SENIXTOOLS.COM
Always position the unit on the operator’s right side. The
use of the unit on the operator’s left side will expose
the user to hot surfaces and can result in possible burn
injury. To avoid burns from hot surfaces, never operate
unit with the bottom of the engine above waist level.
Do not allow familiarity with this product to make you
careless. Remember that a careless fraction of a
second is sufcient to inict serious injury.
Always wear eye protection with side shields marked to
comply with ANSI Z87.1, along with hearing protection.
Failure to do so could result in objects being thrown into
your eyes and other possible serious injuries.
Do not use any attachments or accessories not
recommended by the manufacturer of this product. The
use of attachments or accessories not recommended
can result in serious personal injury.
Operation of this equipment could create sparks that
can start res around dry vegetation. A spark arrestor
may be required. The operator should contact local
re agencies for laws or regulations relating to re
prevention requirements.
Operate this unit only in a well-ventilated outdoor area.
Carbon monoxide exhaust fumes can be lethal in a
conned area.
Avoid accidentally starting the unit. To avoid serious
injury, the operator and the unit must be in a stable
position when pulling the starter rope.
Do not overwork yourself. Take regular breaks and
change working position to ensure you can concentrate
on the work and have full control over the product.
Maintain rm footing and balance during operation.
Inspect unit before each use. Replace damaged parts.
Check for fuel leaks. Make sure all fasteners are in
place and secure.
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
WARNING:
CAUTION:
CAUTION:
PREPARATION
Before each use, check the following items to ensure
safe working conditions.
POLE SAW: Before beginning work, inspect the pole
saw for damage to the housing, the saw chain and the
guide bar. Never use a damaged machine.
OIL TANK: Check the ll level of the oil tank. Also
check whether there is sufcient oil available while
working. Never operate the saw if there is no oil or the
oil level is not visible in order to prevent damage to
the pole saw. On average, an oil lling is sufcient for
the operating time of the fuel tank (depending on the
duration of pauses and the density of the workpiece).
SAW CHAIN: Check the tension of the saw and the
condition of the blades. The sharper the saw chain is,
the easier and more manageable operations will be.
The same applies to chain tension.
Check the tension every 10 minutes of operation
to maximize safety. New saw chains in particular
are subject to changes due to the heat created by
operation.
PROTECTIVE CLOTHING: Make sure to wear the
appropriate close- tting protective clothing such as
hainsaw-protective pants, gloves and safety shoes.
Wear a safety helmet with integrated hearing protection
and a face guard to provide protection against falling
and recoiling branches.

13WWW.SENIXTOOLS.COM
• Stand in the operating position Stand up straight. Do
not bend over.
• Keep feet apart and rmly planted.
• Hold the shaft grip with the right hand. Keep the right
arm slightly bent.
• Hold the handle with the left hand. Keep the left arm
straight.
• Hold the unit at waist level.
• Position the cutting head a few inches above the
ground.
• Do not over-reach; Keep all parts of your body away
from the rotating cutting attachment and hot surfaces.
STARTING AND STOPPING
Restart a warm engine:
HOLDING THE UNIT
STOP THE ENGINE:
To start a cold engine:
1. Slowly press the primer bulb 5-10 times.
NOTE: After the 7th press, fuel should be visible in the
primer bulb. If it is not, continue to press the primer until
you see fuel in the bulb.
2. Push the choke button in to set the choke to FULL
CHOKE position.
NOTE: Do not squeeze the throttle trigger because the
choke will be pop out automatically.
3. Pull the starter grip /cord until resistance is detected.
Rapidly pull 3 to 5 times or until you hear engine turn
over or begin to start.
4. If engine does not start, release choke by squeezing
throttle trigger and choke button pops out.
a.Engine is now in the run position.
b.Rapidly pull starter grip/cord until engine starts.
5. Allow the engine to run for 10 seconds,then squeeze
throttle to provide fuel to engine and use for intended
task.
NOTE: The choke button is only used when starting
a cold engine. Never push the choke button in once
the engine has been turned over or run. Otherwise the
engine could be damaged.
NOTE: DO NOT push choke button in.
1. Make sure the primer bulb has fuel inside.
2. Rapidly pull starter/grip until engine starts.
3. Squeeze throttle to provide fuel to engine.
To stop the engine, depress the STOP switch to the
stop position “STOP”.
NOTE: This Stop switch will come back to the ON
position automatically.
IF ASSISTANCE IS REQUIRED FOR THIS PRODUCT:
Do not return this product to the retail store where it
was purchased. Please call our Customer Service
Department for any issues you may have. For Help
Call: 1-800-261-3981
Throttle Control
On/Off Switch
(I = On / STOP = Off)
Throttle
Lockout
Primer Bulb
Choke
Starting
Position
Starter Rope Grip
Throttle Control

14 WWW.SENIXTOOLS.COM
MAINTENANCE
To avoid serious personal injury, always stop the engine
and allow it to cool before cleaning or maintaining the
unit. Never perform cleaning or maintenance while
the unit is running. Disconnect the spark plug wire to
prevent the unit from starting accidentally.
Wear protective clothing and observe all safety
instructions to prevent serious personal injury.
Old engine oil is considered special waste and has
to be disposed according to your local environment
protection regulation. Do not pour the oil into a garbage
can, sewer, soil etc.
The air lter element should be cleaned to provide the
engine abundant clear air which aids in starting, power,
and life time of the engine.
Reinstall the air lter cover by closing the air lter cover
over the button on the housing, then push the cover
until it locks securely in the place.
NOTE: Make sure the lter is seated properly inside the
cover. Incorrect installation will allow dirt to enter the
engine, causing rapid engine wear.
The engine oil replacement is easier if engine is warm
(NOT HOT!).
Use a small brush to clean the outside of the unit. Do
not use strong detergents. Household cleaners that
contain aromatic oils such as pine and lemon, and
solvents such as kerosene, can damage plastic. Wipe
off any moisture with a soft cloth.
Correct and regular cleaning is not only important for
the safe use of this product, but also extends its life
span.
When servicing, use only identical replacement parts.
Use of any other parts could create a hazard or cause
product damage.
WARNING:
WARNING:
WARNING:
CLEANING
MAINTENANCE SCHEDULE
ADJUST IDLE SPEED
REPLACE ENGINE OIL
REMARKS
CLEAN AIR FILTER
1. Open the oil tank cap and drain the old oil to an
approved container.
2. Return the engine to an upright position and rell with
lubricant following the instructions in the ADDING/
CHECKING ENGINE OIL section in this manual.
3. Clean the oil dropped on the unit if necessary.
1. Remove the air lter cover. To remove, press the
green button on the top of the cover with thumb and
gently push up the cover with index nger.
2. Remove the air lter.
3. If only cleaning of the air lter is necessary, take the
air lter pad out and clean it with dry compressed air
until all dust is removed. Wear protective goggles and
mask to protect your health during this procedure.
• The maintenance interval is only a recommendation
for machines in ordinary operating condition.
• If there are any abnormal signs from the machine,
please do the proper inspection and maintenance
immediately.
• The tightening torque should follow the general screw
specication of different size, class and material.
• If anything is unclear to you, contact our service team
for help.
• All other repairs or maintenance which are not
mentioned here should only be done by our service
team or authorized personnel.
Item Hours of Operation
Check engine oil level
Every time
before use
Check for loose/lost fasteners
Check for damage
Verify function of control elements
Check fuel level
Check for fuel/oil leaks
Check cutting line
Check guide bar/saw chain
Engine oil replacement Every 20 hours
Clean air cleaner Every 20 hours. Every 10 hours in
dusty conditions
Check spark plug Every 20 hours
MAX
Idle Speed Screw
Primer Bulb

15WWW.SENIXTOOLS.COM
The cutting attachment should never turn at idle. Turn
the idle speed screw counterclockwise to reduce the
idle RPM and stop the cutting attachment, or contact
customer support for adjustment and discontinue use
until the repair is made. Serious personal injury could
result from the cutting attachment turning at idle.
To avoid serious personal injury, always stop the engine
and allow it to cool before cleaning or maintaining the
unit. Never perform cleaning or maintenance while
the unit is running. Disconnect the spark plug wire to
prevent the unit from starting accidentally.
Replace chain when cutters are too worn to sharpen
or when chain breaks. Refer to INSTALL THE CHAIN
BAR AND CHAIN. Only use replacement chain noted
in this manual. Always include new drive sprocket when
replacing chain. This will maintain proper driving of
chain.
Wear protective clothing and observe all safety
instructions to prevent serious personal injury.
The cutting head will move when adjusting the idle
speed. Wear all protective clothing and keep all
bystanders, children, and pets at least 50 ft. away. Make
adjustments with the unit supported by hand so that the
cutting head does not contact the ground or any object.
Keep all parts of your body away from the cutting head
and mufer. Failure to follow these instructions could
result in serious personal injury.
Do not remove the spark plug when the engine is hot.
Do not sand blast, scrape or clean spark plug
electrodes. Grit in the engine could damage the
cylinder.
WARNING:
WARNING:
WARNING:
WARNING:
CAUTION:
CAUTION:
MAINTAINING THE SPARK PLUG
REPLACING THE SAW CHAIN AND CHAIN
BAR
STORAGE
If the engine will not idle properly:
1. Start the engine.
2. Release the throttle control and let the engine idle.
• If the engine stops, increase the idle speed. Use a
small Phillips screwdriver to turn the idle speed screw
clockwise, 1/8 of a turn at a time, until the engine
idles smoothly.
• If the cutting head spins when the engine idles,
reduce the idle speed. Turn the idle speed screw
counterclockwise, 1/8 of a turn at a time, until the
cutting head stops moving
1. Stop the engine and allow it to cool. Grasp the spark
plug boot rmly and pull it from the spark plug.
2. Clean around the spark plug. Remove the spark plug
from the cylinder head with a 5/8-inch socket, turning
counterclockwise.
NOTE: A 5/8-inch spark plug wrench is supplied with
this unit.
3. Inspect the spark plug. If the spark plug is cracked,
fouled or dirty, replace it with replacement part
#AM5RC or an equivalent spark plug.
4. Use a feeler gauge to set the air gap at
• Never store a fueled unit where fumes may reach an
open ame or spark.
• Allow the engine to cool before storing.
• Lock up the unit to prevent unauthorized use or
damage.
• Store the unit in a dry, well-ventilated area.
• Store the unit out of the reach of children.
Short-term Storage (1-2 weeks)
Store the unit in a horizontal position. If not possible,
store the unit vertically with the engine at the top.
Long-term Storage
1. Remove the fuel cap, tip the unit and drain the fuel
into an approved container. Reinstall the fuel cap.
2. Start the engine and allow it to run until it stalls.
This ensures that all fuel has been drained from the
carburetor.
3. Allow the engine to cool. Remove the spark plug
and put 5 drops of any high quality motor oil into the
cylinder. Pull the starter rope slowly to distribute the
oil. Reinstall the spark plug.
4. Thoroughly clean the unit and inspect it for any loose
or damaged parts. Repair or replace damaged parts
and tighten loose screws, nuts or bolts.
5. Store the unit in a horizontal position. If horizontal
storage is not possible, store unit vertically with
engine at top.
Preparing the Unit for Use after Long-term Storage
1. Remove the spark plug. Tip the unit and drain all of
the oil from the cylinder into an approved container.
Reinstall the spark plug.
2. Change the oil. Refer to Changing the Oil.
(0.025 in. - 0.31 in.)
0.60 mm - 0.80 mm
0.6 mm - 0.8 mm (0.025 in. - 0.31 in.)
5. Install the spark plug in the cylinder head. Tighten the
spark plug with a 5/8-inch socket, turning it clockwise
until snug.
NOTE: If using a torque wrench, torque to 18 N•m (159
in.•lb.). Do not over tighten.
6. Reattach the spark plug boot.

16 WWW.SENIXTOOLS.COM
Install the guide bar cover when transporting to prevent
personal injury.
Transport the unit in a horizontal position. If not
possible, transport the unit vertically with the engine at
the top. Secure the pole saw to prevent damage during
transport.
CAUTION:
TRANSPORTATION
NOTE: Do not use fuel that has been stored for more
than 30 days. Dispose of old fuel and oil according to
federal, state and local regulations.

17WWW.SENIXTOOLS.COM
If further assistance is required, take the unit to a qualied service dealer.
TROUBLESHOOTING
PROBLEM SOLUTION
THE ENGINE WILL NOT START
The fuel tank is empty Fill the fuel tank with fresh fuel
The primer bulb was not pressed enough Press the primer bulb 10 times
The fuel is old (over 30 days) Drain the fuel tank and add fresh fuel
The spark plug is fouled Replace the spark plug
THE ENGINE WILL NOT IDLE
The air lter is dirty Clean or replace the air lter
The fuel is old (over 30 days) Drain the fuel tank and add fresh fuel
Idle speed screw needs adjustment Turn idle speed screw clockwise to increase idle speed
THE ENGINE EMITS TOO MUCH SMOKE
Too much oil in crankcase Drain engine oil and rell with correct amount of engine
lubricant
THE ENGINE WILL NOT ACCELERATE
The fuel is old (over 30 days) Drain the fuel tank and add fresh fuel
The cutting head is bound with grass Stop the engine and clean the cutting head
The air lter is dirty Clean or replace the air lter
THE ENGINE LACKS POWER OR STALLS
The fuel is old (over 30 days) Drain the fuel tank and add fresh fuel
The air lter is dirty Clean or replace the air lter
The spark plug is fouled Replace the spark plug
GUIDE BAR AND SAW CHAIN ARE RUNNING HOT, SMOKING OR STUCK
The saw chain tension is too tight Adjust the saw chain tension
The chain oil tank is empty Rell the chain oil tank
THE SAW CHAIN DOES NOT ROTATE
The saw chain tension is too tight Adjust the saw chain tension
The guide bar and saw chain are assembled
incorrectly Refer to INSTALL THE CHAIN BAR AND CHAIN
The guide bar and saw chain are damaged Inspect the guide bar and saw chain for damage.
Replace them if necessary
The drive assembly is damaged Take the unit to a qualied service dealer
THE SAW CHAIN ROTATES, BUT DOES NOT CUT
The saw chain is dull Replace the saw chain or have it sharpened by an
authorized service dealer
The saw chain is on backwards Check and correct the saw chain direction

18 WWW.SENIXTOOLS.COM
PARTS

19WWW.SENIXTOOLS.COM
PARTS LIST
No. Part # Description Qty.
1243-0197 Saw Chain 1
2 243-0393 Guide Bar 1
3 9331-T10701-0000130 "Chain Protective Cover" 1
4 199141000002 Pole saw head assembly 1
5 8SJJD05-25D Screw 1
6 199999001469 Lower Drive Shaft assembly 1
7 199999001468 Extension Tube assembly 1
8 199999001470 Rear tube assembly 1
9 8SJJD05-10D Screw 3
10 103001000301 26.5 cc engine 1
11 199004000574 The handle assembly 1
11-1 8SJEB40-14D Screw 5
11-2 202024002294 Right handle 1
11-3 8342-902101-0000000 Return spring 1
11-4 202999001676 Control circle 1
11-5 202004000882 Throttle trigger 1
11-6 202042000206 Control lever 1
11-7 202024002295 Left handle 1
11-8 207180200023 Switch 1
11-9 235-2001 Wire cover 0.2
11-10 199999001317 Stopping wire 1
11-11 199081000107 Cable assembly 1
12 199004000573 The handle assembly 1
12-1 299009000010 Handle sheath 1
12-2 8SJJB50-25D Screw 4
12-3 202024002293 Front handle 1
12-4 202031000615 Handle bracket 1
12-5 202029000219 Pressure plate 1
12-6 8SJJB50-20D Screw 2
16 8261-611601-0100000 Spanner 1
13 201024000010 Harness Hook 1
14 207179900029 Trigger 1
15 202999001666 Plastic bottle 1
17 8261-611601-0100000 Spanner 1
18 202023000077 Stopcock 2
19 208008000051 Harness 1

20 WWW.SENIXTOOLS.COM
WARRANTY
LIMITED THREE-YEAR WARRANTY
Additional Limitations
3-year limited warranty on all Senix 4QL series gasoline powered equipment. FOR THREE YEARS from the
original date of retail purchase this Senix product is warranted against defects in materials or workmanship on
power tools. Defective product will receive free repair.*
This warranty does not cover normal wear of parts and components such as cutting chain, line or blades nor does
this warranty cover product transportation cost for warranty or service.
Any implied warranty granted under state law, including warranties of merchantability or tness for a particular
purpose, are limited to three years from the date of purchase on power tools and chargers and seven years on
batteries. The manufacturer is not responsible for direct, indirect, incidental or consequential damages. Some
states and provinces do not allow limitations on how long an implied warranty lasts and/or do not allow the
exclusion or limitation of incidental damages, so the above limitations and exclusions may not apply to you. This
warranty gives you specic legal rights, and you may also have other rights which vary from state to state or
province to province.
The YAT USA declines any responsibility in regard to civil liability arising from abusive use or not in conformity with
proper use and maintenance of the machine as described in the operator’s manual.
YAT USA is not responsible for direct, indirect, incidental or consequential damages.
After the purchase, the manufacturer recommends proper maintenance of the machine and to read the operator’s
manual before using the machine.
*Original purchase receipt may be required for proof of purchase
For customer service contact us toll free at 1-800-261-3981 or Senixtools.com.
YAT USA, Inc. 9048 E Bahia Dr, suite 105, Scottsdale, AZ 85260
Warranty is subject to the following conditions:
• Warranty applies to the original purchaser at retail and is not transferrable*
• Warranty Registration at www.senixtools.com
• The tool has not been misused, abused, neglected, altered, modied or repaired by anyone other than an
authorized service center
• Only genuine Senix accessories have been used with or on this product
• The tool has been subjected to normal wear and tear
• The tool has not been used for trade or professional purposes
• The tool has not been used for rental purposes
• This warranty only covers defects arising under normal usage and does not cover any malfunction, failure or
defect resulting from misuse, abuse (including overloading the product, exposure to water or rain) accidents,
neglect or lack of proper installation and improper maintenance or storage.
To locate your nearest Senix service provider call toll free at 800-261-3981 or email us at [email protected].
