Instruction manual
RS 220
Digital wireless
system

RS 220 | 1
Contents
Contents
Important safety information ........................................................................... 2
The RS 220 digital RF headphone system ...................................................... 4
Delivery includes .................................................................................................. 5
Product overview ................................................................................................. 6
Overview of the headphones ...................................................................... 6
Overview of the transmitter ........................................................................ 7
Overview of the transmitter’s connections .............................................. 7
Overview of the indicators ........................................................................... 8
Putting the RS 220 into operation ................................................................... 9
Setting up the transmitter ........................................................................... 9
Connecting the transmitter to audio sources ........................................ 10
Connecting the transmitter to the mains ............................................... 14
Charging the rechargeable batteries inside the headphones ............. 14
Adjusting the headband of the headphones ......................................... 15
Using the RS 220 ............................................................................................... 16
Switching the transmitter on/off ............................................................. 16
Switching the headphones on/off ........................................................... 19
Selecting an audio source or toggling between audio sources .......... 21
Adjusting the volume on the headphones ............................................. 23
Adjusting the balance ................................................................................. 23
Associating a second pair of headphones to the transmitter ............ 24
Cleaning and maintaining the RS 220 ........................................................... 25
Changing the rechargeable batteries of the headphones ................... 25
Replacing the ear pads ............................................................................... 26
If a problem occurs ... ........................................................................................ 27
Specifications ...................................................................................................... 29
Manufacturer declarations ............................................................................... 30

Important safety information
2 | RS 220
Important safety information
왘Please read this instruction manual carefully and completely before
using the product.
왘Make this instruction manual easily accessible to all users at all times.
Always include this instruction manual when passing the product on to
third parties.
왘This instruction manual is also available on the Internet at
www.sennheiser.com.
Preventing health problems
왘Before using the product, set the volume to a low level. To protect your
hearing, avoid listening at high volume levels for long periods of time.
왘Do not use the product in situations which require special attention
(e.g. in traffic or when performing skilled jobs).
The product generates stronger permanent magnetic fields that could
cause interference with cardiac pacemakers and implanted defibrillators
(ICDs).
왘Always maintain a distance of at least 3.94” (10 cm) between the ear
piece housing and the cardiac pacemaker or implanted defibrillator.
Preventing damage to the product
왘Always keep the product dry and do not expose it to extreme temper-
atures (normal operating temperatures: 5°C/41°F to 40°C/104°F).
왘Use the product with care and store it in a clean, dust-free environ-
ment. Varnish or furniture polish may degrade the feet of the trans-
mitter, which could stain your furniture. You should therefore place the
transmitter on a non-slip pad to avoid potential staining of furniture.
왘Switch the headphones off after use to conserve battery power.
Remove the batteries if the headphones will not be used for extended
periods of time.
Preventing damage to the power supply unit
왘To reduce the risk of fire or electric shock, do not expose the product to
rain or moisture.
왘Unplug the mains unit from the wall socket to completely disconnect
the product from the mains, during lightning storms or when unused
for long periods of time.
왘Only operate the mains unit from the type of power source specified in
the chapter “Specifications”.
왘To prevent heat accumulation, always ensure that the mains unit is in
a safe operating condition and easily accessible, properly plugged into
the wall socket and not covered or exposed to direct sunlight for longer
periods of time.
왘Only use the power supply units, charging cables and accessories
recommended by Sennheiser. An overview can be found on
www.sennheiser.com.
www.sennheiser.com
www
RS 220
Manual

Important safety information
RS 220 | 3
Intended use
Intended use of the product includes
• having read this instruction manual, especially the chapter “Important
safety information”,
• using the product within the operating conditions and limitations
described in this instruction manual.
“Improper use” means using the product other than as described in this
instruction manual, or under operating conditions which differ from those
described herein.
Safety instructions for the NiMH rechargeable batteries
If abused or misused, the rechargeable batteries may leak. In extreme
cases, they may even present
Please understand that Sennheiser does not accept liability for damage
arising from abuse or misuse.
• a heat hazard,
• a fire hazard,
•anexplosionhazard,
• a smoke or gas hazard.
Keep away from
children.
Only charge the rechargeable
batteries in the headphones
(see page 14).
Observe correct
polarity.
Pack/store charged batteries
so that the terminals cannot
contact each other – danger
of shorting out/fire hazard.
Do not expose to
moisture.
Switch rechargeable battery-
powered products off after use.
Only charge recharge-
able batteries at
ambient temperatures
between 10°C/50°F
and 40°C/104°F.
When not using rechargeable
batteries for extended periods
of time, charge them regularly
(about every 3 months).
Do not mutilate or
dismantle.
Do not heat above 70°C/158°F,
e.g. do not expose to sunlight
or throw into a fire.
Immediately remove
rechargeable batteries
from an obviously
defective product.
Do not continue to use defec-
tive rechargeable batteries.
Only use rechargeable
batteries specified by
Sennheiser.
Dispose of rechargeable bat-
teries at special collection
points or return it to your
specialist dealer.

The RS 220 digital RF headphone system
4 | RS 220
The RS 220 digital RF headphone system
Experience audiophile sound quality with the RS 220 digital wireless head-
phone system. Consisting of a transmitter and open, circum-aural head-
phones, the system offers uncompressed music enjoyment – just like
wired high-end headphones.
The rechargeable batteries can conveniently be recharged while in the
headphones. Enjoy total freedom of sound, stylish design and maximum
comfort.
Additional features of the RS 220 RF headphone system
• Transmits uncompressed CD-quality audio over a robust 2.4 GHz digital
link, enabling you to enjoy your music without the hassles of cables.
• Dynamic transducer systems with powerful neodymium magnets
deliver clear and detailed audio reproduction.
• No set-up required – just plug and play. Simply connect the transmitter
to your personal audio/video player, put on the headphones and turn
it on.
• Up to four persons can listen simultaneously with optional headphones
and a single TR 220 transmitter.
• Signals can be looped through so that the transmitter can be inte-
grated into an existing connection between 2 devices
• Universal connections:
– 1 analog input and output
– 1 coaxial digital input and output
– 1 optical digital input and output

Delivery includes
RS 220 | 5
Delivery includes
HDR 220 headphones
TR 220 transmitter
Power supply unit with country adapters
Stereo audio cable with dual RCA plugs on each end
Coaxial cable with a single RCA plug on each end –
for digital connections
Audio adapter
(3.5 mm jack plug to 2 RCA sockets)
Rechargeable batteries, HR03, AAA size, NiMH
Quick Guide incl. CD ROM
with detailed instruction manual (PDF file)
Safety Guide
A list of accessories can be found on the RS 220 product page
at www.sennheiser.com. For information on suppliers, contact your
local Sennheiser partner: www.sennheiser.com > “Service & Support“.
RS 220
Digital wireless
system
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
QuickGuide
RS 220
Digital wireless
system
Sicherheitshinweise
Indicazionidi sicurezza
Instruçõesde segurança
Veiligheidsvoorschriften
SafetyGuide
Consignesde sécurité
Indicacionesde seguridad
Instruçõesde segurança

Product overview
6 | RS 220
Product overview
Overview of the headphones
1Headband
2Charging contacts
3Battery compartments
4Ear pads
5Volume +/L button
6Balance button
for changing between
Volume/Balance
7Volume –/R button
8On/Off button
9Power LED
0Input button
for selecting the audio source
1
22
34
5
6
7
0
9
8
3

Product overview
RS 220 | 7
Overview of the transmitter
Overview of the transmitter’s connections
ACharging contacts for charging
the headphones
BANALOG LED
CCOAXIAL LED
DOPTICAL LED
ETouch key for selecting the
audio source
FPower touch key
GON LED
HBattery LED
IPairing button
JLEVEL control dial
NOUT
COAXIAL
OPTICAL
DIGITAL
Pairing
-LEVEL
B
C
D
E
G
H
I
F
A
J
쐃DC IN socket for power supply unit
Inputs Outputs
쐇ANALOG IN (analog) 쐄ANALOG OUT (analog)
쐋COAXIAL IN (digital coaxial) 쐂COAXIAL OUT (digital coaxial)
쐏OPTICAL IN (digital optical) 쐆OPTICAL OUT (digital optical)
DC IN
9V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
Pairing
-LEVEL
쐃
쐇 쐄
쐏쐆
쐋쐂
ANALOG

Product overview
8 | RS 220
Overview of the indicators
Indicators on the headphones
Indicators on the transmitter
9
Indicator Status Meaning
Power LED 9lights up blue The headphones have found a suit-
able transmitter.
flashes blue The headphones haven’t found a
suitable transmitter.
flashes
alternately
blue and red
The headphones are in pairing mode.
flashes red The rechargeable batteries are
almost flat.
off The headphones are switched off.
B
C
D
G
H
Indicator Status Meaning
ON LED Glights up green The transmitter has found suitable
headphones.
flashes green The transmitter hasn’t found suit-
able headphones.
lights up red The transmitter is in loop through
mode (i.e. a digital signal can be
looped through to connected
devices).
off The transmitter is in standby mode.
Battery LED Hlights up red The rechargeable batteries are being
charged.
off The rechargeable batteries are fully
charged.
ANALOG LED B/
COAXIAL LED C/
OPTICAL LED D
lights up green The corresponding input (“IN”) has
been selected.

Putting the RS 220 into operation
RS 220 | 9
Putting the RS 220 into operation
Setting up the transmitter
왘Choose a suitable place near your audio source (e.g. TV, stereo or home
cinema system). Avoid placing the transmitter close to metal objects
such as shelf bars, reinforced concrete walls, etc. as this can decrease
the transmitter’s range.
It is not necessary that the transmitter and headphones are in the
same room, so you can move around freely in the home or outside in
the garden.

Putting the RS 220 into operation
10 | RS 220
Connecting the transmitter to audio sources
You can connect up to 3 audio sources (e.g. CD player, DVD player and TV)
to the transmitter. The transmitter is fitted with 2 digital and 1 analog
inputs and outputs. If you connect several audio sources, you can conve-
niently toggle between these audio sources with a key press (see
page 21).
왘Switch your audio source off before connecting the transmitter.
왘Check the available connection possibilities of your audio source.
왘Select the corresponding connection cable and, if necessary, a suitable
adapter.
왘Follow the instructions in the corresponding chapter in order to connect
your transmitter to the audio source.
Connecting the transmitter to RCA sockets
왘Connect the RCA plugs of the stereo audio cable Kto the corre-
sponding RCA sockets of your audio source.
왘Connect the RCA plugs of the stereo audio cable Kto the left (“L”) and
right (“R”) ANALOG IN input 쐇.
Connection possibilities (output) of
the audio source Connection cable/adapter
RCA (analog) Stereo audio cable with dual
RCA plugs on each end
SCART (analog) Stereo audio cable with audio
adapter (to be ordered sepa-
rately)
Headphone socket
(analog)
Stereo audio cable with audio
adapter
Coaxial (digital) Coaxial cable with a single RCA
plug on each end
Optical (digital) Optical digital cable (to be
ordered separately)
A
LR
B
C
D
E
A
DC IN
9V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
OUT
RL
R
L
K
쐇
Pairing
-LEVEL

Putting the RS 220 into operation
RS 220 | 11
Connecting the transmitter to a SCART socket
왘Connect the RCA plugs of the stereo audio cable Kto the corre-
sponding RCA sockets of the SCART adapter.
왘Connect the SCART adapter to the SCART socket of your audio source.
왘Connect the RCA plugs of the stereo audio cable Kto the left (“L”) and
right (“R”) ANALOG IN input 쐇.
Connecting the transmitter to a headphone socket
왘Connect the RCA plugs of the stereo audio cable Kto the corre-
sponding RCA sockets of the audio adapter L.
왘Connect the audio adapter Lto the headphone socket of your audio
source.
왘Connect the RCA plugs of the stereo audio cable Kto the left (“L”) and
right (“R”) ANALOG IN input 쐇.
B
A suitable SCART adapter is available from your specialist dealer.
DC IN
9V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
Pairing
-LEVEL
R
L
K
쐇
C
DC IN
9V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
R
L
K
쐇
Pairing
-LEVEL
L

Putting the RS 220 into operation
12 | RS 220
Connecting the transmitter to a coaxial digital output
왘Connect the RCA plug of the coaxial cable Mto the RCA socket (digital
output) of your audio source.
왘Connect the RCA plug of the coaxial cable Mto the COAXIAL IN input 쐋.
Connecting the transmitter to an optical digital output
왘Connect the connector of the optical digital cable Nto an optical digital
output of your audio source.
왘Connect the connector of the optical digital cable Nto the
OPTICAL IN input 쐏.
D
DC IN
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
R
M
쐋
9V/1A
Pairing
-LEVEL
E
A suitable optical cable is available from your specialist dealer.
DC IN
9V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
Pairing
-LEVEL
쐏
N

Putting the RS 220 into operation
RS 220 | 13
Integrating the transmitter into an existing connection between devices
You can integrate the transmitter into an existing connection between
your audio source and an additional device. By way of example of an ampli-
fier as an additional device, this chapter describes how to integrate the
transmitter into an existing connection.
왘Pull out the plug of the audio cable from the desired input (“IN”) on the
amplifier.
왘Connect this plug to a suitable input (“IN”) on the transmitter (see
page 7).
왘Connect an additional identical audio cable to the output (“OUT”) on
the transmitter and to the input (“IN”) on the amplifier.
To keep the digital connection up even when the transmitter is switched
off:
왘Switch the loop through mode on (see page 17).
The analog connection (RCA/SCART/headphone socket) is kept up
when you disconnect the transmitter from the mains.
The digital connection (coaxial/optical) is interrupted in this case.
DCIN
5V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
Pairing
-LEVEL
DCIN
5V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
Pairing
-LEVEL
DCIN
5V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
Pairing
-LEVEL

Putting the RS 220 into operation
14 | RS 220
Connecting the transmitter to the mains
왘Select a suitable country adapter Ofor your wall socket.
왘Slide the country adapter Oonto the power supply unit Puntil it locks
into place.
왘Connect the connector of the power supply unit to the socket 쐃.
왘Plug the power supply unit Pinto a wall socket.
The transmitter switches on. The ON LED Gand the COAXIAL LED C
light up green.
Charging the rechargeable batteries inside the
headphones
Before using the headphones for the first time, remove the protection strip
from the rechargeable batteries and charge the rechargeable batteries for
optimum operation.
Removing the protection strip
왘Tilt the ear cup slightly inwards.
왘Open the battery compartment 3on the ear cup using your finger nail.
왘Pull the protection strip from the battery compartment.
DC IN
9V/1A
IN OUT
IN OUT
COAXIAL
OPTICAL
DIGITALANALOG
R
L
EU US
Pairing
-LEVEL
쐃
P
P
O
AU/CN
UK
3

Putting the RS 220 into operation
RS 220 | 15
Charging the rechargeable batteries inside the headphones
Charge the rechargeable batteries for at least 16 hours prior to first time
use. The operating time is up to 8 hours.
왘Place the headphones on the charging contacts Aof the transmitter.
The rechargeable batteries are being charged. The Battery LED Hlights
up red.
When the rechargeable batteries are fully charged, the Battery LED H
goes off.
Adjusting the headband of the headphones
For good sound quality and best possible comfort, the headband has to be
adjusted to properly fit your head. To do so, adjust the headband 1via its
snap-in locking mechanism:
왘Wear the headphones so that the headband 1runs over the top of
your head.
왘Adjust the length of the headband so that
– your ears are completely inside the earpads,
– you feel even, gentle pressure around your ears,
– a snug fit of the headband 1on the head is ensured.
16h
Always store the headphones on the headphone holder to ensure
that they are fully charged when they are needed. The battery
charging technology prevents over-charging.
AH
1

Using the RS 220
16 | RS 220
Using the RS 220
To switch the product on and to listen to your audio source, proceed as
follows:
Switching the transmitter on/off
Switching the transmitter on
왘Touch the Power touch key F.
The transmitter switches on. The LED of the last selected audio source
(here COAXIAL) lights up. The ON LED Gflashes until the transmitter
has found suitable headphones and then lights up continuously.
Sequence of steps Page
1. Make sure that the rechargeable batteries are charged. 14
2. Switch your audio source on. –
3. Switch your transmitter on. 16
4. Switch your headphones on. 19
5. Select the desired audio source. 21
6. Put on the headphones. 15
7. Adjust the desired volume on the headphones. 23
If the transmitter doesn’t receive an audio signal for more than
3 minutes, it switches, depending on the setting, to either standby
mode or loop through mode. If the transmitter receives an audio
signal within the next 10 minutes, it automatically switches on
again.
ON
F
G

Using the RS 220
RS 220 | 17
Switching the loop through mode on/off
In loop through mode, the signals are looped through from one device to
another, even when the transmitter is switched off.
To switch the loop through mode on:
왘Touch the touch key for selecting the audio source Eon the trans-
mitter until the ANALOG LED B, the COAXIAL LED Cand the
OPTICAL LED Dlight up green simultaneously for a moment.
왘Switch the transmitter off. The ON LED Glights up red, the transmitter
is in loop through mode.
To switch the loop through mode off:
왘Touch the touch key for selecting the audio source Eon the trans-
mitter again until the ANALOG LED B, the COAXIAL LED Cand the
OPTICAL LED Dlight up green simultaneously.
왘Switch the transmitter off. The ON LED Gis off, the transmitter is in
standby mode.
B
C
D
E

Using the RS 220
18 | RS 220
Switching the transmitter off
왘Briefly touch the Power touch key F.
All LEDs go off. The transmitter is
–instandby mode when the ON LED Gis off or
–inloop through mode when the ON LED Glights up red.
When the transmitter is switched on the next time, it selects the last set
input.
To disconnect the transmitter from the mains:
왘Pull out the mains plug from the wall socket.
The transmitter is reset to the factory default settings. Please note
that In this case, the headphones’ rechargeable batteries will not be
recharged.
ON
F

Using the RS 220
RS 220 | 19
Switching the headphones on/off
Switching the headphones on
왘Press the On/Off button 8until the Power LED 9lights up blue or
flashes.
The headphones switch on and search for a suitable transmitter. Once
the headphones have found a suitable transmitter, the transmitter
connects with the headphones and transmits the audio signal of the
selected input. The Power LED 9lights up continuously.
WARNING
Danger of hearing damage!
Listening at high volume levels for long periods can lead to perma-
nent hearing defects.
왘Before putting the headphones on, set the volume to a low level.
왘Do not continuously expose yourself to high volumes.
WARNING
Interferences due to magnetic fields!
The product generates stronger permanent magnetic fields that
could cause interference with cardiac pacemakers and implanted
defibrillators (ICDs).
왘Always maintain a distance of at least 3.94” (10 cm) between
the ear cup housing and the cardiac pacemaker or implanted
defibrillator.
ON
8
9
