The charger/storage case can simultaneousl recharge 20 receiver and 2 transmitter batteries.
The receivers are charged in the charging docks (as seen below). The transmitter batteries are charged
in the transmitter charging docks.
To charge the s stem remove the mains cable from the pocket on the inside of the storage case lid and
plug into the charger and a mains outlet. Switch the charger ON. A LED on each receiver and the
transmitter charging dock will indicate the charging status: Red=Charging in progress. Green=Full
charged.
A useful facilit of the charger case is the COPY function. This allows the user to preselect all the
channels of the receivers with the push of one button. Place a receiver on the required channel into the
master charging compartment and press the cop function button. This will instantl set all the other
receivers in the charger to the required channel.
Battery life
> Hrs
Stethoset receiver 8
Bod pack receiver 16
Transmitters 8
CHARGER/STORAGE CASE
1 IEC socket and mains switch
2 Transmitter batter charging docks
3 Charging case lid catches
4 Handheld transmitter storage straps
5 Receiver charging compartment
6 Master charging compartment
7 COPY button
8 COPY AVAILABLE LED
9 TEMP ERROR LED
1 POWER LED
11 Trolle frame mount ( underneath)
7
1
3
2
9
1
8
3
3
3
11
4
5
6
IMPORTANT: ENSURE TRANSMITTER AND RECEIVERS ARE CHARGED PRIOR TO USE
Please read these instructions and familiarise ourself with the equipment before our event. The
instructions are intended as a quick guide onl . Should ou require more information please refer to the
manufacturers handbooks or contact us.
A tour guide s stem is a wireless radio s stem used to transmit a message from a presenter to listeners.
The presenter simpl speaks into a microphone and the listeners use receivers to hear the message. A
tour guide s stem can be used indoors and outdoors (with a maximum range of 100m). Up to 6 channels
can be used simultaneousl .
After each use, recharge all transmitters and receivers so the are read for the next event.
INTRODUCTION

Receiver Display
1 Channel displa
2 Batter status displa
3 Volume displa
4 RF signal indication
Two t pes of receiver are available:
This receiver is switched on b pressing the button
on the top. It is used b inserting either headphones
or an inductive neck loop (for hearing aid wearers)
into the socket on the side. The volume is
controlled b rotating the wheel on the front. If the
channel needs to be changed this can be done b
pushing the rocker switch in the centre of the
volume control.
The receiver automaticall switches off 5 mins after
the headphones/ neck loop plug is removed, or b
pressing the button on the top for 3 seconds.
1 Volume control
2 ▲/▼ rocker button for channel selection
3 Headphone socket
4 Displa (see above)
5 Charging status LED
6 ON/OFF button
Please turn over for transmitter instructions
BODYPACK RECEIVER
3
1 2
4
5
4
3
6
1
2
5 5
3 4
1 2
6
This receiver is switched on b opening the arms and
resting in the ears. The volume is controlled b rotating
the wheel on the front. If the channel needs to be
changed this can be done b pushing the rocker switch
in the centre of the volume control.
The receiver automaticall switches off when the
receiver is removed from the ears to preserve batter
life.
Earpads can be cleaned using antibacterial wipes.
1 Volume control
2 ▲/▼ rocker button for channel selection
3 Red/Green LED for charge status
4 Displa
(see below)
5 Earbows
6 Earpads
STETHOSET RECEIVER
