MKE 1 - Care and Cleaning Instructions
The MKE 1 is a high-quality, sub-miniature clip-on microphone which combines
outstanding sound quality and rugged design with extremely small dimensions.
To ensure continuous optimum performance, please observe the following care and
cleaning instructions.
General care instructions
fUse the MZC 1-1 and MZC 1-2 frequency response caps and
the MZC 1-3 make-up protectors to avoid soiling and dysfun-
ctions.
fStore the MKE 1 in a dry, dust-free environment.
fAvoid extreme bending and tearing of the cable.
fAvoid knots in the cable.
Frequency response cap
Make-up protector
Mikrophone sound inlet
Mikrophone head
Anti-kink sleeve
Connector
The MZC 1-1 and MZC 1-2 frequency response caps
fTo wear the MKE 1 directly on the skin, use the large MZC 1-2 frequency response
cap which offers an extended protection against the ingress of sweat.
fRegularly clean or replace the frequency response caps to avoid sound alterations.
Cleaning after use
fRemove the frequency response cap from the microphone capsule. Hold the micro-
phone by the cable and not by the anti-kink sleeve.
fUse a fine bristle brush and isopropanol to remove make-up residues and other
buildup from the gauze.
Gauze
MKE 1 - Cleaning instructions 1/2

The microphone capsule
The microphone capsule features an overmold which only serves as an anti-kink sleeve.
The microphone capsule itself is protected from moisture.
Cleaning after use
fRemove the frequency response cap from the microphone
capsule. Hold the microphone by the cable and not by the
anti-kink sleeve.
fShake the microphone capsule to remove excess moisture.
Aqua
dest
H₂O dist. fBathe the microphone capsule in distilled water to loosen
make-up residues and other soiling.
fDo not use a cloth or a bristle brush to clean the micro-
phone sound inlet.
fDry the microphone for approx. 12 hours. The microphone
sound inlet has to point downwards during drying.
The cable
The anti-kink sleeve on the connector and the microphone is designed to meet the highest
requirements in quality. The use of additional adhesive tapes or shrink-on tubes can dam-
age the material and reduce the service life of the cable.
fOnlyuselavaliertape(LAV-Tape)toattachthecabletotheskin.
Lavalier tape (LAV-Tape) is available as an original Sennhei-
ser accessory.
Cleaning after use
fUse a cloth or a fine bristle brush and isopropanol to remo-
ve make-up residues or other soiling.
NOTE: Particular hints for MKE 1 - musical (M) variants
fOnly use distilled water and a slightly damp cloth for
cleaning the cable.
fWhen cleaning be extremely careful, only use low
pressure, only clean little sections at a time.
Otherwise beads may occur.
fDo not use isopropanol! It may damage the surface of the
cable.
Aqua
dest
H2O dist.
MKE 1 - Cleaning instructions 2/2
Sennheiser electronic GmbH & Co. KG
Am Labor 1, 30900 Wedemark, Germany, www.sennheiser.com
Publ. 05/20, 540099/A04
