SENSORWORX SWX-101 Series Installation instructions

LINE VOLTAGE
WALL SWITCH SENSORS
INSTALLATION & OPERATION INSTRUCTIONS
MODEL # PIR ACOUSTIC PHOTOCELL DEFAULT MODE
SWX-101-xx* •OCC
SWX-103-xx •VAC
SWX-104-xx •VAC
SWX-111-xx • • OCC
SWX-113-xx • • VAC
SWX-121-xx • • OCC
SWX-123-xx • • VAC
SWX-124-xx • • VAC
SWX-131-xx • • • OCC
SWX-133-xx • • • VAC
OVERVIEW
SENSORWORX wall switch sensors detect movement in the infrared energy that
radiates from occupants as they move within the devices eld-of-view. Once occupancy
is identied, the sensor’s internal relay switches power on to the connected lighting.
Units can also be congured to operate in Vacancy Mode (e.g., require lights be manually
switched on). Once lights are on and if equipped with passive dual technology (PIR/
Acoustic), the unit’s microphone is enabled to further enhance detection. An internal timer
is set to keep lights on during brief periods of inactivity and is reset every time occupancy
is signaled by either the passive infrared or acoustic detection technologies. Ambient
daylight detection can also be enabled in the unit so that lights are held off in rooms with
sufcient light contribution from windows or skylights.
SPECIFICATIONS
ELECTRICAL
OPERATING VOLTAGE
120/277 VAC, 50/60 Hz
LOAD RATINGS
MAX: 800W @ 120VAC
1200W @ 277VAC
MIN: None
LOAD TYPES
LED Driver/Lamps
CFL, Electronic/Magnetic Ballasts
(Fluorescent)
Tungsten (Incandescent)
PHYSICAL
SIZE
2.74”H x 1.68”W x 1.39”D
(6.96 x 4.27 x 3.53 cm)
Not Including Mounting Strap
WEIGHT
4.5 oz
MOUNTING
Single Gang Switch Box
ENVIRONMENTAL
OPERATING TEMP
32°F to 122°F (0°C to 50°C)
RELATIVE HUMIDITY
0-95% Non-Condensing,
Indoor Use Only
CODE COMPLIANCE
Wall Switch sensors can be used to
meet many requirements of ASHRAE
90.1(2016), IECC (2015), and Title 24
(2016). In particular, Manual On
(e.g., Vacancy) operation is prescribed
for many building spaces.
FEATURES
ELECTRICAL FEATURES
 Interchangeable Line & Load Wires -
Impossible to Wire Backwards
 Accommodates Neutral (3-wire)
and No-Neutral (2-Wire) Installation
 Electronically Timed Switching
Ensures Long Relay Life
 Compatible with LED, Fluorescent
and Incandescent Lighting
 Meets NEC Guidelines Regarding
Current Leakage
PHYSICAL FEATURES
 Enclosure is 25-40% Shallower than
Other Sensors (< 1” depth into wallbox)
 Unique Bat-Wing Shaped Lens Provides
Enhanced Peripheral Detection
 Self-Grounding Mounting Strap
 Modern Look and Intuitive
Easy-Tap Button
 Rugged Vandal Resistant Lens
 Settings are Adjustable Without Removing
Cover Plate
OPERATIONAL FEATURES
 Wall-To-Wall Passive Infrared
Small Motion Detection
 Passive Acoustic Detection (Optional) -
Prevents False Offs when No Motion is Present
 100% Passive Detection Methods -
No Interference Potential from External Devices
 Ambient Daylight Override Mode Increases
Energy Savings
 Congurable Time Delays and Operating Modes
 Blue Locator LED when Ligths are Off
* xx = color (WH, IV, AL, GY)

WALL SWITCH
0 ft 0 m
41.2
SIDE VIEW
0 ft
0 m
10
3.0
20
6.1
30
9.1
40
12.2
TOP VIEW
4 ft Mount
4012.1
4012.1
206.1
0 ft0 m
206.1
COVERAGE
 30” to 48’ (0.76 - 1.22 m) recommended mounting height
 Wall to wall (~180 degree) coverage
 Small motion (e.g., hand movement) detection up to 20 ft (6.10 m), ~625 ft2
 Large motion (e.g., walking) detection greater than 36 ft (10.97 m), ~ 2025 ft2
 Overlapping acoustic detection of occupants over entire coverage area
 Advanced signal processing lters out nuisance noises while not effecting
overall sensitivity
 As an added safety convenience, the acoustic detection is left active for
10 seconds after sensor turns the lights off to allow for voice reactivation
BLK
WHT
LOAD
BLK
N
SWX
WALL SWITCH
SENSOR
H
GRN
BLK
WHT
BLK
NN
SWX
WALL SWITCH
SENSOR
H
GRN
BLK WHT
LOAD
BLK
SWX
WALL SWITCH
SENSOR
N
GRN
BLK
WHT
BLK
N
SWX
WALL SWITCH
SENSOR
GRN
Standard Wiring
3-Way Wiring
H
1-Sensor: 3-Way Wiring
3-WAY SWITCH
COMMON
TRAVELERS
TRAVELERS
LOAD
* NEUTRAL CONNECTION IS OPTIONAL,CAP IF UNUSED
*
*
*
*
* NEUTRAL CONNECTION IS OPTIONAL,CAP IF UNUSED
* NEUTRAL CONNECTION IS OPTIONAL,CAP IF UNUSED
BLK
WHT
LOAD
BLK
N
SWX
WALL SWITCH
SENSOR
H
GRN
BLK
WHT
BLK
NN
SWX
WALL SWITCH
SENSOR
H
GRN
BLK WHT
LOAD
BLK
SWX
WALL SWITCH
SENSOR
N
GRN
BLK
WHT
BLK
N
SWX
WALL SWITCH
SENSOR
GRN
Standard Wiring
3-Way Wiring
H
1-Sensor: 3-Way Wiring
3-WAY SWITCH
COMMON
TRAVELERS
TRAVELERS
LOAD
* NEUTRAL CONNECTION IS OPTIONAL,CAP IF UNUSED
*
*
*
*
* NEUTRAL CONNECTION IS OPTIONAL,CAP IF UNUSED
* NEUTRAL CONNECTION IS OPTIONAL,CAP IF UNUSED
3-WAY WIRING
TWO SENSORS IN PARALLEL
 Both sensors must time out for lights to turn off (or both buttons
must be switched)
 Recommended for Automatic On (Occupancy) applications only
INSTALLATION
STANDARD WIRING
WARNING: TURN POWER OFF AT THE CIRCUIT BREAKER BEFORE WIRING
* NEUTRAL CONNECTION IS OPTIONAL, CAP IF UNUSED
* NEUTRAL CONNECTION IS OPTIONAL, CAP IF UNUSED
WIRING
 For supply connections, use 14 AWG (90° C) or larger wires
 Risk of Electric Shock - more than one disconnect switch may be required
to de-energize the equipment before servicing
 It is recommended that wiring the unit’s ground connection be done rst.
 Unit works both in installations where Neutral connection is available as
well as installations where only Ground connection is present
 The unit’s two black wires are interchangeable (e.g., one connects to line
power, one connects to load)
 After wiring and mounting, install wall plate (not included) before turning
back on power at the circuit breaker

SETTING # DESCRIPTION
1 Test Mode*
2 30 sec
3 5 min
4 10 min [Default]
5 15 min
6 20 min
7 30 min
CONFIGURATION SETTINGS
There are several settings that can be modied. To change a setting, follow
the below steps:
1Press and hold the push button until blue LED begins ashing rapidly, then release.
2Tap the button the number of times corresponding to the Function # to be changed
(e.g., 2 times for Time Delay).
3The LED will blink back white the number of times equal to the current setting
(e.g., 4 times for 10 minutes). Following a short pause, this blink back sequence
will repeat.
4Interrupt blink back by pressing the button the number of times corresponding to
the new setting. (e.g., 3 times for 5 minutes). The LED will blink back white the
number as conrmation.
5To exit and save, press and hold the push button until blue LED changes to white,
then release. Unit will blink white twice indicating save was successful. If LED
blinks twice blue, an error condition occurred.
FUNCTION #2
OCCUPANCY TIME DELAY SETTINGS
Lights are held on following all occupancy events for the
selected period.
* TEMPORARY 5 SEC TIME DELAY, REVERTS AFTER 10 MIN
INSTALLATION CONT.
MOUNTING
 Designed to mount in 1-gang wall box with 3.28” hole spacing
 Units also can share multiple gang wall boxes with other devices
FRONT SIDE
BREAK-OFF
BRACKET EARS
BREAK-OFF
BRACKET EARS
LED INDICATOR
BUTTON
SENSOR FACE**
2.74”
SUPPLIED MOUNTING SCREWS
FOR MOUNTING TO
SINGLE GANG SWITCH BOX
1.39”
0.94”
1.69”
** SENSOR FACE IS FIELD REMOVABLE IN ORDER TO CHANGE COLORS. CONTACT FACTORY FOR ADDITIONAL FACES
KEY INSTALLATION
FEATURE
25-40% SHALLOWER
THAN OTHER WALL
SWITCH SENSORS
** SENSOR FACE IS FIELD REMOVABLE IN ORDER TO CHANGE COLORS. CONTACT FACTORY FOR ADDITIONAL FACES

CONFIGURATION SETTINGS CONT.
FUNCTION #3 OPERATIONAL MODES
Several pre-programmed operational modes are available to accommodate both
preferences and applicable energy codes.
2 Vacancy Mode (Manual On / Automatic Off)
This mode provides increased energy savings but requires the user to initially turn on
the lights by pressing the button. Lights can also be switched off manually. Models
SWX-103, SWX-104, SWX-113, SWX-123, SWX-124, and SWX-133 default to
Vacancy mode.
3 Occupancy Mode (Automatic On / Automatic Off)
Automatic On and Automatic Off operation. If lights are switched off manually, the
Automatic On functionality is temporarily disabled to allow the occupant a few
seconds to leave the room before returning to Automatic On operation. However, if the
person remains in the space, the unit will stay in a manual on state until the switch is
pressed again. This mode is the default operation of SWX-101, SWX-111, SWX-121,
and SWX-131 models. Not available for models SWX-104 and SWX-124.
4 Automatic On w/ Exit Time Mode (Automatic On/Automatic Off)
If lights are switched off manually, the Automatic On functionality is disabled for a
xed 30 seconds to allow a person time to leave the room. Not available for SWX-104
and SWX-124 models.
5 Override Off Mode
Automatic On and Automatic Off operation until lights are switched off manually, at
which point Automatic On functionality is disabled until the button is pressed again.
Not available for SWX-104 and SWX-124 models.
6 Disabled Switch Mode
Automatic On and Automatic Off operation only. Switch functionality to manually turn
on/off lights is disabled. Not available for SWX-104 and SWX-124 models.
7 Presentation Mode
If lights are switched off manually, the Automatic On functionality is disabled until the
space becomes unoccupied and the sensor’s time delay expires.
SETTING # DESCRIPTION
2 Vacancy Mode
3 Occupancy Mode
4 Automatic On with Exit Time
5 Overide Off Mode
6 Disabled Switch Mode
7 Presentation Mode
OPERATION MODES
FUNCTION #4 AMBIENT LIGHT OVERRIDE (PHOTOCELL)
Sensor will prevent lights from automatically turning on when measured light level
exceeds selected setpoint (e.g., ambient light threshold). LED blinks blue every 10 seconds
when lights are being overridden. If ambient light level falls below threshold for more
than 45 seconds, lights will switch on. During transition time, the LED will blink blue at an
increasingly faster rate. Once on, lights will stay on until occupancy time delay expires,
regardless of ambient light level.
SETTING # DESCRIPTION
2 Disabled [Default]
3 Run Auto-Setpoint*
4 2 fc
5 5 fc
6 15 fc
7 30 fc
8 50 fc
9 75 fc
10 99 fc
*Instead of blinking back setting #, the value of the setpoint will be blinked back in two alternating digits:
 Blue LED = 10’s digit (1-9 blinks or rapid blink or 0)
 White LED = 1’s digit (1-9 blinks or rapid blink or 0)
AUTO-SETPOINT SELECTION DETAILS
AOnce setting 3 “run auto-setpoint” has been selected, exit programming mode by
pressing button until LED changes from blue to white. The sensor’s LED will rapid ash
white twice conrming programming change.
BLED will then blink back blue at an increasing rate for 15 sec. In order to provide user
time to exit area in front of sensor.
CLights will then be cycled in order for sensor to calculate the controlled (articial) light
level. This is done by subtracting the light level with the lights off (relay open) from the
light level with the lights on (relay closed).
D Setpoint selection
 If controlled level is less than 2 fc, setpoint will be set to measured level when
relay is open (minimum 2 fc)
 If controlled level is greater than 75 fc, setpoint will be set to 99 fc
 If controlled level is between 2 and 35 fc, setpoint will be set to that level plus a
reectivity ratio factor.
 If controlled level is between 35 and 70 fc, setpoint will be set to 75 fc
E To check auto selected setpoint, press and hold button again until LED ashes rapidly.
Release and press button 4 times. Setpoint will be blinked back in two alternating digits:
 Blue LED = 10’s digit (1-9 blinks or rapid blink or 0)
 White LED = 1’s digit (1-9 blinks or rapid blink or 0)
Manual Setpoint Options
}

Five-Year Limited Warranty.
Complete Warranty Terms Located at: sensorworx.com/warranty
INS100 | REV 001–190226
SENSORWORX | 3 Essex Sq, Essex, CT 06426
203.678.4224 | www.sensorworx.com
© 2019 BLP Technologies, Inc. All rights reserved.
OPERATIONAL NOTES
TEST MODE
A test mode with a 5 second time delay is provided in order to efciently perform walk
testing. The sensor will blink White on any detected PIR event and Blue on any detected
acoustic event, although its time delay will only be reset by a PIR event. While in test
mode, the blue locator LED also will not be lit when the lights are off (i.e. relay open).
TO PUT A SENSOR IN TEST MODE FOR 10 MINUTES:
 Press and hold the push button until blue LED begins to rapid ash, then release
 Press sensor’s pushbutton 2 times, then wait two seconds
 Press button 1 time to select Test Mode
 To exit and save, press and hold the push button again until blue LED changes to
white, then release. Unit will blink white twice indicating save was successful. If LED
blinks twice blue, an error condition has occurred.
 After 10 minutes, the sensor’s time delay will revert to previous saved time delay
VACANCY MODE
 If sensor is congured for vacancy (manual on) operation, the ambient light override
setting will be overwritten to “DISABLED” and any attempted modications to the
setting will trigger an error condition (indicated by double blue LED ash after exit/
save). The ambient light override feature (i.e. photocell) can only be enabled when the
sensor is in an automatic on operating mode.
 There is a 15 second “grace” period after the sensor times out when the sensor will
switch lights back on automatically. After 15 seconds the sensor will revert to vacancy
(manual on) operation.
MICROPHONE GRACE TIMER
 As an added safety and convenience feature, a sensor with acoustic detection will
keep its microphone enabled for an additional 10 secs. after lights are automatically
turned off to enable voice reactivation.
FUNCTION #5 AUTO ON SENSITIVITY
This setting indicates the sensor’s PIR sensitivity when the lights are off. Typically this
setting should be FULL, but if reective surfaces (like windows) are causing false-ons the
REDUCED setting should be used. Note that the unit returns to full sensitivity after initial
detection.
SETTING # DESCRIPTION
2 Full
3 Reduced
FUNCTION #6 MICROPHONE
Dual technology (i.e. PIR + acoustic) sensors prevent non-occupant sounds from
resetting the time delay by dynamically reducing the microphone’s sensitivity at specic
frequencies. In some environments, decreasing the sensitivity across all frequencies so
that lights go off sooner, may be preferred. A unit’s microphone can also be disabled
(effectively changing sensor to a PIR only version).
SETTING # DESCRIPTION
2 Normal
3 Reduced
4 Disabled
FUNCTION #7 LED FUNCTIONALITY
By default, the sensor’s LED will be solid blue when the unit’s relay is in the open/
off state. This serves as a switch locator. Once the lights are on, the LED will blink
white whenever the sensor detects PIR motion. A unit with dual technology will also
blink the LED white when it acoustically detects occupancy. The blue and/or white LED
functionality can also be disabled.
SETTING # DESCRIPTION
2 Blue locator LED enabled
3 Blue locator LED disabled
4 Blue & White LED disabled
FUNCTION #8 FACTORY RESET
SETTING # DESCRIPTION
3 Restore Factory Settings
CONFIGURATION SETTINGS CONT.
