SentriLock NXT-BLE Installation Manual 2017
Installation Manual
Product Items
 SentriLock® NXT-M and BLE WM Lockbox
 4 x Heco Multi-Monti MMS-S 10 x 100
masonry bolts and washers
 4 x M10 Flat washers
 Installation manual
Tools Needed
 Drill
 8mm Masonry drill bit x 150mm long
 16 mm socket (short/slim) 3/8” drive
 Socket ratchet wrench 3/8” drive
 50mm (or longer) extension 3/8” drive
 Torx driver with T25 bit
 Small flat tip screw driver
 Marking template
 Marker pen
 Small dustpan or tape and plastic bag (to
cacth brick dust whilst drilling)
 Polythene bags for collection of different
coloured dusts
 Elastic band to suspend mechanism
underneath the lid

Installation Manual
SentriLock NXT-BLE Installation Manual 2017 Page 2 of 8
Before Starting
The SentriLock® NXT-M and BLE WM Lockboxes are designed to be mounted directly to a building or other secure
structure. The Lockboxes have been certified to Loss Prevention Standard (“LPS”) 1175, Level 2 when mounted in brick
and when including render of up to 20mm thickness, using the supplied Heco Multi-Monti MMS-S 10 x 100 masonry
bolts and M10 flat washers. It is also possible to use the Heco Multi-Monti MMS-S 10 x 80 masonry bolts (with M10 flat
washers) if mounting onto brick only substrate.
Mounting the lockboxes using any other mounting bolts or onto weaker wall structures will invalidate the security
rating.
It is important that the designated installer follows this instruction manual for the installation to retain the awarded LPS
certification. Should it be required to mount a lockbox on other than a conventional masonry wall, please contact
SentriLock to discuss suitability and the possible use of different specification mounting bolts.
This installation manual is a confidential document which is only issued to designated Installers. The purpose of this
manual is to act as a reference manual for the installation of a SentriLock® NXT-M and BLE WM Lockboxes. The
document remains the property of SentriLock, LLC.
Preparation
Position of Installation
 It is recommended that the Lockbox be mounted in a position that makes attacks more difficult to reduce the
leverage an attacker can impart on the lockbox.
Surface
 It is important that the mounting location is flat. If not, the pressure exerted by the bolts when tightened will
twist the Lockbox frame and may render it inoperable. Do not attempt to mount the lockbox on any surface
that is not flat.
 On rendered walls ensure the use of Heco Multi-Monti MMS-S 10 x 100 masonry bolts and washers as they will
maintain the LPS1175 level 2 security rating.
 Contact SentriLock to discuss suitability and the possible use of different mounting bolts for non-standard
masonry surfaces.
Drilling the Mounting Holes
 Where possible, all bolts should fasten directly into the central part of a brick.
 It is important the mounting holes are not in the mortar between bricks.
 The drill holes must be at 90 degrees’ angle to the wall and to the specified depth.
 Catch and save the dust from drilling to leave the area neat and tidy and to retain the dust for colouring filler
used to refill holes after de-installation.

Installation Manual
SentriLock NXT-BLE Installation Manual 2017 Page 3 of 8
Instructions
See SL30174 for detailed drilling template. (Page 8)
Step
Instructions
1 Open and Disassemble Lockbox
1.1
a) Open the lockbox using FUNC 3 ENT. [ENT wakes up the
Blue tooth].
b) Carefully note the interconnect cable routing and position
before proceeding. You will need to route the cable in exactly
this manner when
reassembling the unit later.
c) Remove the light grey Key Bin and set aside for re-
assembly
NXT-M Lockboxes (ONLY)
Remove the two SCREW, #6-32 X .250 LG. BUTTON
HEAD,TORX (T1O) screws located on the bottom of the
lockbox that attach the door rotation limiter. Save these parts
for later reassembly.
1.2
On the keypad of the lockbox, hold the ENT key down until
you hear a beep from the lockbox and the keypad
illuminates. On the keypad, press FUNC FUNC 3 7 3 7 3
FUNC ENT. This will cause the unit to unlatch and leave the
latches in the retracted state. Leave the lockbox in the open
state while installing.
1.3
a)
Using a T25 Torx screw driver, remove the single center
fastener bolt that retains the metal Security Plate and
Latching Mechanism.
b)
Set aside for re-assembly.

Installation Manual
SentriLock NXT-BLE Installation Manual 2017 Page 4 of 8
Step
Instructions
1.4
a)
Carefully remove the metal Security Plate. Use a flat
blade screwdriver if necessary.
b)
Set aside for re-assembly.
1.5
Remove mechanism box from vault.
WARNING
Be extremely careful not to damage the interconnect cable or
the latch mechanism.
a)
Carefully pry the Latch Mechanism out of the vault by
lifting the bottom edge out first. Use a flat blade
screwdriver if necessary.
b)
Protect the Latch Mechanism and lay on the keypad lid.
c)
It is possible to suspend the mechanism on the
underside of the keypad by means of the elastic
band. This can ensure it is kept out of the way while
screwing the Lockbox to the wall
1.6
a)
Carefully remove the metal Spacer Plate. Use a flat blade
screwdriver if necessary.
b)
Set aside for re-assembly.

Installation Manual
SentriLock NXT-BLE Installation Manual 2017 Page 5 of 8
2 Marking and Drilling Holes
Step
Instructions
2.1
Using the supplied drill template, mark the 4 mounting hole
centres to be drilled onto the surface. (The drill hole
positions in the slots must be at the extreme top end of the
slots, centred some 84mm from the bottom holes.)
WARNING
This is important, otherwise the socket used for installing the
bolts will foul the casing.
See SentriLock
Drawing
SL30174
2.2
Centre punch all four drill points to stop the drill wandering
during the initial drilling.
WARNINGS
Ensure there are no electrical or data cables, gas or water
pipes or other utilities behind the surface before drilling.
Do not drill the holes through the Lockbox.
Do not breathe in the dust created by drilling – it contains
silica which can cause lung disease. Wear respiratory
protection.
a) Drill the holes with an 8mm masonry drill bit to 100 mm
depth. The quality of the drilled hole is the critical factor.
Ensure the holes are drilled perpendicular to the fixing
plane and that they are sufficiently deep.
a. If using the 80mm bolts, drill the holes to an
80mm depth
b) Use the small dustpan to catch the dust from the drilling
or tape a plastic back to the wall underneath where the
holes will be drilled to catch the brick dust.
c) Sweep brick dust into a polythene bag for use during
deinstallation when filling holes and colouring filler.

Installation Manual
SentriLock NXT-BLE Installation Manual 2017 Page 6 of 8
3 Installing the Bolts
Step
Instructions
3.1
Use four bolts and washers, fix the Lockbox to the wall.
a)
Install the top two bolts first by sliding the box up in the
slotted top holes to its highest position (to allow for easy
access to the bolt heads).
b)
Screw them down to within one turn of being tight, but
do not fully tighten at this stage.
3.2
c)
Let the lockbox drop down in the top slotted holes now,
and then install the bottom two bolts. Tighten them
completely.
d)
Go back to the top bolts and tighten them completely,
using the swivel flex drive if necessary.
e)
Check that all four bolts are tightened and firmly secure.
WARNING: It is imperative when tightening the bolts that the
process has not deformed or twisted the vault box. The
installation surface must be flat.
4 Reassemble Lockbox
4.1
Reverse the disassembly process.
a) Re-insert the metal Space Plate, ensuring it sits flush and
level. Ensure it does not sit on the bolt heads or washers,
but covers them.
b) Re-insert the Latch Mechanism (if necessary, by pushing
the door latches in slightly to get them around the latch
supports. Use a small flat blade screwdriver to push the
latch in further, one side at a time.)
c) Re-install the metal Security Plate and the single centre
bolt that retains the mechanism box.
Torque this fastener to 40.32 kg/cm (35 in/lbs).

Installation Manual
SentriLock NXT-BLE Installation Manual 2017 Page 7 of 8
Step
Instructions
4.2
a)
Carefully redress the interconnect cable into the original
position. This step is critical as cable life can only be
maintained if the cable is replaced in its original location
and configuration. Ensure the protective braid has not
slipped down the interconnect cable. There is a notch in
the bottom of the latch mechanism and the key holder
for the cable to locate in.
b)
Re-install the grey Key Holder into the lid.
5 Verify Lockbox works properly
5.1
Check the following:
a)
Door latches move freely;
b)
Cable is properly routed such that it will not be pinched,
stretched or damaged when the Lockbox door is closed;
c)
Fastener bolt is tightened securely;
d)
Lockbox is not twisted
WARNING: Do not close the Lockbox door until latches are
extended (and so proving they move freely.) Failure to do so
may render the unit inoperable and require unit destruction!
NXT-M Lockboxes Only
Reinstall the door rotation limiter utilizing the two screws as
shown.
5.2
To test the system, on the keypad of the lockbox, hold the
ENT key down until you hear a beep from the lockbox and
the keypad illuminates. On the keypad, press FUNC 3 ENT.
The latches should retract slightly the first time and then
return to the extended position. Test the unit with the door
in the open position until you are satisfied the latching
system is functioning properly.
