Sentry DPA S-CM-IOM-00557-0 07-20 Instruction manual

Original Instructions
sentry-equip.com
966 Blue Ribbon Circle North, Oconomowoc,WI 53066 U.S.A. | [phone] | suppor[email protected]
Installation, Operation &Maintenance Manual
Sentry DPA Series
Sample Collection
S-CM-IOM-00557-0 07-20
Do not install, maintain, or operate this equipment without reading,
understanding, and following the appropriate Sentry Equipment Corp
instructions. Otherwise, injury, damage, or both may result.
Copyright
© 2020 by Sentry Equipment Corp. All rights reserved. All product and company
names are property of their respective owners. This document contains
proprietary information. No part of this document may be photocopied or
reproduced without the prior written consent of Sentry Equipment Corp.
Limit of Liability
Sentry Equipment Corp, its employees, agents, and the authors and contributors
to this document specically disclaim all liabilities and warranties, express or
implied (including warranties of merchantability and tness for a particular
purpose), for the accuracy, currency, completeness, and/or reliability of the
information contained herein and/or for the tness for any particular use and/or
for the performance of any material and/or equipment selected in whole or part
with the user of/or in reliance upon information contained herein. Selection of
materials and/or equipment is at the sole risk of the user of this publication.
Note
The information contained in this document is subject to change without notice.
Safety Information
Please read the entire manual before attempting to unpack, set up, or operate this
product. Pay careful attention to all Warnings, Cautions, and Notes. Failure to do so
could result in serious personal injury and/or equipment damage.
Use of Hazard Information
If multiple hazards exist, the signal word corresponding to the greatest hazard
shall be used.
Denitions
DANGER indicates a hazardous situation
which, if not avoided, will result in death
or serious injury.
WARNING indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION, used with the safety alert
symbol, indicates a hazardous situation
which, if not avoided, could result in
minor or moderate injury.
NOTICE is used to address practices not
related to personal injury.
NOTE
Information that requires special emphasis.
TIP
Alternate techniques or clarifying information.
SHALL:
This word is understood to be mandatory.
SHOULD:
This word is understood to be advisory.
Standard Warranty
Sentry Equipment Corp (“Seller”) warrants products manufactured by it and
supplied hereunder (“Products”) to be free from defects in workmanship and, to
the extent materials are selected by Seller, to be free from defects in materials, in
each case for a period as dened in the table below:
Brand Product Line Warranty Period
Sentry® 1. Automatic Sampling
2. Corrosion Monitoring
3. Manual Sampling
4. Sample Conditioning
5. Sampling & Analysis Systems
6. Replacement Parts (without expiration dates)
Eighteen months from
date of shipment or
twelve months from
startup, whichever
occurs rst
Waters
Equipment
1. Sampling & Analysis Systems
2. Replacement Parts (without expiration dates)
Twelve months from
date of shipment
To view the full warranty, go to
www.sentry-equip.com/warranty.
General Safety Precautions
Product Selection, Installation, and Use
Improper selection, installation, or use can cause personal injury or property damage.
It is solely the responsibility of users, through their own analysis and testing, to select
products suitable for their specic application requirements, ensure they are properly
maintained, and limit their use to their intended purpose.
Follow proper local, state, and federal regulations for proper installation and operational
requirements.
Always use caution and common sense when working with any chemical. Read
the product label and Material Safety Data Sheets (MSDS) carefully and follow the
instructions exactly.
Potential Equipment Hazards
Hot surfaces! This equipment may have very hot surfaces. If an operator contacts a hot
surface, injury may occur. Use protective clothing to prevent injury. If other equipment
comes in contact with a hot surface, damage to the equipment may occur. Ensure the
area around this equipment is kept clear to prevent this damage from occurring.
High pressures! This equipment may contain uids at very high pressures. Prior to
installing, removing, or maintaining this equipment, ensure that the equipment is
isolated from all connecting piping, the equipment is depressurized, the contents have
been drained, and the equipment is cool.

General Description:
Sentry® Drip Pot Assemblies are ideal for collecting liquid samples for analysis. Drip
pots are constructed from corrosion resistant 316L stainless steel and incorporate
a needle valve on the main chamber to release excess gas pressure. A liquid
sample can then be safely drawn from the lower ball valve. An optional corrosion
coupon allows for simultaneous corrosion analysis and liquid collection. The
corrosion coupon is attached to the bottom of the assembly with a Fixed Coupon
Holder Plug.
Installation
Read instructions thoroughly before installing or using equipment. Contact your
representative or factory customer service if you have any questions. Failure to follow
these instructions could result in serious injury or death.
Tools needed
Large adjustable wrench
Screwdriver
Moly Anti-Seize lubricant
Teon tape
Unpacking
After carefully removing the Sentry DPA Series sample collection device from its
shipping carton, inspect it for any damage. If damage is evident, please contact
Sentry Equipment immediately.
Installation Instructions
1. Close and lock the process isolation valve to prevent incidental opening while
installing the unit.
a. Check the female threads of the process connection for any aws or visible
damage.
2. Secure Drip Pot Assembly to process isolation valve connection.
a. Apply Teon tape and Molly Anti-Seize lubricant to the top of the Drip Pot
inlet threads.
b. Make sure that the bleeder valve is closed completely.
3. Install Drip Pot Fixed Coupon Holder Plug.
a. Install Coupon(s) to the Lower Plug.
b. Apply Teon tape and Moly Anti-Seize lubricant to the Lower Plug Threads.
Operation
Sample Collection
1. Slowly close the process isolation valve.
2. Open the bleeder valve to relieve any trapped pressure.
3. Open sample valve and hold container under valve.
4. Collect sample uid.
Coupon Removal
1. Slowly close the process isolation valve
2. Open the bleeder valve to relieve any trapped pressure.
3. Open sample valve to remove excess uid
4. Remove the xed lower plug from the drip pot assembly.
5. Replace coupon as required.
Maintenance
1. Wipe out the drip pot to dry once the coupon plug is removed from the
bottom.
2. The coupon holder plug should have the threads cleaned with a wire brush.
3. Once cleaned, apply new layers of Teon tape and a swipe of Moly Anti-Seize
lubricant to the Lower Plug threads.
4. All valves will wear over time and will eventually need to be replaced.
Customer Support
With proven sampling expertise since 1924, Sentry products and services
provide business operations the critical insights to optimize process control and
product quality. We deliver true representative sampling and analysis techniques
to customers around the globe, empowering them to accurately monitor and
measure processes for improved production efficiency, output, and safety.
Standing behind our commitments, we are determined to tackle any application,
anywhere.
We know that running an efficient operation isn’t easy. It requires thorough,
careful analysis of controlled, real-time data achieved through reliable, accurate,
and repeatable process monitoring and measuring. By effectively conditioning,
sampling, and measuring gas, liquid, slurry, powder, solids, steam, or water within
their production environments, our customers obtain the critical insights they
need to control and optimize their processes.
Yet, controlling your processes also means reliable customer support throughout
the life cycle of your equipment.

Customer Service—General information, warranty claims, order management.

Installation Service—For systems that require specialized expertise upon
installation.

Technical Support—Troubleshooting, training, and technical manuals.

Field Service & Retrots—When a problem needs immediate attention.

Replacements Parts & Consumables—Order your replacement parts and
consumables.

Sentry ProShield Services—Select from four ProShield Guardian service plans
providing different levels of support to protect your large system investments
with regularly scheduled maintenance.
To learn more, go to
www.sentry-equip.com/support.
