Sentryus SD-771-60S Quick start guide

Copyright © 2010. All rights reserved. 1 REV122010-V28
www.SentryUS.com
Owner’s Operational Manual
Mechanical Keyless Push Button Door Lock
Features
•Passage Function – Always Unlocked
•Hold Back Function – Always Unlocked w/ Non-Latching
*Door Closer Recommended
*Inside Handle is down
•Disable Code Function – Night Latch
*Inside Handle is up
•Easy Code Combination Changing w/ over 16,000 Codes
Special Functions
1. Passage Function – Always Unlocked
Enter correct codes, turn the inside handle to 6 o'clock position and keep
the handle in downward position. Turn the passage knob from 12 o'clock to
9 o'clock position. Release the handle. Now you can open the door without
a code. See fig. 1 – fig. 4.
To cancel the Passage Function, turn the inside handle to the 6 o’clock
position and turn the passage knob back to the 12 o’clock position.
Fig. 1 Fig. 2 Fig. 3 Fig. 4
Please read the Operational Manual before attempting to use this product.
Installation manual subject to change without prior notice from the manufacturer.
Locks, cards, sensor and power adaptor not included.
•
Suitable for Inside: Right Hand & Left Hand
Outside: Right Hand & Left Hand
•Color: Satin Chrome Finish 626 / US Code 26D
•No Software Required; Audit Free
•Keyless Entry Lock; No Batteries Required
SD-771-60S 2 3/8” / 60mm Backset
SD-771-70H 2 3/4” / 70mm Backset

Copyright © 2010. All rights reserved. 2 REV122010-V28
www.SentryUS.com
2. Hold Back Function – Always Unlocked with Non-Latching
Turn the inside handle down from 3 o’clock position to 6 o’clock position. Then slide
the latch stopper from right to left to keep the hand down.
*A door closure is recommended.
v
3. Disable Code Function – Night Latch
This function is enabled as factory
default. If your door is right hand, turn the
inside handle to 12 o’clock position and
slide the latch stopper from left to right to
keep the hand up (see fig. 5).
To disable function, screw the BLACK
handling screw to the right hole as seen
in fig. 6.
Changing the Code
The Factory Default code is 13579. Slide the code pin from the NON CODE position to
CODE position and the code number will be the new code number. The CLEAR button
MUST ALWAYS be used as the first digit of a code. For security reasons, the code must
be more than 4 digits. Check to see if the new code works before installation.
Note: Entering the code in any sequence will open the door. i.e. 13579 or 97351.
Fig. 5 Fig. 6
