Lockey 2230 eries Latchbolt Keypad Lock

Product Overview

Lockey 2230 Latchbolt Lock

LOCK EVERY TIME! If you want a lock that locks each and

every time the door is closed, then this is the lock for you. It also

comes with a LIFETIME Warranty. If you want a hold back

device to prevent it from locking, check out the 2435.)

The latchbolt is set in the hole in the door where the deadbolt

normally goes, so this lock installs and operates very much like a

standard deadbolt lock. However, the latchbolt head also

contains a burglar-proof plunger for added safety.

Lockey 2230DC Latchbolt Lock

MORE ECURE FOR POOL & GARDEN GATE ! This

double-sided keyless combination lock is most commonly used

on play areas, pool gates, garden gates, or fences, in short, any

access door that requires a combination to enter AND to exit. It

also comes with a LIFETIME Warranty.

The double-sided combination lock can be programmed with

same or different combinations on either side. This lock has a

spring latchbolt that will automatically lock itself when the gate is

closed. To unlock, simply enter your secret code and turn the

knob to retract the spring latch.

Lock Features

•This lock is a latchbolt lock, which means it locks automatically when the door is shut.

•This lock can be used on doors from 1-3/16" to 2" thick. If your door is between 2" to 5" please

order the 2000 Series PT12 Lockey Extension Kit.

•Comes with a 2 3/4" or 2 3/8" backset. If you are planning to use this lock with our PT01

Lockey Gate Box, be sure to order the 2-3/8" latchbolt.

•Covers a 2-1/8" hole.

•This lock has adjustable handedness which means it can be changed from right to left hand

doors.

•We offer a PT02 Lockey Over-sized Knob for this lock that fits over the outside knob.

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 3 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Product Overview

Advantages

1. Comes with a Manufacturer's Lifetime Warranty.

2. Hacksaw-proof, bump-proof and cannot be picked.

3. Never again worry about lost, stolen or copied keys.

4. AC power, wires, or batteries aren't needed--this lock

is completely mechanical. Therefore, power failures

don't affect lock.

5. Easy installation on standard doors.

6. Mechanical reliability.

7. Completely weatherproof finishes.

8. Pays for itself the first time you change your

combination.

Key Overrides

A key override is a handy option that lets you lock and unlock these locks using a key OR a

combination. This is really great if you have multiple locks with different combinations.

•A key override is available on most 2000 series locks.

•If you order more than one lock with the key override option, you

have the option to have them keyed alike or keyed differently.

•Locks with key overrides are installed exactly the same way as

regular locks. If you want to make additional key copies, please

order the PT19 Lockey Key Blank.

•Lockey key override locks cannot be keyed alike to any other

brand.

•This popular item is available in most finishes. Please see below

for available finishes.

•The additional cost is added at the time you add an item to your cart.

•Manufacturer's Lifetime Warranty does not apply to locks with key override.

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 4 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Product Overview

Elegant Lock Finishes

Our locks also have a new 7-coat finish, heavy duty zinc alloy, stainless steel and brass components

and new, changeable brass combination pins. There are many beautiful finishes subject to

availability) to complement a luxury home, modern office, or stylish garden gate:

What's in the Box

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 5 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Product Overview

Lockey 2230 Lock Dimensions

Height Width Depth

Outside Lock Body without knob) 5-1/2 in 1-5/8 in 7/8 in

Outside Lock Body with knob) 5-1/2 in 1-5/8 in 2 in

Inside Lock Body without thumb

turn) 5-1/2 in 1-5/8 in 3/8 in

Inside Lock Body with lever thumb

turn) 5-5/8 in 1-9/16 in 1-1/2 in

Outside Knob 1-3/4 in 1-3/4 in 1-1/8 in

Inside Thumb Turn 1-3/8 in 1/2 in 3/4 in

Trim Plate 6-1/2 in 2-1/2 in 1/4 in

Strike Plate 1 in 2-11/16 in 7/16 in

Spindle 3-3/8 in 1/4 in 1/8 in

Note: If you are going to install this lock underneath an existing dead bolt, you will need at least 4-

5/8 inches from the bottom of the dead bolt down to the center of the large 1 inch hole for this lock.

Lockey 2230DC Lock Dimensions

Height Width Depth

Outside Lock Body without knob) 5-1/2 in 1-5/8 in 7/8 in

Outside Lock Body with knob) 5-1/2 in 1-5/8 in 2 in

Inside Lock Body without thumb

turn) 5-1/2 in 1-5/8 in 7/8 in

Inside Lock Body with lever thumb

turn) 5-1/2 in 1-5/8 in 2 in

Outside Knob 1-3/4 in 1-3/4 in 1-1/8 in

Inside Thumb Turn 1-3/8 in 1/2 in 3/4 in

Trim Plate 6-1/2 in 2-1/2 in 1/4 in

Strike Plate 1 in 2-11/16 in 7/16 in

Spindle 3-3/8 in 1/4 in 1/8 in

Note: If you are going to install this lock underneath an existing dead bolt, you will need at least 5-

3/4 inches from the bottom of the dead bolt down to the center of the large 2-1/8 inch hole for this

lock.

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 6 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Installation

Installation

This replaces or can be used with your existing deadbolt, latchbolt, or dummy lever.

etting your ecret Code

Please note this lock is shipped with 6 red code) and 9 blue non-code) tumblers. This allows for a 6

digit code. If you would like to use more or less letter/numbers, please add PT05 Tumblers to your

cart.

Want us to set your initial secret code? Simply select the "Custom" option under the Initial Secret

Code section below and enter your desired custom code no repeating digits) in the text box. Your

code can be anywhere between 3 and 5 digits.

Locking and Unlocking

Using all our keyless digital locks is quick and easy.

For the 2230, the lock can be unlocked by just turning the thumb turn. On the inside, you don't need

the combination to lock this lock--just turn the knob. To unlock, simply type in your secret code on the

keypad and turn the knob to retract the latchbolt. You'll be amazed at how easily it works!

For the 2230DC, the lock is double-sided meaning it has a knob handle on both the inside and outside

bodies to open the door. To unlock from the inside and outside, simply type in your secret code on the

keypad and turn the knob to the right to retract the latchbolt and open the door. It couldn't be easier!

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 7 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Lockey 3230 Series Latchbolt Keypad Lock

Lockey 3230 eries Latchbolt Keypad Lock

Product Overview

Lockey 3230 Marine-Grade Latchbolt Lock

MADE FOR HAR H, ALT-WATER ENVIRONMENT ! If

you are looking for a heavy duty single-sided latchbolt lock

that is made for salt water environments, then take a look at

this one. This lock is teflon coated to resist salt water and

blowing sand. It also comes with a LIFETIME Warranty.

Our special Teflon finish, Marine Grade, protects your lock

from harsh salt water environments as well as corrosion.

Lockey 3230DC Marine-Grade Latchbolt Lock

MARINE GRADE! If you are looking for a heavy duty double-sided

lock that is made for salt water environments, then take a look at this

one. This lock is teflon coated to resist salt water and blowing sand.

It also comes with a LIFETIME Warranty.

This lock has a latchbolt which will automatically lock when the door

is closed. To unlock, simply enter your secret code, turn knob to

retract the latchbolt.

Lock Features

•This is a latchbolt lock, which means it locks automatically when the door is shut.

•Marine Grade finish to protect from salt-water environments.

•Comes with a 2 3/4" or 2 3/8" backset. If you are planning to use this lock with our PT01

Lockey Gate Box, be sure to order the 2-3/8" latchbolt.

•This lock can be used on doors from 1-3/16" to 2" thick. If your door is between 2" to 5" please

order the 3000 Series PT12 Extension Kit.

•Covers a 2-1/8" hole.

•This lock has adjustable handedness which means it can be changed from right to left hand

doors

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 8 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Product Overview

Advantages

1. Comes with a Manufacturer's Lifetime Warranty.

2. Hacksaw-proof, bump-proof and cannot be picked.

3. Never again worry about lost, stolen or copied keys.

4. AC power, wires, or batteries aren't needed--this lock is completely mechanical. Therefore,

power failures don't affect lock.

5. Easy installation on standard doors.

6. Mechanical reliability.

7. Completely weatherproof finishes.

8. Pays for itself the first time you change your combination.

Lockey 3230 Lock Dimensions

Height Width Depth

Outside Lock Body without

knob) 6-1/4 in 1-3/4 in 7/8 in

Outside Lock Body with knob) 6-1/4 in 1-3/4 in 2-1/8 in

Inside Lock Body without knob) 5-1/4 in 1-3/4 in 1-3/4 in

Inside Lock Body with knob) 5-1/4 in 1-3/4 in 2 in

Outside Knob 1-3/4 in 1-3/4in 1-1/4 in

Inside Knob 1-7/16 in 1-7/16 in 1-1/4 in

Trim Plate 7 in 2-1/2 in 1/4 in

Strike Plate 1-1/2 in 2-3/4 in 1/2 in

Note: If you are going to install this lock underneath an existing dead bolt, you will need at

least 4-5/8 inches from the bottom of the dead bolt down to the center of the large 1 inch

hole for this lock.

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 9 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

©KeylessEntryLocks.com ©KeylessEntryLocks.com

©KeylessEntryLocks.com ©KeylessEntryLocks.com ©KeylessEntryLocks.com

Lockey 2210/3210 Locks Section: Product Overview

Lockey 3210DC Lock Dimensions

Height Width Depth

Outside Lock Body without

knob) 6-5/16 in 1-3/4 in 1 in

Outside Lock Body with knob) 6-5/16 in 1-3/4 in 2-1/16 in

Inside Lock Body without knob) 6-5/16 in 1-3/4 in 1 in

Inside Lock Body with knob) 6-5/16 in 1-3/4 in 2-1/16 in

Outside Knob 1-3/16 in 1-3/16 in 1-5/16 in

Inside Knob 1-3/16 in 1-3/16 in 1-5/16 in

Trim Plate 7-1/16in 2-1/2 in 3/16 in

Strike Plate 2-3/4 in 1-7/16 in 1/2 in

Note: If you are going to install this lock underneath an existing dead bolt, you will need at

least 4 inches from the bottom of the dead bolt down to the center of the large 1 inch hole

for this lock. The bore hole should be between 1 inch to 2-1/8 inches.

Installation

This replaces or can be used with your existing deadbolt, latchbolt, or dummy lever.

etting your ecret Code

Please note this lock is shipped with 6 red code) and 9 blue non-code) tumblers. This allows for a 6

digit code. If you would like to use more or less letter/numbers, please add PT05 Tumblers to your

cart.

Want us to set your initial secret code? Simply select the "Custom" option under the Initial Secret

Code section below and enter your desired custom code no repeating digits) in the text box. Your

code can be anywhere between 3 and 5 digits.

Locking and Unlocking

Using all our keyless digital locks is quick and easy.

For the 3230, the lock can be unlocked by just turning the thumb turn. On the inside, you don't need

the combination to lock this lock--just turn the knob. To unlock, simply type in your secret code on the

keypad and turn the knob to retract the latchbolt. You'll be amazed at how easily it works!

For the 3230DC, the lock is double-sided meaning it has a knob handle on both the inside and outside

bodies to open the door. To unlock from the inside and outside, simply type in your secret code on the

keypad and turn the knob to the right to retract the latchbolt and open the door. It couldn't be easier!

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 10 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

Lockey 2210/3210 Locks Section: Contact & Warranty Information

Contact & Warranty Information

ales Contact Information

Phone: 630) 909-9504

Email: [email protected]

Technical upport

Phone: 630) 909-9504

Email: [email protected]

Warranty Information

LockeyUSA / Digital Systems

Phone: 989) 773-2363

Keyless Entry Locks For current prices, please visit our website. www.KeylessEntryLocks.com

46 Danada Sq West #4133 Phone: 630) 909-9504

Wheaton, IL 60189 Page 11 of 11 FAX: 630) 447-3635

[email protected] Path: Z:\KEY\suppliers\Lockey\website-KEL-zc\_dev\pdfs odified 08/12

This manual suits for next models

Table of contents

Other Keyless Entry Door Lock manuals

Keyless Entry

Keyless Entry iButton Eternity Series Operating instructions

Keyless Entry

Keyless Entry CG-PK User manual

Popular Door Lock manuals by other brands

Yale

Yale Assure Lock 2 Touch manual

Camos

Camos EASY HOME user manual

SDC

SDC E75 Series Programming guide

Rogers

Rogers Weiser Touchscreen Manufacturer's installation guide

Techno CNC Systems

Techno CNC Systems Patriot Troubleshooting

Strand

Strand PH381 instructions

ZKTeco

ZKTeco AL20DB user manual

Toledo

Toledo CV180BLEUS15 INSTALLATION AND PROGRAMING INSTRUCTIONS

ESP

ESP EZ-TAG2 user manual

Assa Abloy

Assa Abloy SARGENT 10X Series installation instructions

GeekTale

GeekTale K02 user manual

Carbine

Carbine CDL-SL8 Installation instruction

uhlmann & zacher

uhlmann & zacher CX2162 Operating and assembly manual

Coastal

Coastal KM078 Fitting instructions

Samsung

Samsung SHP-R80 user manual

Assa Abloy

Assa Abloy Corbin Russwin ED3400 Series installation instructions

Maco

Maco ML196 Product information

Lockly

Lockly SECURE PRO installation guide

Keyless Entry Lockey 2230 Latchbolt Installation guide

Popular Door Lock manuals by other brands
