Serato Allen & Heath Xone:43C User manual

QUICK-START
GUIDE
ALLEN & HEATH
XONE:43C

Installation and Setup
To activate Serato DJ with the Allen & Heath XONE:43C it requires a
Serato DJ license to be purchased and activated on your user account.
The Xone:43C also requires the DVS Expansion Pack to be purchased and
activated before unit can be used with NoiseMap™ control tone to control
DVS playback. You can purchase both products here.
The Allen & Heath XONE:43C requires drivers on both Mac OS X and
Windows. Please make sure you have the latest drivers installed. It is
always important to connect your mixer directly to your computer, rather
than a USB hub. Please also ensure you have installed the latest available
version of Serato DJ.
To use the DVS Expansion Pack with the XONE:43C you will need to follow
the steps in the DVS Control section.

1
# XONE:43C Control Function
1 ON/OFF Power ON/OFF switch
2 KENISNGTON LOCK Connect a Kensington lock to secure mixer
3 PHONO/LINE Connect RCA phono or line level inputs
4 CHANNEL INPUT SOURCE Select channel input source (Phono/Line)
5 GROUNDING POST Connect grounding wire from turntables
6 BOOTH Booth RCA output
7 RECORD Record RCA output
8 X-FX SEND Send out to X-FX unit
9 X-FX RETURN Return in from X-FX unit
10 MASTER Master XLR output
11 X-LINK Connect to link to another X-LINK device
12 USB Connect USB to your computer
13 DC POWER IN Connect DC power cable
432
678910111213
5
Mixer
PHONO
LINE
PHONO
LINE
PHONO
LINE
PHONO
LINE
MASTER RECORD
X:FX
RTNS ND
X:FX
BOOTH

#XONE:43C Control Function
1 MIC SECTION Input and controls for a microphone
2 TRIM Adjust channel trim volume
3 CHANNEL INPUT SOURCE Select channel input source
4 TOTAL KILL EQ Channel EQ controls
5 LED OUTPUT METER Displays output levels
6 MASTER Master output volume
7 BOOTH Booth output volume
8 FILTER SECTION XONE:43C lter controls
9 CROSSFADER CURVE Adjust crossfader curve
10 X/FADE X/Y Select channel crossfader assign
11 CHANNEL VOLUME FADER Control channel volume
12 CROSSFADER Fade audio between channels
13 FILTER ON/OFF Channel Filter On/Off
14 X-FX X-FX Dry/Wet control
15 CUE Monitor channel cue
16 HEADPHONE SECTION Input and control headphone output
XONE:43C User Guide
For further information on XONE:43C controls and details on indvidual Menu
features please refer to the Allen & Heath XONE:43C Hardware User Guide.
Download the XONE:43C User Guide from the Allen & Heath website here.
42
12 11 1013141516 9
3
1
8
7
6
5

DVS Control
To use the Allen & Heath XONE:43C mixer with DVS control and Serato DJ,
you will rst need to own a Serato DJ licence and a DVS Expansion Pack
licence (these two products have been bundled together as the Club Kit).
Click here to purchase the club kit.
Once you have purchased and activated the Club Kit (or individual licences
separately) follow the steps below to get DVS control working with your
Allen & Heath XONE:43C mixer.
Install Drivers
Connect your mixer and open the latest version of Serato DJ. You should
see an ‘INSTALL DRIVER’ dialogue box appear in the right hand side-
panel. Click ‘INSTALL DRIVER’ and follow the installer prompts. If you don’t
have the supported hardware with you right now you can still download the
driver from the hardware manufacturers website.
Select Input source
Once your turntables or CDJs are connected to the mixer, check that you
are using the correct input setting on the back of the mixer. If you have
connected an analogue source (like turntables), make sure you have the
input set to PH (Phono), if you have connected a digital source (like CDJs)
make sure it is set to LN (Line) accordingly.
Select Primary Decks
Open the SETUP screen and click the AUDIO tab, here you will need to
select your Primary Decks.
Choosing Channel 1 and 2, will allow you to have a traditional 1-2-3-4
channel conguration. Choosing Channel 2 and 3 will allow you to have
a 3-1-2-4 conguration (from left to right across the mixer).
Select which deck conguration you are using with the mixer and change
if necessary. If you notice you are getting signal from your control tone but
on the wrong deck, you might need to double-check your Primary Decks in
the SETUP screen or the physical inputs on the back of the mixer.
You are now set up to use your mixer with Serato DJ and DVS control
using the REL or ABS control modes. See the Serato DJ software manual
for more information on Control Modes.

Using the Tool Tips
Click on the icon to enable Tool Tips. This is located in between the
MIDI and setup button in the top right hand corner of the screen. Tool Tips
provide a handy way to learn the various features of Serato DJ.
Move the mouse over a section of the screen to bring up a context sensitive
tool tip. Holding the mouse over the button with Tool Tips turned on
will show you a list of all keyboard shortcuts.
For more information about how to use Serato DJ, please go to our website
www.serato.com or download the Serato DJ Manual.
For more information on your XONE:43C, please refer to the Allen & Heath
XONE:43C manual which can be downloaded from allen-heath.com.
For further help, please email [email protected] or go to serato.com/
support
Recording
To record your mixes with Serato DJ and the XONE:43C you will need to
designate a mixer channel to use for recording. You will not be able to use
this channel in Serato DJ while it is used for recording.
Connect an RCA cable from the Record output on the back of the mixer to
the input of the channel you have nominated. Open the REC panel inside
Serato DJ and select this channel as your recording input. This will record the
software mix.
See the XONE:43C User Guide for more information.
MIDI
The MIDI feature in Serato DJ provides the ability to remap Serato DJ
software functions to your primary Serato DJ controller, interface or mixer.
You can also assign controls to a secondary MIDI controller to further
enhance your performance.
For more information on MIDI mapping with Serato DJ click here.
To remap your supported Serato DJ device, open the SETUP screen and
click the MIDI tab. If your Serato DJ device supports hardware remapping it
will show up in the MIDI Devices list at the top.
Select your connected device from the MIDI Devices list and make sure the
“Enable MIDI device” option is checked.
Once checked, the MIDI assign button at the top of the screen will become
available for you to start remapping.
You can save, edit or delete MIDI presets in the MIDI tab of the SETUP
screen. Clicking ‘Restore Defaults’ will erase any custom mappings for all
connected devices and revert their functions back to default.
Download the Serato DJ software manual for further information.
NOTE: Ofcial Serato Accessories do not currently support user remapping.
Hardware features that cannot be remapped at this stage are Jogwheels/
Platters, Input Switches, Shift buttons and Performance Pad Mode buttons.
Re-mapping any pad(s) in Hot Cue mode will also re-map the same pad in
Saved Flip mode and vice versa.
