Serato Reloop RP-8000 User manual

QUICK-START
GUIDE
RELOOP
RP-8000

Installation And Setup
The Reloop RP-8000 is a class compliant USB plug and play device and requires no
further driver installation.
NOTE: The Reloop RP-8000 is an additional controller that will only work in addition
to supported Serato DJ hardware. Click here to see a list of supported Serato DJ
hardware.
• Download and install the latest version of Serato DJ from http://serato.com/
dj/downloads
• Connect your supported Serato DJ hardware to a USB port.
• Connect your Reloop RP-8000 to an available USB Port.
• Open Serato DJ.
# Reloop RP-8000
control
Function
1PHONO/LINE Use standard RCA cables to connect this
output to a mixer or audio interface
2PH/LN Toggle between phono and line level output
3USB Connect USB cable to this port from computer
or from master RP-8000
4TT LINK Use a USB A to USB B cable to connect a
second RP-8000. You can connect up to 4
RP-8000's in this way
5230V/115V Toggle voltage setting between 230v & 115v
6AC IN Use the included power cable to connect to a
power outlet
1 2 3 4 5 6

START/STOP
START/STOP
1
15
14
13
12
11
10
7 8 96
5
4
3
2
Controller

# Reloop RP-8000 Control Function
1 START/STOP Press to Start/Stop the platter
2 TRAX/BROWSER Turn to browse through currently focused area (library/crates/open panels). Click once to load track to deck. Hold down to
toggle focus between Library and Crates. Double Tap for instant doubles.
3 PERFORMANCE PADS See performance pads section for more information on this section.
4 POWER Toggle power ON/OFF
5 START/STOP Press to Start/Stop the platter
6 REVERSE Press to toggle play direction of the platter
7 33 Press to change platter rotation speed to 33RPM. Press in conjunction with the "45" button to change the platter rotation
speed to 78RPM.
8 45 Press to change platter rotation speed to 45RPM. Press in conjunction with the "33" button to change the platter rotation
speed to 78RPM.
9 QUARZLOCK Press to lock pitch at +/- 0% regardless of pitch fader position
10 PITCH FADER Move to adjust the pitch of the platter
11 +/- 8 Change pitch range to +/- 8%. Press in conjunction with the "+/- 16" button to change the pitch range to +/-50%
12 +/- 16 Change pitch range to +/- 16%. Press in conjunction with the "+/- 8" button to change the pitch range to +/-50%
13 LCD DISPLAY Shows pitch information and used when selecting active deck
14 START/BRAKE Turn to adjust the start and stop time of the platter
15 TORQUE Turn to adjust the torgue of the turntable

Using the Tool Tips
Click on the icon to enable Tool Tips. This is located in between the
MIDI and setup button in the top right hand corner of the screen. Tool
Tips provide a handy way to learn the various features of Serato DJ.
Move the mouse over a section of the screen to bring up a context
sensitive tool tip. Holding the mouse over the button with Tool Tips
turned on will show you a list of all keyboard shortcuts.
For more information about how to use Serato DJ, please go to our
website www.serato.com or refer to the Serato DJ Software Manual.
For more information on your controller, please refer to the hardware
manual.
For further help, please contact [email protected] or go to
www.serato.com/dj/support
Performance Pads
The performance pads have 4 different basic modes you can select. The modes
are; Hot Cue, Auto Loops, Sampler and User.
• HOT CUE Mode: Press “CUE” to activate this mode. When pressing
performance pads 1-8 you can add and trigger up to 8 Cue Points.
• LOOP Mode: Press “LOOP” to activate this mode. When pressing buttons 1-8
you can activate an Auto Loop. The Loop Length ranges from 1/4 to 32 bars.
• SAMPLER Mode: Press “SAMPLER” to activate this mode. Pads 1-6
Trigger Samples loaded in your Sample Banks.
• SLICER Mode: Press “USER” to activate “SLICER MODE”. A specied
range (or domain) is divided into eight equal sections, and these eight
sliced sections are assigned to the respective pads. Pads 1-8 will allow
you to trigger each slice. Holding the USER button while using Pads 1 & 2,
adjusts Quantization of the slicer function. The quantization can be set to:
1/8, 1/4, 1/2 and 1 beat/s. Holding the USER button while using Pads 7 & 8,
adjusts the Domain. The domain can be set to: 2 beats, 4 beats, 8 beats, 16
beats, 32 beats or 64 beats.
You can also combine modes and use two functions at once by pressing CUE
and LOOP, LOOP and SAMPLE or CUE and SAMPLE at the same time. The 8
pads will be divided with 4 pads for one function and 4 for another.
