Sharp AR-122E N User manual

CONTENTS
Parts marked with “ ” are important for maintaining the safety of the machine. Be sure to replace these parts
with the replacement parts specified to maintain the safety and performance of the machine.
SHARP CORPORATION This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
SERVICE MANUAL
CODE : 00ZAR157ENA1E
DIGITAL LASER COPIER/
PRINTER
AR-122E N
AR-123E
AR-152E N
AR-153E N
MODEL AR-157E N
(AR-157E N)
The AR-122E N/AR-123E/AR-152E N/AR-153E N/AR-157E N Service Manual describes
only changed from AR-122E/AR-152E/AR-153E/AR-157E Service Manual.
For the common contents, please refer to the AR-122E/AR-152E/AR-153E/AR-157E
Service Manual (Code: 00ZAR157E/A1E)
[ 1 ] GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
•Parts Guide
MODEL Reference MODEL
1 AR-122E N AR-122E
2 AR-123E AR-153E
3 AR-152E N AR-152E
4 AR-153E N AR-153E
5 AR-157E N AR-157E

AR-122E N/AR-123E/AR-153E N/AR-157E N GENERAL 1 - 2
[1] GENERAL
1. Major functions
Configurations
Descriptions of items
CPM: Copy speed (Copies Per Minute)
SB/MB: SB = Manual feed single bypass, MB = Manual feed multi bypass
2 tray: Second cassette unit.
SPF: Original feed unit
R-SPF: Duplex original feed unit
Color scanner: Color scanner function
GDI printer: GDI printer function with USB.
PCL printer: PCL printer function with USB.
SOPM: Scan Once Print Many function (Many copies are made by one scan.)
Duplex: Auto duplex copy function
Memory: Standard page memory
FAX: FAX function.
Descriptions of table
: Standard provision
: No function or no option available
Opt: Option
∗1: AL-12PK/M
∗2: AR-PG2
Item
CPM SB/MB 2 Tray SPF R-SPF Color
Scanner
GDI
printer
PCL
printer SOPM Duplex Memory FAX
Model
AR-122E N 12CPM SB Opt ∗1Opt
∗18M
AR-123E 12CPM SB Opt Opt Opt ∗1Opt
∗18M
AR-152E N 15CPM SB Opt ∗1Opt
∗18M
AR-153E N 15CPM MB Opt Opt Opt ∗2Opt
∗28M
AR-157E N 15CPM MB Opt ∗2Opt
∗2 16M
AR-122E N/123E/152E N/153E N AR-157E N
AR-SP5
AR-D16
(Options)
AR-PG2AL-12PK/M

AR-122E N/AR-123E/AR-153E N/AR-157E N GENERAL 1 - 3
2. Maintenance display system
*1: Installation of a new toner cartridge allows to display the remaining quantity.
The remaining toner indication is based on the number of revolutions of the toner motor.
3. Remaining toner indication
• The remaining toner indication is based on the number of revolutions of the toner motor.
• The toner END indication appears when the END is detected by the toner sensor, or when the number of revolutions of the toner motor reaches a
given number (equivalent to 8K), whichever comes first.
Toner
Life 8K
Remaining quantity
check *1
a. Press and hold the density adjustment LIGHT key for more than 5 sec, and the machine will enter the user
program mode.
b. Press and hold the "%" key for more than 5 sec, and the remaining quantity will be displayed on the copy
quantity display in one of the following levels: (Remaining quantity display levels: 100%, 75%, 50%, 25%,
10%, LO)
c. Press the density adjustment LIGHT key to cancel.
Remaining quantity NEAR EMPTYAbout 10% EMPTY
LED ON Flash
Machine Operation allowed Stop
Developer
Life 25K
LED ON at 25K of the developer count.
Machine
Selection is available between Not Stop and Stop by Service Simulation (SIM 26-37) Setup.
(If Stop is selected, the LED will flash and stop at 25K.)
* Default: Not Stop
* Clear: SIM 24-06
Maintenance LED
Selection is available among 25K, 13K, 9K, 6K, 3K, and free (no lighting) with SIM 21-1.
* Default: 25K
* Clear: SIM 20-1
Machine Not stop.
TONER FULL
Remaining toner indication Display for users
Indicator
100%
75%
50%
25%
Lo
LOW LEVEL
100-90% 89-75% 74-50% 49-25% 24-10% 10% 10 sheets
NEAR END END

AR-122E N/AR-123E/AR-153E N/AR-157E N GENERAL 1 - 4
4. Additional simulation and trouble code
•Simulation
•Trouble codes
Main
code
Sub
code Content
26 55 CRUM Destination Indication
When the simulation is executed, the CRUM destination currently set (saved) in the CRUM chip is displayed.
Main code Sub code Trouble content
F2 04 Toner cartridge error
U2 40 Main IC chip read error
Code number Setup
00 No set
01 BTA-A
02 BTA-B
03 BTA-C
99 Conversion

qPARTS GUIDE
CONTENTS
Because parts marked with "!" is indispensable for the machine safety maintenance and poeration, it must
Be replaced with the parts specific to the product specification.
SHARP CORPORATION
This document has been published to be used for
after sales service only.
The contents are subject to change without notice.
CODE:00ZAR157EN/P1
DIGITAL LASER COPIER /
PRINTER
AR-122E N
AR-123E
AR-152E N
AR-153E N
MODEL AR-157E N
1Exteriors
3RSPF exteriors (AR-157E N)
4RSPF transport unit (AR-157E N)
6Operation panel
7Side door unit
8Optical frame
FDelivery paper guide unit
GMiddle frame
HBase plate unit 1
IBase plate unit 2
JFusing unit
KDrive unit
NSingle manual paper feeding unit
(AR-122E N/123E/152E N)
R250 sheets tray
SHarness
VPacking material & accessories
XMCU PWB
■Index
The AR-122E N/AR-123E/AR-152E N/AR-153E N/AR-157E N Parts Guide describes only changed from
AR-122E/AR-152E/AR-153E/AR-157E Parts Guide.
For the common parts, please refer to the AR-122E/AR-152E/AR-153E/AR-157E Parts Guide
(Code: 00ZAR157E//P1)
[Note]
MODEL Reference MODEL
AR-122E N
AR-123E
AR-152E N
AR-153E N
AR-157E N
1
2
3
4
5
AR-122E
AR-153E
AR-152E
AR-153E
AR-157E
(AR-157E N)

– 1 –
DEFINITION
The definition of each Rank is as follows and also noted in the list
A: Parts necessary to be stocked as High usage parts.
B: Parts necessary to be stocked as Standard usage parts.
C: Low usage parts.
D: Parts necessary for refurbish.
E: Unit parts recommended to be stocked for efficient after sales service.
Please note that the lead time for the said parts may be longer than normal parts.
S: Consumable parts.
Please note that the following parts used in Copier under the same description are classified into A or B Rank depending upon
the place used.
Example: Gear made of Metal, Sprocket, Bearing, Belt made of Rubber, Spring clutch mechanism.
ARank : The parts which may be with the revolution or loading.
BRank : Parts similar to A Rank parts, but are not included in Rank A.
Because parts marked with "!" is indispensable for the machine safety maintenance and operation, it must be replaced with
the parts specific to the product specification.
FOther than this Parts Guide, please refer to documents Service Manual(including Circuit Diagram)of this model.
FPlease use the 13 digit code described in the right hand corner of front cover of the document, when you place an order.
FFor U.S. only-Use order codes provided in advertising literature. Do not order from parts department.
1Exteriors
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
1CCAB-0003QS23 AS D Front cover (AR-122E N/123E/152E N)
CCAB-0003QS26 AS D Front cover (AR-153E N/157E N)
12 GCOV-0045QSZZ AG D Rear cover SPF (AR-157E N)
GCOV-0045QSZ1 AG D Rear cover OC (AR-122E N/123E/152E N/153E N)
16 PCOVP0035QSJZ AL D Rear exterior cover JAG (AR-122E N/152E N)
PCOVP0040QSJZ AL D Rear exterior cover SPF (AR-123E/153E N/157E N)
17 GCAB-0062QSZ1 AL D Right exterior OC (AR-122E N/152E N)
GCAB-0062QSZZ AL D Right exterior (AR-123E/153E N/157E N)
18 GCAB-0021QSJ1 AY D Rear exterior (AR-122E N/152E N)
GCAB-0026QSJ2 AZ D Rear exterior SPF (AR-123E/153E N/157E N)
22 PTPE-0044QSZZ AC C Slit glass tape (AR-123E/153E N/157E N)
23 PGLSP0008QSZZ AH B SPF glass (AR-123E/153E N/157E N)
24 PSHEZ0181QSJZ AC C Rear cabinet maylar (AR-123E/153E N/157E N)
25 PTPE-0010QSZZ AC C Slit glass tape (AR-123E/153E N/157E N)
26 TLABZ0058QSZZ AD D Class 1 label (Except U.S.A,Soudi arabia)
27 PMLT-0069QSZZ AA C Ground malt (AR-123E)
28 PSHEZ0404QSZZ AF C Right cabinet ground sheet (AR-123E)
29 PTPE-0047QSZZ AC C Ground tape F (AR-123E)
30 PTPE-0048QSZZ AA C Ground tape R (AR-123E)
31 PTPE-0049QSZZ AC C Right cabinet ground tape (AR-123E)

– 2 –
1Exteriors
3RSPF exteriors (AR-157E N)
3RSPF exteriors (AR-157E N)
4RSPF transport unit (AR-157E)
4RSPF transport unit (AR-157E)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
56 PCUSS0025QSZ1 AQ D OC mat
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
11 DHAI-0304QSZZ AP C R-SPF interface harness
PRP01131
1
12
18
16
26
AR-122E N
AR-152E N
AR-122E
AR-152E
17
25 17
22
23
30
27
18
16
24 26
AR-123E
AR-153E N
AR-157E N
29
31
28
27
AR-123E
AR-153E N
AR-157E N
56
PRP01132
11
PRP01133

– 3 –
6Operation panel
6Operation panel
7Side door unit
7Side door unit
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
1
CPNLH0023QS26 AT N D Panel (AR-122E N Other Countries)
CPNLH0023QS27 AT N D Panel (AR-122E N Philippines)
CPNLH0023QS28 AT N D Panel (AR-152E N)
CPNLH0023QS29 AT N D Panel (AR-153E N)
CPNLH0023QS30 AT N D Panel (AR-157E N)
CPNLH0023QS33 AT N D Panel (AR-123E STCL)
CPNLH0023QS43 AT N D Panel (AR-123E Philippines)
8
CPWBF0113QSE8 BB E Operation PWB (AR-122E N/152E N)
CPWBF0113QSE9 BB E Operation PWB (AR-123E/153E N)
CPWBF0113QSF0 BB E Operation PWB (AR-157E N)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
5LPLTM0043QSZZ AD C Earth plate (AR-122E N/123E/152E N/153E N)
LPLTM0132QSZZ AH C Earth plate (AR-157E N)
21 XEPSD30P08X00 AA C Screw(3×8) (AR-157E N)
22 NGERH0048QSZZ AE C DUP drive gear (AR-157E N)
23 NGERH0051QSZZ AE C DUP drive gear A (AR-157E N)
24 NROLP0025QSZZ AM C DUP drive roller (AR-157E N)
25 MSPRC0050QSZZ AB C DUP pressupe spring (AR-157E N)
26 NROLP1122FCZZ AF C PS upper roller (AR-157E N)
1
8
PRP01134
PRP01135
5
5
21
22 23
23
24
25
25
26
26
Except
AR-157E N

– 4 –
8Optical frame
8Optical frame
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
6DUNT-0276QSZZ BT E Carriage unit (Other Countries)
DUNT-0276QS11 BT E Carriage unit (Europe,AR-123E)
17 PBRSR0002QSZ1 AH B Discharger brush (Other Countries)
PBRSR0002QSZ2 AG B Discharger brush (U.S.A,Soudi arabia,AR-123E)
29 PGIDM0059QSJZ AG C OC hinge guide L (AR-123E/153E N)
PGIDM0019QSJZ AH C SPF hinge guide L (AR-157E N)
30 PGIDM0060QSJZ AF C OC hinge guide R (AR-123E/153E N)
PGIDM0020QSJZ AH C SPF hinge guide R (AR-157E N)
33 LPLTP0131QSZZ AD C Book sensor attachment plate (AR-157E N)
34 MLEVP0047QSE1 AD C Book sensor ACT (AR-157E N)
35 MSPRC0153QSZZ AB C Book sensor spring (AR-157E N)
36 VHPGP1A71A1-1 AG B Photo transistor(GP1A71A1) (AR-157E N)
37 DHAI-0303QSZZ AD C Harness (AR-157E N)
39 PSHEZ0389QSZZ AH C Scanner sheet (Other Countries)
PSHEZ0389QSZ1 AK C Scanner sheet (Europe,AR-123E)
40 DHAI-0268QSZZ AZ C CCD-MCU harness (Other Countries)
DHAI-0268QSZ1 AH C CCD-MCU harness (Europe,AR-123E)
44 PSHEZ0403QSZZ AG C Noise sheet (Europe,AR-123E)
45 PSHEZ0401QSZZ AG C Scanner core sheet (Europe,AR-123E)
46 PTPE-0046QSZZ AB C Core double-sided tape (Europe,AR-123E)
47 PMLT-0068QSZZ AC C Core holder malt (Europe,AR-123E)
48 PSHEZ0400QSZZ AG C PWB core miler (Europe,AR-123E)
17
6
29
30
40
33
34
35
36
39
37
PRP01136
44
48
45
47
46

– 5 –
FDelivery paper guide unit
FDelivery paper guide unit
GMiddle frame
GMiddle frame
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
13 PTUBP0005QSZZ AC C Tube (AR-157E N)
15 RCORF0018QSZZ AR C FFC core (Europe,AR-123E)
16 PSHEZ0402QSZZ AG C Panel core sheet (Europe,AR-123E)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
5NBLT-0005QSZZ AH B Delivery roller drive belt (AR-122E N/123E/152E N/153E N)
31 LPLTM0133QSZ1 AE C DUP motor sink (AR-157E N)
32 PSPAZ0017QSZZ AK C DUP spacer (AR-157E N)
33 XEBSD30P10000 AA C Screw(3×10) (AR-157E N)
34 XHBSE30P06000 AA C Screw(3×6) (AR-157E N)
35 RMOTP0012QSZZ AW B DUP transport motor (AR-157E N)
36 PSHEZ0156QSZZ AE C Harness protection sheet (AR-157E N)
37 NBLTT0004QSZZ AH B Belt (AR-157E N)
38 PSHEZ0155QSZZ AD C Sheet (AR-157E N)
40 DHAI-0307QSZZ AT N C DVS harness CRUM2
41 LPLTM0149QSZZ AD C Plate fixing connector
42 LX-BZ0020QSZZ AB C Screw
43 LHLDW1334FCZZ AA C Holder
44 XEBSD30P08000 AA C Screw(3×10)
PRP01137
16
15
13
6
40
41
42
42
43
44
PRP01138
37
34
32
31
35
34
36
34
33
5
AR-157E N
38

– 6 –
HBase plate unit 1
HBase plate unit 1
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
29 PSHEZ2026FCZ1 AB C Sheet M1 (AR-153E N/157E N)
30 LHLDZ0017QSZZ AD C Pressure plate holder (AR-153E N/157E N)
31 MSPRC0047QSZZ AA C Pressure plate spring (AR-153E N/157E N)
32 PCOVP0013QSZZ AD D Malti cover (AR-153E N/157E N)
34 LRALP0001QSJ2 AM C Base plate rail R
36 PSHEZ2174FCZZ AB C Paper feeding sheet (AR-153E N/157E N)
45 XEBSE40P12000 AA C Screw(4×12)
46 CPLTM0038QS02 AG C 2nd joint gear fixing plate (AR-153E N/157E N)
47 NGERH1169FCZZ AF C 2nd joint gear (AR-153E N/157E N)
48 XRESP70-08000 AA C E-ring
53 PCOVP0051QSZZ AF D OP gear cover (AR-123E/153E N)
54 LX-BZ0700FCZZ AA C Screw (AR-123E/153E N)
60 PCOVP0008QSZZ AE C 2nd gear cover (AR-122E N/152E N)
61 PCOVP0009QSZZ AE C 2nd connector cover (AR-122E N/152E N)
62 MSPRC0037QSZZ AB C Transport lower roller spring (AR-122E N/123E/152E N)
PRP01139
29
30
31
32
34
36
47
46
61
60
62
62
29
30
31
32
34
36
47
46
53
54
48
45

– 7 –
IBase plate unit 2
IBase plate unit 2
JFusing unit
JFusing unit
KDrive unit
KDrive unit
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
4
CPWBX0121QS31 BX N E MCU PWB (AR-122E N)
CPWBX0121QS32 BX N E MCU PWB (AR-152E N)
CPWBX0121QS33 BY N E MCU PWB (AR-153E N)
CPWBX0121QS34 BY N E MCU PWB (AR-157E N)
CPWBX0121QS35 BY N E MCU PWB (AR-123E)
37 DHAI-0265QSZZ AM C 2NDCS interface harness (AR-123E/153E N)
38 PSHEZ0405QSZZ AE C Connector ground sheet (Europe,AR-123E)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
17 LBNDJ0013FCZ1 AA C Wire band (Europe)
LBNDJ0037FCZ1 AA C Wire band (Other Countries)
30 LFRM-0005QSZ1 AQ D Fusing lower frame
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
3MSPRC0053QSZ1 AC C Pulley spring (AR-122E N/123E/152E N/153E N)
4NGERH0050QSZZ AD C Ratchet gear(33T) (AR-122E N/123E/152E N/153E N)
5NPLYZ0002QSZZ AC C Pulley(17T) (AR-122E N/123E/152E N/153E N)
(Unit)
901 CPLTM0042RS55 BM E Drive unit[Except No.27] (AR-122E N/123E/152E N/153E N)
CPLTM0042RS56 BM E Drive unit[Except No.27] (AR-157E N)
PRP01140
A
37
38
4
PRP01141
17
30
PRP01142
3
4
5

–8 –
NSingle manual paper feeding unit (AR-122E N/123E/152E N)
NSingle manual paper feeding unit (AR-122E N/123E/152E N)
R250 sheets tray
R250 sheets tray
SHarness
SHarness
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
23 NSFTZ0007QSZ1 AG C Roller shaft (Other Countries)
NSFTZ0007QSZZ AG C Roller shaft (AR-122E N Europe,AR-152E N)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
5LPLTP5107FCZ1 AG C 250 tray side plate F
13 LPLTP5108FCZ1 AG C 250 tray side plate R
20 TLABZ4047FCZZ AC C Enagy star label (U.S.A,Europe,Australia,New zealand)
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
2DHAI-0268QSZZ AZ C CCD-MCU harness (Other Countries)
DHAI-0268QSZ1 AH C CCD-MCU harness (Europe,AR-123E)
9DHAI-0307QSZZ AT N C DVS harness CRUM2
23
PRP01143
PRP01144
20
513
PRP01145
2
9

–9 –
VPacking material & accessories
VPacking material & accessories
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
1
SPAKA0408QSZZ AN D Top packing OC (AR-122E N/152E N)
SPAKA0429QSZZ AM D Top packing OC (AR-123E/153E N)
SPAKA0410QSZZ AQ D Top packing DSPF (AR-157E N)
!
3
QACCB7521QCZZ AS B AC cord (Special Country,South africa,India)
!QACCB7622QCN1 AZ B AC cord (Hong kong)
!QACCBR623QCPZ AY B AC cord (U.Kngdom,Yemen,South arabia,Oman,Qutar,Bahrain,Kuwait,UAE)
!QACCD761AQCZZ BE B AC cord (100V Series)
!QACCE7621QCZZ * NBACcord (Switzrland)
!QACCER622QCPZ AQ B AC cord (Other Countries)
!QACCF7620QCZZ AX B AC cord (Syngapore,Malaysia,Indonesia)
!QACCJ9610QCZZ AR B AC cord (Philippines)
!QACCLR622QCPZ AR B AC cord (Australia,New zealand)
!QACCV6621JHPZ * BACcord (Europe)
7
TINSA0820QSZZ AW N D Operation manual (Arabic)
TINSE0819QSZZ AY N D Operation manual (English)
TINSE0821QSZZ AW N D Operation manual (English(Hong kong))
TINSE0825QSZZ AW N D Operation manual (English(U.S.A))
TINSF0822QSZZ AY N D Operation manual (English,French,Arabic)
TINSF0839QSZZ AY N D Operation manual (English)
TINSZ0823TSZZ * N D Operation manual (English,German,Swedish,Dutch,Italian,Finnish,Norwegian,Danish)
TINSZ0824TSZZ * N D Operation manual (English,German,Swedish,Dutch,Italian,Finnish,Norwegian,Danish)
GCOVZ0149FCZZ AU D Dust cover A3A (AR-122E N Except Australia,New zealand,Philippines,Syngapore,Malaysia,
Indonesia,Hong kong,India,South africa,STCL)
TCADZ0049QSZZ AH D Installation card (Europe)
9
SPAKA0405QSZZ AN D Bottom packing (AR-122E N/152E N)
SPAKA0406QSZZ AS D Bottom packing (AR-123E/153E N)
SPAKA0407QSZZ AS D Bottom packing (AR-157E N)
10
SPAKC0402RS24 AX N D Packing case (AR-122E N Other Countries)
SPAKC0402TS26 * N D Packing case (AR-122E N Europe)
SPAKC0402TS27 * N D Packing case (AR-152E N)
SPAKC0404RS16 AY N D Packing case (AR-157E N)
SPAKC0428RS11 AY N D Packing case (AR-153E N)
SPAKC0428RS12 AY N D Packing case (AR-123E STCL)
SPAKC0428RS14 AY N D Packing case (AR-123E Philippines)
14 SPAKA0051RSZZ AC D OC packing (AR-122E N/123E/152E N/153E N)
SPAKA0163RSZZ AC D OC packing(DSPF) (AR-157E N)
19 SPAKA0421QSZZ AC D Middle tray packing (AR-157E N)
21 SPAKA5116FCZZ AB D SPF protect sheet (AR-157E N)
23 SPAKA0432QSZZ AC D SPF protect sheet JAG (AR-157E N)
10
3
11
9
7
21 14
14
23
3
200V Series
PRP01146
19

– 10 –
XMCU PWB
NO. PARTS CODE PRICE
RANK
NEW
MARK
PART
RANK DESCRIPTION
2QCNCM0923FC14 AE C Connector(14pin) (AR-123E/153E N/157E N)[CN115]
4QCNCM0923FC24 AF C Connector(24pin) [CN101]
QCNCM0923FC24 AF C Connector(24pin) (AR-123E/153E N/157E N)[CN122]
5QCNCW0948FCZ5 AC C Connector(5pin) (AR-157E N)[CN114]
8QCNCM2401SC0D AC C Connector(4pin) [CN103]
10 QCNCM7014SC0C AA C Connector(3pin) [CN113,CN110]
QCNCM7014SC0C AA C Connector(3pin) (AR-123E/153E N/157E N)[CN109]
29 RH-IX0001QSZZ BD B IC(MT48LC8M16ATG-8E) (AR-157E N)[IC110]
30 RH-IX0002QSZZ AZ B IC(MT48LC4M16ATG-8E) (AR-122E N/123E/152E N/153E N)[IC110]
41 VCCCCZ1HH470J AA C Capacitor(50WV 47pF) [C126,C315,C316,C317,C318]
VCCCCZ1HH470J AA C Capacitor(50WV 47pF) [C319,C320,C321,C166,C341]
45 VCEAGA1CW476M AB C Capacitor(16WV 47µF) [C139]
VCEAGA1CW476M AB C Capacitor(16WV 47µF) (AR-123E/153E N/157E N)[C217,C219]
49 VCKYCY1HB104K AA C Capacitor(50WV 0.10µF) [C277,C313,C314,C209,C210]
VCKYCY1HB104K AA C Capacitor(50WV 0.10µF) [C213,C334,C335,C301,C339]
51
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C101,C107,C108,C110,C111]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C112,C113,C114,C115,C124]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C128,C129,C130,C131]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C132,C133,C134,C135,C136]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C137,C138,C140,C141,C142]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C143,C144,C145,C146,C147]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C148,C149,C150,C151,C152]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C153,C154,C155,C156,C157]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C158,C159,C160,C161,C162]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C164,C168,C170]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C173,C176,C177,C178,C179]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C180,C181,C182,C183,C184]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C185,C187,C189,C193,C195]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C196,C198,C199,C205,C207]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C220,C260,C283,C285,C288]
VCKYCZ1CF104Z AB C Capacitor(16WV 0.10µF) [C289,C308,C323,C328,C337,C338]
56 VHDKDS121++-1 AC B Diode(KDS121) [D116,D117,D118,D125,D126]
VHDKDS121++-1 AC B Diode(KDS121) [D130,D131,D132,D136,D141]
58 VHEMTZJ22B/-1 AA B Zener diode(MTZJ22B) (AR-157E N)[D109]
60 VHI74HC151M-1 AD B IC(74HC151M) [IC114,IC115]
VHI74HC151M-1 AD B IC(74HC151M) (AR-123E/153E N/157E N)[IC117]
65 VHIH8S2321+-1 AX B IC(H8S/2321) [IC103]
73 VHIMTD1361F-1 AR B IC(MTD1361F) (AR-123E/153E N/157E N)[IC128]
75 VHINC7ST08M-1 AD B IC(NC7ST08M) [IC107,IC133]
77 VHITD62064AF/ AM B IC(TD62064AF) (AR-157E N)[IC123]
VHITD62064AF/ AM B IC(TD62064AF) (AR-123E/153E N/157E N)[IC126]
80 VRD-HT2EY151J AA C Resistor(1/4W 150Ω±5%) (AR-123E/153E N/157E N)[R251]
85 VRS-CZ1JD100J AA C Resistor(1/16W 10Ω±5%) [R144,R145,R149,R267,R272]
90
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R108,R111,R112,R115,R118]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R122,R123,R124,R125,R126]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R127,R128,R137,R140,R141]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R146,R147,R148,R172,R189]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R208,R209,R210,R212,R213]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R221,R222,R224,R228,R233]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R234,R238,R242,R248,R249,R250]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R266,R263,R269,R271,R283]
VRS-CZ1JD103J AA C Resistor(1/16W 10KΩ±5%) [R284,R290,R286,R292]
103 VRS-CZ1JD301J AA C Resistor(1/16W 300Ω±5%) [R169,R199,R272,R274]
109 VRS-CZ1JD562J AA C Resistor(1/16W 560Ω±5%) [R239]
119 VRS-HT3DA1R0J AB C Resistor(2W 1.0Ω±5%) (AR-123E/153E N/157E N)[R206,R197]
128 VCCCCY1HH470J AA C Capacitor(50WV 47pF) [C336]
129 VHDKDS120++-1 AC N B Diode(KDS120) [D121,D122,D123,D128,D129]
VHDKDS120++-1 AC N B Diode(KDS120) [D133,D134,D135,D137,D142]
130 VHILVX4245M-1 AL B IC(74LVX4245MTCX) [IC32]
(Unit)
901
CPWBX0121QS31 BX N E MCU PWB (AR-122E N)
CPWBX0121QS32 BX N E MCU PWB (AR-152E N)
CPWBX0121QS33 BY N E MCU PWB (AR-153E N)
CPWBX0121QS34 BY N E MCU PWB (AR-157E N)
CPWBX0121QS35 BY N E MCU PWB (AR-123E)

– 11 –
■Index
PARTS CODE NO. PRICE
RANK
NEW
MARK
PART
RANK
[C]
CCAB-0003QS23 1- 1 AS D
CCAB-0003QS26 1- 1 AS D
CPLTM0038QS02 12- 46 AG C
CPLTM0042RS55 15- 901 BM E
CPLTM0042RS56 15- 901 BM E
CPNLH0023QS26 6- 1 AT N D
CPNLH0023QS27 6- 1 AT N D
CPNLH0023QS28 6- 1 AT N D
CPNLH0023QS29 6- 1 AT N D
CPNLH0023QS30 6- 1 AT N D
CPNLH0023QS33 6- 1 AT N D
CPNLH0023QS43 6- 1 AT N D
CPWBF0113QSE8 6- 8 BB E
CPWBF0113QSE9 6- 8 BB E
CPWBF0113QSF0 6- 8 BB E
CPWBX0121QS31 13- 4 BX N E
"28- 901 BX N E
CPWBX0121QS32 13- 4 BX N E
"28- 901 BX N E
CPWBX0121QS33 13- 4 BY N E
"28- 901 BY N E
CPWBX0121QS34 13- 4 BY N E
"28- 901 BY N E
CPWBX0121QS35 13- 4 BY N E
"28- 901 BY N E
[D]
DHAI-0265QSZZ 13- 37 AM C
DHAI-0268QSZ1 23- 2 AH C
"8- 40 AH C
DHAI-0268QSZZ 23- 2 AZ C
"8- 40 AZ C
DHAI-0303QSZZ 8- 37 AD C
DHAI-0304QSZZ 4- 11 AP C
DHAI-0307QSZZ 11- 40 AT N C
"23- 9 AT N C
DUNT-0276QS11 8- 6 BT E
DUNT-0276QSZZ 8- 6 BT E
[G]
GCAB-0021QSJ1 1- 18 AY D
GCAB-0026QSJ2 1- 18 AZ D
GCAB-0062QSZ1 1- 17 AL D
GCAB-0062QSZZ 1- 17 AL D
GCOV-0045QSZ1 1- 12 AG D
GCOV-0045QSZZ 1- 12 AG D
GCOVZ0149FCZZ 26- 7 AU D
[L]
LBNDJ0013FCZ1 14- 17 AA C
LBNDJ0037FCZ1 14- 17 AA C
LFRM-0005QSZ1 14- 30 AQ D
LHLDW1334FCZZ 11- 43 AA C
LHLDZ0017QSZZ 12- 30 AD C
LPLTM0043QSZZ 7- 5 AD C
LPLTM0132QSZZ 7- 5 AH C
LPLTM0133QSZ1 11- 31 AE C
LPLTM0149QSZZ 11- 41 AD C
LPLTP0131QSZZ 8- 33 AD C
LPLTP5107FCZ1 22- 5 AG C
LPLTP5108FCZ1 22- 13 AG C
LRALP0001QSJ2 12- 34 AM C
LX-BZ0020QSZZ 11- 42 AB C
LX-BZ0700FCZZ 12- 54 AA C
[M]
MLEVP0047QSE1 8- 34 AD C
MSPRC0037QSZZ 12- 62 AB C
MSPRC0047QSZZ 12- 31 AA C
MSPRC0050QSZZ 7- 25 AB C
MSPRC0053QSZ1 15- 3 AC C
MSPRC0153QSZZ 8- 35 AB C
[N]
NBLT-0005QSZZ 11- 5 AH B
NBLTT0004QSZZ 11- 37 AH B
NGERH0048QSZZ 7- 22 AE C
NGERH0050QSZZ 15- 4 AD C
NGERH0051QSZZ 7- 23 AE C
NGERH1169FCZZ 12- 47 AF C
NPLYZ0002QSZZ 15- 5 AC C
NROLP0025QSZZ 7- 24 AM C
NROLP1122FCZZ 7- 26 AF C
PARTS CODE NO. PRICE
RANK
NEW
MARK
PART
RANK
NSFTZ0007QSZ1 18- 23 AG C
NSFTZ0007QSZZ 18- 23 AG C
[P]
PBRSR0002QSZ1 8- 17 AH B
PBRSR0002QSZ2 8- 17 AG B
PCOVP0008QSZZ 12- 60 AE C
PCOVP0009QSZZ 12- 61 AE C
PCOVP0013QSZZ 12- 32 AD D
PCOVP0035QSJZ 1- 16 AL D
PCOVP0040QSJZ 1- 16 AL D
PCOVP0051QSZZ 12- 53 AF D
PCUSS0025QSZ1 3- 56 AQ D
PGIDM0019QSJZ 8- 29 AH C
PGIDM0020QSJZ 8- 30 AH C
PGIDM0059QSJZ 8- 29 AG C
PGIDM0060QSJZ 8- 30 AF C
PGLSP0008QSZZ 1- 23 AH B
PMLT-0068QSZZ 8- 47 AC C
PMLT-0069QSZZ 1- 27 AA C
PSHEZ0155QSZZ 11- 38 AD C
PSHEZ0156QSZZ 11- 36 AE C
PSHEZ0181QSJZ 1- 24 AC C
PSHEZ0389QSZ1 8- 39 AK C
PSHEZ0389QSZZ 8- 39 AH C
PSHEZ0400QSZZ 8- 48 AG C
PSHEZ0401QSZZ 8- 45 AG C
PSHEZ0402QSZZ 10- 16 AG C
PSHEZ0403QSZZ 8- 44 AG C
PSHEZ0404QSZZ 1- 28 AF C
PSHEZ0405QSZZ 13- 38 AE C
PSHEZ2026FCZ1 12- 29 AB C
PSHEZ2174FCZZ 12- 36 AB C
PSPAZ0017QSZZ 11- 32 AK C
PTPE-0010QSZZ 1- 25 AC C
PTPE-0044QSZZ 1- 22 AC C
PTPE-0046QSZZ 8- 46 AB C
PTPE-0047QSZZ 1- 29 AC C
PTPE-0048QSZZ 1- 30 AA C
PTPE-0049QSZZ 1- 31 AC C
PTUBP0005QSZZ 10- 13 AC C
[Q]
QACCB7521QCZZ 26- 3 AS B
QACCB7622QCN1 26- 3 AZ B
QACCBR623QCPZ 26- 3 AY B
QACCD761AQCZZ 26- 3 BE B
QACCE7621QCZZ 26- 3 }N B
QACCER622QCPZ 26- 3 AQ B
QACCF7620QCZZ 26- 3 AX B
QACCJ9610QCZZ 26- 3 AR B
QACCLR622QCPZ 26- 3 AR B
QACCV6621JHPZ 26- 3 }B
QCNCM0923FC14 28- 2 AE C
QCNCM0923FC24 28- 4 AF C
QCNCM2401SC0D 28- 8 AC C
QCNCM7014SC0C 28- 10 AA C
QCNCW0948FCZ5 28- 5 AC C
[R]
RCORF0018QSZZ 10- 15 AR C
RH-IX0001QSZZ 28- 29 BD B
RH-IX0002QSZZ 28- 30 AZ B
RMOTP0012QSZZ 11- 35 AW B
[S]
SPAKA0051RSZZ 26- 14 AC D
SPAKA0163RSZZ 26- 14 AC D
SPAKA0405QSZZ 26- 9 AN D
SPAKA0406QSZZ 26- 9 AS D
SPAKA0407QSZZ 26- 9 AS D
SPAKA0408QSZZ 26- 1 AN D
SPAKA0410QSZZ 26- 1 AQ D
SPAKA0421QSZZ 26- 19 AC D
SPAKA0429QSZZ 26- 1 AM D
SPAKA0432QSZZ 26- 23 AC D
SPAKA5116FCZZ 26- 21 AB D
SPAKC0402RS24 26- 10 AX N D
SPAKC0402TS26 26- 10 }N D
SPAKC0402TS27 26- 10 }N D
SPAKC0404RS16 26- 10 AY N D
SPAKC0428RS11 26- 10 AY N D
SPAKC0428RS12 26- 10 AY N D
SPAKC0428RS14 26- 10 AY N D

– 12 –
PARTS CODE NO. PRICE
RANK
NEW
MARK
PART
RANK
[T]
TCADZ0049QSZZ 26- 7 AH D
TINSA0820QSZZ 26- 7 AW N D
TINSE0819QSZZ 26- 7 AY N D
TINSE0821QSZZ 26- 7 AW N D
TINSE0825QSZZ 26- 7 AW N D
TINSF0822QSZZ 26- 7 AY N D
TINSF0839QSZZ 26- 7 AY N D
TINSZ0823TSZZ 26- 7 }N D
TINSZ0824TSZZ 26- 7 }N D
TLABZ0058QSZZ 1- 26 AD D
TLABZ4047FCZZ 22- 20 AC C
[V]
VCCCCY1HH470J 28- 128 AA C
VCCCCZ1HH470J 28- 41 AA C
VCEAGA1CW476M 28- 45 AB C
VCKYCY1HB104K 28- 49 AA C
VCKYCZ1CF104Z 28- 51 AB C
VHDKDS120++-1 28- 129 AC N B
VHDKDS121++-1 28- 56 AC B
VHEMTZJ22B/-1 28- 58 AA B
VHI74HC151M-1 28- 60 AD B
VHIH8S2321+-1 28- 65 AX B
VHILVX4245M-1 28- 130 AL B
VHIMTD1361F-1 28- 73 AR B
VHINC7ST08M-1 28- 75 AD B
VHITD62064AF/ 28- 77 AM B
VHPGP1A71A1-1 8- 36 AG B
VRD-HT2EY151J 28- 80 AA C
VRS-CZ1JD100J 28- 85 AA C
VRS-CZ1JD103J 28- 90 AA C
VRS-CZ1JD301J 28- 103 AA C
VRS-CZ1JD562J 28- 109 AA C
VRS-HT3DA1R0J 28- 119 AB C
[X]
XEBSD30P08000 11- 44 AA C
XEBSD30P10000 11- 33 AA C
XEBSE40P12000 12- 45 AA C
XEPSD30P08X00 7- 21 AA C
XHBSE30P06000 11- 34 AA C
XRESP70-08000 12- 48 AA C
PARTS CODE NO. PRICE
RANK
NEW
MARK
PART
RANK

All rights reserved.
Printed in Japan.
No part of this publication may be reproduced,
stored in a retrieval system, or transmitted,
in any form or by any means,
electronic, mechanical, photocopying, recording, or otherwise,
without prior written permission of the publisher.
Trademark acknowledgments
Windows and Windows NT are trademarks of Microsoft Corporation in the U.S.A.
and other countries.
IBM and PC/AT are trademarks of International Business Machines Corporation.
PCL is a trademark of Hewlett-Packard Company.
Pentium is a registered trademark of Intel Corporation.
All other trademarks and copyrights are the property of their respective owners.
c
COPYRIGHT 2002 BY SHARP CORPORATION
cc
SHARP CORPORATION
Digital Document System Group
Products Quality Assurance Department
Yamatokoriyama, Nara 639-1186, Japan
2002 September Printed in Japan
