Sharp AR-5618 User manual

Parts marked with “ “ are important for maintaining the safety of the set.
Be sure to replace these parts with specified ones for maintaining the safety and performance of the set.
SHARP CORPORATION This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
CODE : 00ZAR5618/S2E
AR-5618
AR-5618S/5620S
AR-5618N
AR-5618D
AR-5620/5623
AR-5620N/5623N
AR-5620D/5623D
1
1
1
1
[ 1 ] GENERAL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
[ 2 ] CONFIGURATION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
[ 3 ] SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
[ 4 ] CONSUMABLE PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
[ 5 ] EXTERNAL VIEWS AND INTERNAL STRUCTURES . . . . . . . 5 - 1
[ 6 ] ADJUSTMENTS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
[ 7 ] SIMULATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1
[ 8 ] TROUBLE CODE LIST . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1
[ 9 ] MAINTENANCE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9 - 1
[10] DISASSEMBLY AND ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . 10 - 1
[11] OPERATIONAL DESCRIPTIONS . . . . . . . . . . . . . . . . . . . . . . 11 - 1
[12] FLASH ROM VERSION UP PROCEDURE. . . . . . . . . . . . . . . 12 - 1
[13] ELECTRICAL SECTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13 - 1
CONTENTS
MODEL
：'11/Jul/22
1
DIGITAL MULTIFUNCTIONAL
SYSTEM
AR-5618/5620/5623
AR-5618S/5620S
AR-5618N/5620N/5623N
AR-5618D/5620D/5623D
1
1

Disconnect the AC cord before servicing the unit. LASER WAVE - LENGTH : 795 15mm
Pulse times : 0.481ms/6mm
Out put power : 5mW

Contains lithium-ion battery. Must be disposed of properly.
Remove the battery from the product and contact
federal or state environmental
agencies for information on recycling and disposal options.
(For USA,CANADA)
CAUTION FOR BATTERY DISPOSAL

CONTENTS
[1] GENERAL
1. Note for servicing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 - 1
[2] CONFIGURATION
1. System Configurations . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 1
[3] SPECIFICATIONS
1. Copy mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 - 1
[4] CONSUMABLE PARTS
1. Supply system table . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 1
2. Environmental conditions . . . . . . . . . . . . . . . . . . . . . . . . 4 - 2
3. Production number identification . . . . . . . . . . . . . . . . . . . 4 - 3
[5] EXTERNAL VIEWS AND INTERNAL STRUCTURES
1. Appearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
2. Internal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 1
3. Operation Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 2
4. Motor, solenoid, clutch . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 3
5. Sensor, switch. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 4
6. PWB unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 5
7. Cross sectional view . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5 - 6
[6] ADJUSTMENTS
1. Adjustment item list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
2. Copier adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6 - 1
[7] SIMULATIONS
1. Entering the simulation mode . . . . . . . . . . . . . . . . . . . . . 7 - 1
2. Canceling the simulation mode . . . . . . . . . . . . . . . . . . . . 7 - 1
3. List of simulations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 1
4. Contents of simulations . . . . . . . . . . . . . . . . . . . . . . . . . . 7 - 3
[8] TROUBLE CODE LIST
1. Trouble code list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1
2. Details of trouble codes. . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 1
[9] MAINTENANCE
1. Maintenance table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9 - 1
2. Maintenance display system . . . . . . . . . . . . . . . . . . . . . .9 - 2
3. Note for replacement of consumable parts . . . . . . . . . . .9 - 2
[10] DISASSEMBLY AND ASSEMBLY
1. High voltage section/Duplex transport section. . . . . . . .10 - 1
2. Optical section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 2
3. Fusing section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 4
4. Paper exit section . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 7
5. MCU/NIC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 9
6. Optical frame unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 9
7. LSU . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 10
8. Tray paper feed section/Paper transport section . . . . .10 - 10
9. Bypass tray section . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 12
10. Power section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 14
11. Developing section. . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 15
12. Process section . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 16
13. Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10 - 17
[11] OPERATIONAL DESCRIPTIONS
1. Paper feed operation . . . . . . . . . . . . . . . . . . . . . . . . . . .11 - 1
[12] FLASH ROM VERSION UP PROCEDURE
1. Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12 - 1
2. Download procedure . . . . . . . . . . . . . . . . . . . . . . . . . . .12 - 1
3. Installation procedure. . . . . . . . . . . . . . . . . . . . . . . . . . .12 - 2
4. AR-5618N/5620N/5623N download procedures . . . . . .12 - 5
[13] ELECTRICAL SECTION
1. Block diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13 - 1
2. Actual wiring diagram. . . . . . . . . . . . . . . . . . . . . . . . . . .13 - 2

AR-5618S GENERAL 1-1
[1] GENERAL
1. Note for servicing
Pictogram
The label ( ) in the fusing area of the machine indicates the
following:
: Caution, risk of danger
: Caution, hot surface
A. Warning for servicing
•The fusing area is hot. Exercise care in this area when removing misfed
paper.
•Do not disassemble the laser unit. Do not insert a reflective material
such as a screwdriver in the laser beam path.
It may damage eyes by reflection of laser beams.
B. Cautions for servicing
•Do not switch the machine rapidly on and off. After turning the machine
off, wait 10 to 15 seconds before turning it back on.
•Machine power must be turned off before installing any supplies.
•Place the machine on a firm, level surface.
•Do not install the machine in a humid or dusty location.
•When the machine is not used for a long time, for example, during
prolonged holidays, turn the power switch off and remove the power
cord from the outlet.
•When moving the machine, be sure to turn the power switch off and
remove the power cord from the outlet.
•Do not cover the machine with a dust cover, cloth or plastic film while
the power is on. Doing so may prevent heat dissipation, damaging the
machine.
•Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous laser radiation
exposure.
•The socket-outlet shall be installed near the machine and shall be easily
accessible.
C. Note for installation place
Improper installation may damage the machine. Please note the
following during initial installation and whenever the machine is moved.
Caution : If the machine is moved from a cool place to a warm place,
condensation may form inside the machine. Operation in this
condition will cause poor copy quality and malfunctions. Leave
the machine at room temperature for at least 2 hours before
use.
Do not install your machine in areas that are:
•damp, humid, or very dusty
•poorly ventilated
•exposed to direct sunlight
•subject to extreme temperature or humidity changes, e.g., near an air
conditioner or heater.
The machine should be installed near an accessible power outlet for
easy connection and disconnection.
Be sure to connect the power cord only to a power outlet that meets the
specified voltage and current requirements. Also make certain the outlet
is properly grounded.
Note : Connect the machine to a power outlet which is not used for other
electric appliances. If a lighting fixture is connected to the same
outlet, the light may flicker.
Be sure to allow the required space around the machine for servicing
and proper ventilation.
20 cm
(8
" )
20 cm
(8
" )
20 cm (8
" )

AR-5618S CONFIGURATION 2-1
[2] CONFIGURATION
1. System Configurations
AR-D36 AR-D37
AR-RP10
AR-5618S/5620S AR-5620N/5623N
AR-5620D/5623D
AR-5618N
AR-5618D
AR-VR7
AR-5620/5623 AR-5618
AR-SP10
11
1MX-NB12
(S/N model:
Option installation disable)
1
MX-USX1
Sharpdesk 1 license kit
MX-USX5
Sharpdesk 5 license kit
MX-US10
Sharpdesk 10 license kit
MX-US50
Sharpdesk 50 license kit
MX-USA0
Sharpdesk 100 license kit
：'11/Jul/22
1

AR-5618S CONFIGURATION 2-2
：'11/Jul/22
1
STD: Standard O : Option installation enable X : Option installation disable
Model
Option AR-5618S/5620S AR-5618/5620/5623 AR-5618N/5620N/5623N AR-5618D/5620D/5623D
AR-RP10 Reversing single pass feeder (RSPF) X X O
AR-SP10 Single pass feeder (SPF) X O X
AR-D36 250-sheet paper feed unit X O O
AR-D37 2x250-sheet paper feed unit X O O
AR-VR7 DOCUMENT COVER STD STD O
MX-NB12 NETWORK EXPANSION KIT X O O
(N model: X )
MX-USX1 SHARPDESK 1 LICENSE KIT X O O
MX-USX5 SHARPDESK 5 LICENSE KIT X O O
MX-US10 SHARPDESK 10 LICENSE KIT X O O
MX-US50 SHARPDESK 50 LICENSE KIT X O O
MX-USA0 SHARPDESK 100 LICENSE KIT X O O
1
1
1
1

AR-5618S SPECIFICATIONS 3-1
：'11/Jul/22
1
[3] SPECIFICATIONS
1. Copy mode
A. Type
B. Machine composition
(1) Option
C. Copy speed
(1) Engine speed (ppm)
(2) Engine performance when printing
*1:S model is contained.
(3) Document replacement speed (Copy mode)
S to S : A4/8.5” x 11” document 11 sheets, copy 1 set
(4) Job efficiency
S to S : A4/8.5”x11” document 10 sheets, copy 5 sets
S to D : A4/8.5”x11” document 10 sheets, copy 5 sets
D to D : A4/8.5”x11” document 10 sheets (20 pages), copy 5 sets
Note : The temperature at the end portion of the heat roller may rise too
high, depending on the kind of paper to be used, when in
continuous printing of small-size paper.
To avoid this, when the thermistor at the end portion detects a
higher temperature than the specified level, output is stopped
temporarily.
During temporary stop, Power Save Indicator lamp flashes in the
same manner as warming up.
(5) First copy time
AE mode, A4/Letter, single surface copy with OC, in polygon ready state
D. Document
E. Paper feed
(1) Paper feed section details
Typ e Desk-top
Paper exit center tray / internal
AR-5618
AR-5618S
AR-5618N
AR-5618D
18-CPM multi function model
AR-5620
AR-5620S
AR-5620N
AR-5620D
20-CPM multi function model
AR-5623
AR-5623N
AR-5623D
23-CPM multi function model
Machine Model
250-sheet paper feed unit AR-D36 AR-5618/5620/5623
AR-5618N/5620N/5623N
AR-5618D/5620D/5623D
2x250-sheet paper feed unit AR-D37
SPF AR-SP10 AR-5618/5620/5623
RSPF AR-RP10 AR-5618N/5620N/5623N
AR-5618D/5620D/5623D
Network expansion kit MX-NB12 AR-5618/5620/5623
AR-5618D/5620D/5623D
Paper size
AR-5623
AR-5623N
AR-5623D
AR-5620
AR-5620S
AR-5620N
AR-5620D
AR-5618
AR-5618S
AR-5618N
AR-5618D
A4/8.5" x 11" 23ppm 20ppm 18ppm
A4R/
8.5" x 11"R
15/16ppm 14/15ppm 14/15ppm
A5/5.5"x8.5" 23ppm 20ppm 18ppm
B5/16K 23ppm 20ppm 18ppm
B5R/16KR 18/16ppm 16/15ppm 16/15ppm
8.5x13" 13ppm 12ppm 12ppm
B4/8.5"x14 13ppm 12ppm 12ppm
A3/11"x17"/
8K
12/11/12ppm 11/10/11ppm 11/10/11ppm
Model 23cpm machine 20cpm machine 18cpm machine
ROPM OFF*1 12ppm or more 12ppm or more 12ppm or more
ROPM ON 23ppm 20ppm 18ppm
Copy
mode
AR-5623
AR-5623N
AR-5623D
AR-5620
AR-5620N
AR-5620D
AR-5618
AR-5618N
AR-5618D
S to S 20cpm (87%) 20cpm (100%) 18cpm (100%)
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Copy
mode
AR-5623
AR-5623N
AR-5623D
AR-5620
AR-5620N
AR-5620D
AR-5618
AR-5618N
AR-5618D
S to S 18cpm (78%) 18cpm (90%) 15cpm (94%)
S to D 10cpm (43%) 10cpm (50%) 10cpm (63%)
D to D 10cpm (43%) 10cpm (50%) 10cpm (63%)
Tray 18/20cpm machine 23cpm machine
1st tray 7.2 sec or less 5.9 sec or less
Max. document size A3, 11" X 17"
Document reference position Left center
Detection (Platen) None
Item 1st tray 2nd tray Bypass tray
Paper capacity 250
sheets
250
sheets
100 sheets
Paper size detection No
(Paper size is set with
the operasion panel.)
Paper type setting No No No
(Heavy
paper setting
is enabled.)
Paper size changing method The paper guide is set by the user.
Default paper size
when shipping
AB series A4 A4 -
Inch
series
8 1/2” x11” 8 1/2” x11” -
Remaining paper quantity
detection
Only empty detection available
1
1
1
1
1

AR-5618S SPECIFICATIONS 3-2
：'11/Jul/22
1
(2) Feedable paper
*1: Switches by SIM26-2. (Operation UI supports by 8.5x13 and exclusion.)
(3)Types of feedable paper
F. Multi copy
G. Warm-up time
H. Copy magnification ratio
I. Copy density
J. Void width
K. Auto duplex
L. Paper exit / finishing
Paper size 1st tray 2nd tray Bypass
tray
A3 297x420 Ye s Ye s Ye s
B4 257x364 Ye s Ye s Ye s
A4 297x210 Ye s Ye s Ye s
A4-R 210x297 Ye s Ye s Ye s
B5 257x182 Ye s Ye s Ye s
B5R 182x257 Ye s Ye s Ye s
A5 210x148.5 Ye s N/A Ye s
A5R 148.5x210 N/A N/A Ye s
A6R 105x148.5 N/A N/A Ye s
B6R 128.5x182 N/A N/A Ye s
Ledger 11x17 in 279.4x431.8 Ye s Ye s Ye s
Legal 8.5x14in. 215.9x355.6 Ye s Ye s Ye s
8.5x13.4 *1 216x340 *1 *1 *1 *1
Foolscap 8.5x13 in 215.9x330.2 Ye s Ye s Ye s
Letter 11x8.5in 279.4x215.9 Ye s Ye s Ye s
Letter-R 8.5x11in 215.9x279.4 Ye s Ye s Ye s
Executive-R 7.25x10.5in. 184.2x266.7 N/A N/A Ye s
Invoice 8.5x5.5 in. 215.9x139.7 Ye s N/A Ye s
Invoice-R 5.5x8.5 in 139.7x215.9 N/A N/A Ye s
8K 270x390 Ye s Ye s Ye s
16K 270x195 Ye s Ye s Ye s
16KR 195x270 Ye s Ye s Ye s
COM10 104.8x241.3 N/A N/A Ye s
Types of paper 1st tray 2nd tray Bypass tray
Thin paper 56-59g/m2
15-15.9lbs
Ye s Ye s Ye s
Plain paper 60-90g/m2
16-24lbs
Ye s Ye s Ye s
Heavy paper 91-105g/m2
16-24lbs
N/A N/A Ye s
(Multi paper feed enable)
Heavy paper 106-128g/m2
24.1-33.5lbs
N/A N/A Ye s
(A4 or less)
(Multi paper feed enable)
Heavy paper 129-200g/m2
33.6-53.2lbs
N/A N/A Ye s
(A4 or less)
(Only single paper feed)
Heavy paper 201-256g/m2
53.3-68lbs
N/A N/A N/A
Envelope 75-90g/m2
20-24lbs
N/A N/A Ye s
Postcard N/A N/A Ye s
OHP film N/A N/A Ye s
Label sheet N/A N/A Ye s
Tab paper 20 N/A N/A N/A
Max. number of multi copy 999 sheets
Warm-up time 25 seconds or less
Pre-heat Available
Jam recovery Within 25 sec
1
1
Fixed
magnification
ratio
AB system:
200, 141, 122, 115, 100, 86, 81, 70, 50%
Inch system:
200, 141, 129, 121, 100, 95, 77, 64, 50%
Zooming 25 ~ 400%
SPF/RSPF (50 ~ 200%)
Independent
zooming(vertical)
Available (25 ~ 400%)
SPF/RSPF (50 ~ 200%)
Independent zooming
(horizontal)
Available (25 ~ 400%)
SPF/RSPF (50 ~ 200%)
Density mode Auto / Text / Photo
No. of manual
adjustment
5 steps (Text / Photo)
Resolution Writing: 600 x 600dpi
Reading: 400 (main) x 600 (sub) (PHOTO mode)
400 (main) x 600 (sub) (AUTO exposure
mode)
400 (main) x 600 (sub) dpi (TEXT mode)
Gradation Reading: 256 gradations
Writing: Binary
Void area Lead edge 1 ~ 4mm
Rear edge 4mm or less
Total of both sides: 6mm or less
Image loss OC Same size 4.0mm or less
SPF/RSPF Same size 4.5mm or less
Standard/
Option
Standard provision (AR-5618N/5620N/5623N,
AR-5618D/5620D/5623D only)
(D→D / D →S enable only when RSPF is installed)
Not available for AR-5618/5620/5623, AR-5618S/5620S
Paper exit section
capacity
Face down 250 sheets
Full detection None
Finishing None
Electronic sort
capacity
A4/ 8.5" x 11" standard document (6%
coverage) 80 sheets
Offset function None
Staple function None
1
1
1
1
1
1

AR-5618S SPECIFICATIONS 3-3
：'11/Jul/22
1
M. Additional functions
O : Available X : Not available
N. Other specifications
O. Package form
P. E x t ern a l view
Q. Power source
R. Power consumption
S. Digital performance
AR-5618S/
5620S
AR-5618/5620/
5623
AR-5618N/
5620N/5623N
AR-5618D/
5620D/5623D
APS X O
AMS O
Auto tray
switching X O
Memory copy X O
Rotation copy O
E-sort (Sorting
function) X
O
Single surface, A4, 6% document,
Max. 80 sheets
E-sort (Grouping
function) X O
Rotation sort X
Prevention of sky
shot X
Independent
zooming O
1 set 2 copy O
SPF: Disable
OC: Enlargement is disable.
Binding margin X O
Default AB series: 10mm
(5, 10, 15, 20mm)
Inch series: 1/2 inch
(1/4, 1/2, 3/4, 1 inch)
Edge erase X
Center erase
X
Black/white
reverse X
2in1/4in1 X O
Offset X
Preheating O
The conditions are set by the system setting.
Auto shut-off O
The conditions are set by the system setting.
System setting O
Counter O
(1) Copy total
(2) Print total
(3) Scan (Except S model)
(4) Toner residual quantity
Coin vendor
support
O
(Need to I/F service parts.)
Auditor support O
(Need to I/F service parts.)
Duplex X O
Toner save O
(Set according to the destination)
Account control O
(Copy: 20 Dept.)
1
1
1
1
Photoconductor type OPC (Organic Photo Conductor)
Photoconductor drum dia. 30mm
Copy lamp WhiteCCFL
Developing system Dry 2-component magnetic brush
development
Charging system Saw teeth charging
Transfer system (+) DC corotron
Separation system (-) DC corotron
Fusing system Heat roller
Cleaning system Contact blade
Body Body / Accessories
S model N model Standard
model D model
External
dimensions
(With the bypass
tray closed)
591mm(W) x 550mm(D) 591mm(W) x 567mm(D)
Occupying area
(With the bypass
tray opened)
883mm(W) x 550mm(D) 883mm(W) x 567mm(D)
Weight
(Excluding
developer)
28.6kg 1 stage
model:
27.8kg
2 stage
model:
33.0kg
1 stage
model:
28.6kg
2 stage
model:
33.8kg
1 stage
model:
27.6kg
2 stage
model:
32.8kg
Voltage 100 - 127V 220 - 240V
Frequency 50/60Hz common
Max. power consumption 1200W
Average power consumption in
operation
Less than 550W
Resolution Reading 400 x 600dpi (PHOTO mode)
400 x 600dpi (AUTO exposure mode)
400 (main) x 600 (sub) dpi (TEXT mode)
Writing 600 x 600dpi
Gradation Reading 256 gradations
Writing Binary
Memory AR-5618S/5620S : 16MB
AR-5618/5620/5623
AR-5618N/5620N/5623N
AR-5618D/5620D/5623D : 64MB
Hard disk None
1
1
1
1

AR-5618S SPECIFICATIONS 3-4
：'11/Jul/22
1
T. Printing function
(1) Platform
(2) Support OS
(3) Printer driver function (SPLC)
Item Content
Support platform IBM PC/AT compatible machine
OS
Main machine When NW expansion kit is enhanced
Twain/
Button Manager SPLC Custom PCL6 SPDL2 Custom PCL5e
Windows 98/Me No No No No
NT 4.0 SP5 or later No No No No
2000 CD-ROM CD-ROM CD-ROM No
XP CD-ROM CD-ROM CD-ROM No
XP x64 CD-ROM CD-ROM CD-ROM No
Server 2003 No No CD-ROM No
Server 2003 x64 No No CD-ROM No
Vista CD-ROM CD-ROM CD-ROM No
Vista x64 CD-ROM CD-ROM CD-ROM No
Server 2008 No No CD-ROM No
Server 2008 x64 No No CD-ROM No
Windows 7 CD-ROM CD-ROM CD-ROM No
Windows 7 x64 CD-ROM CD-ROM CD-ROM No
1
Item SPLC
Support
print
channel
USB USB1.1:
Windows 2000 / XP / Vista /7
USB2.0(High-Speed):
Windows2000 / XP/ Vista /7
LPD ---
IPP ---
Raw Port (Port9100) ---
TCP/IP Print by TCP/IP port
(only for N-model)
WSD (WS-Print) Support WSD print
(only for N-model)
BMLinks ---
Print
function
Bar-code Font N/A
Network Tandem Print N/A
Encrypted PDF/PDF/
TIFF/JPEG XPS Direct
print
N/A
Specify files by Web page
to print
[Web Submit Print]
N/A
ROPM Ye s
Multi access support N/A
Paper direction setting for
duplex printing of letter
head paper or punch
paper.
[Support printing on logo
paper (SEGA AOK
Company)]
N/A
Driver Distribution
Function
N/A
Form Overlay N/A
Support Planet Press N/A
Add support font N/A
Bonjour for Macintosh
environment
N/A
Print
function
Layout print N/A
Perfect binding N/A
Support
SharpPrintSystem
N/A
Support WSD Yes (only for N-model)
Rotation in 90 degrees
function
N/A
Printing position
adjustment for odd/even
pages
N/A
Print Policy Function N/A
Toner Save Mode N/A
Support RET N/A
Print density adjustment Ye s
Item SPLC

AR-5618S SPECIFICATIONS 3-5
：'11/Jul/22
1
U. Scanner function (Except for AR-5618S/5620S)
Typ e Flat bed scanner
Scan system Document table/document feed unit
Resolution 75dpi/ 100dpi/ 150dpi/ 200dpi/ 300dpi/ 400dpi/
600dpi
Custum: 50 - 9600dpi
Document Sheet/Book
Effective scan
range
OC/SPF/RSPF: about 297(length) x 431(width) mm
Scan speed OC/SPF/RSPF:
Color: 1.44msec/line (400dpi)
Gray/Scale: 0.48msec/line (400dpi)
Output data Mono 2 Levels
Gray scale: 8bit
Full color: Each color RGB 8bit
Scan color Black & white / binary / Gray scale / Color
Interface
AR-5618/5620/5623
AR-5618D/5620D/5623D:
USB2.0 (High speed mode, full speed mode)
AR-5618N/5620N/5623N:
10/100 base (Internal full speed connection)
Scanner utility Button Manager
Drop-out color Yes (Red/Green/Blue/White)
Scanner button Provided (5)
Supported OS USB connection:Windows 2000/XP/Vista/7
network connection:Windows 2000/XP/Vista/7
Void area Lead edge/rear edge (2.5mm) on the driver
side Left/right: 3.0mm
1
1
1
1
1

AR-5618S CONSUMABLE PARTS 4-1
：'11/Jul/22
1
[4] CONSUMABLE PARTS
1.Supply system table
A. South and Central America
B. Brazil
C. Europe
D. Australia/New Zealand
E. Middle East, Africa (except Iran) /Israel/Philippines/Others
F. Taiwan
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-235NT Toner cartridge
Vinyl bag
x1
x1
16K
Default is Toner save
mode. Life is 19K.
(200V series)
Life setting by A4 6% document
2Developer MX-235NV Developer x1 50K
3Drum KIT AR-205DR Drum
Drum fixing plate
x1
x1
50K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-235BT Toner cartridge
Vinyl bag
x1
x1
Default is Toner save
mode. Life is 19K.
Life setting by A4 6% document
2Developer MX-235NV Developer x1 50K
3Drum KIT AR-205DR Drum
Drum fixing plate
x1
x1
50K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-235GT Toner cartridge
Vinyl bag
x1
x1
16K Life setting by A4 6% document
2Developer MX-235GV Developer x1 50K
3Drum KIT AR-205DM Drum
Drum fixing plate
x1
x1
50K
No. Name Product name Content Life Remarke
1Toner cartridge(Black) MX-235GT Toner cartridge
Vinyl bag
x1
x1
Default is Toner save
mode. Life is 19K.
Life setting by A4 6% document
2Developer MX-235GV Developer x1 50K
3Drum KIT AR-205DM Drum
Drum fixing plate
x1
x1
50K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-235FT Toner cartridge
Vinyl bag
x1
x1
Default is Toner save
mode. Life is 19K.
Life setting by A4 6% document
2Toner cartridge(Black) MX-236FT Toner cartridge
Vinyl bag
x1
x1
Default is Toner save
mode. Life is 10K.
Life setting by A4 6% document
3Developer MX-235FV Developer x1 50K
4Drum KIT AR-205DR Drum
Drum fixing plate
x1
x1
50K
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-235FT Toner cartridge
Vinyl bag
x1
x1
16K Life setting by A4 6% document
2Toner cartridge(Black) MX-236FT Toner cartridge
Vinyl bag
x1
x1
8.4K Life setting by A4 6% document
3Developer MX-235FV Developer x1 50K
4Drum KIT AR-205DR Drum
Drum fixing plate
x1
x1
50K
1
1

AR-5618S CONSUMABLE PARTS 4-2
：'11/Jul/22
1
G. Asia(Except the above)/Thailand/Hong Kong
2. Environmental conditions
A. Transport conditions
(1) Transport conditions
(2) Storage conditions
B. Use conditions
C. Life(packed conditions)
Photoconductor drum (36 months from the production month)
Developer, toner (24 months from the production month)
No. Name Product name Content Life Remark
1Toner cartridge(Black) MX-235AT Toner cartridge
Vinyl bag
x1
x1
Default is Toner save
mode. Life is 19K.
Life setting by A4 6% document
2Toner cartridge(Black) MX-236AT Toner cartridge
Vinyl bag
x1
x1
Default is Toner save
mode. Life is 10K.
Life setting by A4 6% document
3Developer MX-235AV Developer x1 50K
4Drum KIT AR-205DR Drum
Drum fixing plate
x1
x1
50K
1
Temperature
Humidity (%)
Temperature
Humidity (%)
Humidity (%)
Temperature
Use envi-
ronment
conditions

AR-5618S CONSUMABLE PARTS 4-3
3. Production number identification
<Toner cartridge>
The label on the toner cartridge shows the date of production.
<Drum cartridge>
The lot number, printed on the front side flange, is composed of 10 digits,
each digit showing the following content:
The lot number is of 10 digits. Each digit indicates the content as follows.
The number is printed on the flange on the front side.
Ver.No.Production
place
Serial
number
Year/
Month/
Day
12345678910
1: Number
For this model, this digit is 2.
2: Alphabet
Indicates the model conformity code. G for this model.
3: Number
Indicates the end digit of the production year.
4: Number or X, Y, Z
Indicates the production month.
X stands for October, Y November, and Z December.
5/6: Number
Indicates the day of the production date.
7: Number
Indicates the day of the month of packing.
X stands for October, Y November, and Z December.
8/9: Number
Indicates the day of the packing date.
10: Alphabet
Indicates the production factory.
1
：'11/Jul/22
1

AR-5618S EXTERNAL VIEWS AND INTERNAL STRUCTURES 5-1
：'11/Jul/22
1
[5] EXTERNAL VIEWS AND INTERNAL STRUCTURES
1. Appearance
2. Internal
1Glass cleaner
(when the SPF/RSPF is installed)
2Document feeder cover (when the SPF/
RSPF is installed) /document cover
3Document glass
4Handles 5Power switch 6Operation panel
7Paper output tray 8Front cover 9Paper trays
10 Side cover 11 Side cover handle 12 Bypass tray guides
13 Bypass tray 14 Bypass tray extension 15 Charger cleaner
16 USB 2.0 connector
(Except for AR-5618N/5620N/5623N)
17 10Base-T/100Base-TX LAN connector
(Except for AR-5618S/5620S)
18 Document feeder tray
(when the SPF/RSPF is installed)
19 Original guides
(when the SPF/RSPF is installed)
20 Feeding roller cover
(when the SPF/RSPF is installed)
21 Right side cover
(when the SPF/RSPF is installed)
22 Exit area
(when the SPF/RSPF is installed)
23 Toner cartridge lock release lever
24 Toner cartridge 25 Roller rotating knob 26 Fusing unit release levers
27 Photoconductive drum 28 Fusing unit paper guide
15
17
9
6
7
8
2
3
5
4
1
13 14
10
11
12
4
2
16
1
1
1
1
2018
22
21
25 26
19
28
27
24
23
1
1
1
1
1

AR-5618S EXTERNAL VIEWS AND INTERNAL STRUCTURES 5-2
：'11/Jul/22
1
3. Operation Section
1SCAN MENU key
(Except for AR-5618S/5620S)
2SCAN key / indicator
(Except for AR-5618S/5620S)
3ON LINE key/indicator
4ORIGINAL TO COPY key/indicators
(AR-5618N/5620N/5623N, AR-5618D/
5620D/5623D)
5XY-ZOOM key / indicator 6DUAL PAGE COPY key / indicator
7ERASE key / indicators
(Except for AR-5618S/5620S)
8ORIGINAL DATA indicator
(Except for AR-5618S/5620S)
9SORT/GROUP key / indicators
(Except for AR-5618S/5620S)
10 2 IN 1 / 4 IN 1 key / indicators
(Except for AR-5618S/5620S)
11 MARGIN SHIFT key / indicator
(Except for AR-5618S/5620S)
12 AUTO/TEXT/PHOTO key / indicators 13 ORIGINAL key / ORIGINAL SIZE
indicators
14 PAPER SIZE indicators
15 Paper feed location / misfeed location
indicators
16 Alarm indicators 17 Display
18 Numeric keys 19 CLEAR key 20 INTERRUPT key / indicator
21 Light and Dark keys / indicators 22 PAPER SELECT key 23 AUTO PAPER SELECT indicator
(Except for AR-5618S/5620S)
24 TRAY SETTING key 25 AUTO IMAGE key / indicator 26 SPF/RSPF indicator
(When the SPF/RSPF is installed)
(AR-5618N/5620N/5623N, AR-5618/
5620/5623 and AR-5618D/5620D/5623D)
27 PRESET RATIO selector keys /
indicators
28 Zoom keys 29 Copy ratio display key
30 ZOOM indicator 31 Audit clear key 32 READ-END key
33 CLEAR ALL key 34 POWER SAVE indicator 35 START key / indicator
910
23 4 5 67811
1
13 14 15 26 27
The indications of the operation panel may differ
depending on the country and the region.
This example is of the inch series display.
When the ID
CARD COPY
function is used
(AR-5618S/AR-5620S)
3
5
6
1
1
1
1
1
1
1
1
12 13 14 15 16 17 18 19 20
21 22
23
24 25 26 27 28 29 3031 35343332
When there are two or more paper trays
(AR-5618S/AR-5620S)
16
15
1
1
1
1

AR-5618S EXTERNAL VIEWS AND INTERNAL STRUCTURES 5-3
：'11/Jul/22
1
4. Motor, solenoid, clutch
No. Name Code Function operation
1Mirror motor MRM Drives the optical mirror base (scanner unit).
2Toner motor TM Toner supply
3Duplex motor DPX Switchback operation and paper exit motor in duplex.
4Main motor MM Drives the machine.
51st tray paper feed clutch CPSCL1 Drive the pick up roller
6PS clutch RRC Drives the resist roller
7Bypass tray paper transport clutch MPTC Drives the bypass tray paper transport roller.
8Bypass tray paper feed solenoid MPFS Bypass tray paper feed solenoid
92nd tray transport clutch FSCL1 Drives the 2nd tray transport roller.
(AR-5620/5623/5620N/5623N/5620D/5623D only)
10 2nd tray paper feed clutch PSCL2 Drives the 2nd tray paper feed roller.
(AR-5620/5623/5620N/5623N/5620D/5623D only)
11 Exhaust fan motor PSFM Cools the inside of the machine.
12 Cooling fan motor VFM Cools the inside of the machine.
(The shape of the fan motor differs in the models of AR-5618/5620/5623 and AR-
5618D/5620D/5623D.)
11
910
6
5
7
8
4
3
1212
1
1
1
1
1

AR-5618S EXTERNAL VIEWS AND INTERNAL STRUCTURES 5-4
：'11/Jul/22
1
5. Sensor, switch
No. Name Code Function operation
1Mirror home position sensor MHPS Detects the mirror (scanner unit) home position.
2Side door switch DSWR Side door open detection
3Paper exit sensor (paper exit side) POD1 Detects paper exit.
4Paper exit sensor (DUP side) PDPX Paper transport detection
5Thermistor RTH Fusing section temperature detection
6Thermostat RDTCT Fusing section abnormally high temperature detection
7Toner density sensor TCS Detects the toner density in the developing unit.
82nd tray detection switch CSD2 2nd tray detection
9Bypass tray sensor MPED Bypass tray transport detection
10 2nd tray door open/close sensor DRS2 2nd tray door open/close detection
(AR-5620/5623/5620N/5623N/5620D/5623D only)
11 2nd tray door paper pass sensor PPD2 2nd tray paper entry detection (AR-5620/5623/5620N/5623N/5620D/5623D only)
12 2nd tray paper empty sensor CSS2 2nd tray paper empty detection (AR-5620/5623/5620N/5623N/5620D/5623D only)
13 Paper in sensor PIN Paper transport detection
14 Tr ay e m p t y CSS1 Tray paper entry detection
15 Front cover SW DSWF Front cover open detection
16 Power switch MAIN SW Turns ON/OFF the main power source.
1
15
16 4
5
6
7
8
9
10
11
13
14
12
2
3
1
1
1
1
1
1

AR-5618S EXTERNAL VIEWS AND INTERNAL STRUCTURES 5-5
：'11/Jul/22
1
6. PWB unit
No. Name Function operation
1Copy lamp Inverter PWB Copy lamp control
2CCD sensor PWB Image scanning
3Main control PWB Main control PWB
42nd tray PWB 2nd tray control
5High voltage PWB High voltage control
6Power PWB AC power input/DC power control
7Operation main PWB Operation panel input/Display, operation panel section control
8USB I/F PWB Connect a USB device (Except for AR-5618N/5620N/5623N)
9Nic PWB Network interface PWB (Except for AR-5618S/5620S)
1
9
7
6
5
3
4
2
8
1
1
