Sharp AR-BC320 User manual

•BEFORE USING
THE PRODUCT
•
MANAGING THE MACHINE
•PERIPHERAL DEVICES
•BEFORE MAKING
COPIES
•BASIC PROCEDURE
FOR MAKING COPIES
•CONVENIENT COPY
FUNCTIONS
•
MACHINE MAINTENANCE
(FOR COPYING)
•SPECIFICATIONS
1-1
2-1
3-1
4-1
5-1
6-1
7-1
8-1
Page
DIGITAL FULL COLOR MULTIFUNCTIONAL
SYSTEM
OPERATION MANUAL
(for general information and copier operation)
MODEL
AR-BC320
(Option) Duplex bypass / inverter unit and
Stand / 3 x 500 sheet paper drawer
NA
KS1
CZZ
Be sure to become thoroughly familiar with this manual to
gain the maximum benefit from the product.
Before installing this product, be sure to read the
installation requirements and cautions sections.
Be sure to keep all operation manuals handy for reference
including this manual, the "Operation manual (for general
information and copier operation)" and operation manuals
for any optional equipment which has been installed.
WhaleII_general-copy_SEC.book 1 ページ ２００４年９月１４日 火曜日 午前１１時４５分

Warranty
While every effort has been made to make this document as accurate and helpful as possible, SHARP Corporation
makes no warranty of any kind with regard to its content. All information included herein is subject to change without
notice. SHARP is not responsible for any loss or damages, direct or indirect, arising from or related to the use of this
operation manual.
©Copyright SHARP Corporation 2004. All rights reserved. Reproduction, adaptation or translation without prior
written permission is prohibited, except as allowed under copyright laws.
The power switch positions are marked " I " to indicate power "ON" and " " to indicate stand-by.
In the stand-by position, power is being supplied to a drying heater within the optical system of the copier.
Caution:
For complete electrical disconnection, pull out the main plug.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
FOR YOUR RECORDS ...
To protect against loss or theft, record and retain for reference the machine’s serial number located on the back
of the unit.
Model Number AR-BC320
Serial Number
Date of Purchase
Place of Purchase
Authorized Sharp Copier/Printer
Service Department Number
This operation manual is also used for the AR-BC320 J.
WhaleII_general-copy_SEC.book 1 ページ ２００４年９月１４日 火曜日 午前１１時４５分

Part 1: General Information
WhaleII_general-copy_SEC.book 1 ページ ２００４年９月１４日 火曜日 午前１１時４５分

WhaleII_general-copy_SEC.book 2 ページ ２００４年９月１４日 火曜日 午前１１時４５分

0-1
OPERATION MANUALS
The following operation manuals are provided for the machine. Please read the appropriate manuals as needed for
the features you wish to learn about.
●
●●
●Operation manual (for general information and copier operation) (this manual):
The first half of this manual provides general information about the machine, including safety information, loading
paper, removing misfeeds, and regular maintenance.
The second half of the manual explains how to use the copy functions.
●
●●
●Key operator's guide:
This primarily explains key operator programs for machine management and copier related functions. Key
operator programs for the printer, the facsimile and network scanner functions are explained in separate
manuals.
Key operator programs are used by key operators to configure function settings to meet the needs of the
customer.
●
●●
●Operation manual (for facsimile):
This manual explains the procedures for using the machine as a facsimile. To use the fax function, the facsimile
expansion kit must be installed.
●
●●
●Installation guide (for printer):
This explains how to connect the machine to your computer, install the printer driver for Windows, and configure
the printer driver settings.
●
●●
●Operation manual (for printer)*:
This manual explains the procedures for using the machine as a printer.
●
●●
●Operation manual (for network scanner)*:
This manual explains the procedures for using the machine as a network scanner when connected to a computer.
* The Operation manual (for printer) and the Operation manual (for network scanner) are provided as PDF files
on the supplied CD-ROM.
These manuals are not provided as printed manuals.
NOTES
●Considerable care has been taken in preparing this manual. If you have any comments or concerns about the
manual, please contact your nearest SHARP Service Department.
●This product has undergone strict quality control and inspection procedures. In the unlikely event that a defect
or other problem is discovered, please contact your dealer or nearest SHARP Service Department.
●Aside from instances provided for by law, SHARP is not responsible for failures occurring during use of the
product or its options, or failures due to incorrect operation of the product and its options, or other failures, or for
any damage that occurs due to use of the product.
The display screens, messages, and key names shown in the manual may differ from those on the actual machine
due to product improvements and modifications.
Some options may not be available in some countries and regions. This manual assumes that the optional
facsimile expansion kit has been installed, however, the basic operations of the machine are the same regardless
of the peripheral devices that are installed. For the peripheral devices that can be installed, see "Part names and
functions of peripheral devices" (1-6).
sec_whale_00.fm 1 ページ ２００４年１１月１６日 火曜日 午後１時８分

0-2
Improper installation may damage this product. Please note the following during initial installation and whenever the
machine is moved.
1. The machine should be installed near an accessible
power outlet for easy connection.
2. Be sure to connect the power cord only to a power
outlet that meets the specified voltage and current
requirements. Also make certain the outlet is
properly grounded.
●For the power supply requirements, see the
name plate on the main unit.
3. Do not install your machine in areas that are:
●damp, humid, or very dusty
●exposed to direct sunlight
●poorly ventilated
●subject to extreme temperature or humidity
changes, e.g., near an air conditioner or heater.
4. Be sure to allow the required space around the
machine for servicing and proper ventilation.
A small amount of ozone is produced within the copier during operation. The emission level is insufficient to cause
any health hazard.
NOTE:
The present recommended long term exposure limit for ozone is 0.1 ppm (0.2 mg/m3) calculated as an 8 hr. time-
weighted average concentration.
However, since the small amount that is emitted may have an objectionable odor, it is advisable to place the copier
in a ventilated area.
31-1/2"
(80cm)
23-5/8"
(60cm)
23-5/8"
(60cm)
11-13/16"
(30cm)
INSTALLATION REQUIREMENTS
WhaleII_general-copy_SEC.book 2 ページ ２００４年９月１４日 火曜日 午前１１時４５分

INSTALLATION REQUIREMENTS
0-3
Moving this machine
Pull out the four handles as shown below, grasp them firmly, and keep the machine horizontal while moving it.
If the machine has been placed on a stand/paper drawer:
The stand/paper drawer is on casters for moving. Unlock the casters and the adjusters of the stand/paper drawer and
gently move the machine taking care to steady it to prevent it from toppling.
For locking and unlocking the casters and the adjusters, see page 0-4.
Left side Right side
Bypass
tray
Exit
tray
Handles Handles
Caution
Two people are required to lift and carry this machine.
If the machine is to be left unused for a long time
If the machine is to be left unused for a month or longer, follow the procedure on pages 2-6 and 2-7 to release
the pressure on the fusing roller.
Before lifting the machine,
fold up the exit tray and
tape it securely to the
machine.
Before lifting the machine,
fold up the bypass tray
and tape it securely to the
machine.
WhaleII_general-copy_SEC.book 3 ページ ２００４年９月１４日 火曜日 午前１１時４５分

0-4
CAUTIONS
1. Do not touch the photoconductive drum. Scratches
or smudges on the drum will cause dirty prints.
2. The fusing unit is extremely hot. Exercise care in
this area.
3. Do not look directly at the light source. Doing so may
damage your eyes.
4. Four adjusters are provided on all optional stand/
paper drawer units. These adjusters should be
lowered until they contact the floor.
When moving the machine with the optional stand/
paper drawer, be sure to raise the adjusters. Also,
unlock the two casters at the front of the optional
stand/paper drawer. After moving the machine,
lower the four adjusters until they reach the floor and
lock the two casters.
5. Do not make any modifications to this machine.
Doing so may result in personal injury or damage to
the machine.
6. Since this machine is heavy, it is recommended that
it be moved by more than one person to prevent
injury.
7. When connecting this machine to a computer, be
sure to first turn both the computer and the machine
off.
8. Do not make copies of anything which is prohibited
from copying by law. The following items are
normally prohibited from printing by national law.
Other items may be prohibited by local law.
●Money ●Stamps ●Bonds ●Stocks
●Bank drafts ●Checks ●Passports
●Driver's licenses
"BATTERY DISPOSAL"
THIS PRODUCT CONTAINS A LITHIUM PRIMARY MEMORY BACK-UP BATTERY THAT MUST BE
DISPOSED OF PROPERLY. PLEASE CONTACT YOUR LOCAL SHARP DEALER OR AUTHORIZED SERVICE
REPRESENTATIVE FOR ASSISTANCE IN DISPOSING OF THIS BATTERY.
This product utilizes tin-lead solder, and a fluorescent lamp containing a small amount of mercury.
Disposal of these materials may be regulated due to environmental considerations.
For disposal or recycling information, please contact your local authorities or the Electronics Industries Alliance:
www.eia.org
Fusing unit
Adjuster
Lock
Lock Release
Caster
Release
WhaleII_general-copy_SEC.book 4 ページ ２００４年９月１４日 火曜日 午前１１時４５分

0-5
CONTENTS
OPERATION MANUALS.................................................0-1
INSTALLATION REQUIREMENTS.................................0-2
●Moving this machine..................................................0-3
CAUTIONS......................................................................0-4
CHAPTER 1
BEFORE USING THE PRODUCT
INTRODUCTION.............................................................1-2
MAIN FEATURES ...........................................................1-2
PART NAMES AND FUNCTIONS ..................................1-4
●Exterior ......................................................................1-4
●Interior .......................................................................1-5
●Part names and functions of peripheral devices........1-6
●Operation panel.........................................................1-8
●Touch panel...............................................................1-9
AUDITING MODE .........................................................1-11
●Using the machine when the auditing mode is
enabled ...................................................................1-11
CHAPTER 2
MANAGING THE MACHINE
LOADING PAPER...........................................................2-2
●Loading paper in paper tray 1....................................2-2
●Changing the paper size in paper tray 1....................2-2
●Loading paper in the bypass tray ..............................2-4
●Loading paper in the stand/1 x 500 sheet paper drawer/
stand/3 x 500 sheet paper drawer .............................2-7
●Specifications (stand/1 x 500 sheet paper drawer/
stand/3 x 500 sheet paper drawer)............................2-7
●Loading paper in the duplex module/2 x 500 sheet
paper drawer .............................................................2-8
●Specifications (duplex module/2 x 500 sheet paper
drawer) ......................................................................2-8
●Specifications of paper trays .....................................2-9
●Setting the paper type (except the bypass tray) ......2-11
●Setting the paper size when an extra size is loaded2-11
●Setting the paper type and paper size in the bypass
tray...........................................................................2-12
CUSTOM SETTINGS....................................................2-13
●Operation procedure common to all custom settings
.................................................................................2-13
●About the settings....................................................2-14
REPLACING THE TONER CARTRIDGES ...................2-15
STORAGE OF SUPPLIES ............................................2-17
MISFEED REMOVAL....................................................2-18
●Misfeed removal guidance.......................................2-18
●Misfeed in the paper feed area................................2-19
●Misfeed in the transport area, fusing area, and exit
area .........................................................................2-20
●Misfeed in the stand/1 x 500 sheet paper drawer....2-21
●Misfeed in the stand/3 x 500 sheet paper drawer....2-21
●Misfeed in the duplex bypass/inverter unit and duplex
module/2 x 500 sheet paper drawer........................2-22
TROUBLESHOOTING ..................................................2-24
CHAPTER 3
PERIPHERAL DEVICES
SADDLE STITCH FINISHER ......................................... 3-2
●Part names and functions ......................................... 3-2
●Specifications............................................................ 3-2
●Saddle stitch finisher functions ................................. 3-4
●Using the saddle stitch finisher ................................. 3-6
●
Staple cartridge replacement and staple jam removal .. 3-7
●Misfeed in the saddle stitch finisher........................ 3-10
●Troubleshooting saddle stitch finisher problems..... 3-12
●Stapling position quick reference guide for duplex
output ...................................................................... 3-13
●Relation between print image and saddle stitch ..... 3-14
LARGE CAPACITY TRAY............................................ 3-15
●Part name ............................................................... 3-15
●Specifications.......................................................... 3-15
●Loading paper in the large capacity tray................. 3-16
●Misfeed in the large capacity tray ........................... 3-17
WhaleII_general-copy_SEC.book 5 ページ ２００４年９月１４日 火曜日 午前１１時４５分

CONTENTS
0-6
CHAPTER 4
BEFORE MAKING COPIES
PART NAMES AND FUNCTIONS (The Reversing Automatic
Document Feeder)
........................................................... 4-2
●Exterior ..................................................................... 4-2
●Operation Panel........................................................ 4-3
●Touch Panel (main screen of copy mode)................ 4-4
REVERSING AUTOMATIC DOCUMENT FEEDER....... 4-5
●Acceptable originals.................................................. 4-5
SETTING ORIGINALS ................................................... 4-6
SELECTING THE ORIGINAL SIZE................................ 4-8
STORING, DELETING, AND USING ORIGINAL SIZES ........ 4-9
CHAPTER 5
BASIC PROCEDURE FOR MAKING
COPIES
NORMAL COPYING....................................................... 5-2
●Copying from the reversing automatic document feeder
.................................................................................. 5-2
●Automatic two-sided copying from the reversing
automatic document feeder ...................................... 5-6
●Copying from the document glass ............................ 5-7
●Automatic two-sided copying from the document glass
.................................................................................. 5-9
EXPOSURE ADJUSTMENTS...................................... 5-10
REDUCTION/ENLARGEMENT/ZOOM ........................ 5-12
●Automatic selection (auto image) ........................... 5-12
●Manual selection..................................................... 5-13
●XY ZOOM ............................................................... 5-15
SPECIAL PAPERS....................................................... 5-17
CHAPTER 6
CONVENIENT COPY FUNCTIONS
SPECIAL MODES .......................................................... 6-2
●Common operation procedure for using the special
functions ................................................................... 6-3
●Margin shift ............................................................... 6-4
●Erase ........................................................................ 6-5
●Dual page copy......................................................... 6-6
●Centering .................................................................. 6-7
●Transparency film with insert sheets ........................ 6-8
●Covers ...................................................................... 6-9
●B/W reverse ............................................................ 6-10
COLOR ADJUSTMENTS MENU.................................. 6-11
●RGB adjust ............................................................. 6-12
●Sharpness............................................................... 6-13
●Suppress background............................................. 6-13
●Color balance.......................................................... 6-14
●Brightness............................................................... 6-15
●Intensity .................................................................. 6-15
IMAGE EDIT MENU ..................................................... 6-16
●Single color ............................................................. 6-17
●Mirror image ............................................................ 6-17
●Photo Repeat .......................................................... 6-18
●Multi shot................................................................. 6-19
●11" x 17" (A3) Full-bleed ......................................... 6-21
●Multi-page enlargement .......................................... 6-22
●Pamphlet copy ........................................................ 6-24
JOB PROGRAM MEMORY .......................................... 6-25
●Storing a job program.............................................. 6-25
●Recalling a job program .......................................... 6-26
●Deleting a stored job program................................. 6-26
INTERRUPTING A COPY RUN ................................... 6-27
CHAPTER 7
MACHINE MAINTENANCE (FOR
COPYING)
REMOVING AN ORIGINAL MISFEED ........................... 7-2
●Removing a misfed original from the reversing automatic
document feeder ....................................................... 7-2
USER MAINTENANCE (For copying) ............................ 7-3
TROUBLESHOOTING.................................................... 7-4
CHAPTER 8
SPECIFICATIONS
SPECIFICATIONS.......................................................... 8-2
●Copier and Main unit ................................................. 8-2
●Reversing automatic document feeder ..................... 8-4
●Duplex bypass/inverter unit (optional)....................... 8-4
INDEX............................................................................. 8-5
WhaleII_general-copy_SEC.book 6 ページ ２００４年９月１４日 火曜日 午前１１時４５分

1-1
CHAPTER 1
BEFORE USING THE
PRODUCT
This chapter contains basic information that should be read before using
the product.
Page
INTRODUCTION ...........................................................................................1-2
MAIN FEATURES..........................................................................................1-2
PART NAMES AND FUNCTIONS .................................................................1-4
●Exterior...................................................................................................1-4
●Interior....................................................................................................1-5
●Part names and functions of peripheral devices ....................................1-6
●Operation panel......................................................................................1-8
●Touch panel ...........................................................................................1-9
AUDITING MODE ........................................................................................1-11
●Using the machine when the auditing mode is enabled.......................1-11
WhaleII_general-copy_SEC.book 1 ページ ２００４年９月１４日 火曜日 午前１１時４５分

1-2
INTRODUCTION
To gain the maximum benefits in using this product, it is recommended that the user read this manual to become
familiar with all the features and functions of the basic product and the precautionary information contained in the
manual.
This product is a high speed Digital full color copier / printer that can be expanded to become multifunctional through
the installation of optional peripheral devices. The product can be extended to include printer, network scanning or
network printing capabilities. This manual describes the basic use of the product as a copier and does not contain
information on using any of the optional peripheral devices. Separate operation manuals are included with each of
the optional peripheral devices. Refer to these manuals for their operation.
Original and paper sizes
This machine allows use of standard sizes in both the inch and AB systems.
These are shown in the tables below.
The meaning of "R" in original and paper size indications
Some original and paper sizes can be placed in either the portrait or landscape orientations. To differentiate between
landscape and portrait, the landscape orientation size indication will contain an "R". These are indicated as 8-1/2" x
11"R, 5-1/2" x 8-1/2"R, A4R, B5R, etc. Sizes that can be placed only in the landscape orientation (11" x 17", 8-1/2"
x 14", 8-1/2" x 13", A3, B4) do not contain the "R" in their size indication.
Size indication with "R"
Landscape orientation
Size indication without "R"
Portrait orientation
MAIN FEATURES
1Full-color copies with vivid colors based on digital technology
Photos, color text, and other originals are scanned by full-color CCD sensors, and the acquired image
information is output in vivid full color at a resolution of 600 dpi using digital image processing technology.
The machine can also be used as a full-color network printer, and network scanner.
2A range of optional units to enhance productivity
A range of optional equipment is available to enhance productivity, such as duplex units for producing two-sided
output, additional paper feed units to increase the number of available paper sizes and paper capacity, and
paper output units that are capable of stapling and saddle stitch binding.
Sizes in the inch system
11" x 17" (LEDGER)
8-1/2" x 14" (LEGAL)
8-1/2" x 13" (FOOLSCAP)
8-1/2" x 11" (LETTER)
7-1/4" x 10-1/2" (EXECUTIVE)
5-1/2" x 8-1/2" (INVOICE)
Sizes in the AB system
A3
B4
A4
B5
A5
WhaleII_general-copy_SEC.book 2 ページ ２００４年９月１４日 火曜日 午前１１時４５分

MAIN FEATURES
1-3
1
3Advanced image processing features based on digital technology
The scanned image data is converted to digital data, enabling the following advanced image processing features:
●
●●
●Photo Repeat :
Up to 24 full-size copies of a photo image can be made on a single sheet of paper (page 6-18).
●
●●
●Multi shot :
Up to four original pages can be copied onto a single sheet (page 6-19).
●
●●
●Pamphlet copy* :
Copies of original pages are arranged in proper order for copying so that the copies can be center-stapled and
folded into a pamphlet (page 6-24).
* Pamphlet copy requires the Duplex module/2 x 500 sheet paper drawer and Duplex bypass/inverter unit
options. If a saddle stitch finisher is installed, copies can be stapled in two positions along the center of copies
and folded at the center.
4Image processing manual exposure adjustment for optimal copying
Image processing is optimized for the type of original being copied (text, photo, mixed text and photo or map). This
along with the ability to manually adjust exposure makes it possible to obtain copies that are faithful to the original.
5Standard offset function makes it easy to distinguish between sets of copies
As sets of copies are delivered to the center tray, each set is offset from the previous set for easy separation.
6PostScript compatible
Installation of an optional PS expansion kit (AR-PK4) gives PostScript compatibility (PostScript 3).
Energy saving features
This product has the following two power reducing modes to help conserve natural resources and reduce
environmental pollution.
Preheat mode
Preheat mode automatically reduces the temperature of the fusing unit after the time set in the key operator
programs elapses when the machine is on standby. This allows the machine to use less power while on
standby. The machine automatically returns to normal operation when a key is pressed on the operation
panel, or when an original is placed to make a copy or send a fax.
Auto power shut-off mode
Auto power shut-off mode automatically shuts off power to the fusing unit after the time set in the key
operator programs elapses when the machine is on standby. This minimizes the power used by the
machine while on standby. When this mode activates, the touch panel screen turns off.
To return the machine to normal operation, press the mode select key (the indicator of this key will be lit).
Auto power shut-off mode can be configured in the key operator programs. The mode is initially set (factory
default setting) to activate after 60 seconds elapses. (See page 9 of the key operator's guide.)
If a print job or fax is received while auto power shut-off mode or preheat mode is activated, the machine
automatically returns to normal operation.
As an ENERGY STAR®Partner, SHARP has determined that this product meets the
ENERGY STAR®guidelines for energy efficiency.
The Environmental Choice Program guidelines are applied to the products only in Canada. The
products that meet the Environmental Choice Program guidelines carry the logo shown above.
The products without the logo may not meet the Environmental Choice Program guidelines.
sec_whale_01_1.fm 3 ページ ２００４年９月１７日 金曜日 午前１１時３分

1-4
PART NAMES AND FUNCTIONS
Exterior
Left tray (See page 5-5)
Finished sheets are deposited here.
Left side cover
Open this cover when a paper misfeed occurs in
the fusing unit or the transfer unit.
Reversing automatic document feeder
(See page 4-2)
This automatically feeds originals to be scanned.
The feeder can turn the original over and scan the
back side as well as the front side for support of
two-sided originals.
Power switch
Press to turn power on and off.
Front cover
Open to replace toner cartridge.
Operation panel
Center tray (See page 5-5)
Finished sheets are deposited here.
Bypass tray
Special papers (including transparency film) and
copy paper can be fed from the bypass tray.
Stand/1 x 500 sheet paper drawer*
(See page 2-7)
Stand/3 x 500 sheet paper drawer*
(See page 2-7)
Duplex module/2 x 500 sheet paper drawer*
(See page 2-8)
Paper tray
Each tray can hold approximately 500 sheets of the
recommended paper for color (21 lbs. or 80 g/m
2
),
or approximately 500 sheets of SHARP standard
paper (21 lbs. or 80 g/m
2
).
Left side cover release
Push this release up to open the left side cover.
Duplex bypass/inverter unit and exit tray* (See
page 1-6)
* , , and are peripheral devices. For a description of these devices, see page 1-6.
sec_whale_01_1.fm 4 ページ ２００４年９月１６日 木曜日 午前１０時３５分

PART NAMES AND FUNCTIONS
1-5
1
Interior
Fusing unit
Toner images are fused here.
Toner cartridge
The toner cartridge must be replaced when
indicated on the operation panel. (See page 2-15)
Right side cover
Open when a misfeed has occurred in the paper
feed area.
Right cover of paper drawer
Open this cover to remove paper misfed in the
paper drawer.
CAUTION
The fusing unit is hot. Take care in removing misfed
paper.
WhaleII_general-copy_SEC.book 5 ページ ２００４年９月１４日 火曜日 午前１１時４５分

PART NAMES AND FUNCTIONS
1-6
Part names and functions of peripheral devices
Large Capacity tray (AR-LC8)
The large capacity tray provides the added
convenience of having 3,500 sheets of 8-1/2" x 11"
or A4 paper (21 lbs. or 80 g/m
2
) available.
Stand/1 x 500 sheet paper drawer (AR-D17N)
This stand has one paper tray. It can hold
approximately 500 sheets of the recommended
paper for color (21 lbs. or 80 g/m2), or
approximately 500 sheets of SHARP standard
paper (21 lbs. or 80 g/m2).
Duplex module/2 x 500 sheet paper drawer (AR-D19N)
This stand includes a module for automatic two-
sided printing and two paper trays. The two trays
can hold approximately 500 sheets of the
recommended paper for color (21 lbs. or 80 g/m2),
or approximately 500 sheets of SHARP standard
paper (21 lbs. or 80 g/m2). To perform two-sided
printing, a duplex bypass/inverter unit (AR-RB1) is
required.
Stand/3 x 500 sheet paper drawer (AR-D18N)
This stand has three paper trays. Each tray can
hold approximately 500 sheets of the
recommended paper for color (21 lbs. or 80 g/m2),
or approximately 500 sheets of SHARP standard
paper (21 lbs. or 80 g/m2).
Saddle stitch finisher (AR-F13)
The finisher can deliver sets saddle stitched and
folded at the paper centerline to form a pamphlet,
edge stapled in three different modes or unstapled.
For two-hole or three-hole output, a hole punch
module must be installed.
Exit tray (AR-TE3)
The exit tray is installed on the output outlet of the
machine or the duplex tray / inverter unit.
Duplex bypass/inverter unit (AR-RB1)
This module is required to automatically turn paper
over within the machine for automatic two-sided
printing.
WhaleII_general-copy_SEC.book 6 ページ ２００４年９月１４日 火曜日 午前１１時４５分

PART NAMES AND FUNCTIONS
1-7
1
■
■■
■Other optional equipment
●
●●
●PS3 expansion kit (AR-PK4)
This kit provides compatibility of PostScript level 3
to the printer.
●
●●
●Facsimile expansion kit (AR-FX10)
This kit must be installed to use the fax function.
●
●●
●Fax memory (8 MB) (AR-MM9)
This adds memory for use by the fax function.
●
●●
●256 MB optional memory (AR-SM5)
This adds memory that is used for the copy
function, printer function, and scanner function.
■
■■
■Face-up and face-down output
After printing, the paper is delivered to the exit tray. This product has two exit trays (center tray and left tray). The
paper specifications (page 8-3) and output conditions differ for each tray; however, if the paper and output
conditions are such that the paper can be delivered to either tray, you can select the tray to which the paper will
go.
●Paper exits to the center tray face-down only.
●Paper exits to the left tray face-up only. However, if a duplex bypass/inverter unit has been installed, face-
down output is also possible. In this case, face-up or face-down output is automatically selected according to
the paper and output conditions (it is not possible to manually select face-up or face-down.)
WhaleII_general-copy_SEC.book 7 ページ ２００４年９月１４日 火曜日 午前１１時４５分

PART NAMES AND FUNCTIONS
1-8
Operation panel
Touch panel
The machine status, messages and touch keys are
displayed on the panel. When using the touch
panel, first change the display to the mode that you
wish to use: printer mode, copy mode, network
scanner mode, or fax mode*. For details see the
next page.
Mode select keys and indicators
Use to change modes and the corresponding
display on the touch panel.
[PRINT] key/READY indicator/DATA indicator
Press to enter the printer mode.
READY indicator
Print data can be received when this indicator is
lit.
DATA indicator
Lights up or blinks when print data is being
received. Also lights up or blinks when printing is
being performed.
[IMAGE SEND] key/LINE indicator/DATA
indicator
Press this key to switch the display between
network scanner mode and fax mode*. (See the
operation manuals for network scanner and fax.)
[COPY] key
Press to select the copy mode.
[JOB STATUS] key
Press to display the current job status. (See page
1-10.)
[CUSTOM SETTINGS] key
Use to adjust the contrast of the touch panel or to
set key operator programs. (See page 2-13.)
Numeric keys
Use to enter number values for various settings.
[ ] key ([ACC.#-C] key)
This is used when the copy, network scan, and fax*
functions are used.
[#/P] key
This is used as a program key when using the copy
function, and to dial when using the fax function*.
[C] key
This key is used in copy mode, network scanner
mode, and fax mode*.
[BLACK COPY START ( )] key
This is used to make black and white copies and to
scan a black and white original when the network
scan function is used. This is also used to scan an
original to be faxed using the fax function*.
[CA] key
This key is used in copy mode, network scanner
mode, and fax mode*.
[COLOR COPY START ( )] key
This is used to make full-color or single-color
copies and to scan a color original when the
network scanner function is used.
* When the fax option is installed.
WhaleII_general-copy_SEC.book 8 ページ ２００４年９月１４日 火曜日 午前１１時４５分

PART NAMES AND FUNCTIONS
1-9
1
Touch panel
Using the touch panel
[Example 1]
Items on the touch panel
are easily selectable by
touching the key
associated with the item
with a finger. Selection
of an item will be
accompanied with a
beep tone to confirm the
item was selected. Also,
the key area for the item
will be highlighted for
visual confirmation.
[Example 2]
Keys which are grayed
out on any screen are
not selectable. If a
grayed out key is
touched, a double beep
will be sounded.
The confirmation beeps can be disabled by a key
operator program. (See page 10 of the key
operator's guide.)
The touch panel screens shown in this manual are
printed images, and may appear different from the
actual screens.
Selection of function
[Example 1]
Items which are
highlighted at the time a
screen appears are
already selected and will
be registered to function if
the [OK] key is touched.
[Example 2]
When the machine is
used in the copy mode,
the functions shown in
the table below can only
be set or canceled on
the special feature
screen by alternate
touches of the function
keys on the panel.
[Example 3]
When the machine is
used in the copy mode
and a special feature is
selected, a
corresponding icon
representing the feature
will appear on the touch
key and on the main
screen of the mode
selected. If this icon is
touched, the setting
screen of the function (or
a menu screen) will
appear, allowing the
settings to be checked
or adjusted and the
function to be canceled
easily.
JOB QUEUE
COPY
Suzuki
0666211221
003 / 00
003 / 00
010 / 00
SETS / PRO
Beep
tone
1/13
COMPLETE
Copier feature
●Dual page copy
●Centering
●Transparency inserts
●Mirror image
●11"x17" (A3) Full-bleed
●B/W Reverse
CANCEL OK
RIGHT
BINDING
LEFT
BINDING
TRANSPARENCY
INSERTS
DUAL PAGE
COPY
SPECIAL MODES
2-SIDED COPY
OUTPUT
READY TO COPY.
B4
P
OR
A3
A4
DUPLEX
WhaleII_general-copy_SEC.book 9 ページ ２００４年９月１４日 火曜日 午前１１時４５分

PART NAMES AND FUNCTIONS
1-10
Job status screen (common to print, copy, network scan and fax)
This screen is displayed when the [JOB STATUS] key on the operation panel is pressed.
A job list showing the current job at the top of the job queue or a list showing completed jobs can be displayed.
The contents of jobs can be viewed or jobs can be deleted from the queue. (The screen below is an example and
differs from actual screens.)
Job list
This shows the current job and the jobs waiting to
be run. The icons to the left of the jobs in the queue
show the job mode.
The displayed jobs in the job list are themselves
operation keys. To cancel printing or to give a job
the highest print priority, touch the relevant job key
to select the job and execute the desired operation
using the keys described in 5 and 6.
* "PAPER EMPTY" in the job status display
When a job status display indicates "PAPER
EMPTY", the specified paper size for the job is not
loaded in any of the trays.
When the [DETAIL] key appears, the key of a job in
the job queue can be touched followed by the
[DETAIL] key to change the paper size selection to
a different paper size (only in printer mode).
Mode select key
This only appears in the job status screen of fax
mode. The key is used to switch the job list display
between "JOB QUEUE" and "COMPLETE".
"JOB QUEUE": Shows stored jobs and the job in
progress.
"COMPLETE" : Shows finished jobs.
[PRINT JOB] key
Use to display the print job list for printer, copy and
fax mode.
[SCANNER JOB] key
This displays a list of jobs that only used the
network scanner function.
[FAX JOB] key
This displays the transmission/reception status
and finished jobs of fax mode when the fax option
is installed.
Display switching keys
Use to switch the page of the displayed job list.
[STOP/DELETE] key
Use to cancel or delete the current job or delete the
selected reserved job. Note that a fax print job
cannot be canceled or deleted.
[PRIORITY] key
This only appears in the job status screen of fax
mode. Touch this key to give priority to a job that
has been selected in the job queue.
[DETAIL] key
The key is only effective for computer print jobs and
only appears in the job status screen of the printer
mode. It is used to display detailed information of a
selected print job and to change the paper size for
the print job.
JOB QUEUE
COPY
Suzuki
066211221
STATUS
PAPER EMPTY *
003 / 000
PRINT JOB SCANNER JOB
FAX JOB
JOB QUEUE
COMPLETE
DETAIL
PRIORITY
STOP/DELETE
WAITING
WAITING
003 / 000
001 / 000
1/1
SETS / PROGRESS
Copy mode Printer mode
Network scanner mode
Fax send job Fax reception job
WhaleII_general-copy_SEC.book 10 ページ ２００４年９月１４日 火曜日 午前１１時４５分
