Sharp HT-CN400DVA User manual

MODEL
HT-CN400DVA
HT-CN500DVA
HOME THEATER WITH DVD
OPERATION MANUAL
HTCN400_500DVA_A 92LCN400A0270
HTCN400_500DVA_A 92LCN400A0270 1
MULTI
PRESET
ADJ/VOL
9
8765
4
0>
10
321
ENTER
SLEEP
ST/MO
TUNING
DISPLAY LANGUAGE
MUTE
PROG
MENU/PBC
NTSC/PAL
STEP
A-B
REPEAT
ANGLE
DIRECT
LISTENING
SLOW/MEMORY
TITLE
ZOOM AUDIO
RETURN
MODE
SUBTITLE
SETUP
OPEN/
CLOSE ON/
STAND-BY

2
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
Important Instruction
- Introduction / Special notes -
Introduction
!HT-CN400DVA Home Theater with DVD consisting of HT-CN400DVA (main unit),
CP-CN400AF (front speakers), CP-CN400AC (centre speaker), CP-CN400AR
(surround speakers) and CP-CN400ASW (subwoofer).
!HT-CN500DVA Home Theater with DVD consisting of HT-CN500DVA (main unit),
CP-CN500AF (front speakers), CP-CN500AC (centre speaker), CP-CN500AR
(surround speakers) and CP-CN500ASW (subwoofer).
Special notes
WARNING
!When the ON/STAND-BY button is set at STAND-BY position, mains voltage is still
present inside the unit. When the ON/STAND-BY button is set at STAND-BY posi-
tion, the unit may be brought into operation by the remote control.
!This unit contains no user serviceable parts. Never remove covers unless qualified
to do so. This unit contains dangerous voltages, always remove mains plug from
the socket before any service operation and when not in use for a long period.
!To prevent fire or shock hazard, do not expose this appliance to dripping or splash-
ing. No objects filled with liquids, such as vases, should be placed on the appara-
tus.
CAUTION
Thank you for purchasing this SHARP product. To obtain the best performance from
this product, please read this manual carefully. It will guide you in operating your
SHARP product.
The illustrations of the main unit in this operation manual are for the model HT-
CN500DVA.
Manufactured under license from Dolby Laboratories. "Dolby", "Pro Logic" and the
double-D symbol are trademarks of Dolby Laboratories.
Manufactured under license from Digital Theater Systems, Inc. US Pat.
No.5,451,942, 5,956,674, 5,974,380, 5,978,762 and other world-wide patents
issued and pending. "DTS" and "DTS Digital Surround" are registered trademarks
of Digital Theater Systems, Inc. Copyright 1996, 2000 Digital Theater Systems,
Inc. All Rights Reserved.
!This product is classified as a CLASS 1 LASER product.
!Use of controls, adjustments or performance of procedures other than those spec-
ified herein may result in hazardous radiation exposure.
As the laser beam used in this compact disc player is harmful to the eyes, do not
attempt to disassemble the cabinet. Refer servicing to qualified personnel only.
Material: AlGaAs/AlGalnP
Wavelength: 785 nm/650 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
Laser Diode Properties


3
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Contents -
Contents
Page
"General Information
Types of playable discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Description of discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 - 11
"System Connections
Speaker connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12, 13
Aerial connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Connections to TV, VCR, etc. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 15
"Preparation for Use
System installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Battery installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Turning the power on . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Changing the setup menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18 - 22
General control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
"DVD Operation
DVD playback
Playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24, 25
To resume playback after stopping (resume play) . . . . . . . . . . . . . . . . . . . . . . .25
DVD mode operation indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Basic operation
To locate the beginning of a chapter (track) (skip) . . . . . . . . . . . . . . . . . . . . . . .26
Fast forward/Fast reverse (search) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . .27
Useful operation
Still picture/Frame advance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Slow-motion play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
To change the angle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
To zoom images (zoom) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
To play repeatedly (repeat play) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
To play the contents between the specified points repeatedly (A-B repeat) . .31
To select a title from the top menu of the disc . . . . . . . . . . . . . . . . . . . . . . . . . .31
To select a subtitle or audio language from the disc menu . . . . . . . . . . . . . . . .31
Page
Various settings
To change the subtitle language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
To change the audio language (audio output) . . . . . . . . . . . . . . . . . . . . . . . . . .32
To change the TV type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
To change the audio channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
To change the display on TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
"Video CD and Super Video CD Operation
Video CD and Super Video CD playback
Playback of a video CD (super video CD) with P.B.C. . . . . . . . . . . . . . . . . . . . .34
To play without activating the playback control function . . . . . . . . . . . . . . . . .35
To start playback from the desired point (direct play) . . . . . . . . . . . . . . . . . . . .35
"CD, CD-R and CD-RW Operation
CD operation
To play in the desired order (programmed play) . . . . . . . . . . . . . . . . . . . . . . . . .36
MP3 and JPEG disc operation
Playback on the MP3 menu screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37, 38
Zoom function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
Rotating a picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39
"Radio Operation
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40, 41
"Advanced Features
Enjoying various sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42, 43
Adjusting speaker delay time/speaker level . . . . . . . . . . . . . . . . . . . . . . . . .44, 45
Sleep operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
"References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47, 48
Error indicators and warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .49, 50
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . End of the manual
HTCN400_500DVA_A 92LCN400A0270 2
1

4
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Types of playable discs -
Types of playable discs
The DVD player can play back discs bearing any of the following marks:
!For unplayable discs, see page 7.
Copyright Information:
!Unauthorised copying, broadcast, public display, transmission, public performance
and rental (regardless of whether or not such activities are for profit) of disc con-
tents are prohibited by law.
!This system is equipped with copy protection technology that causes substantial
degradation of images when the contents of a disc are copied to a videotape.
!This system is protected by U. S. patents and other intellectual property rights, the
copyright for which belongs to Macrovision Corporation. The use of Macrovision's
copy protection technology in the system is authorised by Macrovision and is
intended for home use only, unless otherwise authorised in writing by Macrovision.
Reverse engineering or disassembly is prohibited.
Disc type Disc contents Disc size
DVD Video Disc Audio and video
(movies) 12 cm (5")
8 cm (3")
Super Video CD Audio and video
(movies) 12 cm (5")
8 cm (3")
Video CD Audio and video
(movies) 12 cm (5")
8 cm (3")
Audio CD Audio 12 cm (5")
8 cm (3")
CD-R/CD-RW (*1) Audio and picture 12 cm (5")
8 cm (3")
Or CD-R/CD-RW recorded in MP3
format (*2), JPEG format (*3)
(*1): The CD-R/CD-RW may not be played back properly depending on the record-
ing equipment or the disc.
(*2): If the sampling frequency is 44.1 or 48.1 kHz and the fixed bit rate is 128 kbps
or higher, MPEG 1 Audio Layer 3 (MP3) files can be played. However, some
of them may not be played depending on their conditions or formats.
(*3): JPEG or JPG picture discs also play on this unit. However, pictures may not
be clear (depends on resolution and recording method).
Icons used in this operation manual
Some functions may not be available depending on discs. The following icons indicate
the discs that can be used in the section.
... Indicates DVDs.
... Indicates Super video CDs.
... Indicates video CDs.
... Indicates audio CDs.
... Indicates CD-R/RW with MP3 recording.
... Indicates CD-R/RW with JPEG recording.
!Some operations may not be performed depending on discs even if they are de-
scribed in this manual.
!During operation, " " may be displayed on the screen. This means that the opera-
tions described in this manual are not possible.

5
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Accessories -
Accessories
Please confirm that the following accessories are included.
Remote control 1 "AA"sizebattery
(UM/SUM-3, R6, HP-7 or similar) 2 Audio/Video cable 1
FM aerial 1 AM loop aerial 1
Speaker connection lead 6
Purple and Black
(for subwoofer)
approx.5 m (16 feet)
Green and Black
(for centre speaker)
approx.5 m (16 feet)
Blue and Black
(for left surround speaker)
approx.15 m (49 feet)
Grey and Black
(for right surround speaker)
approx.15 m (49 feet)
Red and Black
(for right front speaker)
approx.5 m (16 feet)
White and Black
(for left front speaker)
approx.5 m (16 feet)
Note:
Only the above accessories are included.
1

6
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Precautions -
Precautions
"General
!Please ensure that the equipment is positioned in a well ventilated area and that
there is at least 10 cm (4") of free space along the sides and back. There must
also be a minimum of 15 cm (6") of free space on the top of the unit.
!No naked flame sources, such as lighted candles, should be placed on the appa-
ratus.
!Attention should be drawn to the environmental aspects of battery disposal.
!This unit should only be used within the range of 5°C - 35°C (41°F - 95°F).
Warning:
The voltage used must be the same as that specified by this unit. Using this product
with a higher voltage other than that specified is dangerous and may result in a fire or
other types of accident, causing damage. SHARP will not be held responsible for any
damage resulting from the use of this unit with a voltage other than that specified.
"Volume control
The sound level at a given volume setting depends on speaker efficiency, location,
and various other factors. It is advisable to avoid exposure to high volume levels. Do
not turn the volume on to full at switch on and listen to music at moderate levels.
"Care of DVD/CD discs
DVD/CD discs are fairly resistant to damage, however mistracking can occur due to
an accumulation of dirt on the disc surface. Follow the guidelines below for maximum
enjoyment from your DVD/CD collection and player.
!Do not write on either side of the disc, particularly the non-label side from which
signals are read. Do not mark this surface.
!Keep your discs away from direct sunlight, heat, and excessive moisture.
!Always hold the DVD/CDs by the edges. Fingerprints, dirt, or water on the DVD/
CDs can cause noise or mistracking. If a DVD/CD is dirty or does not play properly,
clean it with a soft, dry cloth, wiping straight out from the centre, along the radius.
!Use the unit on a firm, level surface free from vibra-
tion.
!Keep the unit away from direct sunlight, strong mag-
netic fields, excessive dust, humidity and electronic/
electrical equipment (home computers, facsimiles,
etc.) which generates electrical noise.
!Do not place anything on top of the unit.
!Do not expose the unit to moisture, to temperatures
higher than 60°C (140°F) or to extremely low temper-
atures.
!Ifthe unit does not work properly, unplug and plug it in
again. Then turn on the unit.
!In case of an electrical storm, unplug the unit for safe-
ty.
!Hold the AC power plug by the head when removing it
from the wall socket, as pulling the lead can damage
internal wires.
!Do not remove the outer cover, as this may result
in electric shock. Refer internal service to your lo-
cal SHARP service facility.
10 cm (4") 10 cm (4")
10 cm (4")
15 cm (6")
!The ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers,
tablecloths, curtains, etc.
NO YES
Correct

7
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Description of discs -
Description of discs
"Discs that cannot be played
!The discs above cannot be played at all, or no sound is heard although images
appear on the screen or vice versa.
!Incorrect operation may damage the speakers and can have an negative effect on
your hearing when played at high volume settings.
!You cannot play illegally produced discs.
Notes:
!A disc with has scratches or fingerprints may not play properly. Refer to "Care of
DVD/CD discs (page 6)" and clean the disc.
!Do not play the discs of special shapes (heart or octagon shaped) as they can be
ejected whilst rotating and cause injury.
"Title, chapter and track
DVDs are divided into "titles" and "chapters". If the disc has more than one movie on
it, each movie is a separate "title". "Chapters" are subdivisions of titles.
Audio CDs consist of "tracks".
A "track" is each tune on an audio CD.
Note:
Title, chapter, or track numbers may not be recorded on some discs.
"Icons used on DVD discs
Check the icons on the DVD case before playing your discs.
!DVDswithoutthe regionnumber"4"or
"ALL". !CDG
!CDV
!DVDs with SECAM system !Photo CD
!DVD-ROM !CD-ROM
!DVD-RAM !SACD
!DVD-Audio !Discs recorded in special formats, etc.
Chapter 1
Title 1 Title 2
Chapter 2 Chapter 3 Chapter 1 Chapter 2
Track 1 Track 2 Track 3 Track 4 Track 5
DisplayDescription
Region number (playable area number) DVD discs are programmed with region
numbers indicating countries in which
theycan be played. This system can play
discs with region number "4" or "ALL".
Format recorded on the DVD To adopt the video format to the connect-
ed TVs ("wide-screen TV" or "4:3 size
TV").
Recorded in 4:3.
You can enjoy wide images on a wide-screen TV, and letterbox size
images on the 4:3 size TV.
You can enjoy wide images on a wide-screen TV and 4:3 images
with the side edges cut on the 4:3 size TV.
Type of subtitles recorded Recorded subtitle languages.
Example: Language can be selected with the SUB-
TITLE button.
1: English
2: French
Number of camera angles Number of angles recorded on the DVD.
Angles can be selected with the ANGLE
button.
Number of audio tracks and audio
recording systems The number of audio tracks and audio re-
cording systems are indicated.
Example:
1: Original <English>
(DTS 5.1 Surround)
!The audio recorded on the DVD can
be switched by using the LANGUAGE
button.
!The number of audio tracks and re-
cording systems vary depending on
the DVD. Check them in the DVD's
manual.
2: English (Dolby Digital
5.1 Surround)
4
46
1
ALL
2
2
1

8
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Controls and indicators -
Controls and indicators
"Main unit (front panel)
Reference page
1.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
3.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.Remote Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24, 25
6.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
7.Power Stand-by Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8.Function Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 24, 40
9.Speaker Level Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . 23, 45
10.Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
11.Chapter (track) Skip Down or Tuning Down Button . . . . . . . . 26, 40
12.Volume Up and Down or Speaker Level Adjust Buttons . . . . 23, 45
13.Chapter (track) Skip Up or Tuning Up Button . . . . . . . . . . . . . 26, 40
14.Speaker Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Reference page
15.Dolby Pro Logic Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
16.Dolby Digital Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
17.DVD Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
18.Pause Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
19.Play Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
20.Title Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
21.Track Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
22.Tuner Preset Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
23.Chapter Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
24.Programme Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
25.Sleep Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
26.Repeat Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
27.A - B Repeat Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
28.DTS Signal Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
29.Stereo (2-ch) or FM Stereo Receiving Indicator . . . . . . . . . . . .40, 42
30.SVCD/VCD/CD Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
31.MP3 or JPEG Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
KHz
A-B REPEAT 1SLEEPPROGCHPPRESETTRKTITLE
CD MP3STEREO V
MHz
DIGITAL
Pro Logic
RL
RSLS
C
S
(1)
1
7
24
8 9 10
56
11
12
13
12
14
RL
RSLS
C
S
(3)(2)
(4) (6)(5)
15 16
2726252423 222117 18 19 20
28 29 30 31
3
(1) Left Front Speaker Indicator (4) Left Surround Speaker Indicator
(2) Centre Speaker Indicator (5) Subwoofer Indicator
(3) Right Front Speaker Indicator (6) Right Surround Speaker Indicator

9
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Controls and indicators -
"Main unit (rear panel)
Reference page
1.FM 75 Ohms Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
2.AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
3.Audio Input Sockets 1/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
4.Audio Output Sockets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14, 15
5.Video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
6.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
7.Cooling Fan . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
8.AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
9.S-video Output Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
12 3
9
4 5 86 7
The rating label is located on the bottom of the unit.
Cooling fan
This unit is fitted with a cooling fan at the rear for improved cooling. Do not cover the
opening in this section with any obstacles.
Cooling fan
Caution:
!The unit will get warm whilst being used. Do not touch the warm areas of the unit
for prolonged periods to avoid damage to you.
!This unit is equipped with a special function which protects the amplifier circuit
from damages. When it is activated, the sound switch is turned off. In this case,
unplug the unit and, after 15 minutes or more, plug it in again.
1

10
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Controls and indicators -
Controls and indicators (continued)
"Remote control Reference page
1.Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
2.Set Up Menu Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
3.Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
4.Subtitle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
5.Title Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
6.DVD/Tuner/Auxiliary Input Select Buttons . . . . . . . . . . . . . .15, 24, 40
7.Menu/Playback Control On/Off Button . . . . . . . . . . . . . . . . .31, 35, 37
8.Cursor Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
9.Programme Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .36
10.Slow-motion or Preset Memory Button . . . . . . . . . . . . . . . . . . .28, 41
11.Fast Reverse or Preset Down Button . . . . . . . . . . . . . . . . . . . . .26, 41
12.Fast Forward or Preset Up Button . . . . . . . . . . . . . . . . . . . . . . .26, 41
13.Surround/Stereo (2-ch) Listening Mode Button . . . . . . . . . . . . . . .42
14.Speaker Level Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . .23, 45
15.Direct Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
16.Angle Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29
17.Return Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
18.Zoom Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .29, 39
19.Mute Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
20.On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
21.Language Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
22.Display Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
23.FM Stereo/Mono Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
24.Enter Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
25.Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
26.Play or Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24, 25
27.Stop Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
28.Chapter (track) Skip Up or Tuning Up Button . . . . . . . . . . . . . .26, 40
29.Chapter (track) Skip Down or Tuning Down Button . . . . . . . . .26, 40
30.Volume Up and Down or Speaker Level Adjust Buttons . . . . .23, 45
31.Direct Number Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
32.Frame Advance Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
33.A - B Repeat Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
34.NTSC/PAL Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18, 33
35.Repeat Play Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
36.Audio Select Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33
PRESET
ADJ/VOL
9
8765
4
0> 10
321
ENTER
SLEEP
ST/MO
TUNING
DISPLAY LANGUAGE
MUTE
PROG
MENU/PBC
NTSC/PAL
STEP
A-B
REPEAT
ANGLE
DIRECT
LISTENING
SLOW/MEMORY
TITLE
ZOOM AUDIO
RETURN
MODE
SUBTITLE
SET UP
OPEN/
CLOSE ON/
STAND-BY
4
7
8
9
11
1
21
20
22
23
25
26
27
19
12
10
2
3
28
30
31
32
33
34
35
36
5
6
24
29
14
15
16
17
18
13

11
03/10/24 HTCN400_500DVA_A1.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
General Information
- Controls and indicators -
"Front/centre/surround speakers
Reference page
1.Speaker
2.Bass Reflex Duct
3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
"Subwoofer
Reference page
1.Bass Reflex Duct
2.Woofer
3.Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
"Speaker functions
Notes:
!Do not allow any objects to fall into or to be placed in the bass reflex ducts.
!Front and centre speakers are magnetically shielded.
13
2
3
21
Speaker grilles are removable:
Make sure nothing comes into contact with the speaker
diaphragms when you remove the speaker grilles.
Front speaker:
Reproduces left and right sound (stereo mode) or front surround sound.
Centre speaker:
Reproduces centre surround sound.
Surround speaker:
Reproduces rear surround sound.
Subwoofer:
Reproduces bass sound.
HTCN400_500DVA_A 92LCN400A0270 3
1

12
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
System Connections
- Speaker connection -
Speaker connection
Speaker terminals on the main unit and speakers, and speaker wires are distinguished by colours.
Connect the speaker and the unit by matching the colours.
(For speaker installation, see page 16.)
Subwoofer
Centre speaker
Surround speaker
(right)
Surround speaker
(left)
Front speaker
(right)
Front speaker
(left)
Red
Black
Purple
Green
White
Black
Black Blue
Black
Black
Grey
Black

13
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
System Connections
- Speaker connection / Aerial connection -
!Connecting speaker wires
To prevent accidental short circuits between and terminals, connect the
speaker wires to the speakers first and then to the unit.
Caution:
"The supplied speaker for HT-CN400DVA is designed exclusively for HT-
CN400DVA. The speaker for HT-CN500DVA is exclusively for HT-CN500DVA.
Do not connect speakers for HT-CN400DVA or HT-CN500DVA to other equip-
ment. Also, do not connect other speakers to HT-CN400DVA or HT-
CN500DVA. It may cause malfunction.
"Do not mistake the and , and right and left terminals of the speaker wires. (The
right speaker is placed on the right when you face the unit.)
Aerial connection
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult your dealer.
Make sure to leave the AC power lead disconnected when connecting the
speakers.
"Do not let the bare speaker wires touch each other.
"Do not stand or sit on the speakers. You may be injured.
"Do not short-circuit the speaker wires. If the power is
turned on, malfunction may occur.
"When disconnecting the speaker wires, unplug the AC
power lead, and then disconnect the speaker wires from
the main unit.
Red Red
Red
Black Black
Black
RedBlack
1 Connect the wires to the speakers.
2 Connect the other end to the main
unit.
Incorrect
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS
socket and position the FM aerial wire in the di-
rection where the strongest signal can be re-
ceived.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM socket.
Position the AM loop aerial for optimum recep-
tion. Place the AM loop aerial ona shelf, etc., or
attach it to a stand or a wall with screws (not
supplied).
Note:
Placing the aerial on the unit or near the AC
power lead may cause noise pickup. Place the
aerial away from the unit for better reception.
< Assembling > < Attaching to the wall >
Wall Screws (not supplied)
FM aerial AM loop
aerial
External FM aerial
2

14
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
System Connections
- Connections to TV, VCR, etc. -
Connections to TV, VCR, etc.
!
Connecting to a TV with a video input socket
!
Connecting to a TV with an S-video input socket
!Audio connection to TV or VCR
You can enjoy surround sound from TV or VCR by connecting them to the unit as
shown.
Caution:
Turn off all other equipment before making connections.
TV
To video 
input socket
To audio 
input sockets
Audio/Video cable 
(supplied)
Video signal
Audio signal
TV
S-video cable
(commercially available)
To S-video 
input socket
Video signal
Audio signal To audio 
input sockets
Audio cable (
commercially available )
TV
VCR
To audio 
output sockets
Audio cable 
(commercially available)
To audio 
output sockets
Audio signal
Audio signal

15
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
System Connections
- Connections to TV, VCR, etc. -
To listen to TV or VCR sound via the speakers of this unit:
!Audio connection to other equipment
!Connecting the AC power lead
After checking all the connections have been made correctly, plug the AC power lead
of this unit into the wall socket.
Note:
Unplug the AC power lead from the wall socket if the unit will not be used for a pro-
longed period of time.
Press the AUX button repeatedly to select the desired audio input.
Unit display
"FortheTV,select"AUX
1 IN".
"For the VCR, select
"AUX 2 IN".
"Alternatively, press the FUNCTION button on
the main unit.
Notes:
"Change the TV input in accordance with the connected socket.
"Do not connect other equipment (VCR, etc.) between the TV and this unit. Pic-
tures may be distorted.
"Refer to the operation manual of the equipment to be connected.
"Insert the plugs fully to avoid fuzzy pictures or noise.
ENTER
SLEEP
ST/MO
DISPLAY LANGUAGE
MUTE
PROG
MENU/PBC
TITLE
SUBTITLE
SET UP
OPEN/
CLOSE ON/
STAND-BY
A-B REPEAT 1SLEEPPROGCHP
E
SET
KHz
MHz
A-B REPEAT 1SLEEPPROGCHP
E
SET
KHz
MHz
MD recorder
Audio signal
Audio cable 
(commercially available)
To audio 
input socket
Wall socket
(AC 220 - 240 V, 50/60 Hz)
2

16
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
Preparation for Use
- System installation -
System installation
!Placing the speaker system
The best surround effect will be achieved by placing each speaker at the same
distance from the listening position.
It is recommended to arrange the speakers as shown below.
Notes:
"Place the TV halfway between the front speakers.
"It is recommended that the centre speaker be placed near the television.
"Place the surround speakers at a position just above the height of your ears.
"The subwoofer vibrates whilst reproducing bass. Place it on a stable, sturdy sur-
face.
"The bass sound from the subwoofer is non-directional, however, it is recom-
mended to place it as close as left and right speakers.
!Magnetically shielded speakers
The front and centre speakers may be placed beside or near the TV as they are mag-
netically shielded. However, discolouration may occur depending on the TV type.
If colour variation occurs...
Turn off the TV (with the power switch).
After 15 - 30 minutes, turn the TV on again.
If the colour variation is still present...
Move the speakers further away from the TV.
Refer to the manual of the TV for details.
Note:
The surround speakers and subwoofer are not magnetically shielded.
Note:
If speakers cannot be placed at equal distances, refer to "Speaker delay time set-
ting" (see page 44).
Installation image:
Front 
speaker (left)

Subwoofer
Front 
speaker (right)
Surround 
speaker (left) Surround 
speaker (right)

Centre 
speaker
Front speaker (left)
Same distance
Front speaker (right)
Centre speaker
Same distance

17
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
Preparation for Use
- Battery installation / Turning the power on -
Battery installation
Precautions for battery use:
"Replace all old batteries with new ones at the same time.
"Do not mix old and new batteries.
"Remove the batteries if the unit is not to be used for long periods of time. This will
prevent potential damage due to battery leakage.
Caution:
"Do not use rechargeable batteries (nickel-cadmium battery, etc.).
"Incorrect installation may cause the unit to malfunction.
Notes concerning use:
"Replace the batteries if the operating distance is reduced or if the operation
becomes erratic. Purchase 2 "AA" size batteries (UM/SUM-3, R6, HP-7 or similar).
"Periodically clean the transmitter on the remote control and the sensor on the unit
with a soft cloth.
"Exposing the sensor on the unit to strong light may interfere with operation.
Change the lighting or the direction of the unit.
"Keep the remote control away from moisture, heat, shock, and vibrations.
Turning the power on
!Test of the remote control
Check the remote control operation after making all the connections (see pages 12 -
15).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now, you can enjoy your
system.
!To turn the power on
Press the ON/STAND-BY button.
If the power does not turn on, check the AC power lead is plugged in properly.
To set the unit to the stand-by mode:
Press the ON/STAND-BY button again.
The power stand-by indicator lights up.
1Open the battery cover.
2Insert the supplied batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the battery termi-
nals.
3Close the cover.
ENTER
ST/MO
DISPLAY LANGUAGE
MUTE
MENU/PBC
TITLE
SUBTITLE
SET UP
OPEN/
CLOSE ON/
STAND-BY
Remote sensor
0.2 m - 6 m
(8" - 20')
ON/
STAND-BY
Power stand-by indicator
3

18
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
Preparation for Use
- Changing the setup menu -
Changing the setup menu
Turn on the TV, and switch the input to the "VIDEO 1", "VIDEO 2", etc. accord-
ingly.
Notes:
"During playback, "PREFERENCES" settings cannot be changed.
"Settings are stored even if the unit is set to the stand-by mode.
"The backup function protects the stored settings for a few hours should there be a
power failure or the AC power lead disconnection.
PRESET
ADJ/VOL
9
8765
4
0>
10
321
ENTER
SLEEP
ST/MO
TUNING
DISPLAY LANGUAGE
MUTE
PROG
MENU/PBC
NTSC/PAL
STEP
A-B
REPEAT
ANGLE
DIRECT
LISTENING
SLOW/MEMORY
TITLE
ZOOM AUDIO
RETURN
MODE
SUBTITLE
SET UP
OPEN/
CLOSE ON/
STAND-BY
SET UP
ENTER
ON/
STAND-BY
NTSC/PAL
1Press the ON/STAND-BY button to turn the
power on.
"The startup screen appears.
"The startup screen does not appear when the in-
put is not set to the disc mode. Press the DVD
button.
"If the startup screen is blurred, press the NTSC/
PAL button repeatedly to change the TV type.
2Press the SET UP button.
3Press the or button to select a menu
and press the ENTER button.
See the list on pages 19 - 20 for setup menu.
4Press the , , or button to change the
setting and press the ENTER button.
"See the list on pages 19 - 20 for the selectable
parameters.
"Select "MAIN PAGE" and press the ENTER but-
ton. The main page returns.
5Press the SET UP button.
"The setting is completed.
"To change other settings, begin from step 2.
DVD
VideoCD
CD
Audio Visual
Entertainment
SETUP MENU -- MAIN PAGE
SPEAKER SETUP
AUDIO SETUP
EXIT SETUP
GO TO GENERAL SETUP PAGE
PREFERENCES
GENERAL SETUP
-- GENERAL PAGE --
TV TYPE
MAIN PAGE
SET OSD LANGUAGE
TV DISPLAY
FRENCH
GERMAN
ITALIAN
SPANISH
ENGLISH
SCR SAVER
OSD LANG

19
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
Preparation for Use
- Changing the setup menu -
Setup menu Selectable parameters (* indicates default settings.) Description
GENERAL SETUP TV DISPLAY NORMAL/PS The screen mode should be set according to the connected TV
type (for details, see page 21).
NORMAL/LB *
WIDE
TV TYPE MULTI * Selects the correct colour system (TV standard) (for details, see
page 21).
NTSC
PAL
OSD LANG ENGLISH * YoucanselectthedesiredOSD (OnScreenDisplay)languagefor
the setup menu or playback control screen.
FRENCH
GERMAN
ITALIAN
SPANISH
SCR SAVER ON A screensaver appears.
OFF * The screensaver is disabled.
SPEAKER SETUP CNTR DELAY 1 MS to 5 MS Adjust the delay time of the speakers (for details, see page 44).
OFF *
REAR DELAY 3 MS to 15 MS
OFF *
TEST TONE ON You can check the sound output from the speakers (for details,
see page 45).
OFF *
AUDIO SETUP DYNAMIC (*1) FULL * Audio with fully compressed dynamic range.
7/8 Audio with partially compressed dynamic range.
1/8
OFF Audio with uncompressed dynamic range.
-- GENERAL PAGE --
TV TYPE
MAIN PAGE
GENERAL SETUP
OSD LANG
SCR SAVER
TV DISPLAY
WIDE
NORMAL/PS
NORMAL/LB
-- SPEAKER SETUP PAGE --
REAR DELAY
MAIN PAGE
LOUD SPEAKERS SETUP
CNTR DELAY
TEST TONE
1MS
3MS
5MS
OFF
-- AUDIO SETUP --
MAIN PAGE
AUDIO RELATED
4/8
6/8
FULL
2/8
OFF
DYNAMIC
(*1)
Selects the dynamic range compression to fit the individual listening situation of the audience. This function can be used in DVD playback.
Depending on the disc, sounds may become too loud or inaudible during playback. Dolby Digital's dynamic range control allows you to adjust the sound range.
HTCN400_500DVA_A 92LCN400A0270 4
3

20
03/10/24 HTCN400_500DVA_A2.fm 92LCN400A0270
HT-CN400DVA
HT-CN500DVA
Preparation for Use
- Changing the setup menu -
Changing the setup menu (continued)
Setup menu Selectable parameters (* indicates default settings.) Description
PREFERENCES AUDIO ENGLISH * Selects the language audible from the speakers.
FRENCH
GERMAN
ITALIAN
SPANISH
SUBTITLE ENGLISH * Selects the subtitle displayed on the TV screen.
FRENCH
GERMAN
ITALIAN
SPANISH
OFF
DISC MENU ENGLISH * Selects the disc menu language.
FRENCH
GERMAN
ITALIAN
SPANISH
PARENTAL 1 G
6 PG-R
NO_PARENTAL *
Sets a restriction level for DVD viewing (for details, see page 22).
Enter a 4-digit password.
It is set to 3308 by default.
PASSWORD CHANGE Change the password (for details, see page 22).
DEFAULTS RESET This resets all settings, except for PARENTAL and PASSWORD,
to the factory defaults.
EXIT SETUP The setting is completed.
-- PREFERENCES PAGE --
SUBTITLE
SET PREFERENCES
DEFAULTS
AUDIO
GERMAN
ITALIAN
FRENCH
SPANISH
DISC MENU
MAIN PAGE
PARENTAL
PASSWORD
ENGLISH
SETUP MENU -- MAIN PAGE
SPEAKER SETUP
AUDIO SETUP
EXIT SETUP MENU
PREFERENCES
GENERAL SETUP
EXIT SETUP
