SHARP
SERVICE
MANUAL
CODE : 0OZARRFI/AILE
Automatic Duplex Document Feeder
mopeL AR-RF1
CONTENTS
This Service Manual describes the unpacking and installing procedures
of the model to the full color digital copier, AR-C 150.
For the other items than the unpacking and installing procedures, refer to
the AR-RF1 Service Manual.
Parts marked with “/\” are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
Ss H AR P co R PO R AT (@) N The contents are subject to change without notice.

ADF tray
TE 8
ADF securing screws Tray securing screws
-) (2 pes.)
ADF mounting screws
QO ©
Right cover Left cover
1 pe.) {1 pe.)
SES
Sa~
)
Unplug the power cord fromthe copier and
follow the procedure below.
External view may differ depending on models.
1.Remove thedocumentcover.
Openthe documentcoverandliftitata slightbackward angle toremoveit.
Inserttheleftandrightcovers (includedparts) intothe holes from whichthe
documentcover has been removed.
Document cover
Right eS
Se}
2. Mountthe ADF/RADF onto the copier.
Remove the twocut-outs from the rear partofthe uppercoverofthecopier.
Cut-outs
Rear part of
upper cover
Install the two ADF mounting screws.
ADF mounting screws
Fit the ADF mounting screws into the holes in the hinges of the ADF and
secure the ADF with the two ADF securing screws.
ADF securing screws
ADF mounting screw
ADF securing screw

3. Adjust the angle of the ADF.
Loosen the two securing screws forthe angle adjusting panel attached to
the hinge angie and then fasten the loosened screws while raising the
angle adjusting panel completely.
Angle adjusting panel
securing screws
Long hole i (
NOTE:
Besuretocheck thatthe protrusion oftheangle adjusting panelissecurely
inserted into the long hole of the hinge.
4.Connectthe ADF connector.
Remove the connector cover securing screw to remove the connector
cover from the copier’s rear cover.
Next, connect the ADF connector to the connector on the copier, and fas-
ten the screw on the ADF connectorcompletely.
Securing screw Connector cover
5. Connectthe ADF tray connector.
Thread the M4 x8 tray securing screws (included parts) part way into their
holes, thenconnectthe tray connector.
Tray connector
|
LE
Tray -*<
securing </ f
screws
/
foam Connector on the ADF
6. Attach the ADF tray.
Loosen the two ADF tray securing screws, install the tray as shown in the
figure, and fasten the tray securing screws.
Tray |
securing
screws
Plug the copier into a grounded outlet and turn on the power switch. Then
follow the procedure below.
7. Adjustthe center of the copy.
Setan original inthe ADF tray and make acopy.
Whenthecopyisoffcenteras showninFig. 1 orFig. 2, loosen the two tray
securing screws and adjust the tray by moving it in direction A or B as
shown in the figure below.
Mark Tray securing screw
8.Setthe mode.
© Setthe mode with the key operation of the copier.
©-8-©-@-m--(%}-co-(29]
Clear b >
Press the corresponding = ‘ F
operation key on the display. @ ee ses ine

CAUTION FOR BATTERY REPLACEMENT
(Danish) ADVARSEL !
Lithiumbatteri —- Eksplosionsfare ved fejlagtig handtering.
Udskiftning ma kun ske med batteri
af samme fabrikat og type.
Levér det brugte batteri tilbage til leverandoren.
(English) Caution !
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type
; recommended by the manufacturer. ;
Dispose of used batteries according to manufacturer's instructions.
(Finnish) VAROITUS
Paristo voi rajahtaa, jos se on virheellisesti asennettu.
Vaihda paristo ainoastaan laitevalmistajan suosittelemaan
tyyppiin. Havita kaytetty paristo valmistajan ohjeiden
mukaisesti.
(French) ATTENTION
ll y a danger d’explosion s’ il y a remplacement incorrect
de la batterie. Remplacer uniquement avec une batterie du
méme type ou d’un type équivalent recommandé par
le constructeur.
Mettre au rebut les batteries usagées conformément aux
instructions du fabricant.
(Swedish) VARNING
Explosionsfara vid felaktigt batteribyte.
Anvand samma batterityp eller en ekvivalent
typ som rekommenderas av apparattillverkaren.
Kassera anvant batteri enligt fabrikantens
instruktion.
