Sharp ZQ-P20 User manual

MODEL
ZQ-P20
ELECTRONIC ORGANIZER
OPERATION MANUAL
CONTENTS
Part Names .......................................................................................... 1
Using the Organizer for the First Time ............................................... 2
Entering Characters ............................................................................ 2
Clock Mode .......................................................................................... 3
Telephone Mode .................................................................................. 6
Schedule Mode ................................................................................... 7
To Do Mode ......................................................................................... 8
Memo Mode ......................................................................................... 8
Notes for storing and recalling entries ................................................ 9
Recalling entries .................................................................................. 9
Editing or deleting entries ................................................................. 10
Calculator Mode ................................................................................ 10
Currency/Unit Conversion Mode ....................................................... 11
Game Mode ....................................................................................... 12
Backlight function .............................................................................. 14
Memory Storage ................................................................................ 14
Adjusting the LCD contrast ............................................................... 15
Secret Function ................................................................................. 15
Using the Included PC Software ....................................................... 16
Battery Replacement ......................................................................... 18
Specifications .................................................................................... 20
ZQ-P20(En)(Cover) 03.4.15, 11:25 AM1

NOTICE
• SHARP strongly recommends that separate permanent written records be kept of all important data. Data may be lost or altered in virtually any
electronic memory product under certain circumstances. Therefore, SHARP assumes no responsibility for data lost or otherwise rendered
unusable whether as a result of improper use, repairs, defects, battery replacement, use after the specified battery life has expired, or any other
cause.
• SHARP assumes no responsibility, directly or indirectly, for financial losses or claims from third persons resulting from the use of this product and
any of its functions, such as stolen credit card numbers, the loss of or alteration of stored data, etc.
• The information provided in this manual is subject to change without notice.
CAUTIONS
• Do not carry the Organizer in the back pocket of slacks or trousers.
• Do not drop the Organizer or apply excessive force to it.
• Do not subject the Organizer to extreme temperatures.
• Since this product is not waterproof, do not use it or store it where fluids can splash onto it. Raindrops, water spray, juice, coffee, steam,
perspiration, etc. will also cause malfunction.
• Clean only with a soft, dry cloth.
• Use only a SHARP approved service facility.
NOTES
• All company and/or product names are trademarks and/or registered trademarks of their respective manufactures.
ZQ-P20(En)(Cover) 03.4.15, 11:25 AM2

1
Part Names Key Assignments
: 2nd Function key
Activates the second function specifically assigned to the next
key tapped.
( GAME ): Game mode key
( TEL1 ): Telephone 1 mode key
( TEL2 ): Telephone 2 mode key
( SCHEDULE ): Schedule mode key
( MEMO ): Memo mode key
( TO DO ): To Do mode key
( CLOCK ): Home Clock/World Clock mode key
( CALC/CONV ): Calculation/Conversion mode key
• In this manual, these Mode keys are represented with icons in
parentheses.
Option port
Stylus
Display
RESET switch
(on the back of the unit)
Touch Keyboard section
Mode keys
ENTER key
Backlight key
Power ON/OFF key
Cursor keys
Search keys
Part Names
ZQ-P20(En).pm65 03.4.15, 0:45 PM1

2
Be sure to perform the following operations before using the Organizer
for the first time.
1. Remove the isolating film that is
affixed to the battery holder on the
back of the unit.
2. Press the RESET switch with a stylus.
“RESET?” is displayed.
3. Tap fand press xto initialize
the Organizer.
After “RESET!” is displayed. You have
now cleared the memory contents.
The Select Language screen then appears.
Guidance messages can be displayed in 10
languages – English, Italian, German, French,
Spanish, Portuguese, Hungarian, Czech,
Polish, and Greek. After initializing the
Organizer, the default setting is English.
Select the desired language using >or
<, then press x.
Home clock is displayed. (See “Clock Mode”.)
NOTES
• If the Organizer is subject to strong, extraneous electrical noises or
shocks during use, an abnormal condition may occur in which no
keys (including
ON
OFF
) will respond. Press the RESET switch, tap
f, then press xto delete all the memory contents.
• To minimize battery consumption, the Organizer is designed to
automatically turn off when no key has been pressed for approxi-
mately 5 minutes.
Using the Organizer for the First Time
Entering Characters
Touch Keyboard
Alphabet entry mode Number entry mode
• Each time fis tapped, the touch keyboard switches between the
Alphabet entry mode and the Number entry mode.
To tap the touch keys, use the attached stylus.
• Tap towards the center of each key.
• Numbers, alphanumeric letters, symbols, and “+ – ×÷ .”
can be entered into the dot display area (the 1st line).
• Numbers and some characters (only space, –,
F, and P in Telephone mode) can be entered into the number display
area (the 2nd and the 3rd lines).
• Letters are entered in capital letters (“CAPS” is turned on). To enter
lowercase letters, tap CAPS to turn “CAPS” off.
Entering symbols and letters with an accent mark
• To enter a symbol, tap SMBL repeatedly until the desired symbol
appears:
@#$£¥ ( )~’: /\_&<>ß!?¡¿æµ¢
RESET
• The key touch tone is turned on and off by tapping h
MENU
,
select “KEY TONE?” using >or <, and press x.
Select on/off using >or <, then press x. When the
tone is activated, “ ” will appear.
ZQ-P20(En).pm65 03.4.15, 0:45 PM2

3
• To enter a letter with an accent mark, tap the relevant key shown
below repeatedly after tapping s.
• Activate “CAPS” on to enter capitalized letters.
• In the Greek language, only the capitalized letters can be entered.
Making corrections
Move the cursor to the character to be corrected.
Enter the correct character to replace the previous one.
Cursor
The cursor (_) indicates the position for entering a character. Move the
cursor with the cursor keys ( ).
Inserting characters
Each time INS is tapped, a space is inserted at the cursor position to
allow character entry.
Deleting characters
Tap
DEL
to delete the character at the cursor position.
Tap
C•CE
to clear all the characters you have entered and yet to be
stored.
(Key) (CAPS ON) (CAPS OFF) (Key) (CAPS ON) (CAPS OFF)
Clock Mode
Each time
CLOCK
is tapped, the clock switches between the Home
clock and the World clock mode. (For World clock, “ ” is not
displayed.)
1. Before setting the clock
•The default setting for the date is “DD/MM/YYYY”(day-month-year).
To change the setting to “YYYY/MM/DD”(year-month-day) or “MM/
DD/YYYY”(month-day-year):
1. Tap
CLOCK
once or twice to display the Home clock (with “ ”).
2. Tap
MENU
, select “DATE SET?”by using kor m, and press
x.
3. Press >or <to select the desired type.
4. Press
ENTER
to store the new setting.
•To change the 24-hour clock to the 12-hour clock, tap Z(“A”or
“P”is displayed). Each time Zis tapped, the clock switches.
•For daylight saving time/summer time, tap DST in advance (“#”is
displayed on the left side of the day of the week).
Home clock
Home city (with “ ”) Day of the week
Time
Date
Daylight saving time
set ( with “#”)
CAPS
LON THU
1–1–2004
0–00–00
2nd
#
ZQ-P20(En).pm65 03.4.15, 0:45 PM3

4
2. Setting the clock
1. Tap
CLOCK
once or twice to display the Home clock (with “ ”).
2. Tap feto start setting.
The cursor starts to flash on the city name.
3. Press >or <to select the desired city. (Refer to the list of
cities described below.)
•Enter the city name, if needed (6 characters or under). Only one
changed name for Home clock can be stored.
4. Tap to move the cursor to the day.
5. Enter the day, the month, and the year (4 digits ).
•The built-in calendar extends from January 1st, 1901, to
December 31st, 2098.
•Tap
AM/PM
to select “A”(morning) or “P”(afternoon) for the 12-
hour clock. (in 12 hour)
6. Enter the time (hours and minutes).
7. Press
ENTER
. The clock starts from “00”seconds.
Notes
•To enter a single-digit date or time, enter “0”and the digit (e.g.
“02”).
•If you enter an invalid date or time, “ERROR!”appears briefly. Enter
the correct date and time and press
ENTER
.
Display City Display City
LON LONDON TYO TOKYO
LIS LISBON ADL ADELAIDE
PAR PARIS SYD SYDNEY
BER BERLIN GUM GUAM
ROM ROME NOU NOUMEA
AMS AMSTERDAM WLG WELLINGTON
BCN BARCELONA AKL AUCKLAND
HEL HELSINKI TNG TONGA
CAI CAIRO MID MIDWAY
MOW MOSCOW HNL HONOLULU
RUH RIYADH ANC ANCHORAGE
THR TEHRAN LAX LOS ANGELES
DXB DUBAI DEN DENVER
KBL KABUL CHI CHICAGO
KHI KARACHI NYC NEW YORK
DEL DELHI YYZ TORONTO
DAC DHAKA CCS CARACAS
RGN YANGON RIO RIO DE JANEIRO
BKK BANGKOK MAT MID ATLANTIC
BEI BEIJING –2H 2hrs behind LON
HKG HONG KONG AZO AZORES ISLANDS
SIN SINGAPORE
3. Using World clock
1. Tap
CLOCK
once or twice to display the World clock (without
“ ”).
2. Press >or <to select the desired city.
4. Changing the cities between Home and World
clocks
You can change the home city for a city in another time zone without
adjusting the stored correct time.
ZQ-P20(En).pm65 03.4.15, 0:45 PM4

5
1. Tap
CLOCK
once or twice to display the World clock (without
“ ”).
2. Press >or <and select the desired city to be set as the
new home city.
3. Tap feto change the cities between Home and World
clocks.
•The previous home city is now set as the world city (without
“ ”).
4. Tap
CLOCK
to check the home city.
•The selected city in step 2 is set as the home city (with “ ”).
5. Tap
CLOCK
to recheck the world city, and press >or <to
select the new world city, if needed.
5. Setting daylight saving time (DST: summer time)
1. Tap
CLOCK
once or twice to display the Home or the World clock.
2. Tap DST .
“#”is displayed. The time is set 1 hour ahead. To clear DST, tap
DST to clear “#”. The time is set 1 hour behind.
Notes
•DST can be set independently in either Home or World clock.
•When DST is set for one world city, it is used for all cities displayed
in World clock.
6. Setting alarms
The Organizer has 3 types of alarms:
1. Daily alarm ........ beeps every day at the alarm time (for 1 minute),
when “ ” is turned on.
Up to three daily alarms can be set (ALARM1,
ALARM2, and ALARM3).
2. Hourly alarm ...... beeps every hour when minutes reach “00”, when
“”is turned on.
3. Schedule alarm .. beeps at the time for all the schedule entries (for 1
minute), when “ ” is turned on. (Refer to
“Schedule Mode”.)
Tap any key to stop the alarm beeping.
Setting/Changing the daily alarm time
1. Tap
CLOCK
once or twice to display Home clock (with “ ”).
2. Tap to display the ALARM1 screen.
•Press >or <to display ALARM2 or ALARM3.
3. Tap or to display the screen is turned on the daily alarm, if
the daily alarm time is not displayed.
(The display differs between the 12-hour and 24-hour clock.)
4. Tap fe.
5. Enter the time.
6. Press
ENTER
.
•The daily alarm time is set.
Turning the alarms on and off
An alarm sounds only when the respective symbol ( ,, or )
is turned on.
Display Home clock (tap
CLOCK
once or twice) and tap to display
the daily alarm screen.
Each time you tap while the daily alarm screen is displayed, the
combination of symbols switches.
Note
•Alarms sound even when the Organizer is turned off.
ZQ-P20(En).pm65 03.4.15, 0:45 PM5

6
Turning the each daily alarm on and off
1. Display Home clock and tap .
2. Press >or <to display the daily alarm screen.
3. Each time you tap or , the daily alarm you selected turns on or
off. e.g. daily alarm1.
ALARM on ALARM off
Note
•The daily alarm which is turned off does not beep even though the
“ ” is displayed.
Telephone mode has two filing directories.
To access the first directory, tap TEL1 . Tap TEL2 to access the other.
Use these files for convenience, e.g. business and private files.
A telephone entry consists of name, address, E-mail address, web
address (URL) and number fields.
Storing telephone entries
1. Tap TEL1 or TEL2 to display the
Telephone mode screen.
2. Enter name, e.g. SMITH
SPACE
ROBERT,
and tap .
3. Enter address, e.g. f18
SPACE
fEAST
SPACE
ROAD, and
tap .
4. Enter E-mail address, e.g. SROB SMBL
l(to enter “
@
”) SHARPSEC.COM, and
tap .
•The E-mail address is automatically
entered in lowercase letters.
•To enter “@”, simply tap
@
instead of SMBL .
5. Enter web address (URL), e.g.
WWW.SHARPUSA.COM , and tap .
6. Enter phone number, and fax number if
needed, e.g.
012-3456-7890 f
F
SPACE SPACE SPACE
3456-7891,
and press
ENTER
.
CAPS1
NAME ?
E-mail
harpsec . com–
1
CAPS2nd
NUMBER?
2–3456–7890
3456–7891–
1
Telephone Mode
ZQ-P20(En).pm65 03.4.15, 0:45 PM6

7
•“STORED!”appears briefly, then the Telephone mode screen is
displayed. The telephone entry is now stored.
Notes
•The symbol “NAME”, “ADDRESS”, “E-mail”, or “URL”is turned on
while entering in each field.
•To skip entry of an address, E-mail address, web address (URL), or
number, tap when “ADDRESS?”, “E-MAIL?”, “URL?”, or
“NUMBER?”is displayed. However, entry must be made at the
"NAME?" field.
Allowable characters
The 1st line:
Name,
E-mail address,
web address (URL)
address
Field Number of
characters
The 2nd and the
3rd lines:
Phone number
Alphabetic letters, numbers,
symbols, “+ –×÷.”, space
Numbers, space, –,
F (Fax),
P (Pager)
36 characters or
under
72 characters or
under
36 characters or
under
Schedule Mode
Schedule mode is used for storing schedule details (36 characters or
under), date and time (year, month, day, hour, and minute).
In the 1st line the same characters are allowable as in Telephone
mode.
1. Storing schedule entries
1. Tap to display the Schedule
mode screen.
2. Enter the details and tap .
3. Enter the date and time.
•The types of date and time are the same as the types set for the
clock.
•To enter a single-digit date or time, enter “0”and the digit (e.g.
“O2”).
4. Press
ENTER
to store in the memory.
Notes
•Schedules for the following dates can be stored: January 1901 to
December 2098.
•If an attempt is made to store an entry without a date or time, or
with an invalid date or time, “ERROR!”appears briefly. Enter the
correct date and time and press
ENTER
.
2. Alarm for Schedule mode
When the schedule alarm (“ ”) is turned on, it is set for all the
schedule entries. Beeping sounds for 1 minute when the time for a
schedule entry is reached. Tap any key to stop the alarm. The schedule
alarm cannot be set for an individual entry.
SCHEDULE?
ZQ-P20(En).pm65 03.4.15, 0:45 PM7

8
To Do Mode
In the To Do mode, you can store your important To Do items with a
priority index.
Storing To Do entries
1. Tap
TODO
to enter the To Do mode.
2. Enter the description and tap .
3. Select the Priority number from 1(High) to 9(Low) enter the
number, then tap .
4. Enter the date and time.
•The types of date and time are the same as the types set for the
clock.
•To enter a single-digit date or time, enter “0”and the digit (e.g.
“O2”).
5. Press
ENTER
to store in the memory.
DONE Completed Items
1. Tap
TODO
to enter the To Do mode.
2. Press <or >to select the To Do items.
3. Tap eto enter the status field.
4. Tap to select “D” (Done), then press
ENTER
.
•“P”stands for “pending”.
Memo Mode
Notes or other pieces of information that are not appropriate for
Telephone or Schedule mode can be entered for convenience.
In the 1st line the same characters are allowable as in Telephone
mode. In the 2nd and the 3rd lines you can enter numbers, –, and
space. (36 characters or under can be entered in each line.)
Storing memo entries
1. Tap to display the Memo mode
screen.
2. Enter the memo item and numbers.
E.g. UNION
SPACE
BANK
01
272-0011223
3. Press
ENTER
to store in the memory.
CAPS
MEMO?
CAPS2nd
UN I ON BANK
01
272–0011223–
ZQ-P20(En).pm65 03.4.15, 0:45 PM8

9
Notes for storing and recalling entries
•When the memory is full, “MEMORY FULL!”appears briefly, and the
entry cannot be stored.
•When the symbol “ ” or “ ” appears, more information exists. Tap
or to switch the display.
Checking details of entries in Telephone mode
•To display each field on the 1st line, follow the symbol “ ” or “ ”
and tap or . (The symbol above the 1st line shows each field.)
•Tap and hold to start the auto scroll on the 1st line. Tap again
to stop or restart the scroll. Tap
C•CE
to quit the auto scroll.
Recalling entries – Telephone, Schedule, To Do, Memo –
Tap the desired mode key first.
<: Recalls entries in forward order
>: Recalls entries in reverse order
Sequential search
Press <or >in each mode.
Direct search
•Enter the first characters (8 characters or under) of the person’s
name, schedule details, To Do item or memo item, and press <
or >.
Press <or >then, to continue performing a direct search.
Sorting order
•Telephone and memo entries are stored by the first character of the
person’s name or memo item in the following order (case sensitive):
•“Ch”and “ch”are available in Czech language mode only.
•Schedule entries are stored by date and time.
•To Do entries are stored in the following order : STATUS, PRIORITY,
and DATE.
Note
•When there is no (further or relevant) entry to be recalled, “NOT
FOUND!”appears briefly, and the display returns to the mode
screen.
•Greek characters are sorted as follows:
ZQ-P20(En).pm65 03.4.15, 0:45 PM9

10
Editing or deleting entries – Telephone,
Schedule, To Do, Memo –
Editing
1. Recall the entry to be edited.
2. Tap
EDIT
. The cursor starts to flash.
3. Tap , , , or to move the cursor to the position to be
edited.
4. Enter, insert, or delete characters (refer to “Entering Characters”).
•To cancel editing, tap
C•CE
.
5. Press
ENTER
several times (until “STORED!”appears briefly) to
finish editing and to store the entry.
Deleting
1. Recall the entry to be deleted.
2. Tap
DEL
.
•“DELETE?”is displayed.
•To cancel the deletion operation, tap f.
3. Press
ENTER
to delete the entry.
Calculator Mode
The Organizer can calculate numbers of up
to 10 digits. Tap
CALC/CONV
several times
to display the Calculator mode screen
(Calculator →Currency conversion →Unit
conversion →Calculator...).
Calculation
Be sure to tap
C•CE
,
C•CE
, and
CM
to clear the display and
memory before performing a calculation.
Note
•When , , , or is tapped, the respective symbol, +, –, ×, or ÷
is displayed. (In the examples in this manual, these symbols are not
described.)
If an error occurs
If the calculation result or the integer section in the numerical value in
the memory exceeds 10 digits or if a number is divided by zero (0), an
error occurs (“ERR”is displayed).
2nd
0.
ZQ-P20(En).pm65 03.4.15, 0:45 PM10

11
Calculation examples
Example Operation Display
(–24+2)÷4=–5.5
C•CE
24 2 4 –5.5
34+57=91 34 57 91.
45+57=102 45 102.
(The addend becomes a constant.)
68×25=1700 68 25 1700.
68×40=2720 40 2720.
(The multiplicand becomes a constant.)
200×10%=20 200 10
%
20.
9÷36=25% 9 36
%
25.
200+(200×10%)=220 200 10
%
220.
500–(500×20%)=400 500 20
%
400.
46=(43)2=4096 4 4096.
1/8=0.125 8 0.125
25×5=125
CM
25 5
M+
M
125.
–)84÷3=28 84 3
M–
M
28.
+) 68+17=85 68 17
M+
M
85.
182
RM
M
182.
25 9
앀앙
4.
1234567890×145 1234567890 145 ERR
=179012344050
17.90123440
C•CE
17.90123440
(17.90123440×10
10
=179012344000)
앀앙앙
25–9=4
1. Setting a currency rate
1. Tap
CALC/CONV
several times to display
the currency conversion mode screen
(refer to “Calculator mode”).
Example: 1 CAD (Canada dollars)
= 0.66 USD (US dollars)
2. Press <<<to change the display and tap fe.
The initial character of “CAD”starts to flash.
•You can change each currency name by entering characters (up to
4 in each) and using , if needed.
3. Press
ENTER
. “0”starts to flash.
4. Enter the rate (up to 10 digits).
0.66
5. Press
ENTER
to store in the memory.
2. Converting currency/unit
You need to set the conversion rate before making the currency
conversion.
Example: Convert 500 CAD into USD using the rate that you have set.
1. Display the screen: “CAD →USD”.
2. Enter the value to be converted.
500
Currency/Unit Conversion Mode
CAPS2nd
CAD USD
6
–
–
0.6
CAPS2nd
EURO USD
0.
–
–
ZQ-P20(En).pm65 03.4.15, 0:46 PM11

12
3. Tap to convert CAD into USD.
•To convert in reverse order (e.g. 200
USD into CAD), enter 200 and tap .
•You can use the unit conversion in the
same manner. You cannot change the units or the rates for units.
•The conversion result may have a slight error as a result of
rounding off the number (e.g. up to 2 decimal places for currency
conversions). Use the conversion result for reference.
CAPS2nd
CAD USD
0.
–
–
33
Game Mode
Each time
GAME
is tapped, the display switches between “ALPHA
ATTACK”and “BLACKJACK”.
BLACKJACK (Twenty-one)
Make your “hand”(the total of the numbers on the cards) as close to
21, without going over 21.
1. Tap
GAME
to display the following
Game mode screen.
2. Press
ENTER
to start a game. The left 2 cards are dealt for you.
(One card is faced up and the other is faced down.)
3. Agree the left-displayed maximum bet (up to 10) or enter fewer bet.
4. Tap
SPACE
to see your hand.
Each time
SPACE
is tapped, a new
card is dealt.
•“J”, “Q”, and “K”are counted as 10.
•“A”can be counted as 1 or 11.
•When the first 2 cards are “A”and a
face card (“J”, “Q”, or “K”), your hand
is “BLACKJACK”.
5. Press
ENTER
to stop being dealt and
hold your hand. The dealer’s hand and
the results are displayed.
•When you win, your total flashes and
your bet is doubled.
•When you win with “BLACKJACK”,
your bet is tripled.
6. Press
ENTER
and display the Game mode screen.
•When you have no more chips to bet, the game is over.
•To quit the game, tap
C•CE
or any mode key. Your chips are
stored for the next time.
•To return your chips to 30, tap f
DEL
and press
ENTER
on
the Game mode screen.
ALPHA ATTACK
Type in characters (A to Z) displayed on the
1st line to clear them. 20 levels of speed are
available.
1. Tap
GAME
to display the following
Game mode screen.
CAPS2nd
BLACKJ ACK
30
Your chips
CAPS2nd
J28 4
10 20
Your chipsYour bet
The dealer’s
hand
Your hand
CAPS2nd
J28 32K4
20 19
20 20
Your chips
Your bet
The dealer’s
total
Your total
CAPS2nd
ALPHA ATTACK
01
Level
ZQ-P20(En).pm65 03.4.15, 0:46 PM12

13
2. Enter the level number (2 digits from 01
to 20).
•01: slow, 20: fast
3. Press
ENTER
to start a game.
4. Tap the same key as the first character at the left end of the 1st line.
(In this case, tap keys in the order: E → Y → K → W.)
•Pressing the correct key in the correct order deletes the character.
•When 12 characters are displayed in each level, the game
continues in the faster level (up to 20).
•When no more characters can be displayed, the game is over. The
Game mode screen with the level when the game is over is
displayed.
CAPS
EYK W
01
ZQ-P20(En).pm65 03.4.15, 0:46 PM13

14
Backlight function
T he Backlight allows you to view the display and use the Organizer
even in low-light conditions. Pressing
z
once illuminates the
display for as long as you continue to use the Organizer, or until no
key is pressed for 10 seconds.
•To turn the Backlight off, press zagain.
•The Backlight may remain on for less than the preset interval or
it may not function if the battery level is low.
•The Backlight does not function in the PC Link mode.
Do not use the Backlight unnecessarily
•Since the Backlight drains power from the backlight battery,
excessive use of the Backlight will significantly reduce the life of
your battery.
Memory Storage
1. Checking memory storage
1. Tap TEL1 , TEL2 , , or
TODO
to display “NAME?”,
“SCHEDULE?”, “TO DO?”or “MEMO?”.
2. Tap f
MENU
, select “MEMORY
CHECK”by using kor m, and press
x. The number of remaining bytes is
displayed briefly.
Notes
•Approx. 8,000 telephone entries can be stored (when 14 characters
are entered for name, telephone and fax number fields, and 18
characters are entered for address field).
2. Deleting all the memory contents
Perform steps 2 and 3 as described in the section, “Using the
Organizer for the First Time”.
•To cancel the deletion operation, press any key EXCEPT FOR f
xin step 3.
CAPS
CAPA %
99
CITY
ZQ-P20(En).pm65 03.4.15, 0:46 PM14

15
Adjusting the LCD contrast
1. Tap
CLOCK
once or twice to display Home clock (with “ ”).
2. Press >or <to adjust the LCD contrast.
Secret Function
1. Registering a password
A Secret function is valid for Telephone, Schedule, To Do, and Memo
modes.
Up to 6 characters can be registered as the password.
If the password is forgotten, you cannot delete the password only. You
have to delete all the memory contents. (Perform steps 2 and 3 as
described in the section, “Using the Organizer for the First Time”.) As a
safeguard, make a written record of the password.
Registering a password
1. Tap
CLOCK
once or twice to display Home clock (with “ ”).
2. Tap .
3. Enter a password (case sensitive), e.g.
fABC and press
ENTER
.
•“RECONFIRM !”is displayed.
•If “ERROR !”appears briefly, the password has already been
registered.
4. Enter the same password once more for verification and press
ENTER
.
•The display returns to the Home clock.
The secret function turns on automatically.
•If you enter the wrong password, “ERROR !”appears briefly and
display returns to the Home clock. Follow the above steps again
to register a password.
2. Turning Secret function off
When the Secret function is on, it is necessary to turn off to perform
the Telephone, Schedule, To Do, and Memo modes.
1. Tap TEL1 , TEL2 , ,
TODO
or .
•“PASSWORD?”is displayed.
2. Enter the password and press
ENTER
.
•If you enter an incorrect password, “ERROR!”appears briefly.
Follow the above steps and enter the correct password.
•Secret function will be automatically turned on after the power is
turned off manually or automatically.
3. Changing the password
1. Tap on the Home clock (with “ ”).
2. Enter the password and press
ENTER
.
•“EDIT PASS.?”is displayed.
3. Press
ENTER
.
•The initial character of the password starts to flash.
4. Modify the password and press
ENTER
.
•“RECONFIRM !”is displayed.
5. Enter the same password once more for verification and press
ENTER
.
ZQ-P20(En).pm65 03.4.15, 0:46 PM15

16
•The password is changed and display returns to the Home clock.
The secret function turns on automatically.
•If you enter the wrong password, “ERROR !”appears briefly and
display returns to the Home clock. Follow the above steps again
to change the password.
4. Deleting the password
1. Tap on the Home clock (with “ ”).
2. Enter the password and press
ENTER
.
•“EDIT PASS.?”is displayed.
3. Press
ENTER
.
•The password is displayed.
4. Tap
C•CE
.
•“DEL PASS.?”is displayed.
5. Press
ENTER
to delete the password.
The CD-ROM contains software to enable exchange of data with a
PC.
The software consists of:
Can be used to backup/restore data in the Organizer and export/
import data to different file formats.
Note: The PC Software is intended to run on a PC with English
operating system installed.
Minimum System Requirements:
•IBM PC or 100% compatible
•Microsoft®Windows®98/98SE/2000 Professional/Me/XP
•Pentium®300MHz or higher
•50MB free hard disk space
•64MB RAM for Microsoft®Windows®98/98SE/2000
Professional/Me
•128MB RAM for Microsoft®Windows®XP
•One available 9-pin serial port
•CD-ROM drive
•Mouse or compatible pointing device
Using the Included PC Software
ZQ-P20(En).pm65 03.4.15, 0:46 PM16

17
Connecting the Organizer to Your PC
1. Turn off your PC and the Organizer.
2. Connect the standard 9-pin connector of the PC-Link cable to the
PC’s serial port.
•Using a 25-pin connector will require an additional adapter.
(Commercially available)
3. Connect the other end of the PC-Link cable to the Organizer’s
option port.
4. Turn on the PC and the Organizer.
Installing
1. Insert the PC software CD-ROM into your CD-ROM drive.
Installation process should automatically start.
If the PC software screen does not appear, double-click “My
Computer”to locate the CD-ROM drive directory, then double-click
to launch “install.exe”found on the CD-ROM.
2. Click the "Install" button.
3. Follow the installation instructions that appear on the screen.
Note:
•For Windows2000®Professional and Windows®XP, install/
uninstall programs after logging on as an Administrator.
•When the installation is complete, click the "Finish" button to finish
the installation process.
Desktop Utilities
Launch "Desktop Utilities" from
the Start menu, or double-click
on the shortcut icon on the
desktop. Utilize the Desktop
Utilities via the following
graphic interface:
Serial port
Click “Auto Detect...”to allow
the communication to
automatically detect the appropriate serial port. Make sure that the
unit is physically connected with the PC first, then click this button.
If the desired serial port is not found, manually select the serial port
from the drop-down list.
Backup/Restore
The Backup/Restore menu of the Desktop Utilities allows you to make a
backup file of the unit data, or to restore it back to the internal memory
of the unit. Be noted that the setup parameters won't be backed up.
•Backup: Select “Backup...”from button, then enter the desired
name of the file to be backed up.
•Restore: Select “Restore...”from button, then select the desired
name of the file to be restored.
ZQ-P20(En).pm65 03.4.15, 0:46 PM17

18
Export/Import
The Export/Import menu of the Desktop Utilities allows you to import
data created by each application to the unit, or export data created on
the PC to the unit by application data.
•Export: Select the desired application name, then click “Export...”,
then enter the desired filename to which you wish to export data.
•Import: Select the desired application name, then click “Import...”,
then enter the desired filename from which you wish to import
data.
Batteries used
Type Model Quantity Use
Lithium battery CR2032 1 Unit operation
Lithium battery CR2032 1 Backlighting
•Be sure to write down any important information stored in the
memory before replacing the batteries.
Precautions
Since improper use of the batteries may cause leakage or
explosion, strictly observe the following instructions:
•If fluid from a leaking battery accidentally gets into your eyes, it
may result in serious injury. Should this occur, flush your eyes
with clean water and consult a physician immediately.
•Should fluid from a leaking battery come into contact with your
skin or clothes, immediately wash with clean water.
•If the Organizer will not be used for an extended period of time,
to avoid damaging the Organizer remove batteries and store in a
safe place.
•Do not leave exhausted batteries inside the Organizer.
•Do not use different types of batteries or partially used
batteries.
•Insert the battery with its positive side (+) correctly orientated.
•Never throw batteries into a fire because they might explode.
•Keep batteries out of reach of children.
•When batteries become near exhaustion, remove them from the
Organizer immediately to avoid battery leakage and corrosion
inside the Organizer.
Battery Replacement
ZQ-P20(En).pm65 03.4.15, 0:46 PM18
