Sharp CD-C471 W User manual

CD-C471W
SHARP SERVICE MANUAL
No. S6845CDC471 W/
ciInli%
DIGITAL AUDIO
SURROUND
YYI
PROfLOGIC
Manufactured under license from Dolby Laboratories Licens-
ing Corporation.
DOLBY, the double-D symbol 00 and “PRO LOGIC”
are trademarks of Dolby Laboratories Licensing Corporation.
CD-C471 W
CD-C471 W mini component system consisting of
CD-C471 W mini component system, front (CP-C471), senter
(GBOXS0006AWM6)and surround(GBOXS0007AWM6)
Speaker System.
l In the interests of user-safety the set should be restored to its
original condition and only parts identical to those specified be
used.
/
CONTENTS
.
Page
SAFETY PRECAUTION FOR SERVICE MANUAL .......................................................................................................... 2
VOLTAGE SELECTION..
..................................................................................................................................................
2
SPECIFICATIONS ............................................................................................................................................................
3
NAMES OF PARTS ..........................................................................................................................................................
4
OPERATION MANUAL ..................................................................................................................................................... 6
DISASSEMBLY.. ...............................................................................................................................................................
7
REMOVING AND REINSTALLING THE MAIN PARTS.................................................................................................. IO
ADJUSTMENT.. .............................................................................................................................................................. 11
NOTES ON SCHEMATIC DIAGRAM ............................................................................................................................. 14
TYPE QF TRANSISTOR AND LED ................................................................................................................................ 14
BLOCK DIAGRAM .......................................................................................................................................................... 15
SCHEMATIC DIAGRAM /WIRING SIDE OF P.W.BOARD.. .......................................................................................... 18
WAVEFORMS OF CD
CIRCUIT.. ...................................................................................................................................
39
TROUBLESHOOTING (CD CHANGER CONTROL /CD SECTION). ............................................................................ 40
FUNCTION TABLE OF IC .............................................................................................................................................. 44
FL DISPLAY .................................................................................................................................................................... 54
REPLACEMENT PARTS LIST/EXPLODED VIEW
SHARP CoRPoRATloN
This document has been published to be used
for after sales selvice only.
The contents are subject to change without notice.

CD-C471 W
SAFETY PRECAUTION FOR
SERVICE MANUAL
Precaution to be taken when replacing and servicing the
Laser Pickup.
The AEL (Accessible Emission Level) of Laser Power Output
forthis model is specified to belowerthan Class I Requirements.
However, the following precautions must be observed during
servicing to protect your eyes against exposure to the Laser
beam
(1) When the cabinet has been removed, the power is turned
on without a compact disc, and the Pickup is on a position
outerthan the lead-in position, the Laserwill Iightforseveral
,seconds to detect a disc, Do not look into the Pickup Lens.
(2) The Laser Power Output of the Pickup inside the unit and
replacement service parts have already been adjusted prior
to shipping.
(3) No adjustment to the Laser Power should be attempted
when replacing or servicing the Pickup.
(4) Under no circumstances look directly into the Pickup Lens
at any time.
(5) CAUTION - Use of controls or adjustments, or performance
of procedures other than those specified herein may result
in hazardous radiation exposure.
Laser Dkode Properties
Material: GaAlAs
Wavelength. 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW
CAUTION
0 This Mini Component System is classified as a CLASS
1 LASER product.
0 The CLASS 1 LASER PRODUCT label is located on the
rear cover.
l Use of controls, adjustments or performance of proce-
dures other than those specified herein may result in haz-
ardous radiation exposure.
As the laser beam used in this compact disc player is
harmful to the eyes, do not attempt to disassemble the
cabinet. Refer servicing to qualified personnel only.
1
VOLTAGE SELECTION
The voltage selector is located on the AC voltage selector box. If adjustment is necessary, use a screwdriver in order to turn the
selector in either direction the correct voltage figure is displayed in the window next to the adjustment screw.
QACCB0002AWOO
92LCORD5776
QACCE0005AWOO
QACCL0002AWOO
92LCORDZ1652A
El
92LPLUG027 92LPLUG155A
Figure 2 POWER SUPPLY CORD AND PLUG ADAPTOR
-2-

CD-C471 W
FOR A COMPLETE DESCRIPTION OF THE OPERATION OF THIS UNIT, PLEASE REFER
TO THE OPERATION MANUAL.
SPECIFICATIONS
0 General
Power source:
AC 11 O/l 27/2201230-240 V,
50160 Hz
Power consumption:
112w
Dimensions:
Width; 270 mm (1 O-5/8”)
Height; 303 mm (1 l-l 3116”)
Depth; 350 mm (13-13/16”)
Weight: 7.1 kg (15.3 Ibs.)
0 Amplifier section
Output power: PMPO; 1,000 W (total)
Front speakers;
Input terminals:
Output terminals:
MPO; 176 W (88 W + 88 W)
(10 % T.H.D.)
RMS; 80 W (40 W + 40 W)
(10 % T.H.D.)
Center speaker;
MPO; 32 W (10 % T.H.D.)
RMS; 20 W (10 % T.H.D.)
Surround speakers;
MPO; 32 W (10 % T.H.D.)
RMS; 20 W (10 % T.H.D.)
Video/Auxiliary (audio signal) x 2;
500 mVl47 kohms
Front speakers; 6 ohms
Center speakers; 4 ohms
Surround Speakers; 8 ohms
Headphones; 16-50 ohms
(recommended; 32 ohms)
0 Compact disc player section
Type:
Signal readout:
DIR Converter:
Frequency response:
Dynamic range:
l Tuner section
Frequency range:
3-disc multi-play compact disc player
Non-contact, 3-beam semi-conductor
laser pickup
1 -bit D/A converter
20 - 20,000 Hz
90 dB (1 kHz)
FM; 88 - 108 MHz
AM; 531 - 1,602 kHz
l Cassette deck section
Type:
Compact cassette tape
Frequency response: 50 - 14,000 Hz (Normal tape)
Motor:
DC motor with electronic governor x 1
Signal/noise ratio:
55 dB (TAPE 1, playback)
50 dB (TAPE 2, recording/playback)
Bias and erasure
system:
Tape speed:
Wow and flutter:
Heads:
AC
4.76 cmlsec. (l-718 ips)
0.15 % (WRMS)
TAPE-l : Playback x 1
TAPE-2: Record/playback x 1
Erase x 1
0 Front speaker section
Type:
Maximum input power:
Impedance:
Dimensions:
Weight:
3-way type [130 mm (5-l/8”) woofer,
50 mm (2”) tweeter and super tweeter]
80 W
6 ohms
Width; 200 mm (7-7/8”)
Height; 300 mm (11-13/l 6”)
Depth; 253 mm (10”)
2.7 kg (5.8 Ibs.)/each
l Center speaker section
Type:
100 mm (4”) full-range speaker
Maximum input power: 40 W
Impedance:
4 ohms
Dimensions:
Width; 262 mm (1 O-5/1 6”)
Height; 145 mm (5-3/4”)
Depth; 201 mm (7-15/l 6”)
Weight:
1.2 kg (2.6 Ibs.)/each
l Surround speaker section
Type:
100 mm (4”) full-range speaker
Maximum input power: 20 W
Impedance:
8 ohms
Dimensions:
Width; 170 mm (6-3/4”)
Height; 122 mm (4-l 3/l 6”)
Depth; 176 mm (6-1916”)
Weight:
0.7 kg (1.5 Ibs.)/each
Specifications for this model are subject to change without
prior notice.
