OPERATION MANUAL
MODEL
Thank you for purchasing this SHARP product.
To obtain the best performance from this product, please
read this manual carefully. It will guide you in operating
your SHARP product.
CD-E800W Mini Component System consisting of
CD-E800W (main unit) and CP-E800 (speaker system).
MINI COMPONENT SYSTEM
CD-E800W

1
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
Important Instruction
Special notes
Warning:
!When the ON/STAND-BY button is set at STAND-BY position,
mains voltage is still present inside the unit. When the ON/
STAND-BY button is set at STAND-BY position, the unit may be
brought into operation by the timer mode or remote control.
!This unit contains no user serviceable parts. Never remove cov-
ers unless qualified to do so. This unit contains dangerous volt-
ages, always remove mains plug from the socket before any
service operation and when not in use for a long period.
!To prevent fire or shock hazard, do not expose this appliance to
dripping or splashing. No objects filled with liquids, such as
vases, should be placed on the apparatus.
Note for users in Australia:
Copyright may exist in material you wish to record. Copying or
broadcasting such material without permission of the relevant lic-
ensees or owners of the copyright is prohibited by law. SHARP is
not in a position to authorise the copying or broadcasting of copy-
right materials and nothing in this OPERATION MANUAL should be
implied as giving that authority.
For other countries:
Audio-visual material may consist of copyrighted works which must
not be recorded without the authority of the owner of the copyright.
Please refer to the relevant laws in your country.
CAUTION
!This product is classified as a CLASS 1 LASER product.
!Use of controls, adjustments or performance of procedures other
than those specified herein may result in hazardous radiation ex-
posure.
As the laser beam used in this compact disc player is harmful to
the eyes, do not attempt to disassemble the cabinet. Refer servic-
ing to qualified personnel only.
Laser Diode Properties
Material: GaAIAs
Wavelength: 780 nm
Emission Duration: continuous
Laser Output: max. 0.6 mW

2
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
General Information
Accessories
Please confirm that the following accessories are included.
Note:
Only the above accessories are included.
Contents
Page
"General Information
Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Controls and indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4 - 6
"Preparation for Use
System connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7 - 9
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
"Basic Operation
Sound control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
"CD Playback
Listening to a CD (CDs) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13, 14
Advanced CD playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15, 16
"Radio
Listening to the radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17, 18
"Tape Playback
Listening to a cassette tape (TAPE 1) . . . . . . . . . . . . . . . . . . . 19
Listening to a cassette tape (TAPE 2) . . . . . . . . . . . . . . . . . . . 20
"Karaoke
Playing karaoke . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21, 22
"Tape Recording
Recording to a cassette tape . . . . . . . . . . . . . . . . . . . . . . . 23, 24
"Advanced Features
Timer and sleep operation . . . . . . . . . . . . . . . . . . . . . . . . .25 - 27
Enhancing your system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
"References
Troubleshooting chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29, 30
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31, 32
Remote control 1 "AA" size battery (UM/SUM-3,
R6, HP-7 or similar) 2
AM loop aerial 1 FM aerial 1
CD-E800W(A) TINSE0908AWZZ 2

3
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
General Information
Precautions
"General
!Please ensure that the equipment is positioned in a well venti-
lated area and ensure that there is at least 10 cm (4") of free
space along the sides, top and back of the equipment.
!Use the unit on a firm, level surface free from vibration.
!Keep the unit away from direct sunlight, strong magnetic fields,
excessive dust, humidity and electronic/electrical equipment
(home computers, facsimiles, etc.) which generate electrical
noise.
!Do not place anything on top of the unit.
!Do not expose the unit to moisture, to temperatures higher than
60°C (140°F) or to extremely low temperatures.
!If your system does not work properly, disconnect the AC power
lead from the wall socket. Plug the AC power lead back in, and
then turn on your system.
!In case of an electrical storm, unplug the unit for safety.
!Hold the AC power plug by the head when removing it from the
wall socket, as pulling the lead can damage internal wires.
!Do not remove the outer cover, as this may result in electric
shock. Refer internal service to your local SHARP service
facility.
!The ventilation should not be impeded by covering the ventilation
openings with items, such as newspapers, tablecloths, curtains,
etc.
!No naked flame sources, such as lighted candles, should be
placed on the apparatus.
!Attention should be drawn to the environmental aspects of bat-
tery disposal.
!This unit should only be used within the range of 5°C - 35°C
(41°F - 95°F).
Warning:
The voltage used must be the same as that specified on this unit.
Using this product with a higher voltage other than that which is
specified is dangerous and may result in a fire or other type of acci-
dent causing damage. SHARP will not be held responsible for any
damage resulting from use of this unit with a voltage other than that
which is specified.
"Volume control
The sound level at a given volume setting depends on speaker effi-
ciency, location, and various other factors. It is advisable to avoid
exposure to high volume levels. Do not turn the volume on to full at
switch on and listen to music at moderate levels.
"Care of compact discs
Compact discs are fairly resistant to damage, however mistracking
can occur due to an accumulation of dirt on the disc surface. Follow
the guidelines below for maximum enjoyment from your CD collec-
tion and player.
!Do not write on either side of the disc, particularly the non-label
side from which signals are read. Do not mark this surface.
!Keep your discs away from direct sunlight, heat, and excessive
moisture.
!Always hold the CDs by the edges. Fingerprints, dirt, or water on
the CDs can cause noise or mistracking. If a CD is dirty or does
not play properly, clean it with a soft, dry cloth, wiping straight out
from the centre, along the radius.
10 cm (4") 10 cm (4") 10 cm (4")
10 cm (4")
NO YES
Correct

4
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
General Information
Controls and indicators
"Front panel
Reference page
1. Disc Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
2. Timer Set Indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
3. Memory/Set Button . . . . . . . . . . . . . . . . . . . . . . . . . 12, 16, 18
4. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
5. Clock Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12, 25
6. Timer/Sleep Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25, 27
7. Tuning and Time Up Button . . . . . . . . . . . . . . . . . . . . . 12, 17
8. Tuning and Time Down Button . . . . . . . . . . . . . . . . . . . 12, 17
9. Headphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
10. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . 23, 24
11. Tape 1 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 19
12. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . 11
13. Extra Bass/Demo Mode Button . . . . . . . . . . . . . . . . . . . 9, 11
14. Volume Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
15. Disc Tray Open/Close Button . . . . . . . . . . . . . . . . . . . . . . . 13
16. Disc Skip Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
17. Microphone Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
18. Tape 2 Cassette Compartment . . . . . . . . . . . . . . . . . . . . . . 20
19. Microphone Level Control . . . . . . . . . . . . . . . . . . . . . . . . . . 21
20. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
21. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 20
22. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . 14, 19, 20
23. Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . 20
24. CD Track Down or Fast Reverse, Tape 2 Fast Wind,
Tuner Preset Down Button . . . . . . . . . . . . . . . . . . . 14, 18, 20
25. Tape 2 Reverse Mode Select Button . . . . . . . . . . . . . . . . . 20
26. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
27. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
28. CD Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button . . . . . . . . . . . . . . . 13, 15, 19, 20
29. CD Track Up or Fast Forward, Tape 2 Fast Wind,
Tuner Preset Up Button . . . . . . . . . . . . . . . . . . . . . . 14, 18, 20
3
4
5
2
1
6
11
9
7
8
10
12
16
17
14
15
18
13
26
27
28
29
20
21
22
23
24
25
19
1

5
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
General Information
Controls and indicators (continued)
"Display
1. CD Pause Indicator
2. Extra Bass Indicator
3. Disc Number Indicators
4. Tape 2 Record Indicator
5. FM Stereo Mode Indicator
6. FM Stereo Receiving Indicator
7. Timer Play Indicator
8. Sleep Indicator
9. Timer Recording Indicator
10. CD Play Indicator
11. CD Repeat Play Indicator
12. Karaoke Mode Indicator
13. Tape Reverse Mode Indicator
14. Tape 2 Reverse Play Indicator
15. Tape 1 Play or Tape 2 Forward Play Indicator
16. Memory Indicator
"Rear panel
Reference page
1. Cooling Fan
2. AC Voltage Selector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
3. AC Power Lead . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
4. FM 75 Ohms Aerial Terminal . . . . . . . . . . . . . . . . . . . . . . . . . 7
5. FM Aerial Earth Terminal . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6. AM Loop Aerial Socket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
7. Span Selector Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8. Video/Auxiliary (Audio Signal) Input Sockets . . . . . . . . . . 28
9. Speaker Terminals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7, 8
Note:
This product is equipped with a cooling fan inside, which begins to
run at a specified volume level for better heat radiation.
"Speaker system
1. Super Tweeters
2. Woofer
3. Tweeter
4. Passive Radiator
5. Speaker Wire
3
2
1
4
5
6
8
7
9
13
14 15 16
23456791 8
12
10
11
1
4
3
5
2

6
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
General Information
!Remote control
Reference page
1. Remote Control Transmitter . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2. Disc Number Select Buttons . . . . . . . . . . . . . . . . . . 13, 16, 23
3. CD Memory Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4. Programme Clear Button . . . . . . . . . . . . . . . . . . . . . . . . . . 16
5. Echo Level Up and Down Buttons . . . . . . . . . . . . . . . . . . . 21
6. Karaoke Mode Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
7. CD Pause Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
8. CD Track Down or Fast Reverse,
Tape 2 Fast Wind Button . . . . . . . . . . . . . . . . . . . . . . . . . 14, 20
9. Tape 2 Reverse Play Button . . . . . . . . . . . . . . . . . . . . . . . . . 20
10. CD or Tape Stop Button . . . . . . . . . . . . . . . . . . . . . . . 14, 19, 20
11. Tape 2 Record Pause Button . . . . . . . . . . . . . . . . . . . . . . 23, 24
12. CD Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
13. Tape (1 2) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19, 20
14. On/Stand-by Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
15. CD Random Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
16. Direct Search Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
17. Tuner Preset Up and Down Buttons . . . . . . . . . . . . . . . . . . . 18
18. CD Track Up or Fast Forward,
Tape 2 Fast Wind Button . . . . . . . . . . . . . . . . . . . . . . . . . 14, 20
19. CD Play or Repeat, Tape 1 Play,
Tape 2 Forward Play Button . . . . . . . . . . . . . . . . 13, 15, 19, 20
20. Extra Bass Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
21. Equaliser Mode Select Button . . . . . . . . . . . . . . . . . . . . . . . . 11
22. Volume Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . 11
23. Tuner (Band) Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
24. Video/Auxiliary Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Buttons with " " mark in the illustration or highlighted in bold on the
right can be operated on the remote control only.
1
2
3
7
10
9
8
11
12
13
17
14
415
16
20
21
22
23
24
18
19
5
6
1

7
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
Preparation for Use
System connections
!Aerial connection
Supplied FM aerial:
Connect the FM aerial wire to the FM 75 OHMS terminal and posi-
tion the FM aerial wire in the direction where the strongest signal
can be received.
Supplied AM loop aerial:
Connect the AM loop aerial to the AM LOOP socket. Position the
AM loop aerial for optimum reception. Place the AM loop aerial on a
shelf, etc., or attach it to a stand or a wall with screws (not supplied).
Note:
Placing the aerial on the unit or near the AC power lead may cause
noise pickup. Place the aerial away from the unit for better recep-
tion.
Installing the AM loop aerial:
External FM aerial:
Use an external FM aerial if you require better reception. Consult
your dealer.
Note:
When an external FM aerial is used, disconnect the supplied FM
aerial wire.
Black
Red
AM loop aerial
FM aerial
Left speaker
Right speaker
Wall socket
(See page 8.)
< Assembling > < Attaching to the wall >
Wall Screws
(not supplied)
External
FM aerial
75 ohm
coaxial
cable

8
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
Preparation for Use
!Speaker connection
Connect the black wire to the minus (-) terminal, and the red wire to
the plus (+) terminal.
Caution:
!Placing the speaker system
The left and right speakers have individual shapes. For best perfor-
mance, place the speakers according to the diagram below.
Note:
The speaker grilles are not removable.
!Setting the AC voltage selector
Check the setting of the AC voltage selector located on the rear
panel before plugging the unit into a wall socket. If necessary, adjust
the selector to correspond to the AC power voltage used in your
area.
Turn the selector with a screwdriver until the appropriate volt-
age number appears in the window (110 V, 127 V, 220 V or 230
V - 240 V AC).
!Connecting the AC power lead
After checking all the connections have been made correctly, plug
the AC power lead of this unit into the wall socket. If you plug the
unit first, the unit will enter the demonstration mode (see page 9).
Notes:
"The unit will start the tape initialisation when plugged in to the AC
socket. During this process, initialising sound will be heard and
the unit cannot be turned on. Wait until the process is finished.
"Unplug the AC power lead from the wall socket if the unit will not
be in use for a prolonged period of time.
"Use speakers with an impedance of 6 ohms
or more, as lower impedance speakers can
damage the unit.
"Do not mistake the right and the left chan-
nels. The right speaker is the one on the right
side when you face the unit.
"Do not let the bare speaker wires touch
each other.
"Do not stand or sit on the speakers. You may
be injured.
Incorrect
Left speaker Right speaker
(230 - 240 V, 50/60 Hz)
Wall socket
230V
240V
2

9
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
Preparation for Use
System connections (continued)
!Setting the FM/AM span selector
The International Telecommunication Union (ITU) has established
that member countries should maintain either a 100 kHz or a 50 kHz
interval between broadcasting frequencies of FM stations and 10
kHz or 9 kHz for AM station. The illustration shows the 50/9 kHz
zones (regions 1 and 3), and the 100/10 kHz zone (region 2).
Before using the unit, set the SPAN SELECTOR switch (on the rear
panel) to the interval (span) of your area.
To change the tuning zone:
Caution:
This operation will erase all data stored in memory including clock,
timer settings, tuner preset, and CD programme.
!Demonstration mode
To cancel the demonstration mode:
When the unit is in the power stand-by mode (demonstration mode),
press the X-BASS/DEMO button. The demonstration mode will be
cancelled and the display will disappear.
To return to the demonstration mode:
When the unit is in the power stand-by mode, press the X-BASS/
DEMO button again.
Note:
When the power is on, the X-BASS/DEMO button can be used to
select the extra bass mode.
!To turn the power on
Press the ON/STAND-BY button to turn the power on.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Set the SPAN SELECTOR switch (on the rear panel) as follows.
"For 50 kHz FM interval (9 kHz in AM) 50/9
"For 100 kHz FM interval (10 kHz in AM) 100/10
3 Whilst pressing down the button and the X-BASS/DEMO but-
ton, press the ON/STAND-BY button until "CLEAR AL" appears.
The first time the unit is plugged in, the
unit will enter the demonstration mode.
You will see words scroll.
After use:
Press the ON/STAND-BY button to enter the power stand-by
mode.

10
CD-E800W
03/8/27 CD-E800W(A)1.fm TINSE0908AWZZ
Preparation for Use
Remote control
!Battery installation
Precautions for battery use:
"Replace all old batteries with new ones at the same time.
"Do not mix old and new batteries.
"Remove the batteries if the unit is not to be used for long periods
of time. This will prevent potential damage due to battery leak-
age.
Caution:
"Do not use rechargeable batteries (nickel-cadmium battery, etc.).
"Installing the batteries incorrectly may cause the unit to malfunc-
tion.
Notes concerning use:
"Replace the batteries if the operating distance is reduced or if the
operation becomes erratic. Purchase 2 "AA" size batteries (UM/
SUM-3, R6, HP-7 or similar).
"Periodically clean the transmitter on the remote control and the
sensor on the unit with a soft cloth.
"Exposing the sensor on the unit to strong light may interfere with
operation. Change the lighting or the direction of the unit.
"Keep the remote control away from moisture, heat, shock, and
vibrations.
!Test of the remote control
Check the remote control after checking all the connections (see
pages 7 - 8).
Point the remote control directly at the remote sensor on the unit.
The remote control can be used within the range shown below:
Press the ON/STAND-BY button. Does the power turn on? Now,
you can enjoy music.
1 Remove the battery cover.
2 Insert the batteries according to the direction indicated in
the battery compartment.
When inserting or removing the batteries, push them towards the
battery terminals.
3 Replace the cover.
0.2 m - 6 m
(8" - 20')
Remote sensor
CD-E800W(A) TINSE0908AWZZ 3
2

11
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
Basic Operation
Sound control
!Volume control
Main unit operation:
When the VOLUME control is turned clockwise, the volume will
increase. When it is turned anti-clockwise, the volume will decrease.
Remote control operation:
Press the VOLUME ( or ) button to increase or decrease the vol-
ume.
!Bass control
When the power is first turned on, the unit will enter the extra bass
mode which emphasises the bass frequencies, and "X-BASS" will
appear. To cancel the extra bass mode, press the X-BASS/DEMO
(X-BASS) button.
!Equaliser
When the EQUALIZER (EQUALIZER MODE) button is pressed, the
current mode setting will be displayed. To change to a different
mode, press the EQUALIZER (EQUALIZER MODE) button repeat-
edly until the desired sound mode appears.
012 29 30 MAXIMUM
.....
X-BASS indicator
ROCK
FLAT
CLASSIC
The sound is not modified.
Bass and treble are emphasised.
POPS Bass and treble are slightly emphasised.
JAZZ Treble is slightly emphasised.
Treble is cut a little.
VOCAL Vocals (midrange tones) are emphasised.

12
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
Basic Operation
Setting the clock
In this example, the clock is set for the 24-hour (0:00) display.
To confirm the time display:
Note:
The "CLOCK" or time will flash at the push of the CLOCK button
when the AC power supply is restored after a power failure or
unplugging the unit.
Readjust the clock as follows.
To readjust the clock:
Perform "Setting the clock" from step 1. If the "CLOCK" is not flash-
ing in step 2, step 3 (for selecting the 24-hour or 12-hour display)
will be skipped.
To change the 24-hour or 12-hour display:
1Press the ON/STAND-BY button to turn the power on.
2Press the CLOCK button and within 5 seconds, press the
MEMORY/SET button.
3Press the TUNING/TIME ( or ) button to select 24-hour or
12-hour display and then press the MEMORY/SET button.
"0:00" The 24-hour display will appear.
(0:00 - 23:59)
"AM 12:00" The 12-hour display will appear.
(AM 12:00 - PM 11:59)
"AM 0:00" The 12-hour display will appear.
(AM 0:00 - PM 11:59)
Note that this can only be set when the unit is first installed or it
has been reset. [Refer to "Clearing all the memory (reset)" on
page 30 for details.]
4Press the TUNING/TIME ( or ) button to adjust the hour
and then press the MEMORY/SET button.
"Press the TUNING/TIME ( or ) button once to advance
the time by 1 hour. Hold it down to advance continuously.
"When the 12-hour display is selected, "AM" will change au-
tomatically to "PM".
5Press the TUNING/TIME ( or ) button to adjust the min-
utes and then press the MEMORY/SET button.
"Press the TUNING/TIME ( or ) button once to advance
the time by 1 minute. Hold it down to change the time in 5-
minute intervals.
"The hour will not advance even if minutes advance from "59"
to "00".
Press the CLOCK button.
The time display will appear for about 5
seconds.
1 Clear all the programmed contents. [Refer to "Clearing all the
memory (reset)" on page 30 for details.]
2 Perform "Setting the clock" from step 1.
3

13
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
CD Playback
Listening to a CD (CDs)
This system can also play audio CD-R and CD-RW discs, but can-
not record.
Some audio CD-R and CD-RW discs may not be playable due to the
state of disc or the device that was used for recording.
1Press the ON/STAND-BY button to turn the power on.
2Press the CD button.
3Press the OPEN/CLOSE button to open the disc tray.
4Place the CD(s) on the disc tray, label side up.
When loading a third disc, press the DISC SKIP button to
turn the disc tray, then place the CD in the open position.
"CDs can be placed on any open position on the disc tray.
"Be sure to place 8 cm (3") CDs in the middle of the disc po-
sitions.
5Press the OPEN/CLOSE button to close the disc tray.
Total number of tracks on
the CD whose number is
flashing
Total playing time of the CD
whose number is flashing
6To select the CD you want to listen to first, press one of the
1 - 3 buttons on the remote control.
7Press the ( ) button to start playback.
"Playback will begin from track 1 on the disc you have select-
ed to play. After that disc finishes playing, the next disc will
automatically start playback.
"When the last track on the third disc has finished playing, the
CD player will automatically stop.
"When there is no CD in one of the disc 1 - 3 positions, that
position will be skipped and the next CD will begin to play.
12 cm (5") 8 cm (3")

14
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
CD Playback
To interrupt playback:
Press the CD button on the remote control.
To resume playback from the same point, press the button.
To stop playback:
Press the button.
To remove the CDs:
Whilst in the stop mode, press the OPEN/CLOSE button.
The disc tray will open. Remove the two discs. Then, press the
DISC SKIP button to rotate the disc tray and remove the remaining
disc.
Caution:
"Do not place two CDs in one disc tray.
"Do not play discs with special shapes (heart- or octagon-
shaped). It may cause malfunctions.
"Do not push the disc tray whilst it is moving.
"Do not turn the disc tray by hand. This may cause malfunctions.
"If the power fails whilst the tray is open, wait until the power is
restored.
"If the disc tray is stopped with force, "ER-CD10" will appear on
the display for 3 seconds and the unit will not function. If this
occurs, press the ON/STAND-BY button to enter the power
stand-by mode and then turn the power on again.
"If TV or radio interference occurs during CD operation, move the
unit away from the TV or radio.
"If a disc is damaged, dirty, or loaded upside down, the disc will
skip or not play back.
!To locate the beginning of a track
Notes:
"You can locate the beginning of a track on a single disc only.
"You can skip to any track by pressing the or button
repeatedly until the desired track number appears.
!To locate the desired portion
Notes:
"Normal playback will resume when the or button is
released.
"You can locate the desired portion on a single disc only.
"When the end of the last track is reached during fast forward,
"END" will appear on the display and CD operation will be
paused. When the beginning of the first track is reached during
fast reverse, the unit will enter the playback mode.
To move to the beginning of the next track:
Press the button for less than 0.5 seconds during playback.
To restart the track being played:
Press the button for less than 0.5 seconds during playback.
For audible fast forward:
Press and hold down the button during playback.
For audible fast reverse:
Press and hold down the button during playback.
4

15
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
CD Playback
Advanced CD playback
!Direct search of the track
By using the direct search buttons, the desired tracks can be played.
To stop playback:
Press the button.
Notes:
"The selected track can be started simply by pressing the direct
search buttons during playback. (It is not necessary to press the
button.)
"A track number higher than the number of tracks on the disc can-
not be selected.
"During random play, direct search is not possible.
!Repeat play
All tracks on up to 3 discs, or a programmed sequence can be con-
tinuously repeated.
To cancel repeat play:
Press the ( ) button again. " " will go out.
!Random play
The tracks on the disc(s) can be played in random order automatically.
To cancel random play:
Press the button.
Notes:
"If you press the button during random play, you can move
to the track selected next by the random operation. On the other
hand, the button does not allow you to move to the previ-
ous track. The beginning of the track being played will be located.
"In random play, the CD player will select and play tracks auto-
matically. (You cannot select the order of the tracks.)
Caution:
After performing repeat or random play, be sure to press the but-
ton. Otherwise, the disc(s) will play continuously.
1Whilst in the stop mode, press one of the 1 - 3 buttons
on the remote control or DISC SKIP button to select the de-
sired disc.
2Use the direct search buttons
on the remote control to select
the desired track. Selected track number
"The direct search buttons allow you to select up to number 9.
"When selecting number 10 or more, use the "+10" button.
A. For example, to choose 13
1 Press the "+10" button once.
2 Press the "3" button.
B. For example, to choose 30
1 Press the "+10" button three times.
2 Press the "0" button.
3Press the button to start playback.
Playback of the selected track is started. When the end of last
track of the disc selected is reached, the next disc will be auto-
matically started.
To repeat all tracks on up to 3 discs:
Press the ( ) button twice.
To repeat a desired track:
Perform steps 1 - 4 in the "Programmed play" section on page 16
and then press the ( ) button twice.
Press the RANDOM button on the remote control to begin ran-
dom play.

16
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
CD Playback
!Programmed play
You can choose up to 32 selections for playback in the order you
like.
Adding tracks to the programme:
If a programme has been previously stored, the "MEMORY" indica-
tor will be displayed. Then follow steps 1 - 3 to add tracks. The new
tracks will be stored after the last track of the original programme.
Notes:
"Opening the disc tray automatically cancels the programmed
sequence.
"Even if you press the ON/STAND-BY button to enter the stand-by
mode or change the function from CD to another, the pro-
grammed selections will not be cleared.
"During programme operation, random play is not possible.
1Whilst in the stop mode, press
one of the 1 - 3 buttons on
the remote control to select
the desired disc.
Selected disc number
2Press the direct search but-
tons on the remote control to
select the desired track. Selected track number
You can also select a track by pressing the or
button.
3Press the MEMORY/SET (MEMORY) button to save the
track number.
Playback order
When the track is memorised, "MEMORY" will appear.
4Repeat steps 1 - 3 for other tracks. Up to 32 tracks can be
programmed.
If you make a mistake, the programmed tracks can be cleared
by pressing the CLEAR button.
5Press the ( ) button to start playback.
To clear the programmed selections:
Whilst the "MEMORY" indicator is lit, set the
CD to the stop mode and then press the
CLEAR button.
Each time the button is pressed, one track will
be cleared, beginning with the last track pro-
grammed. When all the tracks are cleared,
"MEMORY" will disappear. 4

17
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
Radio
Listening to the radio
!Tuning
To receive an FM stereo transmission:
Press the TUNER (BAND) button to display the "ST" indicator.
"" " will appear when an FM broadcast is in stereo.
"If the FM reception is weak, press the TUNER (BAND) button to
extinguish the "ST" indicator. The reception changes to monau-
ral, and the sound becomes clearer.
Note:
This product can receive FM stereo/FM monaural and AM monaural
broadcasts. AM stereo broadcasts will not be played in stereo.
1Press the ON/STAND-BY button to turn the power on.
2Press the TUNER (BAND) button repeatedly to select the
desired frequency band (FM or AM).
3Press the TUNING/TIME ( or ) button to tune in to the de-
sired station.
Manual tuning:
Press the TUNING/TIME button as many times as required to
tune in to the desired station.
Auto tuning:
When the TUNING/TIME button is pressed for more than 0.5
seconds, scanning will start automatically and the tuner will
stop at the first receivable broadcast station.
Notes:
"When radio interference occurs, auto scan tuning may stop
automatically at that point.
"Auto scan tuning will skip weak signal stations.
"To stop the auto tuning, press the TUNING/TIME button
again.
FM stereo mode indicator
FM stereo receiving indicator

18
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
Radio
!Memorising a station
You can store 40 AM and FM stations in memory and recall them at
the push of a button. (Preset tuning)
Note:
The backup function protects the memorised stations for a few
hours should there be a power failure or if the AC lead is discon-
nected.
!To recall a memorised station
Press the PRESET ( or ) button for less than 0.5 seconds to
select the desired station.
This can be operated by pressing the TUNER PRESET ( or )
button on the remote control.
!To scan the preset stations
The stations saved in memory can be scanned automatically. (Pre-
set memory scan)
!To erase entire preset memory
1Perform steps 1 - 3 in "Tuning" on page 17.
2Press the MEMORY/SET button to enter the preset tuning
saving mode.
3Within 30 seconds, press the PRESET ( or ) button to
select the preset channel number.
Store the stations in memory, in order, starting with preset
channel 1.
4Within 30 seconds, press the MEMORY/SET button to store
that station in memory.
If the "MEMORY" and preset number indicators go out before
the station is memorised, repeat the operation from step 2.
5Repeat steps 1 - 4 to set other stations, or to change a pre-
set station.
When a new station is stored in memory, the station previously
memorised will be erased.
1 Press the PRESET ( or ) button for more than 0.5 seconds.
"The preset number will flash and the programmed stations will
be tuned in sequentially, for 5 seconds each.
"This can be operated by pressing the TUNER PRESET ( or
) button on the remote control.
2 Press the PRESET ( or ) button again when the desired sta-
tion is located.
1 Press the ON/STAND-BY button to enter the stand-by mode.
2 Whilst pressing down the TUNER (BAND) button and the X-
BASS/DEMO button, press the ON/STAND-BY button until
"TUNER CL" appears.
5

19
CD-E800W
03/8/27 CD-E800W(A)2.fm TINSE0908AWZZ
Tape Playback
Listening to a cassette tape (TAPE 1)
Before playback:
To stop playback:
Press the button.
Note:
You cannot fast-forward or rewind the cassette in the TAPE 1 com-
partment.
"For playback, use normal or low-noise tapes for
the best sound. (Metal or CrO tapes are not rec-
ommended.)
"Do not use C-120 tapes or poor-quality tapes, as
they may cause malfunctions.
"Before loading a tape into the cassette compartment,
tighten the slack with a pen or a pencil.
1Press the ON/STAND-BY button to turn the power on.
2Press the TAPE (1 2) button to select TAPE 1.
3Open the cassette door by pushing the area marked "PUSH
EJECT ".
4Load a cassette into the TAPE 1
cassette compartment with the
side to be played facing toward
you.
5Press the ( ) button to start playback.
