OPERATION MANUAL
COLOUR TELEVISION
Please read this operation manual
carefully before using the colour
television.
MODEL
29H-FX3M
ON
TIMERPOWER
SAVE
STANDBY
POWER
29H-FX3M(Front) 10/4/04, 9:23 PM1

E 1
Contents
Preparation
Accessories ................................................................ 2
Easy setup ................................................................. 3
Safety precautions ..................................................... 4
Part names ................................................................. 6
Installing batteries in the remote control unit ............. 6
Watching TV
Watching a TV programme ........................................ 8
Operating the TV buttons ........................................... 9
Useful features
Clock/Timer/Channel display ................................... 10
Mute ......................................................................... 10
Sound mode ............................................................. 11
Channel recall .......................................................... 11
TV/Video selection ................................................... 11
Selecting menu items
Selecting a menu item.............................................. 12
Settings and adjustments
On-screen display language selection ..................... 14
Auto channel tuning ................................................. 15
Manual channel tuning ............................................. 16
Channel setting ........................................................ 17
Picture adjustment ................................................... 21
Sound adjustment .................................................... 23
Equalizer .................................................................. 24
Surround sound ....................................................... 25
Blue screen .............................................................. 25
Auto select ............................................................... 26
Power save ............................................................... 27
16:9 mode ................................................................ 28
Child lock .................................................................. 29
Demo ....................................................................... 32
Clock ........................................................................ 33
Day ........................................................................... 34
On timer ................................................................... 34
Off timer ................................................................... 36
Reminder on-screen timer ....................................... 37
View timer ................................................................ 39
Beep reminder ......................................................... 42
Favourite channels ................................................... 43
Broadcast features
Teletext broadcasts .................................................. 44
Connections
Connecting to a DVD player ..................................... 49
Watching DVD Playback .......................................... 49
Connecting to an antenna ........................................ 50
Connecting to an antenna via a VCR ....................... 50
Connecting to video equipment ............................... 51
Troubleshooting
Troubleshooting ........................................................ 52
Specifications
Specifications ........................................................... 53
Definition of Terms ................................................... 54
29H-FX3M(01-10)EN 10/4/04, 9:23 PM1

E 2
Dear SHARP Customer
Thank you for buying SHARP’s Colour
Television. We hope you will have many
years of enjoyment from this television
set. To ensure proper operation, please
read this manual carefully, and keep it in
a safe place for future reference.
Remote control Size-AA batteries Operation manual
The following accessories are included with this television.
Accessories
29H-FX3M
P
O
W
E
R
SA
VE
POWER
STANDBYON
TIMER
29H-FX3M(01-10)EN 10/4/04, 9:23 PM2

E 3
Easy setup
To use your TV set, perform the easy setup procedure below.
The mark indicates the page numbers with more detailed information.
Connect the antenna.
• See
50
to connect the antenna.
Connect any video equipment.
• See
50
,
51
to connect video equipment.
• See the operation manual of your video equipment when
connecting to the TV set.
Insert the batteries into the remote control.
• Use the two batteries included with the TV.
• See
6
.
Insert the AC plug to the power outlet.
• If you will not use the TV set for a considerable length of
time, as a safety precaution, unplug the cord from the
outlet.
Tune the channels.
• Use the buttons on the TV.
• See
15
,
16
.
29H-FX3M(01-10)EN 10/4/04, 9:23 PM3

E 4
Safety precautions
Damage
Turn off the power and unplug the power cord from the wall
outlet immediately if the TV set begins to make any unusual
noises or gives off smoke or an unusual smell. Then call your
dealer for service.
Servicing
To reduce the risk of electric shock, do not remove the back of
the cabinet. This TV set contains dangerous voltage.
Unstable surface and shocks
Do not place this TV set on an unstable cart, stand, shelf, or
table. The TV set may fall, causing serious injury to a child or
adult, and serious damage to the set.
Sharp recommends securing the TV set to a stable surface or
wall to prevent the set from falling due to sudden shocks or
impact.
Water
To prevent fire or electrical shock, do not place the TV set near a
bathroom, swimming pool or other area where it may become
wet.
Moisture
To prevent electrical shock, do not use the TV set in an
excessively damp place.
Power-cord protection
To prevent electrical shock, do not subject the AC power cord to
damage by bending or twisting it, or by placing heavy items on
top of it and do not place the AC power cord under the TV set. If
the AC power cord becomes damaged, unplug it from the wall
outlet immediately and call your dealer for service.
29H-FX3M(01-10)EN 10/4/04, 9:23 PM4

E 5
Safety precautions
Liquid entry
Do not place a flower vase or anything else containing liquid on
the TV set, as liquid spilt on the TV set can cause electrical
shock or failure.
Object entry
Never insert or drop any metallic or inflammable objects into the
ventilation openings of the TV set, as this can cause fire,
electrical shock, or electrical failure.
Ventilation
Do not place this TV set in a confined area, such as on a
bookshelf or in a built-in case. Leave adequate space behind the
TV for proper ventilation.
TV Set position
Do place the TV set onto an even stand, table or track which
size is bigger than the TV set.
If the TV set is put onto a smaller size or uneven stand, table or
track may cause the TV cabinet distort.
Do not put or insert anything between TV set and the stand,
table or track.
Uneven surface and excessive force
Television equipment and cart combination should be moved
with care. Quick stops, excessive force, and uneven surfaces
may cause the equipment and cart combination to overturn.
Fire prevention
To prevent fire, never place any type of candle or naked flames
on the top or near the TV set.
29H-FX3M(01-10)EN 10/4/04, 9:23 PM5

E 6
Part names
Remote control
The mark indicates the page numbers with more detailed information.
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
NORMAL
TV/TEXT
123
456
78
0
9
CH
CH
MENU
LIST
BACD
MPX
Turns the TV on or to
Standby mode.
Mutes the sound and restores
sound to previous level.
Switches between MOVIE,
MUSIC, NEWS and CUSTOM.
Switches between “OFF”, “ESS”or
“SRS”(during receiving signal stereo)
and “OFF”or “EPS”(during
receiving signal monaural).
Adjusts the volume.
Used for MENU setup.
Resets all settings.
Operate the Favourite Channel
and Teletext functions.
Colour buttons
8
10
25
11
12-13
44-48
43,44
8
21
SOUND MODE
SURROUND
NORMAL
/
This button does not
work in this model.
Infrared Transmitter Window
Aim this window at the infrared
sensor window on your TV set.
Displays the clock, timer and
channel settings on the screen.
Number buttons
Switches between one- or two-digit
mode channel selection.
Returns to previously viewed
channel.
Selects the channel.
Used for MENU setup.
Calls the MENU screen.
Switches between TV broadcasts
and A/V input programmes.
Switches between ON or OFF.
TV/VIDEO
MENU
CH
CH /
POWER SAVE
27
11
10
8
8
11
8
Operate the Teletext functions.
Teletext Control buttons
With your thumbnail, pull
up at the slit to open the
battery cover.
Insert two batteries
(size AA).
Replace the battery cover.
Installing batteries in the remote control unit
•Be sure to match the battery j/kterminals with the j/kmarks inside the compartment.
•Remove the batteries if weak or if the unit is not in use for long periods.
•Do not mix old and new batteries.
•Incorrect installation of the batteries may damage the remote control.
29H-FX3M(01-10)EN 10/4/04, 9:23 PM6

E 7
•Minimal electric power remains consumed if the TV is in standby mode.
TV set
To open the door
Using the projection located under
the “PULL-OPEN”indication, pull
and lift the door open.
To close the door
Using the projection, lower the door
until closed.
Caution:
•When opening or closing the door,
do not insert your fingers into the
gap between the door and front
panel. This may result in an injury.
ON
TIMER
STANDBY POWER
SAVE
POWER
ON
TIMER POWER
SAVE
VIDEO (MONO) L-AUDIO-R
S-VIDEO AV-3 IN
MENU/PRESET
CH
POWER
STANDBY
Bottom
Top
12
8
8
35
9
27
51
8
8
6
51
51
Volume up/down button
Adjust the volume.
Make adjustments in PRESET.
MENU/PRESET button
Used for MENU setup.
Tunes the channels.
/
MENU/PRESET
Channel up/down button
Select the channels.
Tune or set the channels.
CH
CH /
STANDBY indicator
Power can be turned on by the remote
control when the indicator is lit red.
ON TIMER indicator
Lights up red when the On Timer is set.
Video input terminal (AV-3)
Connects to a camcorder, video game, etc.
Headphone jack ( )
Used to listen to the audio with
headphone.
(When using headphone, see .)
POWER SAVE indicator
Lights up red when the
Power Save is set.
Audio input terminals (AV-3)
Connects to a camcorder,
video game, etc.
S-Video input terminal (SAV3)
Connects to a camcorder, video game, etc.
POWER switch
Turns the main power on and off.
Infrared sensor window
Receives the infrared wave from the remote control.
POWER
9
Door
Part names
29H-FX3M(01-10)EN 10/4/04, 9:23 PM7

E 8
Watching TV
Watching a TV programme
Simple operations for watching a TV programme.
With the number buttons (on remote control)
•To select a one-digit channel, such as 5, press
5
.
If “5-”is indicated, press to select one-digit input, and then
press
5
again.
•To select a two-digit channel,
such as 15, press to
select the two-digit input. Press
1
, and then press
5
.
•When the Standby indicator is red, either
CH
/
CH
on the TV can be pressed to turn on
the power.
•The channel number is displayed in green for channels tuned by auto tuning and displayed in yellow for
channels tuned using fine tuning.
•When the Standby indicator is red, the TV is in Standby mode and power is still supplied to the TV. If
you will not watch TV for a while, turn off the main power by pressing
POWER
on the TV set. Also, if
you will not be at home for a considerable length of time, unplug the cord from the outlet.
•The AV1 (or SAV1), AV2 (or COMPONENT) and AV3 (or SAV3) input channels can be selected using
TV/VIDEO
.
•Channels that have been skipped cannot be selected by
CH
/
CH
. See
18
.
•The on-screen displays in this manual may differ from their actual appearance.
1Turn on power.
•When the Standby indicator is off, press
POWER
.
•When the Standby indicator is red, press on the remote
control. The Standby indicator changes to green and a picture
appears.
2Select channel.
With
CH
/
CH
•Press
CH
and channels change as shown below.
1 /2 / ... /98 /99 /AV1 (or SAV1) /AV2 (or COMPONENT) /
AV3 (or SAV3) /0 /1 /2 ...
•Press
CH
and channels change as shown below.
1 /0 /AV3 (or SAV3) /AV2 (or COMPONENT) /AV1 (or SAV1) /
99 /98 /... /2 /1 /0 ...
3Adjust volume using
/ .
•The volume bar disappears
approximately five seconds
after the volume has been
adjusted.
TV Set (Bottom)
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
CH
CH
1
5
––
–1
51
VOLU M E19
ON
TIMER
STANDBY POWER
SAVE
POWER
Standby indicator
MENU/PRESET
CH
CH
CH
TV Set (Top)
29H-FX3M(01-10)EN 10/4/04, 9:23 PM8

E 9
•Select an appropriate volume so as not to injure your hearing.
•To avoid injuring your hearing, do not put on the headphone before plugging them into the headphone
jack and before the power is turned on.
•The proper impedance for the headphone is 32 ohms.
•Remove the headphone plug from the jack when not using the headphone.
Operating the TV buttons
Simple operation of the TV set.
Using /
Press to increase volume.
Press to decrease
volume.
Using
CH
/
CH
Press CH to increase channel
number.
Press CH to decrease
channel number.
Using headphone
Insert headphone plug into headphone jack to listen to audio with
headphone.
•The audio from the speakers is turned off.
VOLU M E19
5
Behind the door
Watching TV
MENU/PRESET
CH
CH
CH
VIDEO (MONO) L-AUDIO-R
S-VIDEO AV-3 IN
TV Set (Top)
29H-FX3M(01-10)EN 10/4/04, 9:23 PM9

E 10
Clock/Timer/Channel display
Displays the clock, the timer, the current channel number and
other settings on the screen.
2Press again.
•The channel number appear on
the screen.
1Press .
•The clock and the time on the
On timer, Off timer, View timer
and the remaining time of the
Reminder appears on the
screen.
Useful features
Mute
Silences the sound.
1Press .
•“ ”appears on the screen,
and the sound is silenced.
2Press again.
•The volume returns to its
previous level.
3Press once again.
•The display disappears.
•Mute will be cancelled if the is pressed at any time.
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
OFF 2 : 30 A M
VIE W 1:30
ON 12 : 1 5 A
M
CLOCK 9 : 28 A M
1:50
5
29H-FX3M(01-10)EN 10/4/04, 9:23 PM10

E 11
TV/Video selection
Switches between TV broadcasts and AV input programmes.
Each time you press the
TV/VIDEO
,
the input switches between AV1 (or
SAV1), AV2 (or COMPONENT), AV3
(or SAV3) and TV programme.
Channel recall
Switches back to the channel you were watching just before the
current channel.
Press .
•The channel previously viewed returns
to the screen.
Example:
After switching from channel 5 to
channel 7, is pressed, the
channel will change to channel 5. Press
again to return to channel 7.
Each time you press the
SOUND MODE
,
the mode switches between MOVIE,
MUSIC, NEWS and CUSTOM.
MOVIE: Movie mode
MUSIC: Music mode
NEWS: News mode
CUSTOM: Custom mode
Sound mode
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
Number
buttons
TV/VIDEO
SOUND MODE
100 300 1K 3K 8K
+
CUSTO
M
–
M OV I E
M US I C
N E W S
5
7
5
7
or
or
or
1VAS1VA
52
TNENOPMOC2VA
3VAS3VA
•The SOUND MODE display can be adjusted using the EQUALIZER menu. See
24
.
Useful features
29H-FX3M(11-20)EN 10/4/04, 9:23 PM11

E 12
Selecting a menu item
1Press
MENU
/
MENU/PRESET
to call MENU screen.
3Press /
to enter.
•The corresponding menu
screen will appear.
This TV set allows you to adjust the picture and sound, and set the channels and other
features using the On-screen display with the remote control or from the TV set. Select
the desired menu item by following the steps below and then refer to the indicated page
for details.
Remote control
2Press
CH
/
CH
to select desired menu item.
•The selected item is
highlighted with purple bar.
•If you press
MENU/PRESET
on TV set for more than two seconds, the LANGUAGE mode screen will appear
instead of the MENU screen. To display the MENU screen, press
MENU/PRESET
until the normal screen
appears, then press the button again. See
14
.
•The procedures for setting and selecting the menu items on the following pages are described using the
buttons on the remote control. These procedures can also be performed using the corresponding
buttons on the TV set.
Selecting menu items
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
CH
CH
MENU
M ENU
SOUND
FEATURE
TI
M ER
CH - SETT I NG
SELECT : CH ENTER: RETURN :
M ENU
M ENU
SOUND
FEATURE
TI
M ER
CH - SETT I NG
SELECT : CH ENTER: RETURN :
M ENU
OFF
ON
SOUND
SURROUND
BBE
EQUAL I ZER
ANCE 0
ON
ER BASS ON
BAL
AVL
SUP
SELECT : CH ENTER: RETURN :
M ENU
4Press
MENU
/
MENU/PRESET
until normal screen appears.
MENU/PRESET
CH
CH
CH
MENU/PRESET
TV Set (Top)
29H-FX3M(11-20)EN 10/4/04, 9:23 PM12

E 13
Menu item
Selecting menu items
ON
TIMER
STANDBY
POWER
SAVE
POWER
M ENU
SOUND
FEATURE
TI
M ER
CH - SETT I NG
SELECT : CH ENTER: RETURN:
M ENU
Operation guide
CONTRAST 60
COLOUR +6
VIDEO
M ODE DYNA M IC
BR I GHTNESS 0
TINT 0
SHARPNESS +6
PICTURE NR OFF
W HI TE TE M P
SELECT : CH ADJUST : RETURN :
M ENU
PICTURE menu............................
2221
SOUND menu...............................
FEATURE menu............................ TIMER menu.................................
CH-SETTING menu.......................
SOUND
SURROUND OF F
EQUAL I ZER
BBE ON
BALANCE 0
AVL ON
SUPER BASS ON
SELECT : CH ENTER: RETURN:
M ENU
FEATURE
AUTO SELECT OFF
PO
W ER SAV E OFF
OFF
BLUE BACK OFF
16: 9
M ODE
CH I LD LOCK
DE
M OOFF
ESLECT:CH ADJUST: RETURN:
M ENU
TI M ER
DAY SUN
ON ––:–– A
M
CLOCK ––:–– A
M
STATUS ONCE
POS I T I ON ––
VOLU
M E––
OFF –– :–– A
M
––:––
VIE
W
BEEP RE M INDER OFF
SELECT : CH ADJUST : 0
– 9
,
RETURN: M ENU
CH - SETT I NG
POS I T I ON NA
M E
COLOUR- SYST E
M
AUTO
POS I T I ON 12
SOUND- SYST E
M
AUTO
SK I P OFF
AUTO
M ANUAL 168 . 25
M Hz
SORT
LANGUAGE ENGL I SH
SELECT : CH ADJUST : RE TURN :
M ENU
–
3225 –
2017 –
4233 –
24
–
23
•The on-screen displays in this manual may
differ from their actual appearance.
29H-FX3M(11-20)EN 10/4/04, 9:23 PM13

E 14
Settings and adjustments
On-screen display language selection
The on-screen display language can be set to English, Chinese,
French, Malay or Arabic.
3Press
MENU/PRESET
until normal screen appears.
2Press
CH
/
CH
to select desired language.
•Pressing
MENU/PRESET
changes the screen as shown below.
1Press
MENU/PRESET
for more
than two seconds during
normal screen.
•The language select mode
appears.
•In order to enter to language
select mode, press
MENU/PRESET
during normal screen.
TV set
Language AUTO
Normal screen
MANUAL
E
N
G
L
I
S
H
F
R
A
S
SELECT : CH
3Press /
to display CH-SETTING
menu.
4Press
CH
/
CH
to select “LANGUAGE”.
5Press /
to select the desired
language.
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to select “CH-SETTING”.
Using MENU screen
M ENU
SOUND
FEATURE
TI
M ER
CH - SETT I NG
SELECT : CH ENTER: RETURN :
M ENU
P
AUTO
P12
AUTO
OFF
168 . 25
M Hz
CH - SETT I NG
OS I T I ON NA
M E
COLOUR- SYSTE
M
OS I T I ON
SOUND- SYST E
M
SK I P
AUTO
M ANUAL
SORT
LANGUAGE ENGL ISH
SELECT : CH ADJUST : RETURN :
M ENU
ENGLISH FRANCAIS
MELAYU
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
CH
CH
MENU
6Press
MENU
until normal screen appears.
MENU/PRESET
CH
CH
CH
MENU/PRESET
TV Set (Top)
29H-FX3M(11-20)EN 10/4/04, 9:23 PM14

E 15
1Press
MENU/PRESET
for more
than two seconds during
normal screen.
•The language select mode
appears.
•In order to enter to language
select mode, press
MENU/PRESET
during normal screen.
•AUTO PRESET stores all receivable channels including those which may be very weak and not clearly
visible. To preset only those channels designated for the local viewing region, use MANUAL PRESET.
See
16
.
•Unused channels are automatically skipped.
2Press
MENU/PRESET
again to
display AUTO mode screen.
•Pressing
MENU/PRESET
changes the
screen as shown below.
3Press /
on TV set.
•All the TV stations in your area
that can be received by the TV
set are automatically preset
between channels 1 to 99.
•The screen shows whatever is
on channel 1 when auto
channel preset is finished.
Language AUTO
Normal screen
MANUAL
Auto channel tuning
Automatically tunes in and presets receivable TV stations.
E
N
G
L
I
S
H
F
R
A
S
SELECT : CH
AUTO 1
48.25
M Hz
1
Settings and adjustments
MENU/PRESET
CH
MENU/PRESET
TV Set (Top)
29H-FX3M(11-20)EN 10/4/04, 9:23 PM15

E 16
1Press
MENU/PRESET
for more
than two seconds during
normal screen.
•The language select mode
appears.
•In order to enter to language
select mode, press
MENU/PRESET
during normal screen.
2Press
MENU/PRESET
twice to
display MANUAL mode
screen.
•Pressing
MENU/PRESET
changes the
screen as shown below.
3Press
CH
/
CH
or number buttons to select
channel position.
4Press /
on TV set to locate channel
you wish to preset to current
channel position.
•Search is initiated and when a
TV signal is received during the
search, the search stops.
5Repeat steps 3 and 4 above, to preset channel positions for
other broadcasts.
6Press
MENU/PRESET
again to display normal screen.
Channel position
Manual channel tuning
Enables manual channel tuning to a desired TV station.
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
MENU
LIST
BACD
MPX
123
456
78
0
9
Number
buttons
CH
CH
E
N
G
L
I
S
H
F
R
A
S
SELECT : CH
M ANUAL 1
48.25
M Hz
M ANUAL 5
107.50
M H z
Language AUTO
Normal screen
MANUAL
MENU/PRESET
CH
CH
CH
MENU/PRESET
TV Set (Top)
29H-FX3M(11-20)EN 10/4/04, 9:23 PM16

E 17
POSITION
•The channel position changes to the higher or lower number.
POSITION NAME
•To enter the name of the channel. Maximum 7 alphanumeric can be
input.
e.g. CINEMAX
•Press
CH
/
CH
: To select a desired alphanumeric.
•Press / : To select the previous/next alphanumeric.
•To exit press / until input cursor disappear.
•If the wrong alphanumeric is entered, select “”(space character) to
clear.
COLOUR-SYSTEM
1Press
MENU
to call MENU
screen.
2Press
CH
/
CH
to select “CH-SETTING”.
3Press /
to display CH-SETTING
menu.
4Press
CH
/
CH
to select desired setting.
5Each time you press
/ , setting
for individual items changes
as follows:
Channel setting
Enables individual channel setting.
AUTO PAL
N443N358
SECAM
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
CH
CH
MENU
CINE M AX
AUTO
12
AUTO
OFF
168 . 25
M Hz
CH - SETT I NG
POS I T I ON NA
M E
COLOUR- SYSTE
M
POS I T I ON
SOUND- SYST E
M
SK I P
AUTO
M ANUAL
SORT
LANGUAGE ENGL ISH
SELECT : CH ADJUST : RETURN :
M ENU
M ENU
SOUND
FEATURE
TI
M ER
CH - SETT I NG
SELECT : CH ENTER: RETURN :
M ENU
•Switching COLOUR-SYSTEM:
Set the system to “AUTO”for normal TV reception. The AUTO mode automatically detects the receiving
signal system and changes the reception system of the TV set. When the picture is not stable, switching
to an appropriate system may improve the picture quality.
(continue)
Settings and adjustments
... ...AZ0 9+–/
)•( “”(space character)
29H-FX3M(11-20)EN 10/4/04, 9:23 PM17

E 18
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
SOUND-SYSTEM
SKIP
When set “SKIP” to “ON”, the channel number are set to SKIP. To turn off
SKIP, press the number buttons to select the desired channel and then
set “SKIP” to “OFF”.
AUTO
• Press / and
Auto Channel Tuning is started.
Auto tuning bar will shown
during Auto Search only.
(Please see page
15
for
details on Auto Channel
Tuning.)
MANUAL (FINE tuning)
(i) Each time
/
is pressed, the frequency changes to
allow fine tuning and the colour of channel number changes to yellow
to indicate fine tuning.
(ii) Press / for more than 2 seconds, the “Manual
Channel Tuning” will start. If a signal is found, the Manual Channel
Tuning will stop searching.
ON OFF
•In a weak reception area, or under bad reception conditions, you can change the frequency for fine
tuning.
•When using FINE tuning, the channel number changes from green to yellow.
•To return the channel to its original frequency setting, follow the manual channel tuning procedure.
See
16
.
CINE M AX
AUTO
12
AUTO
OFF
168 . 25
M Hz
CH - SETT I NG
POS I T I ON NA
M E
COLOUR- SYST E
M
POS I T I ON
SOUND- SYST E
M
SK I P
AUTO
M ANUAL
SORT
LANGUAGE ENGL ISH
SELECT : CH ADJUST : RETURN :
M ENU
(continue)
Channel setting (continued)
AUTO
D/K IM
B/G
29H-FX3M(11-20)EN 10/20/04, 3:10 PM18

E 19
POWER
SAVE
TV/VIDEO
SURROUND
SOUND MODE
CH
CH
NORMAL
TV/TEXT
123
456
78
0
9
MENU
LIST
BACD
MPX
CH
CH
1
SORT
•To sort the program numbers according to your preference.
Moving a program
TV2 (at program number 2) to program number 5
1. When you press /
in step 5 on page
17
, SORT menu will be
displayed.
2. Press
CH
/
CH
or
/ to select
program number 2 (e.g. TV2)
to be moved.
3. Press
1
, and program
number 2 (e.g. TV2) will be
set as program to be moved.
SORT
2TV2 11 20
3HALL
M RK 12 21
1STAR
W LD 10 19
4HBO 13 22
5 D I SCOVR 14 23
6LEARN 15 24
716 25
817 26
918 27
SELECT : CH
M OVE:1 DELETE: 2
SORT
2TV2 11 20
3HALL
M RK 12 21
1STAR
W LD 10 19
4HBO 13 22
5 D I SCOVR 1 4 23
6LEARN 15 24
716 25
817 26
918 27
SELECT : CH
M OVE:1 DELETE: 2
SORT
2TV2 11 20
3HALL
M RK 12 21
1STAR
W LD 10 19
4HBO 13 22
5 D I SCOVR 1 4 23
6LEARN 15 24
716 25
817 26
918 27
SELECT : CH
M OVE : 1 2 TO. . .
4. Press
CH
/
CH
or
/ to select
program number 5 (e.g.
DISCOVR).
SORT
2TV2 11 20
3HALL
M RK 12 21
1STAR
W LD 10 19
4HBO 13 22
5 D I SCOVR 14 23
6LEARN 15 24
716 25
817 26
918 27
SELECT : CH
M OVE : 1 2 TO. . .
5. Press
1
again, TV2
will be moved to program
number 5. The programs in
program number 3 to 5 will be
shifted up 1 position.
•TV will tune to program
number 5 having TV2
program.
SORT
2HALL
M RK 11 20
3HBO 12 21
1STAR
W LD 10 19
4DISCOVR 13 22
5TV2 14 23
6LEARN 15 24
716 25
817 26
918 27
SELECT : CH
M OVE:1 DELETE: 2
(continue)
Channel setting (continued)
Settings and adjustments
29H-FX3M(11-20)EN 10/4/04, 9:23 PM19
