DC2C1BZ001
User’s Manual

DC2C1BZ001 User’s Manual DOC NO.EU-01Z05A
2
<< DESCRIPTION >>
This user’s manual covers the Sharp BluetoothTM CF Card model DC2C1BZ001 intended for design
application use with PDAs, Notebook PCs, mobile phones, digital cameras or PC peripherals.
(Source: Bluetooth V.1.1 Radio specification Part A)
Ref no. of QPN : 010-7LI_1 *QPN : Qualification Product Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
<< REMARK >>
(1) This CF card is not designed for use in Life Support Application products where malfunction of those
products can be reasonably expected to result in personal injury. SHARP customers using or selling these
products for use in such applications do so at their risk and agree to fully indemnify SHARP for any
damages resulting from such improper use or sale.
(2) Country of origin: Japan or China.
<< NOTICE >>
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
This transmitter complies with FCC radiation exposure limits set forth for an uncontrolled environment.
To comply with the FCC RF exposure compliance requirements, no change to the antenna or the device is
permitted. Any change to the antenna or the device could result in the device exceeding the RF exposure
requirements and void user. In addition, this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.
<< FCC WARNING >>
Changes or modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.

DC2C1BZ001 User’s Manual DOC NO.EU-01Z05A
3
1. INSTALL
a) Insert CF card to CF card slot or PC card slot with CF card Adapter card.
b) PC detect CF card and pop up the window. Push Next button.
c) Select “Display a list of all …..” and push Next button.

DC2C1BZ001 User’s Manual DOC NO.EU-01Z05A
4
d) Select “Ports[COM & LPT]” and push Next button.
e) Select “Communication Point” and push Next button.
f) Pop up the warning window, push Yes button.

DC2C1BZ001 User’s Manual DOC NO.EU-01Z05A
5
g) Push Next button.
h) Push Finish button.

DC2C1BZ001 User’s Manual DOC NO.EU-01Z05A
6
2. HOW TO USE BLUETOOTH
This Bluetooth Card has under HCI protocol.
You can use the HCI command through the COM port
There is Bluetooth specification on http://www.bluetooth.com/
3. GENERAL SPECIFICATIONS
1-1 Bluetooth Specification Power Class 3
1-2 Frequency range 2402 MHz to 2480 MHz
1-3 Channel system TDMA
1-4 Duplex system Half duplex/TDD
1-5 Total number of channels 79 ch
1-6 Nominal antenna impedance 50 ohm
1-7 Intermediate frequency Zero IF
1-8 Modulation system GFSK/ BbT= 0.5
(Air Interface) Data rate: 1Mbps
Process gain Frequency hopping 1600hops/sec
1-9 Operating voltage Vcc: 3.3 V+/-5%
1-10 Absolute maximum supply voltage Vcc: 4.0 V
(Ta=25deg.)
1-11 Weight 13 g/ typ.

DC2C1BZ001 User’s Manual DOC NO.EU-01Z05A
7
4. DIMENSION AND MOUNTING DETAILS
DRAFT
