Sharpe SHARPE 309987B User manual

998 NON-HVLP
SPRAY GUN
FOR PART DESCRIPTION AND MODELS AVAILABLE SEE OTHER SIDE
© 1999 SHARPE MFG. CO.
1-998-02 1-SGF98-01
(38001)
1-998-04
(SEE NOZZLE CHART) 1-998-29
(27310) 1-20-28
(10326) 1-71-27
(16153)
1-971-21
(26032)
1-71-25
(16151)
1-PLT-11A
(34940)
1-71-42
(16167)
1-971-34
(U26044) 1-PLT-35
(34962)
1-71-50
(16175)
1-971-56
(U26066)
1-SGF98-55X
(38155)
1-SGF98-24
(38124) 1-975-54
(27060)
1-971-45
(26055)
1-998-26
(27305)
1-71-38
(16163)
1-71-38
(16163)
1-PLT-32
(34959)
1-971-06
(U26016)
1-971-21
(26032)
1-71-37
(16162)
1-SGF-46
(37046)
1-SGF98-08
(38108) 1-SGF98-03
(SEE NOZZLE CHART)
1-SGF98-13
(38120)
1-775-41X
(25066)
1-975-65
(27075)
1-975-66
(27076)
1-975-48
(27058)
1-971-44
(26054)
1-PLT-33
(34960)
1-PLT-33
(34960)
1-PLT-11B
(34941)
®
THE SPRAY GUN PEOPLE

PART NO. COMP. NO. DESCRIPTION PART NO. COMP. NO. DESCRIPTION
1-20-28 10326 HEAD ATTACHMENT GASKET
1-PLT-35 34962 TRIGGER SCREW
1-SGF98-01 38001 TIP GASKET
1-71-27 16153 HEAD ATTACHING SCREW
1-71-37 16162 AIR VALVE PACKING
1-71-38 16163 GASKET
1-71-38 16163 GASKET
1-71-42 16167 AIR VALVE SPRING
1-71-50 16175 "E" CLIP
1-SGF98-24 38124 NEEDLE SPRING
1-775-41X 25066 AIR VALVE
1-PLT-11A 34940 PACKING
1-PLT-11B 34941 PACKING SEAL
1-PLT-33 34960 SPRING WASHER
1-PLT-33 34960 SPRING WASHER
1-971-21 26032 PACKING NUT
1-971-21 26032 PACKING NUT
1-PLT-3234959TRIGGER
1-971-34U26044 TRIGGER SHAFT
1-971-44 26054 PLUG
MODELS
AVAILABLE
PCOMBINATION CHART FOR MODEL 998 NON-HVLP SIPHON SPRAY GUN
998-A-55
COMP. # 5622
998-C-55
COMP. # 5622
998-9P-45
COMP. # 5622
998-10-70
COMP. # 5622
1-998-02#A
COMP. # 27275
1-998-02#A
COMP. # 27280
1-998-02#A
COMP. # 27285
1-998-02#A
COMP. # 27270
(.055)
1-998-04-55NI
COMP.# 27255
(.055)
1-998-04-55NI
COMP.# 27255
(.045)
1-998-04-45NI
COMP.# 27245
(.070)
1-998-04NI
COMP.# 27260
(.045)
1-SGF98-03-45N
COMP.# 27240
(.045)
1-SGF98-03-45N
COMP.# 27240
(.045)
1-998-03-45N
COMP.# 27240
(.045)
1-SGF98-03-70N
COMP.# 27242
Recommended for
Low V,O,C, - All Purpose
Recommended for
Low V.O.C. - Clears
Recommended for
Pressure Feed
Production
Recommended for
Medium Solids Color
and Clears
AIR CAP FLUIDTIP FLUID NEEDLE
©1999 SHARPE MFG.CO.,
1-971-45 26055 AIR INLET NIPPLE
1-998HVLP-02 * AIR CAP (See Nozzle Chart)
1-SGF98-03 * ORDER SGF98-05 MATCHED SET
(See Nozzle Chart)
1-971-06U26016 AIR VALVE ASSEMBLY
1-SGF98-08 38108 WIDTH CONTROL ASSEMBLY
1-SGF98-13 38120 WIDTH CONTROL O-RING
1-71-25 16151 AIR VALVE CAGE
1-998-26H 27306 HVLP GUN HANDLE
1-998-29 27310 HVLP GUN HEAD
1-SGF-46 37046 MATERIAL CONTROL BUSHING
1-975-48 27058 FLUID INLET GASKET
1-975-54 27060 MATERIAL CONTROL KNOB
1-SGF98-55X 38155 WIDTH CONTROL KNOB & VALVE
1-971-56U26066 WIDTH CONTROL BODY
1-975-65 27075 FLUID INLET NIPPLE
1-975-66 27076 FLUID INLET LOCK NUT
1-SGF98-05 * FLUID TIP & FLUID NEEDLE
MATCHED SET(See Nozzle Chart)
RECOMMENDED
USAGE
998-PL
