shelta AG25 Quick setup guide

AG25 CANTILEVER UMBRELLA
ASSEMBLY AND USE INSTRUCTIONS
Phone: [phone] Unit 4 / 1 Foundation Place
Fax: [phone] Prospect NSW 2148

Components
After taking the umbrella out of the carton, please make sure that you inspect the
included components.
COMPONENT REF QTY
AG25 Frame A1
Vent top Plastic Cap B1
Fabric Canopy (in bag) C1
Ballast Block Frames D2
Crank E1
Rotate Bearing F1
20mm Bolt / Washer
(+ Allen Key)
F1 4
25mm Bolt / Washer
(+ Allen Key)
F2 2
# 3/ # 5/ # 6 Allen Keys G3
Protective Cover and
Metal Wand (in bag)
H1

AG25 Mounting Options
Mounting Option 1: Onground Plate
Suitable for a concrete slab (minimum 10cm thick) or a concrete column (30cm diameter by 75cm deep). With this
option the umbrella can be rotated. Purchase 4 Stainless Steel masonry anchors such as 10mm x 75mm Dynabolts
from your local hardware.
1. Place the Onground Plate in the required location. Use metal spacers if the
surface is not flat and horizontal. Mark the position of the 4 corner holes with
a felt pen. Use a 10mm masonry bit to drill holes to a depth of 80mm. Fasten
the Plate to the slab using the 4 masonry anchors.
2. If necessary, remove the Rotate Bearing (F) from the bottom of the Side-post
and attach to the Onground plate using the four M8 x 20mm bolts and washers
provided
The Umbrella may also be bolted to a wooden deck using the same hardware however it is strongly
recommended a builder reinforce the deck with extra joists under the boards and the pass-through stainless
steel bolts or 100mm M12 galvanized or stainless steel coach bolts go through the joists.
Mounting Option 2: Shelta Resin Base (not included).
Suitable for most surfaces including timber decks. Purchase a Shelta Large Resin base from your local retailer
(wheeled and non-wheeled versions available). Note: the Ballast Block Frame
and the Onground Plate are not required for this option.
100 Kilos of 5mm blue metal and 10 Kilos of sand will be required to fill the
Resin base for ballast
1. Remove the square plate from the bottom of the Rotate Bearing (F) by
unscrewing the 4 countersunk screws.
2. If necessary, remove the Rotate Bearing from the bottom of the Side-post
and attach to the Resin Base “Top Hat” using the 4 countersunk screws.
3. Follow the assembly instructions included with the Large Resin Base.
Mounting Option 3: Ballast Block Frame (C included).
Suitable for most surfaces including grass. This should be ballasted with between 110 and 140 kilograms of
weight. Purchase at least 6 Shelta Resinstone Ballast Weights or concrete pavers (45 x 45 x 4cm) from your
outdoor retailer or hardware.
1. Assemble the 2 parts of the Ballast Block Frame (C) at right angles.
2. If necessary, remove the Rotate Bearing (F) from the bottom of the Side
-post and attach to the Ballast Block Frame using four M8x20mm
screws and washers provided.
3. Place the assembled frame in the required location. Note: for safe use
the surface should be flat and horizontal.
4. Place at least 6 Resinstone or paving blocks on the assembled frame
with double-stacked blocks on the side opposite the umbrella.

Operating Instructions
1. Loosen ribs prior to winding.
2. Release the slide tilt and lift to the top position.
3. Opening. Turn the crank clockwise, the umbrella will open. Turn the crank anticlock-
wise, the umbrella will close. When cranking, if you feel pressure and the umbrella is
not opening, spread the umbrella ribs using your hands, then continue to crank open.
4. Tilting. When you want to change the angle of your umbrella (Tilt), slide the runner up
or down the mast until you reach the angle that you desire. Rotate tilt lock knob clock-
wise to lock.
5. Closing. When closing umbrella slide the knob down towards bottom of mast, at same
time turn handle anti-clockwise to close the umbrella. Use fabric tie to secure umbrella
frame to mast.
6. Rotating. The umbrella will rotate 360 degrees by simply stepping on the base pedal;
rotate the main frame by hand. When the umbrella reaches the position desired, re-
lease the foot pedal and the umbrella will lock into place.
7. LED Light Attachment. Attaching optional Shelta LED ‘Flying Saucer’ light (available
at your Shelta retailer) is easy. Rotate the light attach bracket on underside of umbrella
hub in either direction to cause it to drop down. The opened LED light is attached to
this, then clicked closed. Battery life is at least 60 hours.
