shelta AG5A User manual

Canopy Change
AG5a, AG5c,AG25, AG25R, AG35, AG45, AD45, AG55, AG65

Step 1
Remove all the screws from the Rib ends (7)

Step 2
Raise the umbrella slightly so you can remove the support bar canopy
screw –depending on the model, this step may require a stumpy Phillips head.
Rip the Velcro apart all the way to the protector pad

Step 3
Remove the finial by unscrewing it in a counter clockwise direction.
You can use a step ladder for this step

Step 4
Lift the canopy up and over the structure.
You can use a step ladder for this step

Step 5
Place the new canopy over the structure and align the hole
and the support arm Velcro under the protective pad

Step 6
Replace the finial by screwing it in a clockwise direction.
You can use a step ladder for this step

Step 7
Replace the screw into the support arm
Join the Velcro all the way to under the protector pad

Step 8
Replace all the screws in the Rib ends (7)
Then wind up the canopy slowly to allow proper unfolding
