Shimadzu Nexera CL Series Parts list manual

228-97194B
Sep. 2022
Shimadzu Liquid Chromatograph
Nexera CL series
System Guide
Read this manual thoroughly before you use the product.
Keep this manual for future reference.

This page is intentionally left blank.

Read this manual thoroughly before using the product.
Thank you for purchasing this product.
This manual describes overall system user instructions, hardware validation, installation
guidelines, and so on. For information about how to use individual components or
information about accessories or optional products, refer to the instruction manual for
the respective components.
For information about the product warranty, after-sales service, and various precautions
for ensuring the product is used safely, refer to the separate Safety Guideline booklet
or PDF.
Read this manual thoroughly before using the product and operate the product in
accordance with the instructions in this manual.
Keep this manual for future reference.
IMPORTANT
• If the user or usage location changes, ensure that this manual is always kept
together with the product.
•If this manual, other instruction manual, or a product warning label of a
component is lost or damaged, immediately contact your Shimadzu representative
to request a replacement.
•The Safety Guideline specify important precautions for ensuring the system is
operated safely. Be sure to read the Safety Guideline before using the product.
• To ensure safe operation, contact your Shimadzu representative if product
installation, adjustment, re-installation (after the product is moved), or repair is
required.
© 2020-2022 Shimadzu Corporation. All rights reserved.
Original version is approved in English.
Introduction
Nexera CL series i

Notice
• Information in this manual is subject to change without notice and does not represent
a commitment on the part of the vendor.
• Any errors or omissions which may have occurred in this manual despite the utmost
care taken in its production will be corrected as soon as possible, although not
necessarily immediately after detection.
• All rights are reserved, including those to reproduce this manual or parts thereof in
any form without permission from Shimadzu Corporation.
•Illustrations in this manual may differ from the actual product used.
• Windows and Internet Explorer are registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Screenshots of Microsoft products are used in accordance with guidelines from Microsoft
Corporation.
Third-party trademarks and trade names may be used in this publication to refer to
either the entities or their products/services, whether or not they are used with
trademark symbol "TM"or "®".
•Screenshots of Microsoft products are used in accordance with guidelines from Microsoft
Corporation.
Instruction Manual Components
The instruction manuals for the product comprise the
following documents.
Please use them according to the given operating objectives or other criteria.
nSafety Guideline
This provides information about the product warranty, obtaining after-sales service, and
various precautions for ensuring the product is used safely. Be sure to read it before
using the product.
nSystem Guide
This manual is the System Guide. It describes overall instructions for using the system,
hardware validation, installation guidelines, and so on.
nMaintenance Guide
It describes the maintenance for each component.
ii Nexera CL series
Introduction

nInstruction Manuals Included with Respective Components
These describe the accessories and options for each component, the name and function
of various parts of the component, how to prepare, operate, and maintain the
component, and so on.
Nexera CL series iii
Instruction Manual Components

Indications Used in This Manual
Precaution symbols are indicated using the following conventions:
Indication Meaning
Indicates a potentially hazardous situation which, if not
avoided, could result in serious injury or possibly death.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor to moderate injury or equipment
damage.
Emphasizes additional information that is provided to ensure
the proper use of this product.
The following symbols are used in this manual:
Indication Meaning
Indicates an action that must not be performed.
Indicates an action that must be performed.
Indicates information provided to improve product performance.
Indicates the location of related reference information.
iv Nexera CL series
Introduction

Operating Nexera CL System
nIntended Use
This system is designed to perform qualitative and quantitative analysis of target
compounds in a sample matrix and can be used as a liquid chromatograph for general
in vitro diagnostic applications. This instrument operates with reduced technician
involvement and automation of some, but not all, procedural steps. However, only
personnel who have received appropriate training on use of the system can use it for
these purposes.
nCalibration
A calibration curve should be generated for each analyte in appropriate methods. At
least four out of six non-zero standards should meet the appropriate criteria, including
the calibration standard lower than the assumed LOQ and the calibration standard at
the highest concentration.
nQuality Control
Implement quality control of the instrument by routinely measuring at least one each of
four types of quality-control samples (a sample with a normal concentration level, a
sample with a concentration level higher than normal as well as a sample lower than
normal, and a blank sample). Check the selectivity/specificity in the matrix used for the
actual sample, the accuracy, correctness, recovery rate, dynamic range, linearity, and lower
limit of quantitation.
Based on these assessment results, check that the results are within the permissible range.
If the assessment results are out of range, the measured data may be invalid, so do not
use analysis results obtained from the instrument in question until it can be confirmed
that it is functioning normally. When, for example, analyzing samples that contain
complex sample matrices such as serum, plasma or urine, it may be possible to obtain
stabilized data by using an appropriate pre-treatment or an internal standard.
Nexera CL series v
Operating Nexera CL System

Contents
Introduction Instruction Manual Components .......................... ii
Indications Used in This Manual ......................... iv
Operating Nexera CL System ............................... v
1Overview 1.1 System Features .................................................. 1
1.1.1 LC-40D XR CL, LC-40D X3 CL, or LC-40B X3 CL
Solvent Delivery Unit ............................................ 1
1.1.2 SIL-40C XR CL or SIL-40C X3 CL Autosampler ............... 2
1.1.3 CTO-40C CL Column Oven .................................... 3
1.1.4 SPD-40 CL UV-VIS Detector .................................... 3
1.2 Optional Parts ................................................... 3
1.3 Configuration List ................................................ 6
2Analysis 2.1 Switching ON the Power Supply and Opening
the [Realtime Analysis] Window ......................... 10
2.1.1 Switching ON the Instruments Power Supply ................ 10
2.1.2 Logging in to LabSolutions and Opening the [Realtime
Analysis] Window ............................................. 12
2.2 Specifying Analytical Conditions .......................... 15
2.2.1 Editing Methods ............................................... 15
2.3 Placing Mobile Phases and Autosampler Rinse
Solutions ........................................................... 22
2.3.1 Placing Mobile Phase and Rinse Solution Bottles on the
Reservoir Tray ................................................. 22
2.3.2 Performing Auto-Purging ...................................... 24
2.3.3 Manual Purging the Solvent Delivery Pump .................. 26
2.4 Attaching the Column ....................................... 29
2.4.1 Attaching Columns in the Column Oven .................... 29
2.4.2 Warming Up the System ..................................... 32
2.5 Placing Samples ................................................. 34
2.5.1 Preparing Sample Vials (or Sample Plates) ................... 34
2.5.2 Placing Samples in the Autosampler ......................... 36
2.6 Performing a Single Run Analysis ....................... 40
2.6.1 Check List to Confirm before Starting Analysis (while
Waiting for Stabilization) ...................................... 40
vi Nexera CL series

2.6.2 Performing a Single Run Analysis ............................ 41
2.6.3 Performing Postrun Analysis .................................. 43
2.6.4 Displaying and Printing Data Reports ........................ 47
2.7 Performing Realtime Batch (Sequence) Analysis
......................................................................... 48
2.7.1 Performing Realtime Batch (Sequence) Analysis .............. 48
2.7.2 Analyzing Multiple Sets of Data Using Data Browser ....... 51
2.7.3 Outputting Summary Reports ................................. 53
2.8 Stopping Analysis and Shutting OFF the Power
Supply .............................................................. 55
2.8.1 Check List to Confirm after Analysis is Finished
(Precautions for Extended Disuse) ............................ 55
2.8.2 Purging Columns with a Column Storage Solution .......... 55
2.8.3 Shutting Down the Instruments .............................. 56
2.8.4 Setting Up Startup for Next Use ............................. 58
2.9 Key Points for Analysis ...................................... 58
2.9.1 Before Analysis ................................................ 58
2.9.2 Precautions for Selecting and Handling Mobile Phase
Solvents ........................................................ 64
2.9.3 Precautions When Replacing the Mobile Phase .............. 64
2.9.4 Precautions for Selecting an Autosampler Rinse Solution
................................................................. 65
2.9.5 Using Buffer Solutions as a Mobile Phase ................... 68
3Application
Operations
3.1 Startup and Shutdown Functions ........................ 70
3.2 Startup Function ................................................ 70
3.2.1 Executing the Startup Process ................................ 70
3.2.2 Executing a Startup Process and Starting a Batch
Analysis at a Specified Date/Time ............................ 72
3.3 Shutdown Function ............................................ 75
3.3.1 Executing the Shutdown Function ............................ 75
3.3.2 Executing a Batch File with a Shutdown Function
Specified in the File ........................................... 77
3.4 Auto-Diagnostics (Pulsation Check) and
Auto-Recovery ................................................... 81
3.4.1 Auto-Diagnostics (Pulsation Check) ........................... 81
3.4.2 Auto-Recovery ................................................. 81
Nexera CL series vii
Contents

3.5 Autosampler Functions ....................................... 85
3.5.1 Pretreatment Functions ........................................ 85
3.5.2 Cut off Loop Function ........................................ 88
3.5.3 Low Dispersion Injection ...................................... 89
3.6 Batch Action Functions ...................................... 89
3.7 Using ACTO (Analytical Condition Transfer and
Optimization) Functions ..................................... 93
3.7.1 Concentration Gradient Start Adjustment Function .......... 93
3.7.2 Method Migration Functions .................................. 95
3.8 Useful Data Analysis Functions ........................... 98
3.8.1 i-PeakFinder .................................................... 98
3.9 Column Management ....................................... 100
3.9.1 Column Management Workflow ............................ 101
3.9.2 Setup for LabSolutions ...................................... 102
3.9.3 Column Registration and Replacement (Discard) ........... 106
3.9.4 Analysis with LabSolutions .................................. 115
3.9.5 Viewing the Acquisition Log ................................ 118
4Hardware Validation 4.1 Hardware Validation Overview ......................... 122
4.1.1 Hardware Validation Classifications ......................... 122
4.2 Timing for Hardware Validation ....................... 122
4.2.1 Periodic Inspections .......................................... 122
4.2.2 Routine Inspections .......................................... 123
4.2.3 Inspections during Maintenance ............................ 123
4.3 Precautions for Periodic Inspections ................... 123
4.4 Parts Required for Periodic Inspections .............. 123
4.5 Periodic Inspection of Solvent Delivery Pumps ... 127
4.5.1 Inspection Item .............................................. 127
4.5.2 Testing Flowrate Accuracy .................................. 127
4.6 Periodic Inspection of Autosamplers .................. 130
4.6.1 Inspection Item .............................................. 130
4.6.2 Injection Volume Accuracy Test (Total Injection Method
Only) ......................................................... 130
4.6.3 Temperature Accuracy Test ................................. 131
4.7 Periodic Inspection of Plate Changers ................ 134
viii Nexera CL series
Contents

4.7.1 Inspection Item .............................................. 134
4.7.2 Checking Temperature Accuracy ............................ 134
4.8 Periodic Inspection of Column Ovens ................ 137
4.8.1 Inspection Item .............................................. 137
4.8.2 Testing the Temperature Adjustment Function ............. 137
4.9 Periodic Inspection of UV Absorbance
Detectors ........................................................ 140
4.9.1 Inspection Item .............................................. 140
4.9.2 Wavelength Accuracy Test .................................. 140
4.10 Periodic Inspections of Systems ......................... 146
4.10.1 Inspection Item .............................................. 147
4.10.2 Absorbance Linearity Test ................................... 147
4.10.3 Noise/Drift Test .............................................. 149
4.10.4 Gradient Concentration Test (Gradient System) ............ 152
4.10.5 Reproducibility Test .......................................... 156
4.10.6 Injection Linearity Test ...................................... 159
4.10.7 Carryover Test ............................................... 159
4.11 Corrective Measures if Control Criteria are Not
Satisfied .......................................................... 161
5Troubleshooting 5.1 Errors and Operating Problems ......................... 162
5.2 Resolving Common Troubleshooting Issues ......... 163
5.2.1 Communication fails ......................................... 163
5.2.2 Solvent Flow Does Not Stabilize ............................ 164
5.2.3 Solvent Delivery Pressure Increases ......................... 165
5.2.4 Baseline Does Not Stabilize ................................. 168
5.2.5 Noise Appears in Baseline .................................. 169
5.2.6 Poor Area Value Reproducibility ............................ 171
5.2.7 Carryover Does Not Disappear .............................. 174
5.3 Troubleshooting ............................................... 175
5.3.1 Symptoms Presumably Due to an Error, Based on the
Hardware Status ............................................. 175
5.3.2 Symptoms Presumably Due to an Error, Based on a
Chromatogram ............................................... 184
5.4 List of Error Messages ...................................... 194
Nexera CL series ix
Contents

5.4.1 System Controller ............................................ 194
5.4.2 Pump ........................................................ 199
5.4.3 Autosampler ................................................. 203
5.4.4 Column oven ................................................ 232
5.4.5 UV Detector ................................................. 239
6Selecting
Components
6.1 Selecting a System ........................................... 245
6.1.1 System Installation Arrangement ............................ 246
6.1.2 System Tubing ............................................... 248
6.2 Ultra High-Speed Analysis ................................. 250
6.3 Selecting a Mixer ............................................. 251
6.4 Selecting the Cell ............................................ 252
7Installation 7.1 Installing the System ........................................ 253
7.1.1 Removing Items Used to Secure the System during
Shipping ..................................................... 253
7.1.2 Installing the Autosampler .................................. 254
7.1.3 Installing the Solvent Delivery Pump (LC-40D XR CL,
LC-40D X3 CL, or LC-40B X3 CL) ......................... 257
7.1.4 Installing the Detectors (SPD-40 CL) ........................ 258
7.1.5 Installing the Degassing Unit (DGU-405 CL) ............... 259
7.1.6 Installing the Reservoir Tray ................................. 260
7.1.7 Installing the Column Oven (CTO-40C CL) ................. 261
7.1.8 Installing Other Instruments ................................. 262
7.2 Cable Connections ........................................... 263
7.2.1 Connecting the Power Cord ................................ 263
7.2.2 Connecting Optical Cables .................................. 263
7.2.3 Connecting a Degassing Unit (DGU-405 CL) to the
Solvent Delivery Pump ...................................... 267
7.3 Tubing Connections ......................................... 270
7.3.1 Installing Tubes and Joints for Draining Leakage .......... 272
7.3.2 Connecting Low-Pressure Flow Channel Tubing ............ 281
7.3.3 Connecting Tubing for High-Pressure Flow Channels
(Connection Methods) ....................................... 294
xNexera CL series
Contents

7.3.4 Connecting Tubing for High-Pressure Flow Channels
(Gradient Systems) ........................................... 300
7.3.5 Connecting Tubing for High-Pressure Flow Channels
(Isocratic Systems) ........................................... 304
7.4 Checking Computer and System Controller
Connections ..................................................... 305
7.4.1 Setting the Computer IP Address .......................... 306
7.4.2 Specifying Computer Browser Settings ..................... 308
7.4.3 Specifying System Controller Settings ..................... 310
7.5 Other Installation Processes .............................. 312
7.5.1 Connecting to LabSolutions ................................. 312
7.5.2 Connecting the Computer to the System Controller ...... 312
7.5.3 Installing Optional Column Management Functionality
(Column Management Device or “CMD”) ................. 313
8Addendum 8.1 Mobile Phase Properties ................................... 316
Index ......................................................... 323
Nexera CL series xi
Contents

This page is intentionally left blank.

Shimadzu Nexera CL series liquid chromatographs are designed to offer even higher levels
of performance for meeting the increasingly diverse needs of liquid chromatograph users.
1.1 System Features
n A New Benchmark of Intelligence
Mobile phase monitor
Startup (FlowPilot) and shutdown at specified times
Self-diagnostics (Pulsation Check) and auto-recovery
nA New Benchmark of Efficiency
Ultra high-speed injection
Automatic pretreatment functions (The pretreatment program is automatically created by
fill in the template.)
Continuous analysis of up to 16 MTPs in half the space of previous models (on systems
with a plate changer)
nA New Benchmark of Design
30 % smaller installation space (than previous models)
Stable baseline improves quantitative accuracy for low-concentration components.
1.1.1 LC-40D XR CL, LC-40D X3 CL, or LC-40B X3 CL Solvent Delivery Unit
Micro-plungers with a discharge volume of 10 µL per stroke enable solvent delivery with
minimal pulsation. Newly developed plungers and plunger seals provide a longer service
life for each pressure region than previous models.
Two gradient methods are available, depending on objectives. A high-pressure gradient
can be selected to minimize the gradient delay volume or a low-pressure gradient can
be selected for low-cost delivery of up to four solvents.
Furthermore, an optional solvent selection valve (built into the pump) or reservoir
selection valve can be used to switch between multiple mobile phases for each solvent
delivery unit. Using such a mobile phase selection system allows samples to be
continuously analyzed using different analytical systems or columns to be automatically
rinsed after analysis.
Model
Name
Pressure
Capacity
Single/Dual
Flow Channel
Low-Pressure
Gradient Unit Degassing Unit Automatic Rinsing Kit
LC-40D XR
CL 70 MPa Single Optional Optional Standard
LC-40D X3
CL 130 MPa Single Optional Optional Standard
1Overview
Nexera CL series 1
1

Model
Name
Pressure
Capacity
Single/Dual
Flow Channel
Low-Pressure
Gradient Unit Degassing Unit Automatic Rinsing Kit
LC-40B X3
CL 130 MPa Dual Not supported Standard Standard
1.1.2 SIL-40C XR CL or SIL-40C X3 CL Autosampler
These autosamplers provide the low carryover required for high sensitivity analysis, high
reproducibility for trace quantity injection, and high expandability for satisfying a wide
variety of analytical needs.
Model Name Pressure Capacity Temperature-Co
ntrol Function Rinsing Function Multi-Rinsing
SIL-40C XR CL 80 MPa Yes Standard Optional
SIL-40C X3 CL 130 MPa Yes Standard Standard
The standard injection method involves no sample losses and is a total injection method
with high injection reproducibility.
Equipped with automatic pretreatment functionality for diluting samples online, adding
internal standard samples, or derivatizing samples online, these autosamplers help
increase throughput.
Functionality for rinsing the exterior surface of the needles is also included standard to
ensure low carryover levels. By using the rinsing functionality, the exterior surface of
needles can be rinsed with two types of rinse solutions and, using the multi-rinsing
functionality, the interior surface of needles can be rinsed with three types of rinse
solutions or the injection port can be rinsed.
Sample racks can hold three microplates, deep-well plates, 1.5 mL vial plates, or other
plates, for processing up to 1152 analytes (three MTP384 plates).
Furthermore, up to three optional plate changers can be connected to load up to 44
microplates. In combination with temperature-control functionality, that enables
continuous multianalyte analysis with high reliability.
2Nexera CL series
1 Overview

1.1.3 CTO-40C CL Column Oven
These ovens use an air circulation method that provides high temperature control
accuracy, which improves analysis reproducibility and peak separation capability by
ensuring a constant temperature in columns and flow channels.
The CTO-40C CL can control temperature up to 100 ℃ include a cooling mechanism that
can cool the oven down to 10 ℃ below room temperature. The temperature gradient
within the column can be reduced to improve separation capabilities by adding an active
preheater (optional) that can control the temperature of individual mobile phases flowing
through the column.
1.1.4 SPD-40 CL UV-VIS Detector
The SPD-40 CL includes a D2 (deuterium) lamp and additional functionality that can be
used in a wide variety of situations, such as a simultaneous dual wavelength measurement
function and wavelength scanning function (for measuring absorbance spectra).
By controlling the flow cell temperature, the mobile phase and sample temperature can
be kept constant even if the room temperature varies, which enables stable analysis.
The detectors also include an internal cell ID memory that remembers the type and ID
number of cells and a lamp ID memory that remembers the illumination time and ID
number of lamps. Information about the cell and lamp used for analysis is automatically
recorded in analytical data to improve analysis traceability.
1.2 Optional Parts
Optional Part P/N Features
Wiring Kits
A 228-70247-41 Includes one 600 mm link cable, one 1000
mm link cable, and wiring covers (1 set)
B 228-70247-42 Includes two 600 mm link cables, one 1000
mm link cable, and wiring covers (1 set)
C 228-70247-43
Includes three 600 mm link cables, one
1000 mm link cable, and wiring covers (1
set)
D 228-70247-44 Includes four 600 mm link cables, one 1000
mm link cable, and wiring covers (1 set)
Wiring Cover Set 228-70247-49
Used to collectively secure the link cables
and power cord on the back side of the
instrument.
Link Cables
600 mm 228-77025-06 Link Cable, 600 mm
800 mm 228-77025-08 Link Cable, 800 mm
1000 mm 228-77025-10 Link Cable, 1000 mm
Power Cord 071-60821-08 For use in North America
071-60845-01 For use in Europe
Nexera CL series 3
1.2 Optional Parts
1

Optional Part P/N Features
Power Outlet Unit, 6P
228-65523-42 This power outlet unit is used to
completely shut OFF the main power
supply to all instruments at the same time.
The switch can be installed in front of the
reservoir tray. The outlet has six sockets.
• The switch can only be installed
on Nexera CL series or reservoir
tray. Use the power outlet unit
in combination with a Nexera CL
series reservoir tray.
• -42 for North America
-58 for Europe
228-65523-58
PLATE CHANGER CL 228-65110-55
This plate changer is intended specifically
for SIL-40 CL series autosamplers. It can
automatically transport up to 14
microplates or up to 7 deep-well plates or
dedicated sample vial plates (optional) into
an autosampler. Furthermore, up to three
plate changers can be connected to load
up to 44 microplates. Additional optional
accessories are required for connecting the
second and third unit. For more
information, contact your Shimadzu
representative.
Use a power outlet unit for
installation sites where it is
difficult to access the back of
the instrument. Using a plate
changer could make it more
difficult to access the main
power switch on the back of
each instrument.
Tubing Kits
A 228-70254-41 OUT tubing for high-pressure gradient, 0.3
mm I.D.
B 228-70254-42 OUT tubing for high-pressure gradient, 0.1
mm I.D.
C 228-70254-43 OUT tubing for low-pressure gradient, 0.3
mm I.D.
D 228-70254-44 OUT tubing for low-pressure gradient, 0.1
mm I.D.
Tubing (0.1 I.D. × 600 mm) 228-53184-91 Autosampler OUT tubing
Tubing (0.17 I.D. × 600 mm) 228-53184-48 Autosampler OUT tubing
Tubing (0.3 I.D. × 600 mm) 228-53184-49 Autosampler OUT tubing
Tubing (0.3 I.D. × 600 mm) 228-53184-54
For pump OUT tubing. Used to connect the
pump and autosampler for isocratic
analysis.
4Nexera CL series
1 Overview

Optional Part P/N Features
Tubing (0.3 I.D. × 1000 mm) 228-53184-96
For pump OUT tubing. Used for application
systems where 600 mm tubing is not long
enough.
UHPLC Fitting 228-56867-41
Used to connect the above tubing. 130
MPa pressure capacity. Reusable up to 20
times.
Set of Five Mobile Phase
Bottles (1 L with cap) 228-38583-42 This set includes five 1 L mobile phase bottles with caps.
BOTTLE CAP SET FOR GPC,
GL45 228-77057-41
Bottle Cap for using a mobile phase with
strong dissolution such as THF. For GL 45
bottle diameter standard.
MPM-40 Mobile
Phase Monitor
Controller 228-65525-58
This controller is for instruments that can
measure mobile phase levels. It is used by
connecting it to the bottle holder indicated
below. Can be connected to up to six sets
of 1L bottle holders or up to four sets of
large bottle holders.
1L bottle
holder 228-65526-58
This is the bottle holder accommodating a
1L bottle.
• A single bottle holder can monitor the
remaining volume of two reservoir
bottle.
•A maximum of three bottle holders can
be put on a reservoir tray.
Large
bottle
holder
228-65549-58
This is the bottle holder accommodating a
large bottle with a 130 to 186 mm
diameter.
• A single bottle holder can monitor the
remaining volume of one large bottle.
•A maximum of two bottle holders can be
put on a reservoir tray.
AC adapter 074-83019-01 Use this USB cable to supply power for the
MPM-40.
Tool Kit 228-57647-43
This tool kit is used for all models. It
includes the main tools used for the
respective models of solvent delivery
pumps, autosamplers, column ovens,
detectors, and other instruments.
Bottle Retainer Kit for
Earthquakes (1L bottle) 228-77027-41
Mobile phase bottles can be secured by
attaching the kit to the reservoir tray. It
can secure up to six 1L bottles.
Bottle Retainer Kit for
Earthquakes
(Large bottle)
228-76081-41
Mobile phase bottles can be secured by
attaching the kit to the reservoir tray. It
can secure up to two large bottles.
Bottle Net Set for Earthquakes 228-54791-91 The net is placed over the reservoir bottles
to prevent them from falling.
Bottle holder extension cable 228-76080 This cable (approx. 1 m) extends the length
of the bottle holder cable.
Nexera CL series 5
1.2 Optional Parts
1

Optional Part P/N Features
System Anchoring Strap for
Earthquakes 228-54756-02
By strapping stacked components together,
this strap secures the system in the event
of an earthquake (4 m long, with buckle).
L-Type Retainer Plate for
Earthquakes 228-77035-41
This part is used to fasten the strapped
stack of system components to an
installation base stand. It is fastened
directly to the base stand with bolts.
System Base Kit A 228-77036-41
Systems are placed on this base stand.
Used in combination with a system
anchoring strap for earthquakes, this kit
can be used to secure the system to the
base stand. It also enables liquid waste to
be drained from the back of the system
(420 mm wide).
System Base Kit B 228-77036-42 Same as Kit A, except 290 mm wide
System Base Kit C 228-77036-43 Same as Kit A, except 170 mm wide for
plate changers
For IVDR systems (for Europe),MPM-40 cannot be used.
1.3 Configuration List
Shimadzu Nexera CL series liquid chromatographs can be connected to the following
units.
Model P/N Model Name
High Performance Liquid
Chromatograph Mass
Spectrometer
225-31400-55
225-31800-55 LCMS-8045 CL
High Performance Liquid
Chromatograph Mass
Spectrometer
225-19600-55
225-19610-55 LCMS-8050 CL
High Performance Liquid
Chromatograph Mass
Spectrometer
225-27800-55
225-27810-55 LCMS-8060 CL
High Performance Liquid
Chromatograph Mass
Spectrometer
225-41600-55
225-41690-55 LCMS-8060NX CL
APCI unit 225-19601-55 APCI-8050
Fully automated sample
preparation module for LCMS 241-18700-55 CLAM-2040 CL
6Nexera CL series
1 Overview
