DT-329 Stroboscope
Specications

The NEW SHIMPO DT-329 Linear Stroboscope employs High Brightness LED Technology.
No other strobe on the market delivers a crisper, clearer image while operating at all flash rates with High
Brightness. Even at ultra high repeats up to 120,000 (FPM), the service life of the DT-329 is 5x’s greater
than many traditional stroboscopes which incorporate xenon flash tubes. Due to LED engineering, which
eliminates the need for xenon flash tubes, no sound is produced when in use; an added benefit and a great
asset for audio and speaker research.
The DT-329 is ideal for wide and narrow web printing, motion and machine vibration analysis, audio (speaker)
research, pulp and paper manufacturing and a wide range of rolling mill applications. Easy to mount and
set up, the DT-329’s design provides for daisy chain and external triggering methods. Phase shifting (flash
advance/delay in degrees and mSec), external and internal flash control, and a back-lit LCD display provides
the operator an easy to use visual inspection tool to monitor production quality under all line speeds.
DT-329 STROBOSCOPE DIMENSIONS
40 mm
(1.57”)
30 mm
(1.18“)
185 mm
(7.28”)
370 mm
(14.57”)
340 mm
(13.39”)
100 mm
(3.94”)
153 mm
(6.02”)

stnetnoCmetI
Unit FPM (Flashes Per Minute), Hz
High Range 60 – 120,000 FPM, 1 – 2,000Hz
Flash Rate Range Low Range 60 – 12,000 FPM, 1 – 200Hz
Flash Rate Accuracy 0.02 % ± 1 digit at 77 F
60 – 30,000 FPM
2 FPM
60,005 – 100,000 FPM
High Range
100,010 – 120,000 FPM
0.1 FPM 60.0 – 3,000.0 FPM
0.2 FPM 3,000.2 – 6,000.0 FPM
Unit FPM
Low Range
0.5 FPM 6,000.5 – 12,000.0 FPM
High Range 0.1 Hz
Flash Setting Resolution
Unit Hz Low Range 0.01Hz
Ratio (Flash Duty) 0.1 – 2.5 (/ 360 ) Setting of every 0.1
Light Source High Brightness LEDs
Time 0 – 999 ms
Flash Delay Angle 0 – 359 
Controls Power, Multiply by 2, Divide by 2, Phase Shift±, Ratio, Mode Setting
External Trigger Input Photocoupler input 12mA/DC12V
External Clock Output Photocoupler Output 30mA/DC30V, Pulse width 200μs
1,250 lux 6,000 FPM 7.87in (20cm)
)mc05(ni96.91xul007
1,950 lux 120,000 FPM 7.87in (20cm)
Light Power
(Illumination/Brightness)
)mc05(ni96.91xul068
Display LCD with
Backlight Sub-display: Flash, Units, Battery, Settings
Main Display: 6 characters
Display Update Continuous
Power Supply AC 100V – 240V 50/60Hz
Weight 11lbs (5kg)
Operating Temperature 32 - 95° F (0 - 30° C)
Includes AC cable, 1 Input Connector, 1 Output Connector, Manual, Warranty Card
6,000 FPM
120,000 FPM
1 FPM
30,002 – 60,000 FPM
0.1 - 2000 Hz
0.01 - 200 Hz
5 FPM
10 FPM
Warranty 2 Years
DT-329 STROBOSCOPE SPECIFICATIONS
Operation Panel
External Output Connector
AC Input Jack
External Input Connector
Power Switch
Dial for Setting Flash Rate
Operation Keys
LCD with Backlight
