Triplett CamView5 User manual

CamView5 IP 1080P
HD CCTV Tester
USER MANUAL
850 Perimeter Road • Manchester, NH
[phone] • [email protected]
8150
www.triplett.com/8150

Thank you for purchasing the IP camera tester. Please read the manual before
usingthe IP camera tester.
Please firstread the「Safety Information」carefully in the manual.
The manual should be kept with unit in case reference is needed.
Keep the S/N label for after-sale service within warranty period. Product without
S/N label will be charged for repair service.
If there is any question or problem while using the IP camera tester, or damage to
the product, please contact our technical department.
（V01.00）

CCTV TESTER User Manual
1. Safety information ................................................................................................1
2. IP Camera Tester Introduction...............................................................................1
2.1 General.........................................................................................................1
2.2 Packing list...................................................................................................1
2.3 Function interface.........................................................................................2
3. Operation..............................................................................................................3
3.1 Installing the Battery.....................................................................................3
4. IP camera test.......................................................................................................3
4.1 Power output................................................................................................3
4.2 IPC Test pro.................................................................................................4
4.3 IPdiscovery..................................................................................................4
4.4 Rapid ONVIF test.........................................................................................5
4.5 Non-Onvif IP camera test..............................................................................8
5. Analog camera test................................................................................................9
5.1 CVBS...........................................................................................................9
5.2 Auto HD.......................................................................................................9
5.3 CVI camera test..........................................................................................10
5.4 TVI camera test........................................................................................111
5.5 AHD camera test........................................................................................12
6. Other functions...................................................................................................12
6.1 Network tool ..............................................................................................13
6.2 RJ45 cable TDR test...................................................................................14
6.3 Cable Tester...............................................................................................14
6.4 PoE power / DC12V 3A power output.........................................................15
6.5 Update........................................................................................................16
6.6 File explorer...............................................................................................16
6.7 System Setting............................................................................................17
6.8 HDMI out (*Optional)................................................................................19
7. Specifications .....................................................................................................19

CCTV TESTER User Manual
1
1.Safetyinformation
◆The tester is intended for use in compliance with the local rules for electrical testers.
◆To prevent the functional failure, the product should not come in contact with water.
◆The exposed part of the tester should notbe exposed to any liquids.
◆During transportation and use, avoid vibrationof the tester.
◆Do notleave the tester unattended while charging. If the battery becomes overheated, the tester should be immediately removed fromthe
electrical source. The tester should not be charged over 6 hours.
◆Do notuse the tester in high humidity conditions. Once the tester becomes damp, power off immediately.
◆The tester should not be used in an environment with the flammable gas.
◆Do not disassemble the instrument. There are no user replaceable parts inside.
◆The instrument shouldnot be used in an environment with strongelectromagnetic interference.
◆Do not touch the tester with wet hands.
◆Do notuse detergent to clean the unit. A dry cloth is recommended. If the dirt is not easy to remove, a damp cloth with water can be used.
2. IPCamera TesterIntroduction
2.1 General
The 5-inch IPS touch screen IPcamera tester is designed for maintenance and installation of IPcameras, analogcameras, TVI, CVI, AHD,
SDI/EX-SDI cameras, as well as testing 4K H.264 /4K H.265 camera by mainstream. The 1920x1080 resolutionenables it to display a high
resolution imagefrom the camera. The meter supports many ONVIFand analogPTZ controls. The combination of touch screen and touch
control keys make the IP camera tester very user- friendly.
2.2Packinglist
1) Tester
2) Adaptor DC12V 1A
3) Network cable tester
4) Lithium ion battery
5) BNC cable
6) RS485 cable
7) RJ45-BNC converter (Only for optionalfunction cable tracer)
8) DC12V Power cable
9) Audio cable
10) Safety cord
11) Wrist belt
12) Tool bag
13) Manual

CCTV TESTER User Manual
2
2.3 Function interface
1
Menu key
2
Confirm key
3
Return: Return or cancel while settingparameters of the menu
4
4x zoom the image display
5
LED light
6
The RS485 data transmission and received indicator lights red while the data is
beingtransmitted or received.
7
The power indicator lights red while the tester is powered on by the adapter
Top interface
Bottom interface

CCTV TESTER User Manual
3
8
Press more than 2 seconds to turn on or off, short pressto turn on or off the menu display
9
Micro SD card removeable, supports up to 32G
10
DC12V 3A power output, temporarily supply power to the camera
11
PoE power supply output/LAN testinterface
12
HDMI output
13
Video image /AHD/TVI/CVI signal input（BNC interface）
14
LED lamp
15
DC 12V 1A charging interface
16
RS485 Interface: RS485communication for PTZ control
17
Audio input
18
UTP cable port: UTP cable tester port/ Cable tracer port (Optional)
3. Operation
3.1Installing theBattery
The tester has abuilt-in lithium ion rechargeable battery. The battery should be disconnected for safety duringtransportation!
Prior to the use of the instrument, please remove the battery insulation paper. Pressingthe key to power on /off the tester.
Notice: Please use the original adaptor and connected cable of the device!
When the battery icon is fullor the charge indicator turns off, battery chargingis completed.
Notice: When the Charge Indicator turns off, the battery is approximately 90% charged. Chargingtime can be extended for about
1 hour and the charging time under 12 hours willnot damage the battery.
Notice: Press the key several seconds to restore the default settings when the instrument works abnormally.
Notice: While Charging, someone must bepresent.
4. IPcamera test
4.1 Poweroutput
Camera can be powered from the DC 12V/3A output or by Power over Ethernet.

CCTV TESTER User Manual
4
4.2 IPCTestpro
Camera test often needs to open multiple apps, "IPCTEST PRO" app, usingnew technology and combingmultiple functions into one APP,
can increase efficiency.
Application:
Support multi-segment IPaddress scan, can visually display camera brand, click IPaddress to display the image. Can supply the power to
PoE camera.
Real-time display network port connection status.
Use one key to connect camera test tool, browser can login and configure camera.
Batch activate Hikvision and Dahua cameras.
4.3 IPdiscovery
Press IPdiscovery ,tester to auto-scan the entire network segmentIP, as well as auto-modify the tester’s IP to the same network
segment with the scanned camera's IP. The meter auto-search the entire network segment IP, and auto-add the IP from different network
segments.

CCTV TESTER User Manual
5
Local IP: Tester’s IP address, Tester can auto-modify the tester’s IP to the same network segment with the scanned camera's IP.
Discovery IP: Connected tester equipment’s IP address. If the camera is connected to the tester directly, the tester will display the camera’s
IP address, if the tester connects to Local Area Network, it displays the current IP address.
Start: PING function, click "Start", can PING camera’s IP.
ONVIF: Rapid ONVIF Quick link.
IPC TEST: IPC TEST Quick link, Non-OnVIF IP camera test.
4.4 RapidONVIFtest
Rapid ONVIF can display 4K H.265/H.264 camera image by tester’s mainstream.
The meter auto-scans all ONVIF cameras in different network segments. It lists cameras’name and IP address on the leftof screen. Tester
can auto login camera and display camera image. Factory default uses admin passwordto auto login, if you modified the password, then
default uses the modified password to login.
Click the button “Refresh”, the tester will scan the ONVIF camera again. Click the newly displayed ONVIF camera on the “Device List”.
The tester will show the IP camera’s relative information and settings.
Pop-up settings menu when you click the “setting” icon in the upper left corner.
Across network segments scan: After openingthis function, Rapid ONVIF function can scan across network segments to scan camera’s
IP.
Auto Login: After openingthis function, the tester can auto login camera and display camera image (The login default password is
"admin")
Video transmission protocol: UTP and TCP protocol.
Show focus Info: Focus Information.
View manual: Opens the Manual.
Restore Defaults: Restore “Rapid ONVIF” to default settings.

CCTV TESTER User Manual
6
Confirm: Save the modified parameters.
Click “MENU” icon to open camera setting.
While in the “Live video” menu, click “Video Menu” at the top right of the image to access the followingtools: Snapshot, Record, Photo,
Playback, Lens simulation, PTZ and Settings.
Network setting:Click “Network Set” to change the IP address. Some cameras cannot support change IP address, so there is no change
after saving.
When usingthe network video input, the tester supports resolutions up to 1080p, the input image remains clear after it is enlarged. This is
helpful to installers to ensure the IP camera’s video coverage and determine the IP camera’s install site.
Lens simulation: Simulate differentlenses’display area. Supportedlens: “2.8/3.6/4/6/8/12/16/25mm", for choosing the suitable camera
lens.
OSD Menu: Select OSD and popup the OSD menu. include time, channel name and other optional items.

CCTV TESTER User Manual
7
After selectinga channel, you can edit the channel name, modify the display position, and switch the fontsize. Select “Content location -
Default location”. Select “Customize” to arbitrarily adjust the channel name and display location.
Click “OK” to save the modification. Press return key or click any area on the screen to return to the previous interface.
Video files can play in the Video player on the main menu.
PTZ
Set preset position: Move the camera to preset position, enter the preset number on the bottom right corner to complete position preset.
Call the preset position: Select the preset number on the left, click "Call" to call preset.
PTZ speed set: Horizontal and Vertical speed set.

CCTV TESTER User Manual
8
Doc: Click "Create document”, to create a test report document for the camera, . Click “Preview” to view the report document
Enter the camera test information, click "Create Document" to complete the report.
Click doc menu again, you can preview the report document.
Icons description: The description of function icons on the bottom toolbar.
4.5Non-OnVIFIPcamera test
Display image from the 4K H.265 camera by mainstream.
Note: Currently, the IPC Test App only supports some brands’ specific IP cameras, these include specific models made by ACTI,
AXIS, Dahua, Hikvision, Samsung, and many more. If the camera is not fully integrated, please use the ONVIF or RTSP apps.
Local IP: This is the tester’s IP address. Click “Edit” to enter “IP setting” and change the tester’s IP address settings.

CCTV TESTER User Manual
9
IP camera type: Click on the IP Camera type to select the manufacturer and model number of the connected IP camera.
Manual: Click IP camera type, list Honeywell, Kodak, Tiandy, Aipu-waton, ACTi, WoshiDA IP camera etc. If the brand has official
original protocols, pls select camera type, input IP camera address, username and password, click “official” to enter the camera image
display interface.
Stream code: When testing the camera via RTSP, you can select mainstream or sub stream to test (if camera’s RTSP ha s notbeen started,
it will prompt “auto match” fail, please switch to manual selection.
IP Camera's IP: Enter the IPcamera’s IP address manually or click “Search” to auto-scan for the camera’s IP address. It is better to
directly connectthe IP camera to the tester so the search results will only display the camera’s IP address.
IPC Port: When you select the IP camera type, it will default the camera’s port number and does not need to be changed.
After all settings are completed, click “Enter” to view the live video .
5.Analog cameratest
5.1 CVBS
Analog camera test and PTZ control.
Check and set the protocols, address, interface and baud, all must be consistent with the dome camera for the tester to work. After setting
the parameter, the tester can control the PTZ and lens.
5.2 Auto HD
Automatically recognize type and resolution of TVI/CVI/AHD camera and display an image.
Support coaxial PTZ and call OSD menu. Support CVBS and 8MP TVI/CVI/
AHD cameras. Select relative function on the right toolbar to operate, functions including “Photos”, “Snapshot”, “Record”, “Playback”,
“PTZ”, “Set”.
Double tap on the screen to display in full screen.

CCTV TESTER User Manual
10
5.3CVI cameratest
When HD CVI signal input, the tester will display the image resolution at the top of the screen. Double tap on the screen to display the
image in full screen.
The tester supports resolutionup to 3840 x 2160P 12.5/15FPS.
（1）PTZcontrol
1.1 CoaxialPTZ control
Click the icon “PTZ” on the right toolbar to do the correspondingsetting.
“Port”: select coaxial control
Enter PTZ address to perform parameterssetting.
The PTZ address in the tester must be consistent with the dome camera or decoder for the IPC tester to work. After setting the
parameter, the tester can control the PTZ and lens.
Set preset position:
Move the PTZ camera to the preset position, tap it and input preset position number. Tap “Set position” to comp lete set preset position.
Call preset position:
Tap the preset position area, input preset position number. Tap “call position” to complete call preset position .
1.2 RS485 control

CCTV TESTER User Manual
11
（2）Coaxial camera menusetting
Input calling dome camera menu address code, you can press the key “Enter” or click the icon to call the dome camera menu.
set the parameters by
5.4TVIcamera test
When usingan HD TVI signal input, the tester will display the image resolution atthe top of the screen. Double tap on the screen to display
the image in full screen.
The tester supports resolutionup to 3840 x 2160P 12.5/15FPS.
Coaxial camera menu settings:
Tap icon “UTC”, select “MENU” to enter the dome camera menu.

CCTV TESTER User Manual
12
Input calling dome camera menu address code, after finishingthe parameter settings, you can press the key “Enter” or click the icon to
call the dome camera menu.
5.5 AHD cameratest
When usingan AHD signal input, the tester will display the image resolution atthe top of the screen. Double tap on the screen to display
the image in full screen.
The tester supports resolutionup to 3840 x 2160P 15 FPS.
(1) Coaxial PTZ control
UTC control: Select “PTZ or PTZ-2” (AHD camera has two different order, if the “PTZ” not working, pls go “PTZ-2” )
To use coaxial PTZ control with the AHD camera, no parameter settings are needed.

CCTV TESTER User Manual
13
6.1 Networktool
(1) IP address scan
Connect the cable to the LAN port, click icon to enter, set your IP address search range by changingthe Start and End IP addresses.
Click the “Start” button to scan the IP address range. You can also input an IP address in the Port Number Scan to scan for o pen ports.
(2) PING Test
Application: PING testing is the most conventional network debuggingtool. Itis used for testingif the connected. IP camera or other
network equipment’s Ethernet port is working normally, and the IPaddress is correct.
It is normal that the firstdata packet will be lost when testingstarts.
(3) Network test (Ethernetbandwidth test)
To use the Network tester, you will need two IP testers. One is used as a Server and the other as a Client. In order to communicate, both
devices must be on the same network segment.
(4) Port Flashing
Application:
The tester will send special signals to make the connected LAN port flicker at special frequency, which will aid the installer in finding the
connected Ethernet cable easily and quickly. This function can prevent mistakenly inserting or disconnecting the wrong cable and
interruptingnetwork connection.
(5) DHCP server
Click on the DHCP icon to open the DHCP server app. Select the “Start” check box at the top and make any desired changes to t he network
settings. Click “Save” to start assigning dynamic IP addresses for IP cameras and other networked devices. Click the “Refresh” button to
check your Client list.

CCTV TESTER User Manual
14
(6) Trace route
It is used to determine the path of the IP packet access target.
Note: Trace route testing results only for reference, for accurate test route tracking, use a professional Ethernet tester.
(7) Link monitor
This app is used to see if an IP address is occupied by other network devices. This willavoid new address conflicts.
6.2 RJ45 cable TDRtest
Connect cable to tester’s LAN port, click icon “ ” to enter app.
Single test: Test cable status, length and attenuation.
Repeat test: Continue to testcable status, length and attenuation.
Status: After link-up, the screen displays “online”, or for an open circuit, the screen displays“open circuit”, if the cable pair has a short
circuit, the screen displays “short circuit”.
Length: The max test length is 180 meters, when the cable is open circuit or short circuit, can test the cable length, if screen display
“online”, the testing result would not be accurate.
Cable quality test: Green is good quality cable, Yellow is poor quality cable, Red is water damaged cable, the attenuation value will be
displayed when a cable is over 10 meters.
Advanced Test: Test cable pair status, length, attenuation, reflectivity, impedance, skew and other parameters.
Attenuationreflectivity: After link-up, if the reflectivity value is 0, it is the best quality communication
Impedance: After link-up, if the impedance value is 100 Ω, it is the best quality communication, the range is generally in 85-135 Ω
Skew: After 1000M link up, if the skew value is 0ns, itis the best quality communication, if over 50ns, it will cause a Bit Error Rate in the
transmission.
Click “Help”, check the instruction of all parameters.
6.3 Cable Tester
Click icon to enter.

CCTV TESTER User Manual
15
Test LAN cable or telephone cable.
Connect LAN cable or telephone cable with the CCTV tester and cable tester. And then the connectingstatus, cable type and the sequence
of wires as well as the serial number of the cabletester kit will be displayed.
The number of the cable tester is 255.
Quickly detect the near-end, mid-end and far-end fault pointof RJ45 cable connector
Cable test:
Tap "Diagram of the cable sequence", pop up the connection diagram of Straight-through cable and crossover cable.You can then create a
test report.
6.4 PoE / DC12V3Apower output
When the tester is turned on, the DC12V power output functions are automatically turned on.
To use the PoE Power Output function, change the switch “ON” or “OFF”.
The IP camera needs to connect the LAN port before you turn on PoE Power. If the IP camera supports PoE, the PoE power is delivered via
pins 1, 2, 3, and 6 on the LAN port. The IP tester will display “48V ON” at the top of the screen when the POE power is on.
Note:

CCTV TESTER User Manual
16
1. Do notinput power into the “DC12/3A OUTPUT” port.
2. Do notoutput the DC12V/3A power into the DC12V/IN port of the IP camera tester.
3. The IPC tester power output is close to 3A, if the IP camera’s power is over 3A, the tester will auto enter protection mode. Disconnect all
tester connections and then connect the tester with the power adaptor to continue.
4. Before turningon the PoE power output, make sure the IP camera supports PoE power. Otherwise it may damage the IP camera.
5. Before turningon PoE power output, connect the IP camera to the LAN port of tester.
6. Make sure the tester is full charged or more than 80% charged, or it will show “low power”, “not able to supply power”.
6.5 Update
Copy the downloaded update file to SD card "update" directory, if there is no directory, please create one.
Click the icon to open the Update menu. Select “Local Update” to update via the SD card or select “Online Update” to c heck for
updates on the internet. If there are applications thatneed updating, the applications will be listed in the interface, click related applications,
update to the latest version.
Online update: Connect the Internet to update the apps.
App management: This can uninstall and open APP.
6.6 File explorer
Click “File” on the top toolbar, to select internal or external storage. Click on the upper right corner Icon “...”., to select other operations
from the menu or exit.
Browse
It includes Music, Videos, Pictures, Documents, zip file etc.to conveniently view and manage.
FTP server

CCTV TESTER User Manual
17
You can choose internal or external SD card.
For other operation details, refer to FTP settings.
6.7 SystemSetting
Language: Select your desired language: English, Chinese, Korean, Russian, Italian, Polish, Spanish, French or Japanese.
Typewriting: You can select typewritingor install other typewriting:
Date/Time: Set the Date/time of the IP tester.
IP setting: Manually set the IP address, Subnet Mask, Default Gateway and DNS address or select “Dynamic allocation” to use DHCP. To
test multiple network segments, click “Advanced” and then click “Add” to enter another IP address for the IP tester.
WLAN Net: Turn WiFi off or on by pressing the “Open the wifi” button. Once WiFi is turned on, click connected WIFI, to scan for
wireless networks in your area.
Select and press “WIFI” several seconds, to set static IP address.
Wi-Fi hotspot: Input “SSID” name and “password”, and then click “ok” to create Wi-Fi hotspot.
