Shinybow USA SB-8188TB User manual

SB-8188TB
8x8 VGA (RGBHV) HDTV w/ Stereo Analog Audio (Terminal block)
Matrix Routing Switcher
INSTRUCTION MANUAL

SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of re, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit from AC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
ow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualied service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports rst, then remove the power cable; nally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualied service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain.
D. The equipment does not appear to operate normally, or exhibits a marked change in performance.
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATURE AND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL.

CONTENTS
INTRODUCTION & CONTENTS.....................................1
FEATURES & SPECIFICATIONS ....................................2
FRONT PANEL ................................................................3
BACK PANEL ..................................................................6
REMOTE CONTROL .......................................................7
RS-232 SERIAL INTERFACE ........................................9
IR EXTENDER ...............................................................10
TYPICAL APPLICATION .............................................. 11
INTRODUCTION
Congratulations on your purchase one of the most innovative
VGA (RGBHV)/Stereo Audio (AR/AL) 8x8 matrix switching
products on the market today. The SB-8188TB is a true matrix
routing switcher for VGA(RGBHV)/Stereo Audio(AR/AL) signals.
It has (8) individual VGA (RGBHV)/Stereo Audio (AR/AL) inputs
with (8) individual VGA (RGBHV) /Stereo Audio(AR/AL) outputs.
Because it is a matrix router, any input may be routed to any
output; or the same input may be routed to all outputs or any
combination. It completely eliminates the need to constantly
move around audio and video input cables and output via VGA
(RGBHV) cables. The SB-8188TB is useful for matrix signals
from VGA source devices (such as: Personal computer, Set Top
Box, and Satellite Receivers, etc.) to VGA destination devices
over VGA cables to (LCD Monitors, VGA Monitors, Plasma LCD
TV, VGA Projectors, etc.). Selection of inputs is made via the front
panel push buttons or an Infrared Remote Control unit or RS-232
control by a computer.
PACKAGE CONTENTS
Check that you have the following components:
• SB-8188TB 8x8 Matrix Switcher
• IR Remote Control (SW-8188)
• 19 inch 2RU (3½”) rack mount brackets (Part # 2U-440L)
• SB-100 IR Extender Receiver Set
• RS-232 Cable
• CD Contents: Manual, Windows GUI
• Users Guide
• AC/DC Adapter: 12VDC, 2A Universal Type 50/60Hz,
100~230VAC
1
VGA-Audio Matrix Switcher Series
Thank you for purchasing the SB-8188TB VGA-Audio Matrix Switcher. You will nd this unit easy to install and highly reliable
but it is essential that you read this manual thoroughly before attempting to use this switcher.
TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of re,
electrical shock and injury to persons.
• To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow for
sufcient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update
or to keep current the information contained in this document.
We reserve the right to make improvements to this document
and/or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise — without express written permission and consent.
© Copyright 2016. All Rights Reserved.
Version 2.2 JULY 2016
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.

FEATURES
• Supports (8) VGA+Stereo Audio inputs to (8) VGA+Stereo Audio outputs
• (8) VGA (RGBHV), Stereo Audio (AR/AL) Input signals
• (8) VGA (RGBHV), Stereo Audio (AR/AL) Output signals to VGA monitor displays
• Higher video bandwidth 450MB each path R,G,B signals
• Supports HD high denition resolutions XGA, SXGA, UXGA, WSXGA, WUXGA
• Compatible with all VGA video monitor devices, plasma displays and projectors
• Supports RS-232 serial interface protocol command list
• Control via PC RS-232 drive compatible with WIN95/98/2000/XP
• Various User Interface Controls:
• Attached Window based control software for Desktop or NB control by RS-232 port
• Manual control by front panel buttons
• IR remote control
• Supports desktop or rack mountable ear mounts 19 inch with rack mount
• Power supply DC12Volt, Universal type awitch 100~230VAC, 50/60Hz
SPECIFICATIONS
• Type of Switcher: (8) In to (8) Out, VGA (RGBHV)-Audio Matrix Switcher
• Input Ports: Group:
• (8) VGA (RGBHV) via HD-15p VGA female connectors
• (8) Stereo Audio (AR/AL) via Terminal Block 5 pin female jacks
• Output Ports: Group:
• (8) VGA (RGBHV) via HD-15p VGA female connectors
• (8) Stereo Audio (AR/AL) via Terminal Block 5 pin female jacks
• Video Bandwidth: 325MHz (-3dB), 200mVpp
• Video Supported: Higher resolution formats HD 1920x1200 (WUXGA)
• Audio Supported: Stereo Audio
• Low All Hostile Crosstalk: -83dB@5MHz
• Controls: IR remote, Select buttons on the front panel & RS-232
• PC RS-232 Control: RS-232 interface serial via DRV on a PC
• Gain Control: 60MHz 0.1dB gain atness
• Chassis Material: Metal
• Dimensions (WxDxH): 17.5 x 8 x 3.5 in
• Weight: 7.5 lb (Unit only) / 10.6 lb (Net)
• Safety Approvals: CE, FCC, VCCl, Erp, WEEE
• Power Supply: DC12V / 2A (consumption 1.6A Max) Universal switch type 50/60Hz,100~230VAC
As product improvements are continuous, specications are subject to change and without notice.
2
FEATURES & SPECIFICATIONS

3
FRONT PANEL
FRONT PANEL
1. POWER ON SWITCH: The power switch turns the unit on and off. The LED will illuminate red to indicate that the switcher is ON and is
receiving power. The switcher will remember that last state during a power cycle. When power is removed and resorted, the last conguration
will be evoked.
2. INPUT STATUS DISPLAY: Input sources 1 to 8 LED illuminates blue to indicate that a video source is present on that input.
3. OUTPUT STATUS DISPLAY: Each Output (destination) channel shows which input (source) it is assigned.
4. DESTINATION SELECT BUTTONS: Separate outputs 1 thru 8 select buttons are provided for each destination assignment. Routing can be
source to destination or one source to multiple destinations.
Example: Press Destination 1, 3, 5 then press Source 2. It will route Input 2 to Output 1, 3, 5 respectfully.
5. SOURCE SELECT BUTTONS: Separate inputs 1 thru 8 select buttons are provided for each source selection.
6. IR SENSOR: The IR sensor receives IR commands from the supplied remote control or third party IR emitter.
7. 19 INCH EAR MOUNT PAIR: Converts dest-top to 19 inch rack mount bracket (part # 1U-440L) INCLUDED. Image shows rack mount
bracket attached.

4
FRONT PANEL
FRONT PANEL
8. FUNCTION KEY - ALL:
Disables (mutes) video on all destinations OR selects the same source to all destinations.
Option 1
- Press ALL followed by OFF button. The display will show “0“ indicating all
destinations that have no video selected.
Option 2
- Press ALL followed by Source 1 THRU 8. The display will show the Source selected.
- Press ENTER. The pre-set source selection will be assigned all destinations.
9. FUNCTION KEY - OFF:
Disables (mutes) video to selected channels for either destination.
- Press OFF button followed by any Destination channel.
- Press 1 THRU 8 output destination. The display will show “0“ for the selected
channel indicating no video selected.
10. FUNCTION KEY - RECALL:
The system will show previously stored presets, up to a total of (16). Presets are stored
in local memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory
preset location.
- Press RECALL button.
- Press 1 THRU 8 on either Source or Destination row.
- Press ENTER. The pre-set conguration will execute.
Operation completes.
Note: Operation will abort if no keys are pressed with 5 seconds.
11. FUNCTION KEY - ENTER: - Press ENTER to conrm entries.

5
FRONT PANEL
FRONT PANEL
12. FUNCTION KEY - MEMORY:
The system will show store presets, up to a total of (16). Presets are stored in local
memory using Source keys 1 thru 8 or Destination keys 1 thru 8 as the memory preset
location.
- Congure desired matrices.
- Press MEMORY button.
- Press 1 THRU 8 on either Source or Destination row.
- Press ENTER to ready memory location.
- Or press MEMORY again to cancel the operation.
Operation completes.
Note: Operation will abort if no keys are pressed within 5 seconds.
13. FUNCTION KEY - LOCK:
- Press and hold LOCK button for two seconds lockout the front panel.
- Press and hold LOCK button for two seconds to enable the front panel.

6
BACK PANEL
BACK PANEL
1. DC POWER INLET: The switcher is tted with a DC power plug-
park input connector. Please ensure that the plug used is of an
approved type and is of sufcient current carrying capacity with
the correct voltage and connector polarity. 12Volt DC power supply
2A Max.
2. IR EXTERNAL IN: (EXT. IR TO CONTROL SWITCHER): Supports an IR
extender to control the switcher. Extends a maximum distance of up
to ~1000 ft /300M. When you plug the external IR extender into the
switcher, the front panel IR receiver remains active.
3. RS-232 CONNECTION: RS-232 control port allows for interfacing
to a PC, such as a computer or touch panel control, to the switcher
via a DB-9pin female connector for serial RS-232 control.
4. INPUTS - 1~8 VGA-RGBHV-AUDIO PORTS: Connects up to (8) VGA
(RGBHV) & Stereo Audio player devices to (8) VGA/Audio matrix
switcher outputs.
5. OUTPUTS - 1~8 VGA-RGBHV-AUDIO PORTS: Connects up to (8)
VGA (RGBHV) & Stereo Audio signals via (8) VGA cables to VGA
monitor displays and audio speaker devices.
POWER JACK:
DC Jack - Inner OD Ø 2.1mm (+)
Outside OD Ø 5.5mm (GND)
Power Input -12VDC, 2A
IR EXTENDER JACK: Female jack
REMOTE PORT: DB-9pinfemale connector
VGA-AUDIO VIA: HD-15p connector & TB jack
Note: Connects with the female D-Sub HD-
15F connector and the female Terminal
Block-5 pin
VGA-AUDIO VIA: HD-15p connector & TB jack
Note: Connects with the female D-Sub HD-
15F connector and the female Terminal
Block-5 pin

7
REMOTE CONTROL
Before making any connections to the switcher, observe the following:
• Ensure the main voltage supply matches the label on the supplied plug-pack (+/-10%).
• Ensure that the power switch is OFF.
• Ensure that all system grounds (earth) are connected to a common point.
• Avoid powering equipment within a system from multiple power sources that may be separated by large distances.
• Connect all audio video sources and destination equipment.
• Power up all source and destination audio-visual sources.
• For each destination output select the appropriate input source by using the front panel input select buttons. The supplied IR remote
control. Or through the RS-232 serial communications port.
• Upon powering up the switcher, it will return to its last used setting before being powered down.
REMOTE CONTROL
IR REMOTE CONTROL KEY:
1./2. SWITCH POWER ON or OFF:
Power ON and OFF
3. DESTINATION: 1 thru 8 OUTPUT SELECTION:
Destination buttons to select the output display channel
4. SOURCE: 1 thru 8 INPUT SOURCE SELECTION:
Input 1~8 source selection buttons
5. FUNCTION KEY: Function selection buttons
ALL OFF RECALL EDID
ENTER MEMORY LOCK

8
REMOTE PROTOCOL COMMANDS
IR REMOTE CUSTOM AND DATA CODES (NEC Standard)
HOW TO CONTROL IR CODES CUSTOM CODE: 35CA
POWER ON: 35CA A15E LOCK: 35CA B54A
POWER OFF: 35CA A25D RECALL: 35CA B24D
ALL: 35CA B04F MEMORY: 35CA B44B
OFF: 35CA B14E ENTER: 35CA B34C
EDID: 35CA B748
PRESS DESTINATION then - # PRESS SOURCE - #
DESTINATION #1 : 35CA 10EF
DESTINATION #2 : 35CA 20DF
DESTINATION #3 : 35CA 30CF
DESTINATION #4 : 35CA 40BF
DESTINATION #5 : 35CA 50AF
DESTINATION #6 : 35CA 609F
DESTINATION #7 : 35CA 708F
DESTINATION #8 : 35CA 807F
SOURCE #1 : 35CA 01FE
SOURCE #2 : 35CA 02FD
SOURCE #3 : 35CA 03FC
SOURCE #4 : 35CA 04FB
SOURCE #5 : 35CA 05FA
SOURCE #6 : 35CA 06F9
SOURCE #7 : 35CA 07F8
SOURCE #8 : 35CA 08F7
For Example:
Select Destination # 1 to show Source #1~8
The IR Data Code list :
Destination # 1 , Source #1 35CA 10EF 35CA 01FE
Destination # 1 , Source #2 35CA 10EF 35CA 02FD
Destination # 1 , Source #3 35CA 10EF 35CA 03FC
Destination # 1 , Source #4 35CA 10EF 35CA 04FB
Destination # 1 , Source #5 35CA 10EF 35CA 05FA
Destination # 1 , Source #6 35CA 10EF 35CA 06F9
Destination # 1 , Source #7 35CA 10EF 35CA 07F8
Destination # 1 , Source #8 35CA 10EF 35CA 08F7

9
RS-232 SERIAL INTERFACE CONNECT a PC or CONTROL SYSTEM. VERSION COMPATIBLE V2.0
For a complete list of commands, please reference external document
extended RS-232 Protocol Instruction Manual.
RS-232 PROTOCOL COMMANDS ( RS-232 Control driver V2.0.1 )
The ShinybowUSA switcher can be controlled via the RS-232 serial control port to allow for interfacing to a PC, or similar third party control
system.
The serial communication parameters are 9600 baud, 8 bit, No Parity and 1 stop bit - this is often referred to as 9600 8N1.
When the unit recognizes a complete command it will perform the requested action - there is no delimiter character required.
RS-232 SERIAL INTERFACE
RS-232 SERIAL INTERFACE
Pin RS-232 Denition
1 -------- Not used
2 TX Transmitter
3 RX Receiver
4 -------- Not used
5 GND Ground
6 -------- Not used
7 -------- Not used
8 -------- Not used
9 -------- Not used

Note: The External IR jack has voltage on the “Ring” portion of a 3-conductor plug. You must use a 3-conductor plug (aka: stereo plug).
Using a 2-conductor plug will short out the power supply. Always make connections with the switcher power off.
*** When you plug the External IR extender into the switcher, the front panel IR receiver remains active. ***
SB-100 IR Receiver Set
IR Receiver cable 6ft (2M)
SB-100C IR Receiver Cable
1. SB-100 IR 300M Receiver
Switcher IR EXT. In Cable (3C) IR Receiver (SB-100)
2. SB-100C IR 2M Receiver Switcher IR EXT. In
Cable (2C) IR Receiver (SB-100C)
Pin configuration for IR 984 feet (300M) Extender Receiver such as SB-100 compatible
VCC (Ring)
Signal (center)
GND (Sleeve)
TipRing
Sleeve
Tip: Signal
Ring :VCC
Sleeve: GND
Ring
Tip (center)
Sleeve
SB-100 IR Receiver Set
Pin configuration for IR Receiver 6 feet (2M) cable such as SB-100C compatible
IR Receiver cable 6ft (2M)
SB-100C IR Receiver Cable
Signal (center)
GND (Sleeve)
TipRing
Sleeve
Tip: Signal
Ring: NC
Sleeve: GND
Ring
Tip (center)
Sleeve
The SB-100 IR Receiver is required when using the port “ALL in” Jack.
The SB-100C IR Receiver will not function on the port “ALL in” Jack.
SB-100C Maximum Distance ~ 6 feet (2M)
INPUT
DC 12V
RoHS /95/EC
IR EXT .
RS -232
RS-232 IR EXT. in
ANI-100
IR Rx
POWER
INP UT-1
1234
1 2 34
12 3 4
1 2 3 4
HDMI MAT RIX S WIT CHE R
ONOFF
INPUT - 2
INPUT -3
INPUT-4
SW IR
Distance: Max.(2M)
IR PN#: SB-XXXX
Control Switch SB-XXXX
INPUT
DC 12V
RoHS /9 5/EC
IR EXT .
RS -232
RS-232 IR EXT. in
ANI-100
IR Rx
POWER
INP UT - 1
12 3 4
1 2 3 4
1 2 3 4
12 3 4
HDMI MAT RIX SW IT C H E R
ONOFF
INPUT - 2
INPUT -3
INPUT-4
SW IR
Distance: Max.300M
IR PN#: SB-XXXX
Control Switch SB-XXXX
SB-100 Maximum Distance ~ 984 feet (300M)
SB-100 Receiver and SB-101 Transmitter The DISTANCE maximum ~ 984 feet (300M)
SB-100 Receiver and SB-101C Transmitter The DISTANCE maximum ~ 984 feet (300M)
10
IR EXTENDER

INSTALLING DIAGRAM 8X8 VGA-AUDIO MATRIX SWITCHER
SB-8188TB
Sample Connection:
Using 8x8 VGA-AUDIO Matrix Switcher. Switches signals to VGA-Audio Monitor Displays via VGA & Audio cable with SB-8188TB and
Audio Amplier to speakers and signals from Satellite Receiver.
NOTE:
1. Switch the satellite receiver signal over
VGA and Audio cable connects to the monitors.
2. STB VGA/Audio signals switch via SB-8188TB
VGA-Adio matrix switched to the VGA monitors.
3. SB-8188TB matrix control via RS-232 by a pc.
Supports SB-8188TB VGA and Stereo Audio outputs via VGA and Stereo Audio cable.
11
TYPICAL APPLICATION

THIS PAGE IS INTENTIONALLY LEFT BLANK.

13
LIMITED WARRANTY
PLEASE READ THE FOLLOWING TERMS AND CONDITIONS CAREFULLY BEFORE USING THIS HARDWARE, COMPONENTS AND SOFTWARE PROVIDED
BY, THROUGH OR UNDER SHINYBOWUSA, INC (COLLECTIVELY, THE “PRODUCT”). By using installing or using the Product, you unconditionally signify your
agreement to these Terms and Conditions. If you do not agree to these Terms and Conditions, do not use the Product and return the Product to SHINYBOWUSA,
Inc. at the return address set forth on the Product’s packing label at your expense. SHINYBOWUSA, Inc. may modify these Terms and Conditions at anytime,
without notice to you.
RESTRICTIONS ON USE OF THE PRODUCT
It is your responsibility to read and understand the installation and operation instructions, both verbal and in writing, provided to you with respect to the Product.
You are authorized to use the Product solely in connection with such instructions. Any use of the Product not in accordance with such instructions shall void any
warranty pertaining to the Product. Any and all damages that may occur in the use of the Product that is not strictly in accordance with such instructions shall be
borne by you and you agree to indemnify and hold harmless SHINYBOWUSA, Inc. from and against any such damage.
The Product is protected by certain intellectual property rights owned by or licensed to SHINYBOWUSA. Any intellectual property rights pertaining to the Product
are licensed to you by SHINYBOWUSA, Inc. and/or its afliates, including any manufacturers or distributors of the Product (collectively, “SHINYBOWUSA”) for your
personal use only, provided that you do not change or delete any proprietary notices that may be provided with respect to the Product.
The Product is sold to you and any use of any associated intellectual property is deemed to be licensed to you by SHINYBOWUSA for your personal use only.
SHINYBOWUSA does not transfer either the title or the intellectual property rights to the Product and SHINYBOWUSA retains full and complete title to the
intellectual property rights therein. All trademarks and logos are owned by SHINYBOWUSA or its licensors and providers of the Product, and you may not copy or
use them in any manner without the prior written consent of SHINYBOWUSA, which consent may be withheld at the sole discretion of SHINYBOWUSA.
The functionality and usability of the Product is controlled by SHINYBOWUSA, Inc. from its ofces within the State of Texas, United States of America. SHINYBOWUSA
makes no representation that materials pertaining to the Product are appropriate or available for use in other locations other than the shipping address you provided
with respect thereto. You are advised that the Product may be subject to U.S. export controls.
DISCLAIMERS AND LIMITATION OF LIABILITY
SHINYBOWUSA may change or modify the Product at any time, from time to time.
THE PRODUCT IS PROVIDED “AS IS” AND WITHOUT WARRANTIES OF ANY KIND EITHER EXPRESS OR IMPLIED. SHINYBOWUSA DOES NOT WARRANT
OR MAKEANY REPRESENTATIONS REGARDING THE USE OR THE RESULTS OF THE USE OF THE PRODUCT’S CORRECTNESS,ACCURACY, RELIABILITY,
OR OTHERWISE.
SHINYBOWUSA has no duty or policy to update any information or statements pertaining to the Product and, therefore, such information or statements should
not be relied upon as being current as of the date you use the Product. Moreover, any portion of the materials pertaining to the Product may include technical
inaccuracies or typographical errors. Changes may be made from time to time without notice with respect to the Product.
TO THE FULLEST EXTENT PERMISSIBLE PURSUANT TO APPLICABLE LAW, SHINYBOWUSA DISCLAIMS ALL WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-INFRINGEMENT.
SHINYBOWUSA DOES NOT WARRANT THE ACCURACY, COMPLETENESS OR USEFULNESS OF ANY INFORMATION WITH RESPECT TO THE PRODUCT.
SHINYBOWUSA DOES NOT WARRANT THAT THE FUNCTIONS PERTAINING TO THE PRODUCT WILL BE ERROR-FREE, THAT DEFECTS WITH RESPECT TO
THE PRODUCT WILL BE CORRECTED, OR THAT THE MATERIALS PERTAINING THERETO ARE FREE OF DEFECTS OR OTHER HARMFUL COMPONENTS.
SHINYBOWUSA WILL USE ITS REASONABLE EFFORTS TO CORRECT ANY DEFECTS IN THE PRODUCT UPON TIMELY WRITTEN NOTICE FROM YOU
NOT TO EXCEED 10 BUSINESS DAYS AFTER RECEIPT BY YOU OF THE PRODUCT, BUT YOU (AND NOT SHINYBOWUSA) ASSUME THE ENTIRE COST
OF ALL NECESSARY SERVICING, REPAIR AND CORRECTION THAT WAS CAUSED BY YOU UNLESS OTHERWISE AGREED TO IN A SEPARATE WRITING
BY SHINYBOWUSA.
UNDER NO CIRCUMSTANCES, INCLUDING, BUT NOT LIMITED TO, NEGLIGENCE, SHALL SHINYBOWUSA BE LIABLE FOR ANY SPECIAL OR
CONSEQUENTIAL DAMAGES THAT RESULT FROM THE USE OF, OR THE INABILITY TO USE THE PRODUCT IN ACCORDANCE WITH ITS SPECIFICATIONS,
EVEN IF SHINYBOWUSA OR ITS REPRESENTATIVES HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO EVENT SHALL
SHINYBOWUSA’S TOTAL LIABILITY TO YOU FROM ALL DAMAGES, LOSSES, AND CAUSES OF ACTION (WHETHER IN CONTRACT, OR OTHERWISE)
EXCEED THE AMOUNT YOU PAID TO SHINYBOWUSA, IF ANY, FOR THE PRODUCT.
END OF DOCUMENT

122 Rose Ln. Suite 303 | Frisco, Texas 75034
1-877-SHINY-USA
1-877-744-6987
1-972-377-2508
[email protected]
www.shinybowusa.com
