Shinybow USA SB-5680CAK User manual

INSTRUCTION MANUAL
MODEL : SB-5680CAK
8x8 HDMI-HDBaseT Matrix Switcher
8x8 HDMI-HDBaseT Matrix Switch with Auxiliary Audio I/O
HDMI-HDBaseT-AUDIO MATRIX SWITCHER SERIES
Thank you for purchasing the SB-5680CAK HDMI-HDBaseT Matrix Switcher. You will find this unit easy to install
and highly reliable but it is essential that you read this manual thoroughly before attempting to use 8x8 HDMI-
HDBaseT Matrix switcher.
MULTIMEDIA AUDIO AND VISUAL

SAFETY INFORMATION
1. To ensure the best results from this product, please read this manual and all other documentation before operating your equipment.
Retain all documentation for future reference.
2. Follow all instructions printed on unit chassis for proper operation.
3. To reduce the risk of fire, do not spill water or other liquids into or on the unit, or operate the unit while standing in liquid.
4. Make sure power outlets conform to the power requirements listed on the back of the unit. Keep unit protected from rain, water and
excessive moisture.
5. Do not attempt to clean the unit with chemical solvents or aerosol cleaners, as this may damage the unit. Dust with a clean dry cloth.
6. Do not use the unit if the electrical power cord is frayed or broken. The power supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or against them, paying particular attention to cords and plugs, convenience
receptacles, and the point where they exit from the appliance.
7. Do not force switched or external connections in any way. They should all connect easily, without needing to be forced.
8. Always operate the unit with the AC ground wire connected to the electrical system ground. Precautions should be taken so that the
means of grounding of a piece of equipment is not defeated.
9. AC voltage must be correct and the same as that printed on the rear of the unit. Damage caused by connection to improper AC
voltage is not covered by any warranty.
10. Turn power off and disconnect unit fromAC current before making connections.
11. Never hold a power switch in the “ON” position.
12. This unit should be installed in a cool dry place, away from sources of excessive heat, vibration, dust, moisture and cold. Do not use
the unit near stoves, heat registers, radiators, or other heat producing devices.
13. Do not block fan intake or exhaust ports. Do not operate equipment on a surface or in an environment which may impede the normal
flow of air around the unit, such as a bed, rug, carpet, or completely enclosed rack. If the unit is used in an extremely dusty or smoky
environment, the unit should be periodically “blown free” of foreign dust and matter.
14. To reduce the risk of electric shock, do not remove the cover. There are no user serviceable parts inside. Refer all servicing to
qualified service personnel. There are no user serviceable parts inside.
15. When moving the unit, disconnect input ports first, then remove the power cable; finally, disconnect the interconnecting cables to
other devices.
16. Do not drive the inputs with a signal level greater than that required to drive equipment to full output.
17. The equipment power cord should be unplugged from the outlet when left unused for a long period of time.
18. Save the carton and packing material even if the equipment has arrived in good condition. Should you ever need to ship the unit,
use only the original factory packing.
19. Service Information Equipment should be serviced by qualifier service personnel when:
A. The power supply cord or the plug has been damaged.
B. Objects have fallen, or liquid has been spilled into the equipment.
C. The equipment has been exposed to rain
D. The equipment does not appear to operate normally, or exhibits a marked change in performance
E. The equipment has been dropped, or the enclosure damaged.
THIS SAFETY INFORMATION IS OF A GENERAL NATUREAND MAY BE SUPERSEDED BY INSTRUCTIONS CONTAINED WITHIN THIS MANUAL

TABLE OF CONTENTS
SAFETY PRECAUTIONS
Please read all instructions before attempting to unpack, install or
operate this equipment and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
• Always follow basic safety precautions to reduce the risk of fire,
electrical shock and injury to persons.
• To prevent fire or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
• Never spill liquid of any kind on or into this product.
• Never push an object of any kind into this product through any
openings or empty slots in the unit, as you may damage parts
inside the unit.
• Do not attach the power supply cabling to building surfaces.
• Use only the supplied power supply unit (PSU). Do not use the
PSU if it is damaged.
• Do not allow anything to rest on the power cabling or allow any
weight to be placed upon it or any person walk on it.
• To protect the unit from overheating, do not block any vents or
openings in the unit housing that provide ventilation and allow
for sufficient space for air to circulate around the unit.
DISCLAIMERS
The information in this manual has been carefully checked and
is believed to be accurate. We assume no responsibility for any
infringements of patents or other rights of third parties which may
result from its use.
We assume no responsibility for any inaccuracies that may be
contained in this document. We make no commitment to update or
to keep current the information contained in this document.
We reserve the right to make improvements to this document and/
or product at any time and without notice.
COPYRIGHT NOTICE
No part of this document may be reproduced, transmitted,
transcribed,storedin aretrievalsystem, orany ofitspart translated
into any language or computer file, in any form or by any means
— electronic, mechanical, magnetic, optical, chemical, manual, or
otherwise — without express written permission and consent
© Copyright 1997. All Rights Reserved.
Version 1.3 MAR 2014
TRADEMARK ACKNOWLEDGMENTS
All products or service names mentioned in this document may
be trademarks of the companies with which they are associated.
CONTENTS
INTRODUCTION ...............................................................1
PACKAGE CONTENTS .................................................. 2
FEATURES ....................................................................... 3
SPECIFICATIONS ............................................................ 4
FRONT PANEL ................................................................. 5
FRONT PANEL-ARC ................................................... 6
FRONT PANEL - AUX ................................................. 7
FRONT PANEL - HDBaseT ......................................... 8
FRONT PANEL - EDID ............................................... 9
FRONTPANEL- ALL-OFF-LOCK-ENTER...............10
FRONTPANEL-RECALL-MEMORY.........................11
REAR PANEL ................................................................ 12
BACKPANEL- HDMIINPUT/ OUTPUT..................... 13
BACK PANEL - HDBaseT CONTROLS ..................... 14
BACK PANEL - HDBaseT I/O ................................... 15
HDBaseT I/O TRANSMISSION ..................................... 16
REMOTE CONTROL ...................................................... 17
EDID FUNCTIONS ......................................................... 21
TYPICAL APPLICATION ............................................... 24
HDBaseT APPLICATION .............................................. 29
IR EXTENDER ............................................................... 30
ETHERNET SERIAL INTERFACE ................................ 32
RS-232 PROTOCOL .................................................... 33
INTRODUCTION
The SB-5680CAK is professional 8x8 matrix routing switch.
Supporting eight (8) HDMI Inputs, 8 Auxiliary Audio Inputs, and
(8) HDBaseT Inputs. Supports 8 HDMI Outputs, 8 SPDIF Outputs,
and 8 HDBaseT (PoE) Outputs. The SB-5680CAK is based on the
HDBaseT standard and supports full resolution HDMI Video with
embedded PoE, Audio, RS-232, Ethernet and bi-directional IR,
all over a single CATx cable. With a signal bandwidth of 340Mhz,
there is no signal degradation. High Definition Digital signals
can be selected and distributed to any 8 Inputs to 16 Outputs
simultaneously(channeloutputsmirrored). TheSwitcheriscertified
as being fully CEC and HDCP 2.2 compliant, HDMI 4K2K V1.4a 3D
formats, data rates up to 6.75 Gbps. Supports UXGA/WUXGA/DVI
1920x1200 resolution to any HD displays. The SB-5680CAK has
1x HDBaseT and 1x HDMI connector for each Input and output,
effectively making this an 8 in x16 out switcher (same signal on
both outputs). Using the HDBaseT Input and our HDBaseT remote
Transmitter allows you to connect a source in a remote location.
Likewise, the HDBaseT Output and our HDBaseT Receiver allows
you to connect a display in a remote location. EDID management
can be selected between eight (8) different modes. Control is
provided via Front panel push buttons, IR remote, RS-232 or TCP/
IP (not a web-browser). An RS-232 Windows GUI interface is
provided for matrix routing control (Windows only).
1

PACKAGE CONTENTS
PACKAGE CONTENTS
Check that you have the following components;
• SB-5680CAK Matrix Switcher
• Master wireless IR Remote Control (SW-5680)
• 8 each; Individual wireless IR Control (SW-5680-IR01~IR08)
• 19 inch Ear mount bracket (Part # 3U-440L)
• SB-101 IR Extender distance ~984 feet (300M) Transmitter set.
• SB-100 IR Extender distance ~984 feet (300M) Receiver set.
• SB-101C IR Extender distance 6ft(2M) Transmitter Cable.
• SB-100C IR Extender distance 6ft(2M) Receiver Cable.
• CD Contents : This manual, Windows GUI, ISP V1.0 Windows driver
• RS-232 Cable 6 feet (2M)
• ISO Screws
• RS-232 V2.0 Protocol Instructions
• Ethernet V2.0 Protocol Instructions
• Users Guide
• Worldwide Universal Power Supply 100~230 VAC, AC 50/60Hz, 10A.
-- SB-6320T HDBaseT Transmitters & SB-6320R HDBaseT Receiver sold separately. –
2

FEATURES
FEATURES
Based on HDBaseT; bi-directional IR, RS-232, Multi formatAudio, Ethernet and PoE. Full resolution HD Video, all HDBaseT signals over
one CATx cable.
• (8)x HDMI withAuxiliary Audio (Analog Audio) and (8)x HDBaseT Receiver devices matrix switched to
• (8)x HDMI with S/PDIF outputs and (8)x HDBaseT Transmitter with PoE output to (8)x destinations.
• Application HDBaseT Specification with PoE (optional), IR, RS-232, Multi Audio Format and HD
• Video Signals over one CATx (6/6a/7) category cable.
• HDMI digital Video w/embedded HDCP, DVI format and CEC/HDCP 2.2 compliant
• Worldwide control EDID modes for HDMI full 4K2K HD Video resolutions.
• Link speeds of up to 6.75 Gbps (link clock rate of 340MbHz), Support HDMI 4K2K, 1.4a 3D formats.
• Wide range of HD resolutions from PC XGAto WUXGA 1920x1200 and HDTV/DTV HDMI resolutions
• 480i/480p, 576i/576p, 720p, 1080i/p & 4K2K.
• Compatible with all HDMI source devices, PC monitors, Plasma HD display, HDTV and audio receivers or audio amplifiers.
• Digital Video TMDS formats Resolution up to 4K2K with Deep color 36-bit.
• DigitalAudio Support :
• Dolby TrueHD,
• Dolby Digital,
• Dolby Digital Plug/ex,
• DTS,
• DTS-HD,
• DTS-HD Master,
• DTS-EX
• PCM,
• PCM2,
• LPCM2
• Audio Input : SupportAuxiliary Audio (Analog stereo audio).
• Audio Output : Support Digital audioARC or Digital audio S/PDIF ( from HDMI source or Auxiliary Audio )
• Various User Interface controls:
• Windows based GUI control via RS-232 port
• Front Panel push button
• IR wireless remote controller
• Ethernet Switch control
• Third party RS-232 controller (via simpleASCII)
• Support world wide (10)x control function keys:ARC / AUX/ HDBaseT /ALL / OFF / EDID / LOCK / RECALL / MEMORY / ENTER
• Support EDID modes :
• Embedded EDID modes : FSS/ H24-3D/ H24-3D-M/ H36-3D/ H36-3D-M/ 4K2K-3D / DVI-D 1920x1200-60Hz/AUTO
• External modes : Learning mode.
• Automatic scanning input & output status via LCM show on front panel.
• Support IR Remote and IR Extender with distance up to ~ 984 feet (300M) Maximum.
• EDID configuration via Internal and External modes.
• Support Universal power adaptorAC90V~AC230V, 50/60Hz.
• The Switcher will remember that last state during a power cycle.
• When power is removed and resorted, the last configuration will be invoked.
The Switcher will remember that last state during a power cycle.
When power is removed and resorted, the last configuration will be invoked.
3

SPECIFICATIONS
SPECIFICATIONS
• Type of HDMI Switcher: 8x inputs To 8x Outputs HDMI & HDBaseT Matrix Switch withAudio and Extension
• HDMI Support: HDMI 4K2K, 1080p-@60Hz, H36-bit Deep color, 3D of HDMI V1.4 formats
• HDBaseT Support: Bi-directional IR, RS-232, Multi formatAudio, Ethernet and PoE. over one CATx cable.
• HDCP / CEC Support: HDCP 2.2 Compliant, CEC Compliant
• Video Bandwidth: Double Data Rates: 340 MHz, Total 6.75Gbps bandwidth
• Digital Video Support: HD:480i/ 480p/ 720p/ 1080i/p and 4K2K up to 36bit deep color
• Inputs:
• 1. HDMI:
• 8x HDMI (HDMI or DVI digital source).
• 8x Audio (Auxiliary Audio : Analog Stereo Audio).
• 2. HDBaseT:
• 8x HDBaseT Receiver (via category cable CATx & RJ-45 connector)
• 8x IR in (Send IR signals To 8x Rooms via HDBaseT Transmitter)
• 1xALL IR in (Send IR Signals To 8x Rooms - Via HDBaseT Transmitter)
• 1x LAN (ALL Switcher’s HDBaseT Receiver Ethernets Link to External HDBaseT Transmitter)
• Outputs:
• 1. HDMI:
• 8x HDMI (To Destination).
• 8x S/PDIF /ARC: S/PDIF : Source from HDMI or Auxiliary audio / ARC : TV Return Channel Audio.
• 2. HDBaseT:
• 8x HDBaseT Transmitter with PoE (optional) via category cable & RJ-45 connector)
• 8x RS-232 I/O (Control 8x Rooms RS-232 via HDBaseT Extender)
• 8x IR out (Link to Receive IR signals from 8x Rooms via HDBaseT Extender)
• 1xALL IR out (Link to Receive IR signals from 8x Rooms via HDBaseT Extender)
• 1x LAN (All Switcher HDBaseT Transmitter Ethernets link to HDBaseT Receiver)
• Switcher Controls:
• 1x Select & Function buttons on front panel (Data status via LCM panel show out)
• 1x IR Remote Controller (switch control)
• 8x IR Room Remote Controller (switch control)
• 1x IR External port (switch control via 3.5mm OD Jack)
• 1x RS-232 series interface (switch control)
• 1x Ethernet series interface (switch control)
• Digital Audio Support: Multi Audio Formats 5.1 / 7.1, MAT(MLP), Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTS-ES
6CH, DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
• Source Status: Input status LEDs indicates presence of a live signal
• (26) Function Control Keys: 1.ARC, 2.AUX, 3. HDBaseT, 4.ALL, 5. OFF, 6. RECALL, 7. ENTER, 8. MEMORY, 9. LOCK, 10. EDID,
11. Destination 1 thru 8, 12. Source 1 thru 8
• (8) EDID management:
• Select Embedded EDID modes : Mode1: FSS, Mode2: H24-3D, Mode3: H24-3D-M, Mode4: H36-3D, Mode5: H36-3D-M,
Mode6: 4K2K-3D, PCM-2CH, Mode7: DVI-D 1920x1200, Mode8: Auto
• Select LEARNING mode : Learning Destination EDID To Link Source.
• Infrared Frequency: 38 Khz
• IR Extend Distance: ~984 feet / 300 meters maximum.
• HDBaseT Extender Distance: ~328 feet / 100 meters maximum.
• HDMI I/O Connector: HDMI Type A - SMD 19-pin female type
• Temperature: Operating Temperature 32°F - 100°F (0°C - 32°C)
• Dimensions (LxWxH): 19 x 9.85 x 5.19 in (482 x 250 x 132mm)
• Rack Mount: 3RU High 19 ”Rack Mount #3U-440L (with rack mount)
• Power Supply: AC 100~240 VAC 50/60Hz (Power Consumption:10A Maximum)
• Safety Approvals: CE, FCC, RoHS, REACH.
• Product Weight: 4.85 Kgs / 8.08 lb
As product improvements are continuous, specifications are subject to change without notice.
4

FRONT PANEL
FRONT PANEL
1. POWER ON SWITCH
The power switch turns the unit on and off. The LCM will illuminate blue to indicate the switcher is ON and receiving power. The switcher
will remember the last setting during a power cycle. When power is removed and resorted, the last configuration will be evoked.
2. OUTPUT STATUS DISPLAY
Each Output (destination ) Channel shows which input (source) is assigned.
3. IR SENSOR
The IR sensor receives IR commands from the supplied remote controller or third party IR emitter.
4. INPUT STATUS DISPLAY
Input sources 1 to 8 LED illuminates blue to indicate that a video source is present on that input.
5. SOURCE SELECT BUTTONS
Separate inputs 1 thru 8 select buttons are provided each source selection.
6. EDID MODE SELECT BUTTONS
Used to select EDID mode using buttons Source button #1 or #2.
7. DESTINATION SELECT BUTTONS
Separate outputs 1 thru 8 select buttons are provided for each destination assignment.
Routing can be Source to Destination or one source to multiple destinations.
Example : Press Destination 1,3,5 then press Source 2 will route Input 2 to Output 1,3,5 respectfully.
8. 19 INCH EAR MOUNT PAIR
Converts desktop to 19 inch rack mount. Bracket (part # 2U-440L) INCLUDED. Image shows rack mount bracket attached.
5

FRONT PANEL- ARC
FRONT PANEL
9. FUNCTION KEY - ARC
Audio Return Channel (ARC) is a feature that sends audio from the TV back down the HDMI (or HDBaseT) cable to its source device, in
this case, the switcher, The audio additional on the “Audio/ARC” port. Not all displays supportARC; check your Users Guide for additional
information. ( Default = ARC Disabled )
To Enable the ARC option on a specific Output, perform the follow steps:
- Press the ARC button.
- On the Destination row, Press 1 thru 8 (the button will illuminate).
- Press ENTER button. The new configuration will be storedThe front panel LCD display will now show an “A“ under the Output port.
- Or press ARC again to cancel operation.
To Disable the ARC option on a specific Output, perform the follow steps:
- Press the ARC button.
- On the Destination row, press 1 thru 8 (the button will illuminate).
- Press ENTER The pre-set configuration will execute. The front panel LCD display will be blank under the Output port.
- Or press ARC again to cancel operation.
Operation completes.
Note : Operation will abort if no keys are pressed within 5 seconds.
6

FRONT PANEL- AUX
FRONT PANEL
10. FUNCTION KEY - AUX
The AUX FUNCTION feature allows you to replace the embedded HDMI audio signal with an audio signal that is connected to the
switchers Audio AUX Input. Using the AUX function replaces the audio and does not mix the audio. ( Default = AUX Disabled )
To Enable the AUX option on a specific Output, perform the follow steps:
- Press the AUX button.
- On the SOURCE row, Press 1 thru 8 (the button will illuminate).
- Press ENTER The new configuration will be stored. The front panel LCD display will show an “X” under the Source port
- Or press AUX again to cancel operation.
To Disable the AUX option on a specific Output, perform the follow steps:
- Press the AUX button.
- On the SOURCE row, Press 1 thru 8 (the button will illuminate).
- Press ENTER The pre-set configuration will execute. The front panel LCD display will be blank under the Output port indicating
audio source is that which is embedded on the HDMI cable.
- Or press AUX again to cancel operation.
Note :
1. Operation will abort if no keys are pressed within 5 seconds.
2. TheAUX Audio input only function when a valid HDMI / DVI video signal is present. Without a video, theAUX audio will not operate.
7

FRONT PANEL- HDBaseT
FRONT PANEL
11. FUNCTION KEY - HDBaseT
This switcher supports an Input signal originating from either the HDMI Input or HDBaseT Input ( Default = HDMI ).
You assign the Input type by following these steps:
For HDBaseT Input:
- Press the HDBaseT BUTTON.
- On the SOURCE row, press 1 thru 8 (the button will illuminate).
- Press ENTER the new configuration will be stored. The front panel LCD display will show a “ C “ under the source port.
- Or press HDBaseT again to cancel operation.
For HDMI Input:
- Press the HDBaseT BUTTON.
- On the SOURCE row, press 1 thru 8 (the button will illuminate).
- Press ENTER The new configuration will be stored, The front panel LCD display will be blank under the Source port.
- Or press HDBaseT again to cancel operation.
Note :
1. Operation will abort if no keys are dressed within 5 seconds.
2. When you select both HDBaseT Input AND HDBaseT Output; the SB-5680CAK will pass the RS-232 and IR signals between the
HDBaseT Transmitter (ie; SB-6320T) and the HDBaseT Receiver (ie; SB-6320R). The switcher’s build-in RS-232 ports for that channel
will be disabled. Re. Using the HDBaseT Extender and Switcher control define table please be reference the page -27.
8

FRONT PANEL- EDID
FRONT PANEL
12. FUNCTION KEY - EDID (1)
Used to display change current EDID mode.
- Press EDID to select new EDID mode or select
- Press SOURCE row #1 or #2 Select EDID modes.
- Press ENTER to ready memory location.
- Or press EDID again to cancel operation.
Operation completes.
Note : Operation will abort if no keys are pressed within 5 seconds.
FUNCTION KEY - EDID (2)
Select external LEARNING mode
- Press EDID to select new EDID mode or select
- Press Destination again, press the same Destination #1 thru #8 to learn HDBaseT out port EDID, The EDID for HDBaseT (CATx)
has been learned.
- Press ENTER to ready memory location.
- Or press EDID again to cancel operation.
Operation completes.
Note : Operation will abort if no keys are pressed within 5 seconds.
9

FRONT PANEL - ALL - OFF - LOCK - ENTER
FRONT PANEL
13. FUNCTION KEY - ALL
Disables (mute) video on all destinations OR assign the same source to all destinations.
Option 1
- Press ALL followed by OFF button. The display will show ”0” to indicate none of the destinations are assigned a video source.
Option 2
- Press ALL followed by Source 1 thru 8. The display will show the Source selected.
- Press ENTER The pre-set source selection will be assigned all destinations.
14. FUNCTION KEY - OFF
Disables (mute) video on the selected destinations.
- Press OFF button followed by any Destination channel.
- Press 1 thru 8 output destination. The display will show “ 0 “ for the selected channel, indicating no video selected.
15. FUNCTION KEY - LOCK
- Press and hold LOCK button for two seconds lockout the front panel.
- Press and hold LOCK button for two seconds to enable the front panel.
16. FUNCTION KEY - ENTER
Press ENTER to confirm entries.
10

FRONT PANEL - RECALL - MEMORY
FRONT PANEL
17. FUNCTION KEY - RECALL
The system will show previously stored presets, up to a total of 16. Presets are stored in local memory using Source keys 1 thru 8 or
Destination keys 1 thru 8 as the memory preset location.
- Press RECALL button.
- Press 1 thru 8 on either Source or Destination row.
- Press ENTER The pre-set configuration will execute.
Operation completes.
Note: Operation will abort if no keys are pressed within 5 seconds.
- Or press RECALL again to cancel operation.
18. FUNCTION KEY - MEMORY
The system will show store presets, up to a total of 16. Presets are stored in local memory using Source keys 1 thru 8 or Destination keys
1 thru 8 as the memory preset location.
- Configure desired matrices.
- Press MEMORY button.
- Press 1 thru 8 on either Source or Destination row.
- Press ENTER to ready memory location.
- Or press MEMORY again to cancel operation.
Operation completes.
Note : Operation will abort if no keys are pressed within 5 seconds.
- Or press MEMORY again to cancel operation.
11

BACK PANEL - SWITCH CONTROLS
BACK PANEL
12
1. DC POWER INLET:
The Switcher is fitted with a AC power plug input connector.
Ensure that the used is of an approved type and is of sufficient
current carrying connector capacity with the correct voltage and
connector polarity. 100~240Volt AC, 50/60Hz power supply.
2. IR EXTENDER CONTROL:
Support one of IR Extender. Extend distance maximum 300
Meters / ~984 feet. When you plug the External IR extender into
the switcher, the front panel IR receiver remain active.
3. RS-232 CONNECTION:
RS-232 control port to allow for interfacing to a PC. Such as a
computer or touch panel control, to the switcher via this DB-9pin
Female connector for serial RS-232 control.
4. ETHERNET CONNECTION:
ETHERNET control port to allow for TCP/IP interfacing to a PC.
Suchasacomputeror touchpanelcontrol(nota web-browser),to
the switcher via this RJ-45 Female connector to control switcher.
Power Socket :
Connector Type : IEC 60320 C13
IR Extender Jack: Female Jack - inner OD Ø 3.5mm
Remote Port: DB-9pin Female connector
Remote Port : Control the switcher RJ-45 Female
connector
Ethernet Port:
Note: the Ethernet port and RS-232 port cannot
be used simultaneously. Any connection to the
Ethernet port will disable serial commands send
to the RS-232 port.

BACK PANEL - HDMI INPUT / OUTPUT
BACK PANEL
13
5. INPUTS- 1,2,3,4,5,6,7, & 8 HDMI:
Connect a HDMI signal source link of HDMI source direct HDMI
digital video/audio to this Female HDMI connector. This HDMI
port support HDMI and DVI digital video sources. If you remove
the HDMI screw post, use the provides IOS screw to keep the
internal HDMI jack secure. Removing the HDMI Screws without
installing the ISO screws will void your warranty.
6. INPUTS- 1,2,3,4,5,6,7, & 8 AUDIO:
Connect a Auxiliary Audio signal link of AUDIO direct Stereo
Audio to this 3.5mm OD Female Jack. This jack supports DVI
audio or Auxiliary Analog Stereo Audio sources.
AUDIO Connector with Input 1 ~ Input 8
Audio: Supporttheauxiliary audioinputwhen youuseDVI signals.
7. OUTPUTS- 1,2,3,4,5,6,7 & 8 HDMI:
Connect a HDMI signal link of destination direct HDMI signal to
this Female HDMI connector. This HDMI port support HDMI and
DVI digital video signals.
HDMI Audio Output : support with HDMI source audio, DVI
audio and Auxiliary Audio output.
8. OUTPUTS- 1,2,3,4,5,6,7 & 8 S/PDIF / ARC:
Connect a Audio signal output link of the Auxiliary Audio, HDMI
digital audio source orARC TV return channel audio direct to this
RCA jack audio connector. This port use ARC digital audio(TV
return digital Audio) and S/PDIF digital audio from HDMI or
Auxiliary Audio. Use RCA connector with Output 1 ~ Output 8
Audio Output signals :
- ARC Audio (HDTV ARC Turn On)
- S/PDIF (HDMI/DVI SourceAudio orAuxiliaryAudio LPCM-2CH)
HDMI Connector: HDMI TypeASMD 19pin Female
socket connector.
Note: With the proper adapters, the switcher
can be used with DVI digital video signals HDCP
compliant. The DVI support Audio input.
AUDIO Connector: 3.5mm OD phone jack female
socket connector.
Note: With the proper adapters, the switcher can
be used with Auxiliary Audio signals and the DVI
support Audio input.
HDMI Connector: HDMI TypeASMD 19pin Female
socket connector
Note: With the proper adapters, the switcher
can be used with DVI digital video signals HDCP
compliant. The DVI Audio supported.
ARC & SPDIF Audio Connector: RCA Female
connector.
Note: With the proper adapters, the Audio can be
used with HDMI Audio, DVI Audio and Auxiliary
Audio signals outputs. The Auxiliary Audio use
digital LPCM-2CH output.

BACK PANEL - HDBaseT CONTROLS
BACK PANEL
14
8. HDBaseT LAN CONNECTION:
All Tx LAN : Provides Ethernet (LAN) connection from the
switcher to All HDBaseT Transmitter (ie. SB-6320T).
All Rx LAN : Provides Ethernet (LAN) connection from the
switcher to All HDBaseT Receiver (ie. SB-6320R).
10. HDBaseT RS-232 - 1,2,3,4,5,6,7 & 8 CONNECTION:
(8)x RS-232 control port to allow for interfacing to a PC. Controls
I/O via Switcher HDBaseT Transmitter (8) Rooms each via this
Terminal Block-3pin Female socket for serial RS-232 control.
11. HDBaseT IR INPUT - 1,2,3,4,5,6,7 & 8
REMOTE IR SIGNAL TO ROOM:
Send (8)x IR signals to (8) rooms via Switcher HDBaseT
Transmitter. When you plug the Switcher HDBaseT IR Transmitter
intotheexternalport,the roomIRHDBaseTreceiver remainactive.
12. HDBaseT ALL IN : 1,2,3,4,5,6,7 & 8
REMOTE IR SIGNAL TO ROOM:
Send IR signal to room via Switcher HDBaseTTransmitter. When
you plug the Switcher HDBaseT IR Transmitter into the external
port, the room IR HDBaseT receiver remain active.
13. HDBaseT IR OUTPUT - 1,2,3,4,5,6,7 & 8
REMOTE IR SIGNAL FROM ROOM:
Receive (8)x IR signals from (8) rooms each via HDBaseT
Transmitter. When you plug the Switcher HDBaseT IR Transmitter
intotheexternalport,the roomIRHDBaseTreceiver remainactive.
14. HDBaseT ALL OUT : - 1,2,3,4,5,6,7 & 8
REMOTE IR SIGNAL FROM ROOM:
Receive IR signal from room via Switcher HDBaseT Transmitter.
When you plug the Switcher HDBaseT IR Transmitter into the
external port, the room IR HDBaseT receiver remain active.
ALL HDBaseT Tx LAN Port Connector: HDBaseT
Phone-Jack 8P8C, RJ-45 Female socket.
LAN Controls: Note: from switcher to HDBaseT
Transmitter.
ALL HDBaseT Rx LAN Port Connector: HDBaseT
Phone-Jack 8P8C, RJ-45 Female socket.
LAN Controls: Note: from HDBaseT Receiver to
Transmitter via switcher
Remote Port : Terminal Block-3pin Female socket
IR Extender Jack: Female Jack - inner OD Ø 3.5 mm
IR Extender Jack: Female Jack - inner OD Ø 3.5 mm
IR Extender Jack: Female Jack - inner OD Ø 3.5 mm
IR Extender Jack: Female Jack - inner OD Ø 3.5 mm

BACK PANEL - HDBaseT I/O
BACK PANEL
15
15. INPUT - 1,2,3,4,5,6,7 & 8 HDBaseT (Receiver):
To Receive (8) HDMI and control signals via Switcher (8)x
HDBaseT Receivers to link of Switcher HDBaseT Transmitter.
Switcher used (8)x HDBaseT Receiver Input #1 ~ Input #8 with
RJ-45 via CATx (6/6a/7) category extend cable. Controls signals
RS-232, ethernet, IR input & output between Transmitter and
Switcher.
16. OUTPUT - 1,2,3,4,5,6,7 & 8 HDBaseT (Transmitter):
To send (8) HDMI and control signals via Switcher (8)x HDBaseT
Transmitters to link (8)x external HDBaseT Receiver.
Switcher used (8)x HDBaseT Transmitter Output #1 ~ Output
#8 with PoE (optional) RJ-45 via CATx(6/6a/7) category cable.
Controls signals RS-232, ethernet, IR input, IR output and PoE
between Switcher and Receiver.
HDBaseT Receiver Connector: 8x RJ-45 Jack
8P8C Female socket.
Link LED :
solid = valid link
Flash = attempting to link
Off = no link established
HDBaseT Transmitter Connector: 8x RJ-45 Jack
8P8C Female socket.
Link LED :
solid = valid link
Flash = attempting to link
Off = no link established

HDBaseT I/O TRANSMISSION
HDBASET I/O TRANSMISSION
16
RS-232 Cable Pins Out:
PC 232 PINS
DB-9P, MALE plug
HDBaseT Transmitter SB-6320T:
RS-232 PINS OUT
DB-9P, FEMALE socket
HDBaseT Receiver SB-6320R:
RS-232 PINS OUT
DB-9P , FEMALE socket

17
REMOTE CONTROL
Before making any connections to the switcher, observe the following:
• Ensure the mains voltage supply matches the label on the supplied plug- Pack (+/- 10%).
• Ensure that the power switch is OFF.
• Ensure that all system grounds (earth) are connected to a common point.
• Avoid powering equipment within a system from multiple power sources that may be separated by large distances.
• Connect all audio video sources and destination equipment.
• Power up all source and destination audio-visual sources.
• For each destination output, select the appropriate input source by using the front panel input 1~8 select buttons. The supplied IR remote
control or through the RS-232 serial communications port.
• Upon power up the switcher will return to its last used setting before Powered down.
REMOTE CONTROL
IR REMOTE CONTROL KEY :
IR REMOTE : SW-HD88CAK
1. & 2. SWITCH POWER ON or OFF:
Controller with a separate power ON and OFF
3. DESTINATION : 1 thru 8 OUTPUT SELECTION:
Press the destination button to select the output display channel.
4. SOURCE : 1 thru 8 INPUT SOURCE SELECTION:
Press input 1~8 sources with selection button.
5. FUNCTION KEY:
ARC - function selection button
AUX - function selection button
HDBaseT - function selection button
ALL - function selection button
OFF - function selection button
EDID - function selection button
RECALL - function selection button
MEMORY - function selection button
ENTER - function selection button
LOCK - function selection button

18
REMOTE PROTOCOL COMMANDS
IR REMOTE CUSTOM AND DATA CODES (NEC STANDARD)
HOW TO SETUP IR CODES : CUSTOM CODE : 41BE
POWER ON : 41BE A15E
POWER OFF : 41BE A25D
ARC : 41BE B847 LOCK : 41BE B54A
AUX : 41BE 9966 EDID : 41BE B748
HDBaseT : 41BE 9A65 RECALL : 41BE B24D
ALL : 41BE B04F ENTER : 41BE B34C
OFF : 41BE B14E MEMORY : 41BE B44B
PRESS DESTINATION - # then PRESS SOURCE - #
DESTINATION #1 : 41BE 10EF SOURCE #1 : 41BE 01FE
DESTINATION #2 : 41BE 20DF SOURCE #2 : 41BE 02FD
DESTINATION #3 : 41BE 30CF SOURCE #3 : 41BE 03FC
DESTINATION #4 : 41BE 40BF SOURCE #4 : 41BE 04FB
DESTINATION #5 : 41BE 50AF SOURCE #5 : 41BE 05FA
DESTINATION #6 : 41BE 609F SOURCE #6 : 41BE 06F9
DESTINATION #7 : 41BE 708F SOURCE #7 : 41BE 07F8
DESTINATION #8 : 41BE 807F SOURCE #8 : 41BE 08F7
For example;
Select Destination # 1 to show Source #1~8,
The IR Data Code list :
Destination # 1 , Source #1 41BE 10EF 41BE 01FE 01FE
Destination # 1 , Source #2 41BE 10EF 41BE 01FE 02FD
Destination # 1 , Source #3 41BE 10EF 41BE 01FE 03FC
Destination # 1 , Source #4 41BE 10EF 41BE 01FE 04FB
Destination # 1 , Source #5 41BE 10EF 41BE 01FE 05FA
Destination # 1 , Source #6 41BE 10EF 41BE 01FE 06F9
Destination # 1 , Source #7 41BE 10EF 41BE 01FE 07F8
Destination # 1 , Source #8 41BE 10EF 41BE 01FE 08F7
