Show Tec Creator 1024 pro User manual

Creator 1024 PRO V2
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 50731
Firmware: 2.3.10
MANUAL
ENGLISH

1
Ordercode: 50731
Creator 1024 PRO
Table of contents
Warning ...............................................................................................................................................................................3
Safety Instructions .........................................................................................................................................................3
Operating Determinations ..........................................................................................................................................5
Connection with the mains.........................................................................................................................................5
Return Procedure..........................................................................................................................................................6
Claims..............................................................................................................................................................................6
Description of the device.................................................................................................................................................7
Overview ........................................................................................................................................................................8
Glossary.........................................................................................................................................................................10
Backside .......................................................................................................................................................................10
Installation.........................................................................................................................................................................10
Set Up and Operation .....................................................................................................................................................11
Patching .......................................................................................................................................................................11
1. Patching Dimmers ...............................................................................................................................................11
2. Patching Moving Light Fixtures..........................................................................................................................11
3. View the Patching ...............................................................................................................................................12
4. Changing the DMX Address of a Fixture.........................................................................................................12
5. Deleting a Patched Fixture ................................................................................................................................12
6. Patch Utilities.........................................................................................................................................................13
Controlling Dimmers and Fixtures ............................................................................................................................14
1. Selecting Fixtures and Dimmers for Control....................................................................................................14
2. Changing Attributes of the Selected Fixtures ................................................................................................14
3. Grouping ...............................................................................................................................................................15
4. Stepping Through Selected Fixture (One at a Time) ....................................................................................15
5. Move Lighting Menu ...........................................................................................................................................15
6. The Align Function ...............................................................................................................................................16
7. Flip Fixtures.............................................................................................................................................................16
8. Fan Mode..............................................................................................................................................................16
9. Advanced Options .............................................................................................................................................17
Palette...........................................................................................................................................................................18
1. Customize Palette ...............................................................................................................................................18
2. Palette Page.........................................................................................................................................................18
3. Shared and individual Palette ..........................................................................................................................18
4. Which Attributes Are Stored in Palettes...........................................................................................................18
5. Storing a Palette ..................................................................................................................................................19
6. Recalling a Palette Value ..................................................................................................................................19
7. Palettes in Playback............................................................................................................................................19
8. Delete a Palette...................................................................................................................................................19
Shapes...........................................................................................................................................................................20
1. Selecting a Shape ...............................................................................................................................................20
2. Blocking a Shape.................................................................................................................................................20
3. Shape Parameters...............................................................................................................................................21
4. Edit a Shape .........................................................................................................................................................22
5. Remove a Shape from Fixtures .........................................................................................................................22
6. Delete a Shape....................................................................................................................................................22
7. Relative Shapes and Absolute Shapes ...........................................................................................................22
8. Playback Parameters .........................................................................................................................................22
Scenes...........................................................................................................................................................................23
1. How the Creator 1024 PRO works when programming ...............................................................................23
2. Creating a Scene ................................................................................................................................................23
3. Using Shapes in Scenes ......................................................................................................................................24
4. Running Playbacks with a Scene (Autoload) ................................................................................................24
5. HTP and LTP Channels.........................................................................................................................................24
6. Playing Back a Scene .........................................................................................................................................25
7. Turning Playback Pages .....................................................................................................................................25
8. Editing a Scene ....................................................................................................................................................25
9. The Include Function...........................................................................................................................................26

2
Ordercode: 50731
Creator 1024 PRO
10. The “Off” Button.................................................................................................................................................26
11. Copy a Scene ....................................................................................................................................................26
12. Delete a Scene ..................................................................................................................................................26
13. Time ......................................................................................................................................................................27
14. Overlap Function...............................................................................................................................................28
15. Priority...................................................................................................................................................................28
Chase ............................................................................................................................................................................29
1. Programming a Chase .......................................................................................................................................29
2. Running Playbacks with a Step (Autoload) ...................................................................................................29
3. Running a Chase .................................................................................................................................................30
4. Connecting a Chase to the Wheels A/B ........................................................................................................30
5. Setting Speed, Crossfade and Direction ........................................................................................................30
6. Manually Controlling the Chase Step .............................................................................................................31
7. Add a Step............................................................................................................................................................31
8. Unfold a Chase for Editing .................................................................................................................................31
9. Include the Data of a Chase Step...................................................................................................................31
10. Delete a Chase..................................................................................................................................................31
11. Delete a Chase Step ........................................................................................................................................31
12. Adjust Speed and Fade Time with Wheels ...................................................................................................31
13. The Global Time of a Chase............................................................................................................................31
14. Set Separate Time for a Step...........................................................................................................................32
15. Overlap Function...............................................................................................................................................33
16. Priority...................................................................................................................................................................33
15. Advanced Options ...........................................................................................................................................33
Show Recording ..........................................................................................................................................................34
1. Record a Show.....................................................................................................................................................34
2. Run a Show ...........................................................................................................................................................34
3. Delete a Show......................................................................................................................................................34
4. Save/Load a Show ..............................................................................................................................................35
Save Show List...........................................................................................................................................................35
Load Show List ..........................................................................................................................................................35
Save a Single Show .................................................................................................................................................35
Load a Single Show .................................................................................................................................................35
Setup .............................................................................................................................................................................35
1. Save & Load .........................................................................................................................................................35
2. Wipe Data.............................................................................................................................................................35
3. Select Language .................................................................................................................................................35
4. Personality Management ..................................................................................................................................36
Delete Personality ....................................................................................................................................................36
Delete All Personality...............................................................................................................................................36
Update Personality ..................................................................................................................................................36
Edit Personality..........................................................................................................................................................36
5. Show Record ........................................................................................................................................................36
6. User Settings..........................................................................................................................................................36
Console Lock ...............................................................................................................................................................37
Updating.......................................................................................................................................................................37
Personality Builder .......................................................................................................................................................38
1. Interface of the Personality Builder ..................................................................................................................38
2. How to create a new Personality (Library) .....................................................................................................38
2. Creating Pallettes ................................................................................................................................................39
Maintenance....................................................................................................................................................................40
Troubleshooting ...............................................................................................................................................................40
No Light.........................................................................................................................................................................40
Incorrect Language ...................................................................................................................................................40
No Response to DMX..................................................................................................................................................41
Playback Buttons Do Not Respond to Commands..............................................................................................41
Product Specifications....................................................................................................................................................41
Dimensions........................................................................................................................................................................42

3
Ordercode: 50731
Creator 1024 PRO
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
Creator 1024 PRO
Power cable
User manual
Dust cover
Flight case
Optional Accessories
Goose-neck lamp (ordercode: 60722)
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

4
Ordercode: 50731
Creator 1024 PRO
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Do not open the device and do not modify the device.
Never use anything to cover the ground contact.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Do not shake the device. Avoid brute force when installing or operating the device.
Never use the device during thunderstorms, unplug the device immediately.
Only use device indoors, avoid contact with water or other liquids.
Do not touch the device’s housing bare-handed during its operation (housing becomes hot).
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the external cable is damaged, it has to be replaced by a qualified technician.
If the glass is obviously damaged, it has to be replaced, so that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Light effect must be installed out of the reach of children. Never leave the unit
running unattended.
For replacement use fuses of same type and rating only.
Allow time to cool down, before replacing lamp.
The user is responsible for correct positioning and operating of the Creator 1024 PRO. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

5
Ordercode: 50731
Creator 1024 PRO
Operating Determinations
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The maximum ambient temperature ta = 40°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 40°C.
If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Improper installation can cause serious damage to people and property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
FASE
N
BLUE
BLACK
SILVER
NUL
YELLOW/GREEN
GREEN
GREEN
EARTH
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

6
Ordercode: 50731
Creator 1024 PRO
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

7
Ordercode: 50731
Creator 1024 PRO
Description of the device
Features
DMX channel
1024
Fixture
80
Re-patched fixture address
Yes
Swop Pan/Tilt
Yes
Reversed channel output
Yes
Channel slope modification
Yes
Channels for each fixture
40 primary + 40 fine tune
Library
Avolite Pearl R20 library supported
Scene
600
Scenes to run simultaneously
20
Total scene steps
600
Time control of scenes
Fade in/out, LTP slope
Shapes for each scene
5
Scene and dimmer by slider
Yes
Swop scene
Yes
Flash scene
Yes
Shape generator
Shapes of Dimmer, Pan/Tilt, RGB, CMY,
Color, Gobo, Iris and Focus
Shapes to run simultaneously
10
Master slider
Global, playback, fixture
Real time blackout
Yes
Channel value by wheel
Yes
Channel value by slider
Yes
Dimmer by slider
Yes
USB memory
FAT32 supported
Fuse:
F1L/250V
Dimensions:
655 x 550 x 135 mm (LxWxH)
Weight:
12,6 kg

8
Ordercode: 50731
Creator 1024 PRO
Overview
Fig. 01

9
Ordercode: 50731
Creator 1024 PRO
Fig. 02
The Preset Sliders are used for controlling individual dimmer channels and fixture intensities or control
fixture attributes.
The Fixture buttons are used for patching and selecting fixtures.
The Palette buttons allow you to quickly apply many effects (e.g. color, gobo, position) on you
fixtures.
The Fixture Page buttons select 4 pages for the fixtures and palettes.
The Fixture Controls buttons control the fixture selection in different ways.
The Active Pages and Roller Pages allow you to select different pages of playbacks and to write the
playback names on the roller, so that you know what’s in them.
The Function Swap for Playbacks swap the Latch, swop and flash functions of the playback buttons.
The Master sliders control the overall output of the various parts of the console. You will normally
have these set to full. Otherwise, the indicator of the Blackout button will keep flashing.
The Blackout button allows you to black the whole console out.
The Playback sliders and playback buttons are used for playing back scenes you have
programmed, when running a show.
The Menu Operation buttons is used for cancelling, select or page up/down in menu operation.
The Menu Option buttons are used for selecting control options. The display next to the buttons shows
what each one will do. The options for each key change depending on what the console is doing.
The Function buttons are used for functions such as storing cues, copying, saving to disk, etc. These
buttons are equipped with light indicators, to indicate whether they are active or not.
The Attribute buttons are used for selecting which attributes of a fixture (e.g. color, gobo, pan, focus)
are going to be controlled with the control wheels. The buttons have light indicators, to show you
which attributes are active. Repeatedly press the buttons to switch between their functions –you do
not have to press the Page button anymore.
The Fixture Group buttons allow you to group the selected fixtures so that all the fixtures in the group
can be activated with one single button.

10
Ordercode: 50731
Creator 1024 PRO
Glossary
Scene: The data of a stage scene that is saved in a playback.
Chase: The data of a series of fixture performances that is saved in a playback.
HTP: The type of the channels with the highest output (highest takes precedence), normally for
dimmer channels.
LTP: The type of the channels with the latest output (latest takes precedence), for non-dimmer
channels.
Fade in: The intensity of the light changes from dark to bright.
Fade out: The intensity of the light changes from bright to dark.
Record by fixture: This is the normal mode of the Creator 1024 PRO. It means that, when you record a
cue, all attributes of every fixture that you have changed are recorded in the cue. So if you change
only the position of a fixture, the color, gobo, intensity and all other attributes of that fixture are
recorded as well. This is useful because you know that, when you recall a cue, it will look exactly as it
did when you saved it. However, it can be slightly inflexible if you want to combine cues.
Record by channel: This means that only attributes you have changed are recorded in the cue. If
you change the position of a fixture, only the position is recorded. When you recall the cue, the
color, gobo etc will remain as they were last set. This means that you can use a cue to change the
position of some fixtures while leaving the color set for a previous cue, allowing more variety when
you are running a show. It is a powerful feature but you can easily get yourself into trouble with it, so
you need to be sure which attributes you need to record and which you want to “show through”.
When you’re learning, it’s best to have some cues “recorded by fixture” which turn on the fixtures in
a known state, then have some color cues to modify just the color, or some gobo cues to set the
gobo, or other attributes.
Backside
Fig. 03
01) ON/OFF
02) IEC Power connector 100-240V AC + Fuse F1L/250V
03) Ground/earth connection
04) 3-pin DMX Output A
05) 3-pin DMX Output B
06) 5-pin DMX Output A
07) 5-pin DMX Output B
08) Audio Input
09) Microphone
10) MIDI Input
11) MIDI Thru
12) MIDI Output
Installation
Remove all packing materials from the Creator 1024 PRO. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.

11
Ordercode: 50731
Creator 1024 PRO
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.
This user manual is based on the software version 2.3.10.
Patching
Patching is the process during which you tell the Creator 1024 PRO:
What type of lighting units you have connected to it
What DMX addresses they are operating at
Which DMX output line each unit is connected to
Which fixture button you want to use in order to access them
You can either patch the DMX channels on your console, to match your lighting rig, or set up the console
first and then set the lighting rig to match.
1. Patching Dimmers
Each dimmer channel is assigned to one fixture button. If you want to link dimmers together, you can
assign several dimmers to the same fixture button.
01) In the initial menu, press <Patch>, then <A> [Dimmer].
02) In the second line, the display shows the DMX address which is going to be used. You can change
this by turning the Wheel V. Press <A> to patch onto the other DMX output line.
03) To patch a single dimmer, press one of the fixture buttons. To patch a range of dimmers, hold down
the fixture button for the first dimmer in the range, then press the last fixture button in the range. The
range of dimmers will be patched to sequential DMX addresses.
04) To patch another dimmer to the same fixture button, enter the new DMX channel and press the
fixture button again.
05) Repeat from step 2 for other dimmers.
You can patch multiple dimmers to the same fixture button by inserting the DMX address of the next
dimmer to be patched and subsequently pressing the fixture button again.
2. Patching Moving Light Fixtures
Moving light fixtures are more complicated to patch than dimmers because they have more attributes to
control, such as pan, tilt, color etc., whereas a dimmer channel just has intensity. When you patch a
fixture, you will see on the display that it occupies a block of DMX channels rather than just one.
01) In the initial menu, press <Patch>.
02) If the desired fixture library is not available in the console, you can copy it (in R20 format) to the root
directory of a USB memory stick (do not save more than 40, FAT32 files on a USB memory stick).
03) Press <B> [Select a Fixture]. It will access the fixture library in the USB memory stick; if the USB is not
inserted, then, it will access the library in the console.
04) Press <Up> or <Down> to browse through the library; Press the soft key to select. When a library from
the USB memory is selected, the library will be added or updated into the console.
05) In the second line, the display shows the DMX address which is going to be used. You can change
this by turning the Wheel V. Press <A> to patch onto the other DMX output line.
06) Press an unused fixture button to patch the fixture. If you want to use a different fixture page, select
the new page first.
07) Press <Exit> to return to the upper menu; then, you can select fixtures of other types.
You can patch a range of fixtures by holding down the first and last fixture buttons of the range,
the same as for dimmers.
Unlike dimmers, you cannot patch more than one fixture to a fixture button. If the fixture button is
already used, then the patch will fail. Use a different fixture button or delete the already existing
fixture from the fixture button, if you do not want it any more.

12
Ordercode: 50731
Creator 1024 PRO
3. View the Patching
Follow the below steps to view the patching:
01) In the initial menu, press <Patch> to enter Patch menu.
02) Press <E> [Patch Information] to view the patching info.
03) The button number, fixture name and address code will be displayed in the menu. Press < Up> or
<Down> to browse. Press the fixture button to go to the fixture directly.
4. Changing the DMX Address of a Fixture
You can re-patch a fixture to a different DMX address or a different DMX output line. All programming is
kept.
01) In the initial menu, press <Patch> to enter Patch menu.
02) Press <C> [Repatch Fixtures].
03) In the second line, the display shows the DMX address which is going to be used. You can change
this by turning the Wheel V. You can also use menu option A to patch onto the other DMX output
line.
04) Press the fixture button for fixture to patch that fixture at the new address.
05) Press <Enter> to confirm the change.
06) Repeat from step 3 if you want to change other fixture
If the new DMX address was already used, the fixture or dimmer on that fixture button will be
“parked”. All programming for the fixture button is preserved, but you need to patch it to a new DMX
address using the above procedure before you can use it again. If you view the fixture patch as
described above, the display will show “park.”
5. Deleting a Patched Fixture
01) In the initial menu, press <Patch> to enter Patch menu.
02) Press <Delete> to enter Delete Patch menu.
03) Press the fixture button, assigned to the fixture which you want to delete.
04) Press <Enter> to delete.
You can delete individual DMX channels from a fixture button by modifying the channel number
instead of pressing a fixture button. This is useful for deleting dimmer channels from fixture buttons
which have multiple channels patched to them. Be careful not to delete individual channels from
the fixtures using this function.

13
Ordercode: 50731
Creator 1024 PRO
6. Patch Utilities
The Creator 1024 PRO allows several options to be set for each fixture or dimmer when it is being
patched. Patch options menu can be accessed by pressing <D> [Patch utilities] while you are in patch
mode. Set the options before you start programming, because scenes will play back differently when the
options are on. The options are:
Invert –Allows you to invert an attribute of a fixture, so when you set zero the output will be full. You
cannot invert some attributes.
01) In the initial menu, press <Patch> to enter Patch menu.
02) Press <D>[Patch Utilities].
03) Press <A>[Set Invert].
04) Select the desired fixtures and press the attribute buttons to select the desired attributes. Then, press
<A> or <B> on the right hand side of the screen to modify.
Set/Reset Instant Mode –When the Creator 1024 PRO faders LTP (movement) channels between two
scenes, the LTP values normally change smoothly. You can set Instant mode to make the channel
snap instantly to the new value.
01) In the initial menu, press <Patch> to enter Patch menu.
02) Press <D>[Patch Utilities].
03) Press <B> [Set/Reset Instant Mode].
04) Select the desired fixtures and press the attribute buttons to select the desired attributes. Then, press
<A> or <B> on the right hand side of the screen to modify.
Swap Pan & Tilt - If you have some fixtures mounted sideways, it can be useful to swap the pan and
tilt channels over.
01) In the initial menu, press <Patch> to enter Patch menu.
02) Press <D> [Patch Utilities].
03) Press <C> [Swap Pan & Tilt] to enter Swop Pan and Tilt.
04) Press <Up> or <Down> to browse the swop info of pan and tilt. You can change the setting with the
buttons on the right of the screen.

14
Ordercode: 50731
Creator 1024 PRO
Controlling Dimmers and Fixtures
When you are programming a show, and sometimes when you are running a show, you need to
manually control the fixtures and dimmers to set the intensity, position, color, etc. To do this you first select
the fixtures you want to change using the Swop buttons, then you set the attributes of those fixtures using
the wheels and attribute buttons.
1. Selecting Fixtures and Dimmers for Control
To select the fixtures or dimmer channels that you want to control, you use the fixture buttons. You can
select fixtures or dimmers individually, or several at once.
You can control dimmer channels and fixture intensity directly from the fader control of the handle, or
select the channels as described below and use the dimmer attribute.
01) Press the fixture buttons for the fixtures you want. The LED on the fixture button will light up for the
selected fixtures.
02) To select a range of fixtures, hold down the fixture button for the first fixture then press the fixture
button for the last fixture.
Press <Locate> to position the selected fixtures in open white at a central position. These values are
not loaded into the programmer –they will not be saved in a scene unless you modify the fixture.
If you want to light up a fixture without moving its position, press <M.L. MENU> then <A> [Locate
without P/T]
If you select a fixture you do not want, press its fixture button again to deselect it.
You can deselect a fixture by pressing the fixture select button again.
Once you have changed any attribute, pressing a fixture button will deselect all fixtures and start the
selection process again.
You can select fixtures on another page by pressing one of the Pages of Fixtures buttons.
2. Changing Attributes of the Selected Fixtures
“Attributes” are the functions of the fixture, like pan, tilt, color, dimmer, etc. You select which attributes
you want to modify using the buttons on the right edge of the console and set values, by turning the
wheels at the bottom of the Creator 1024 PRO. The attributes available depend on the fixture type.
Dimmer channels only have a dimmer attribute. The Creator 1024 PRO can control up to 40 attributes per
fixture. Each attribute button controls two attributes, one on the left wheel and one on the right wheel.
01) Press the button for the attribute to be changed.
02) Turn the wheels to set the attribute. The display above the wheels shows which attributes are being
controlled.
03) Repeat the steps to change other attributes of the selected fixtures.
The attribute buttons let you select the first 20 attributes. Another 20 attributes are available by
pressing the attribute 11-20 buttons, to cater for the weird and wonderful DMX fixtures of the future.
The light on the button stays on when you are using the top 20 attributes.
If the display above the wheels does not show the attribute when you press the button, that attribute
is not available on the selected fixtures.
There are three operation modes for the sliders above the fixture buttons. In “Live Programming
Mode” menu, press <A> to change the operation modes:
Dimmer (Programming): The faders are to control the dimmer channels of the fixture button.
The data will enter the programming area.
Dimmer (Playback): The faders are to control the dimmer channels of the fixture button. The
data will not enter the programming area.
Attribute: To control the attributes of the selected fixtures. The data will enter the programming
area.

15
Ordercode: 50731
Creator 1024 PRO
3. Grouping
You can create groups of fixtures or dimmer channels, to make selecting them faster. You can, for
example, make a group for each type of fixture, or group by left / right stage, etc.
01) Select the desired fixtures for group setting (be aware of the order in which you select the fixtures as
it will have influence upon the performance).
02) In “Live Programming Mode” menu, press <D> [Record Group].
03) Select a fixture group button to save.
04) Repeat steps 1-3 to set another group.
Other useful things to know about groups:
To select all the fixtures of a group, simply press the fixture group button. Other fixtures will not be
selected.
The order in which you select the fixtures takes effect when you use the last fixture –next fixture
functions described in the next section, and when you use Shapes and Fan mode.
4. Stepping Through Selected Fixture (One at a Time)
If you have selected a range of fixtures, or a group, the Creator 1024 PRO has functions to step through
the selected fixtures, one at a time. This can make it easier to program a range of fixtures because you
do not have to select each one manually.
This mode uses the fixture control buttons, which are normally used for controlling chases.
01) Select a range of fixtures or a group.
02) Press <←> (Reverse) and <→> (Forward) will select the fixtures in the range one at time.
03) The <HiLight> button will highlight the output of the selected fixture so that you can see it on sate (the
button LED is lit when in Highlight mode).
04) The <All> button reselects the whole range of fixtures.
Press <Odd> or <Even>, the fixtures at the odd/eve positions will be selected.
You can also use the left and right arrow keys to step through selected fixtures.
The selected fixture from the range will light up, and the other fixtures will black out (if the LED of
<HiLight> is turned on).
5. Move Lighting Menu
In Fixture menu, there are more options for fixture operation. Press <M.L. MENU> to turn the pages.
Locate without P/T: Turns on the selected fixtures but does not move them tot he central position. It is
useful if you do not want to change the positioning of the fixtures.
Align Fixture/Attribute: See The Align Function, page 16.
Flip: See Flip Fixtures, page 16.
Macro: Serves the purpose of lighting up or auto testing a fixture. Alter the personality settings first, for
this function to work.
De-Select fixtures: Deselects all fixtures but does not clear the programmer.
Flip Pan: Pan movement flip.
Flip Tilt: Tilt movement flip.
Remove Shape Temp: Move two fixtures running the same shape to the desired position.

16
Ordercode: 50731
Creator 1024 PRO
6. The Align Function
The Align function allows you to copy an attribute from one fixture to others. This can be useful if you want
to set a row of scans to have the same tilt position, or if you want to copy a color from one fixture onto
other fixtures.
01) Press an attribute button of the attribute that you want to align.
02) Select the fixture which is to be used as the reference.
03) Select the other fixtures you want to align to the first one.
04) Press <M.L. MENU>, then, press <C> [Align Attribute].
05) The attributes will be copied to all the selected fixtures.
You can align all attributes of the fixtures using <B> [Align Fixtures] (it does not matter which attribute
is selected).
If you use a group to select the fixtures, the one you selected first when you recorded the group will
be the reference fixture.
7. Flip Fixtures
The Flip function is mainly used for moving heads. This type of fixture has two kinds of movement: pan/tilt.
This function alternates between those two movements. While using this function, you do not have to stop
pan movement all the time.
01) Select the desired fixtures.
02) Press <M.L. MENU>.
03) Press <D> to flip the fixtures.
8. Fan Mode
Fan mode automatically spreads out the values on a selected range of fixtures. If used on pan and tilt,
the result is spreading out “rays” of light beams. The first and last fixtures of the range are affected most,
and the central fixtures are affected least. The amount of fan can be set by turning the wheels.
As with shapes, the order in which you select the fixtures sets how the fan effect works. The fixtures you
select first and last will be the ones which change most. If you use a group to select the fixtures, the order
is the one in which the fixtures in the group were selected when it was created.
The fan effect, while normally used on pan or tilt attributes, can be applied to any attribute.
01) Select the fixtures which you want to fan.
02) Select the attributes to fan (Pan/Tilt, Color, etc).
03) Press <Fan> and set the reference point for the fan effect. You can select 3 modes:
<A> Middle.
<B> First
<C> Symmetric
04) The controllable attributes will be displayed in the bottom two lines in the screen.
05) The display shows which attribute is being controlled by each wheel.
06) Turn off Fan by pressing the <Fan> button again, when you have finished.
Fan mode needs to be used on at least 4 fixtures to give good effects. If you have an odd number of
fixtures, the central fixture will not move in fan mode.
Press the <Fan> button again to leave Fan mode. Any effects which you have set will remain in the
programmer.
<A> Middle: In this mode, the fixtures on the edges will move fully, while the fixture close to the
middle will move partially. If the total number of fixtures is odd, then the fixture located on the right
middle will nove move at all.
<B> First/Last: If set to First, the first fixture will remain static and the remaining fixtures will move in the
way that every fixture will move more than its predecessor. If set to Last, the last fixture will remain
static and the remaining fixtures will move in the way that every fixture will move less than its
predecessor.
<C> Symmetric: The fixtures will be divided into 2 groups. Both groups will run in Middle mode (see
above).

17
Ordercode: 50731
Creator 1024 PRO
It is fairly easy to accidentally leave Fan mode turned on and be very confused about why the wheels
are not working properly, so turn it off as soon as you have completed the effect.
9. Advanced Options
Locate positions selected fixtures at central position with light coming out of them. The settings are
not placed in the programmer, so you need to change the values if you want to save them. The
“locate fixture” settings for each type of fixture are defined in the personality file.
De-Select fixtures deselects all fixtures but does not clear the programmer.
Close Fixture: Select a fixture, press <Close Fixture>, then, all the channels except the pan/tilt
channels of the fixture will output 0.
If you use the firmware version 2.3.10., press <Close Fixture> to temporarily and rapidly remove the built-in
shapes from the selected fixtures. Press <Clear> to recover.

18
Ordercode: 50731
Creator 1024 PRO
Palette
When in programming, you will find some of the positions or colors will be frequently used. The console
allows you to store the frequently used data, like an artist using his palette. Therefore, you can access
such data quickly by pressing a single button. 20 x 4 pages of palettes are available in the console. Every
time you patch a fixture, the console will reserve 10 preset positions, 10 colors and 10 gobos to the
palette assigned to this fixture. Using those presets, you do not need to turn the wheels to search for a
specific color or gobo. Usually, preset positions should be set in advance and the presets should be
available in the fixture’s personality file.
1. Customize Palette
The Creator allows you to select the way in which the palettes can be used.
01) Press <Setup> and then press <Down> to scroll down.
02) Press <A> [User Setting].
03) There are 2 options in the menu:
Save Pal. Not link A/Save Pal. Link Attr.: When recording a palette entry, you can select to link it to
attributes or not. If yes, then only the data of the selected attributes in the programmer will be
recorded. Otherwise, all the data in the programmer will be recorded.
Use Pal. Not link At/Use Pal. Link Attr.: When loading a palette entry, you can select to link it to
attributes or not. If yes, then only the data of the selected attributes will be loaded. Otherwise, all
the data will be loaded.
2. Palette Page
Palette pages can be locked/unlocked, as fixture pages are turning.
01) Press <Setup> and then press <Down> to scroll down.
02) Press <A> [User Setting].
03) Press <Down> to scroll down.
04) Press <A> [Palette Page ON/OFF].
If set to ON, then the palette pages will turn together with the fixture pages.
If set to OFF, then the palette page will be locked on page 1.
3. Shared and individual Palette
Palette entries can be shared or individual.
Shared: If there is only one fixture in the programmer (you have only changed one fixture) when
recording the palette entry, then you can use that palette entry for all fixtures of the same type. So
you could save a value for “Red” on the first of your moving heads and then use that value for any
of your other moving heads. This is a shared palette, useful for values which are the same for all the
fixtures of one type, such as color, gobo, prism etc. The preprogrammed palettes are all shared.
Individual: If there is more than one fixture in the programmer when recording the palette entry, then
the entry is unique for each fixture. Therefore, when you save an entry with pan/tilt positions for your 4
central moving heads, those positions will only ever apply to those fixtures. You can later add values
for other fixtures; fixtures which have no values saved will not change when the palette is recalled.
This is an individual palette, useful for values which vary for each fixture, like pan, tilt and image
focus.
4. Which Attributes Are Stored in Palettes
A palette entry can store any or all attributes of a fixture, so you could store position, color and gobo in
the same palette entry. However, it is easier to operate the Creator 1024 PRO if you have some palettes
for position, some for color, some for gobo and so on. There are 80 palettes available so you do not need
to mix them up.
Some attributes are linked to each other. When we store or recall the first attribute, the console will store
all the other modified attributes or recall al the other attributes stored with data. The 4th attribute button is
also linked to the 9th and the 10th attribute buttons.

19
Ordercode: 50731
Creator 1024 PRO
5. Storing a Palette
This is how you save a palette value:
01) Press <Clear> to clear the programmer.
02) Select the fixtures for which you want to store palette values. Select one fixture only to record a
shared palette entry.
03) Using the attribute buttons and wheels, set the attributes you want in the palette entry. You can store
any or all attributes of a fixture in each palette entry. Only attributes you have changed will be
recorded.
04) Press the attribute button for the attributes you want to store (the dimmer button will store all
attributes). The buttons light up to show you which attributes are going to be recorded. It’s best to
save only one type of attribute (e.g. Tilt/Pan).
05) Press <Store Palette>, then press one of the palette buttons, to save.
6. Recalling a Palette Value
To recall a palette value, this is what you do:
01) Select the fixtures to be changed. Shared palettes can be set to any fixture of the same type.
Individual palettes will set individual values to each fixture.
02) Select the attributes you want to recall from the palette. The <Dimmer> attribute button will recall
everything stored in the palette (the LEDs on the buttons show you which attributes are active)
03) Press one of the palette buttons to recall it.
It is easiest to save only one type of attribute (such as pan/tilt) into each palette, then you can just
leave the <Dimmer> attribute button selected when recalling the palette. If you store a mixture of
attributes, you always have to make sure that the correct attributes are selected when recalling a
palette and this is an extra step which you could do without.
7. Palettes in Playback
In firmware version 2.3.10., once a palette is recalled and stored in a playback, the playback will change
as the palette is changed. For example, if we have a palette or red color and store it in a playback, the
playback will output red. However, if we change the palette color from red to green and run the
playback again, the playback will output green.
Due to the free space limit, we suggest to recall only one palette in each playback. If you recall
more palettes, it may cause a time lag. This issue will be addressed in the future update.
This function can be disabled. While in the main menu, press <C> [Edit Time], press the desired
playback button, then press <Down> twice and, finally, press <E> to toggle between [Relate palette]
and [Not relate palette].
8. Delete a Palette
Press <Delete>, then, press <Palette> to delete.
