Show Tec Phantom 70 Beam RGBW V1 User manual

Phantom 70 Beam RGBW V1
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Ordercode: 40051
MANUAL
ENGLISH

1
Ordercode: 40051
Phantom 70 Beam RGBW
Table of contents
Warning ...............................................................................................................................................................................3
Safety Instructions .........................................................................................................................................................3
Operating Determinations ..........................................................................................................................................5
Rigging ............................................................................................................................................................................5
Mounting a bracket and quick-locks to the underside of the Phantom 70 Beam RGBW. ............................5
Connection with the mains.........................................................................................................................................6
Return Procedure..........................................................................................................................................................7
Claims..............................................................................................................................................................................7
Description of the device.................................................................................................................................................8
Overview ........................................................................................................................................................................8
Frontside..........................................................................................................................................................................9
Backside .......................................................................................................................................................................10
Installation.........................................................................................................................................................................10
Set Up and Operation .....................................................................................................................................................10
Control Modes.............................................................................................................................................................11
One Phantom 70 Beam RGBW (Built-in Programs and Manual) ....................................................................11
One Phantom 70 Beam RGBW (Sound-controlled) ..........................................................................................11
Multiple Phantom Beams (Master/Slave Control) .............................................................................................11
Multiple Phantom Beams (DMX Control) ............................................................................................................12
Fixture Linking...............................................................................................................................................................13
Data Cabling...............................................................................................................................................................13
Control Panel ...............................................................................................................................................................14
DMX Control Mode.....................................................................................................................................................14
DMX Addressing ..........................................................................................................................................................14
Menu Overview...........................................................................................................................................................15
Main Menu Options....................................................................................................................................................16
1. DMX-512 ................................................................................................................................................................16
2. Channel Mode.....................................................................................................................................................17
3. Run Mode..............................................................................................................................................................17
3.1 DMX Mode..........................................................................................................................................................17
3.2 Master Mode ......................................................................................................................................................17
3.3 Slave Mode.........................................................................................................................................................18
3.4 Sound Mode .......................................................................................................................................................18
3.5 Manual Mode ....................................................................................................................................................18
4. Functions Mode ...................................................................................................................................................19
4.1 Pan Invert ............................................................................................................................................................19
4.2 Tilt Invert...............................................................................................................................................................19
4.3 Dimmer Curve ....................................................................................................................................................20
4.4 DMX Fail Curve...................................................................................................................................................20
4.5 Display .................................................................................................................................................................20
4.6 Back Light............................................................................................................................................................21
4.7 Reset.....................................................................................................................................................................21
4.8 Factory Sets.........................................................................................................................................................21
4.9 Auto Test..............................................................................................................................................................21
5. Version ...................................................................................................................................................................21
DMX Channels .............................................................................................................................................................22
8 Channels ................................................................................................................................................................22
Black out during pan/ tilt movement...................................................................................................................23
12 Channels ..............................................................................................................................................................23
16 Channels ..............................................................................................................................................................25
Black out during pan/ tilt movement...................................................................................................................26
Maintenance....................................................................................................................................................................28
Replacing the Fuse.....................................................................................................................................................28

2
Ordercode: 40051
Phantom 70 Beam RGBW
Troubleshooting ...............................................................................................................................................................28
No Light.........................................................................................................................................................................28
No Response to DMX..................................................................................................................................................29
Product Specifications....................................................................................................................................................30
Dimensions........................................................................................................................................................................31
Notes ..................................................................................................................................................................................32

3
Ordercode: 40051
Phantom 70 Beam RGBW
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
●Showtec Phantom 70 Beam RGBW
●Mounting bracket with 2 mounting screws
●Pro Power connector to Schuko cable (length 1,5 m)
●User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
●be qualified
●follow the instructions of this manual
Before your initial start-up, please make sure that there is no damage caused by transportation. Should
there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.

4
Ordercode: 40051
Phantom 70 Beam RGBW
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
Never remove warning or informative labels from the unit.
Never use anything to cover the ground contact.
Never lift the fixture by holding it at the projector-head, as the mechanics may be damaged.
Never place any material over the lens.
Never look directly into the light source.
Never leave any cables lying around.
Do not insert objects into air vents.
Do not connect this device to a dimmerpack.
Do not switch the device on and off in short intervals, as this would reduce the device’s life.
Do not touch the device’s housing bare-handed during its operation. Allow the fixture to cool for at
least 5 minutes before handling.
Do not shake the device. Avoid brute force when installing or operating the device.
Only use device indoor, avoid contact with water or other liquids.
Only operate the fixture after having checked that the housing is firmly closed and all screws are
tightly fastened.
Only operate the device after having familiarized with its functions.
Avoid flames and do not put close to flammable liquids or gases.
Always keep case closed while operating.
Always allow free air space of at least 50 cm around the unit for ventilation.
Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord by the plug. Never pull out the plug by tugging the power cord.
Make sure that the device is not exposed to extreme heat, moisture or dust.
Make sure that the available voltage is not higher than stated on the rear panel.
Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
If the lens is obviously damaged, it has to be replaced. So that its functions are not impaired, due to
cracks or deep scratches.
If device is dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
If your Showtec device fails to work properly, discontinue use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
For adult use only. Device must be installed out of the reach of children. Never leave the unit running
unattended.
Never attempt to bypass the thermostatic switch or fuses.
For replacement use fuses of same type and rating only.
The user is responsible for correct positioning and operating of the Phantom 70 Beam RGBW. The
manufacturer will not accept liability for damages caused by the misuse or incorrect installation of
this device.
This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
Repairs, servicing and electric connection must be carried out by a qualified technician.
WARRANTY: Till one year after date of purchase.

5
Ordercode: 40051
Phantom 70 Beam RGBW
Operating Determinations
This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
The minimum distance between light-output and the illuminated surface must be more than 1 meter.
The maximum ambient temperature ta = 40°C must never be exceeded.
The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
If this device is operated in any other way, than the one described in this manual, the product may
suffer damages and the warranty becomes void.
Any other operation may lead to dangers like short-circuit, burns, electric shock, crash etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
If the Phantom 70 Beam RGBW is lowered from the ceiling or high joists, professional trussing systems
have to be used.
Use a clamp to mount the Phantom 70 Beam RGBW, with the mounting-bracket, to the trussing
system.
The Phantom 70 Beam RGBW must never be fixed swinging freely in the room.
The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety-cable.
When rigging, derigging or servicing the projector, always make sure, that the area below the
installation place is blocked and staying in the area is forbidden.
Mounting a bracket and quick-locks to the underside of the Phantom 70 Beam RGBW.

6
Ordercode: 40051
Phantom 70 Beam RGBW
The Phantom 70 Beam RGBW can be placed on a flat stage floor or be mounted to any kind of truss by
means of a mounting bracket with quick-locks.
Improper installation can cause serious damage to people and property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always pay attention, that the right color cable is connected to the right place.
International
EU Cable
UK Cable
US Cable
Pin
L
BROWN
RED
YELLOW/COPPER
PHASE
N
BLUE
BLACK
SILVER
NEUTRAL
YELLOW/GREEN
GREEN
GREEN
PROTECTIVE GROUND
Make sure that the device is always connected properly to the earth!
Improper installation can cause serious damage to people and property!

7
Ordercode: 40051
Phantom 70 Beam RGBW
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name.
02) Your address.
03) Your phone number.
04) A brief description of the symptoms.
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
otherwise agreed in writing.
Complaints against us must be made known in writing or by fax within 10 working days after receipt of the
invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement of which the obligation is resulting.

8
Ordercode: 40051
Phantom 70 Beam RGBW
Description of the device
Features
The Showtec Phantom 70 Beam RGBW is a moving-head with high output and great effects
The clear optical system, in combination with the RGBW LEDs, creates a vivid beam
8 degree optical system ensuring small and razor-sharp beams
Onboard: Bright LCD display for easy setup
Input voltage: 100-240 VAC, 60/50Hz
Power consumption: 90W max. at full output
LED Quantity: 7 X 10W RGBW 4-in-1 LEDs
Control mode: Auto, Manual, Sound-controlled, Master/Slave, DMX512
Preset colors, built-in color jump and fade programs are selectable by DMX
Special: Pan/ Tilt reverse & Black out by DMX
DMX Modes: 8, 12, 16 Channels
DMX-control via standard DMX-controller
Beam angle: 5º
60mm 5° Optics
Dimmer: 0-100% electronic dimmer
Compact Powerful Beam
IFS Technology
Strobe: 0-20Hz
Dimmer curves: Linear, Square, I-Square, S curve
RGBW Color mixing
Pan 0º -- 540º, Tilt 0º -- 270º
Pan/Tilt resolution: 16 bit
On-Board: Display including gravity sensor
Lux @ 2m: 27150lux
Connections: Blue Pro Power connector IN and Grey Pro Power connector OUT
Data Connections: 3-pin DMX IN and OUT
Fuse: T3A/250V
Working temperature: -10⁰C~40⁰C
Housing: Black Flame-retardant plastic, Die-cast aluminum
Dimensions: 310 x 150 x 382 mm (LxWxH)
Weight: 6,4 kg
Included: Pro Power connector to Schuko cable (length 1,5 m) and mounting bracket
Overview
Fig. 01

9
Ordercode: 40051
Phantom 70 Beam RGBW
Frontside
Fig. 02
01) 7 X 10W RGBW 4-in-1 LEDs
02) Control LEDs
03) LCD Display
04) MENU control
NOTE: Knowledge of DMX is required to fully utilize this unit.

10
Ordercode: 40051
Phantom 70 Beam RGBW
Backside
Fig. 03
05) Fuse T3A/250V
06) 3-pin DMX signal connector IN
07) 3-pin DMX signal connector OUT
08) Blue Pro Power connector IN
09) Grey Pro Power connector OUT
10) Power switch ON/OFF
11) Ground/earth connection
Installation
Remove all packing materials from the Phantom 70 Beam RGBW. Check if all foam and plastic padding
is removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.

11
Ordercode: 40051
Phantom 70 Beam RGBW
Control Modes
There are 5 modes:
•Built-in programs (Master Mode)
•Manual
•Sound-controlled
•Master/Slave Mode
•DMX-512 (8CH, 12CH, 16CH)
One Phantom 70 Beam RGBW (Built-in Programs and Manual)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) When the Phantom 70 Beam RGBW is not connected with a DMX-cable, it functions as a stand-alone
device. Please see page 17 and 18 for more information.
One Phantom 70 Beam RGBW (Sound-controlled)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) Turn on the music. If the device is set to sound-control, then the Phantom 70 Beam will react to the
beat of the music. Please see page 18 for more information about the sound-control options.
Multiple Phantom Beams (Master/Slave Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Phantom Beams.
The pins:
01) Earth
02) Signal (-)
03) Signal (+)
05) Link the units as shown in (Fig.04). Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units. You can
use the same functions on the master device as described on pages 17-18. This means that you can
set your desired operation mode on the master device and all slave devices will react the same as
the master device.
Multiple Phantom Beams (Master/Slave Set Up)
Fig. 04

12
Ordercode: 40051
Phantom 70 Beam RGBW
Multiple Phantom Beams (DMX Control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Plug the end of the electric mains power cord into a proper electric power supply socket.
04) Use a 3-pin XLR cable to connect the Phantom Beam RGBW and other devices.
05) Link the units as shown in (Fig.05), Connect a DMX signal cable from the first unit's DMX "out" socket to
the second unit's "in" socket. Repeat this process to link the second, third, and fourth units.
06) Supply electric power: Plug electric mains power cords into each unit's Pro Power socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Phantom Beams (DMX Set Up)
Fig. 05

13
Ordercode: 40051
Phantom 70 Beam RGBW
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows on two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important:
Fixtures on a serial data link must be daisy chained in one single line. To comply with the
EIA-485 standard no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX optically
isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of Phantom Beams on a DMX data link: 30 fixtures
Data Cabling
To link fixtures together you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).
The Phantom 70 Beam RGBW can be operated with a controller in control mode or without the controller
in stand-alone mode.

14
Ordercode: 40051
Phantom 70 Beam RGBW
Control Panel
Press and turn the control to navigate
through the menu options
Fig. 06
DMX Control Mode
The fixtures are individually addressed on a data-link and connected to the controller. When a DMX
signal is present, the DMX LED will blink.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address the next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign the DMX fixture address, which is the
first channel from which the Phantom 70 Beam RGBW will respond to the controller.
Please note when you use the controller, the unit has 16 channels.
When using multiple Phantom Beams make sure you set the DMX addresses right.
Therefore, the DMX address of the first Phantom Beam RGBW should be 1(001); the DMX address of the
second Phantom Beam RGBW should be 1+16=17 (017); the DMX address of the third Phantom Beam
RGBW should be 17+16=33 (033), etc.
Please, be sure that you do not have any overlapping channels in order to control each Phantom Beam
RGBW correctly.
If two or more Phantom Beams are addressed similarly, they will work similarly.
Controlling:
After having addressed all Phantom Beam RGBW fixtures, you may now start operating these via your
lighting controller.
Note: After switching on, the Phantom Beam RGBW will automatically detect whether DMX 512 data is
received or not. If there is no data received at the DMX-input, the DMX LED will not blink.
The problem may be:
The XLR cable from the controller is not connected with the input of the Phantom Beam RGBW.
The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 10 seconds
When no button is pressed for 10 seconds, the display will turn off.
To light up the display, you have to press or turn the MENU control (03).
Once you have pressed or turned the control, the display will light up.

15
Ordercode: 40051
Phantom 70 Beam RGBW
Menu Overview

16
Ordercode: 40051
Phantom 70 Beam RGBW
The Phantom 70 Beam will only show its entire version number at start-up !
Main Menu Options
There are 5 menu modes:
•1. DMX-512
•2. Channel Mode
•3. Run Mode
•4. Functions
•5. Version
1. DMX-512
01) While in main menu, turn the MENU control (03) until the display shows:
02) Press the MENU control (03) to enter the menu.
03) The display will show the following screen:
04) Turn the MENU control (03) to set the desired DMX address.
05) The adjustment range is between 001-512.
06) Press the MENU control (03) to confirm the DMX address.

17
Ordercode: 40051
Phantom 70 Beam RGBW
2. Channel Mode
01) While in main menu, turn the MENU control (03) until the display shows:
02) Press the MENU control (03) to enter the menu.
03) Turn the MENU control (03) to toggle between the 3 available channel modes:
8 channels
12 channels
16 channels
04) Press the MENU control (03) to choose the desired channel mode.
05) For more information about the DMX channels and their functions, see page 22.
3. Run Mode
01) While in main menu, turn the MENU control (03) until the display shows:
02) Press the MENU control (03) to enter the menu.
03) Turn the MENU control (03) to toggle between the 5 available modes:
DMX
Master
Slave
Sound
Manual
04) Press the MENU control (03) to open the mode of your choice.
3.1 DMX Mode
01) Press the MENU control (03) to confirm the DMX mode.
3.2 Master Mode
01) Turn the MENU control (03) to choose one of 8 built-in auto shows:
Showmode 01 –Showmode 08
02) Press the MENU control (03) to confirm your choice.
03) The device will now run the desired auto show.

18
Ordercode: 40051
Phantom 70 Beam RGBW
3.3 Slave Mode
01) Turn the MENU control (03) to choose one of 2 built-in Slave modes.
02) Turn the MENU control (03) to toggle between the 2 slave functions:
Slave1 (normal slave mode)
Slave2 (mirror slave mode)
03) Press the MENU control (03) to confirm your preferred slave mode.
04) The device is now operating in slave mode and it will react the same as the master device (Slave1),
or it will mirror the actions of the master device (Slave2).
3.4 Sound Mode
01) Turn the MENU control (03) to choose Sound and press the MENU control (03) to enter the menu.
02) The display will show the following screen:
03) Turn the MENU control (03) to adjust the sound sensitivity of the device. The adjustment range is
between 000-255, from low to high sensitivity.
04) Press the MENU control (03) to confirm the changes.
3.5 Manual Mode
01) Turn the MENU control (03) to toggle between the 7 available functions:
Pan (Pan adjustment)
Tilt (Tilt adjustment)
Red (Red LED intensity)
Green (Green LED intensity)
Blue (Blue LED intensity)
White (White LED intensity)
Strobe (Strobe intensity)
02) The adjustment range of each function is between 000-255.
03) Once the value has been set, press the MENU control (03) to confirm the changes.
04) Turn the MENU control (03) to choose EXIT.

19
Ordercode: 40051
Phantom 70 Beam RGBW
4. Functions Mode
01) While in main menu, turn the MENU control (03) until the display shows:
02) Press the MENU control (03) to enter the menu.
03) Turn the MENU control (03) to toggle between the 9 available functions:
Pan Invert
Tilt Invert
Dimmer Curve
DMX Fail
Display
Back Light
Reset
Factory Sets
Auto Test
4.1 Pan Invert
01) Press the MENU control (03) to enter the menu.
02) Turn the MENU control (03),choose Normal and press the MENU control (03) to deactivate pan
inversion.
03) Turn the MENU control (03),choose Invert and press the MENU control (03) to activate pan inversion.
04) Press the MENU control (03) to confirm the changes.
4.2 Tilt Invert
01) Press the MENU control (03) to enter the menu.
02) Turn the MENU control (03),choose Normal and press the MENU control (03) to deactivate tilt
inversion.
03) Turn the MENU control (03),choose Invert and press the MENU control (03) to activate tilt inversion.
04) Press the MENU control (03) to confirm the changes.
