Show Tec Expression 550S User manual

Expression 550S V1
Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands
Ordercode: 41394
MANUAL
ENGLISH

1
Ordercode: 41394
Expression 550S
Table of contents
Warning........................................................................................................................................................................... 3
Safety Instructions ..................................................................................................................................................... 3
Operating Determinations....................................................................................................................................... 5
Rigging........................................................................................................................................................................ 5
Connection with the mains ..................................................................................................................................... 6
Return Procedure...................................................................................................................................................... 7
Claims ......................................................................................................................................................................... 7
Description of the device............................................................................................................................................. 8
Frontside ..................................................................................................................................................................... 8
Backside ..................................................................................................................................................................... 9
Installation ...................................................................................................................................................................... 9
Set Up and Operation................................................................................................................................................... 9
Control Modes.........................................................................................................................................................10
One Expression (Auto and Manual)..................................................................................................................10
Multiple Expressions (Master/Slave control) .....................................................................................................10
Multiple Expressions (DMX Control) ...................................................................................................................11
Fixture Linking ...........................................................................................................................................................12
Data Cabling ...........................................................................................................................................................12
Control Panel ...........................................................................................................................................................13
Control Mode ..........................................................................................................................................................13
DMX Addressing ...................................................................................................................................................... 13
Menu Overview.......................................................................................................................................................14
Main Menu Options ................................................................................................................................................15
1. Address ..............................................................................................................................................................15
2. Personality .........................................................................................................................................................16
3. Perform ..............................................................................................................................................................16
3.1. Fans .................................................................................................................................................................16
3.2. Pan/Tilt ............................................................................................................................................................16
3.3. Blackout..........................................................................................................................................................17
3.4. Dimmer ...........................................................................................................................................................17
3.5. Color ...............................................................................................................................................................17
3.6. DMX Error ........................................................................................................................................................ 17
3.7. DMX Reset ...................................................................................................................................................... 17
3.8. Display On ......................................................................................................................................................17
3.9. Display Lock ...................................................................................................................................................17
3.10. Upload..........................................................................................................................................................17
3.11. Settings .........................................................................................................................................................18
3.11.1. Settings Lock.............................................................................................................................................18
3.11.2. Service Lock..............................................................................................................................................18
3.11.3. Recovery ................................................................................................................................................... 18
3.11.4. Wireless DMX Hide ...................................................................................................................................18
3.12. Wireless DMX................................................................................................................................................18
4. Stand-alone ......................................................................................................................................................19
4.1. Run ..................................................................................................................................................................19
4.2. Edit...................................................................................................................................................................19
5. Info......................................................................................................................................................................21
6. Manual ..............................................................................................................................................................21
7. Service ...............................................................................................................................................................22
7.1. CALIB.M ..........................................................................................................................................................22
7.2. RGBtoW ..........................................................................................................................................................22
7.3. CALIB.C........................................................................................................................................................... 22
DMX Channels .........................................................................................................................................................23
17 channels (HSIC)...............................................................................................................................................23
18 channels (PERSON1).......................................................................................................................................25

2
Ordercode: 41394
Expression 550S
23 channels (PERSON2).......................................................................................................................................27
17 channels (CMY)............................................................................................................................................... 30
Channel Settings .....................................................................................................................................................32
Maintenance................................................................................................................................................................33
Replacing the Fuse .................................................................................................................................................33
Gobo Size .................................................................................................................................................................34
Replacing a gobo from the rotating gobo wheel ............................................................................................34
Rotating Gobo Wheel .................................................................................................................................................35
Troubleshooting ...........................................................................................................................................................36
No Light..................................................................................................................................................................... 36
No Response to DMX..............................................................................................................................................36
Product Specifications................................................................................................................................................38
Dimensions ...................................................................................................................................................................39
Notes..............................................................................................................................................................................40

3
Ordercode: 41394
Expression 550S
Warning
Unpacking Instructions
Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure
that all parts are present, and have been received in good condition. Notify the dealer immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture must be
returned to the factory, it is important that the fixture be returned in the original factory box and packing.
Your shipment includes:
● Showtec Expression 550S
● Mounting bracket with quick-locks
● Safety cable
● User manual
LED Expected Lifespan
LEDs gradually decline in brightness over time. HEAT is the dominant factor that leads to the acceleration
of this decline. Packaged in clusters, LEDs exhibit higher operating temperatures than in ideal or singular
optimum conditions. For this reason, when all color LEDs are used at their fullest intensity, life of the LEDs is
significantly reduced. If improving the lifespan is of higher priority, place care in providing for lower
operational temperatures. This may include climatic-environmental and the reduction of overall
projection intensity.
Safety Instructions
Every person involved with the installation, operation and maintenance of this device has to:
be qualified
follow the instructions of this manual

4
Ordercode: 41394
Expression 550S
Before the initial start-up, please make sure that there is no damage caused by transportation.
Should there be any, consult your dealer and do not use the device.
To maintain perfect condition and to ensure a safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes contained in this manual.
Please consider that damages caused by manual modifications to the device are not subject to
warranty.
This device contains no user-serviceable parts. Refer servicing to qualified technicians only.
IMPORTANT:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual or any unauthorized modification to the device.
•Never let the power cord come into contact with other cables! Handle the power cord and all
connections with the mains with particular caution!
•Never remove warning or informative labels from the unit.
•Never use anything to cover the ground contact.
•Never lift the fixture holding it by the projector-head, as the mechanics may be damaged. Always
hold the fixture by the transport handles.
•Never place any material over the lens.
•Never look directly into the light source.
•Never leave any cables lying around.
•Do not insert objects into air vents.
•Do not connect this device to a dimmerpack.
•Do not switch the device on and off in short intervals, as this will reduce the device’s life.
•Do not touch the device’s housing bare-handed during its operation (housing becomes hot). Allow
the fixture to cool for at least 5 minutes before handling.
•Do not shake the device. Avoid brute force when installing or operating the device.
•Only use the device indoors, avoid contact with water or other liquids.
•Only operate the fixture after having checked if the housing is firmly closed and all screws are tightly
fastened.
•Only operate the device after having familiarized with its functions.
•Avoid flames and do not put close to flammable liquids or gases.
•Always keep the case closed while operating.
•Always allow a free air space of at least 50 cm around the unit for ventilation.
•Always disconnect power from the mains, when device is not used or before cleaning! Only handle
the power cord holding it by the plug. Never pull out the plug by tugging the power cord.
•Make sure that the device is not exposed to extreme heat, moisture or dust.
•Make sure that the available voltage is not higher than stated on the rear panel.
•Make sure that the power cord is never crimped or damaged. Check the device and the power
cord from time to time.
•If the lens is obviously damaged, it has to be replaced.
•If device was dropped or struck, disconnect mains power supply immediately. Have a qualified
engineer inspect for safety before operating.
•If the device has been exposed to drastic temperature fluctuation (e.g. after transportation), do not
switch it on immediately. The arising condensation water might damage your device. Leave the
device switched off until it has reached room temperature.
•If your Showtec device fails to work properly, discontinue the use immediately. Pack the unit securely
(preferably in the original packing material), and return it to your Showtec dealer for service.
•For adult use only. Moving head must be installed beyond the reach of children. Never leave the unit
running unattended.
•Never attempt to bypass the thermostatic switch or fuses.
•For replacement use fuses of same type and rating only.

5
Ordercode: 41394
Expression 550S
•The user is responsible for correct positioning and operating of the Expression. The manufacturer will
not accept liability for damages caused by the misuse or incorrect installation of this device.
•This device falls under protection class I. Therefore it is essential to connect the yellow/green
conductor to earth.
•Repairs, servicing and electric connection must be carried out by a qualified technician.
•WARRANTY: Till one year after date of purchase.
Operating Determinations
•This device is not designed for permanent operation. Consistent operation breaks will ensure that the
device will serve you for a long time without defects.
•The minimum distance between light output and the illuminated surface must be bigger than 1
meter.
•The maximum ambient temperature ta= 40°C must never be exceeded.
•The relative humidity must not exceed 50 % with an ambient temperature of 40° C.
•If this device is operated in any other way than the one described in this manual, the product may
suffer damages and the warranty becomes void.
•Any other operation may lead to dangers like short-circuit, burns, electric shock, crash, etc.
You endanger your own safety and the safety of others!
Rigging
Please follow the European and national guidelines concerning rigging, trussing and all
other safety issues.
Do not attempt the installation yourself !
Always let the installation be carried out by an authorized dealer !
Procedure:
•If the projector is lowered from the ceiling or high joists, professional trussing systems have to be used.
•Use a clamp to mount the projector, with the mounting bracket, to the trussing system.
•The projector must never be fixed swinging freely in the room.
•The installation must always be secured with a safety attachment, e.g. an appropriate safety net or
safety cable.
•When rigging, derigging or servicing the projector, always make sure, that the area below the
installation site is secured and that there are not any unauthorized people around.

6
Ordercode: 41394
Expression 550S
The Expression can be placed on a flat stage floor or mounted to any kind of truss with a clamp or quick
locks.
Improper installation can cause serious injuries and/or damage of property!
Connection with the mains
Connect the device to the mains with the power-plug.
Always check if the right color cable is connected to the right place.
International EU Cable UK Cable US Cable Pin
L BROWN RED YELLOW/COPPER PHASE
N BLUE BLACK SILVER NEUTRAL
YELLOW/GREEN GREEN GREEN PROTECTIVE
GROUND
Make sure that the device is always properly connected to the earth!
Improper installation can cause serious injuries and/or damage of property!

7
Ordercode: 41394
Expression 550S
Return Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned
without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility.
Call Highlite 0031-455667723 or mail [e-mail] and request an RMA prior to shipping the fixture.
Be prepared to provide the model number, serial number and a brief description of the cause for the
return. Be sure to properly pack fixture, any shipping damage resulting from inadequate packaging is the
customer’s responsibility. Highlite reserves the right to use its own discretion to repair or replace
product(s). As a suggestion, proper UPS packing or double-boxing is always a safe method to use.
Note: If you are given an RMA number, please include the following information on a piece of paper
inside the box:
01) Your name
02) Your address
03) Your phone number
04) A brief description of the symptoms
Claims
The client has the obligation to check the delivered goods immediately upon delivery for any short-
comings and/or visible defects, or perform this check after our announcement that the goods are at their
disposal. Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise.
It is the customer's responsibility to report and submit claims with the shipper in the event that a fixture is
damaged due to shipping. Transportation damage has to be reported to us within one day after receipt
of the delivery.
Any return shipment has to be made post-paid at all times. Return shipments must be accompanied with
a letter defining the reason for return shipment. Non-prepaid return shipments will be refused, unless
agreed otherwise in writing.
Complaints against us must be prepared in writing or sent by fax within 10 working days after receipt of
the invoice. After this period complaints will not be handled anymore.
Complaints will only then be considered if the client has so far complied with all parts of the agreement,
regardless of the agreement from which the obligation is resulting.

8
Ordercode: 41394
Expression 550S
Description of the device
Features
The Expression 550S is a moving head with high output and great effects.
Input voltage: 100-240V AC, 60/50Hz
Power consumption: 105W
Light source: 1 x RGBW 60W LED
Light output: 4400 Lux @ 2m
DMX channels: 17, 17, 18, 23 channels
LCD display for easy setup
Control modes: Auto, Manual (Custom), Master/Slave, DMX-512
Control protocol: DMX-512
Beam angle: 12°
Motorized focus
Dimmer: 0-100%
Strobe: 0-20Hz
Pan: continuous
Tilt: 270°
Gobo wheel: 8 metal gobos + open
3-facet prism
Housing: Metal & flame retardant plastic
Connections: 3-pin/5-pin XLR data connectors & PowerCON power connector IN/OUT
IP rating: IP20
Fuse: T2,5AL/250V
Dimensions: 205 x 240 x 355 mm (LxWxH)
Weight: 7,4 kg
Optional accessories:
MOD41394 – Wireless DMX upgrade kit
90600 – Pro Power to Schuko, power cable (1,5 m)
90601 – Pro Power to Schuko, power cable (3 m)
90602 – Pro Power to Schuko, power cable (6 m)
90603 – Pro Power to Schuko, power cable (10 m)
90604 – Pro Power to Schuko, power cable (20 m)
The Wireless DMX upgrade kit should be installed ONLY by a qualified technician.
Do not attempt installation yourself!
Frontside
Fig. 01
01) LED Lens
02) LCD display + menu buttons

9
Ordercode: 41394
Expression 550S
Backside
Fig. 02
03) Fuse T2,5AL/250V
04) PowerCON power connector 100-240V IN
05) PowerCON power connector 100-240V OUT
06) 5-pin DMX signal connector IN
07) 3-pin DMX signal connector IN
08) 3-pin DMX signal connector OUT
09) 5-pin DMX signal connector OUT
Installation
Remove all packing materials from the Expression 550S. Check if all foam and plastic padding is
removed. Connect all cables.
Do not supply power before the whole system is set up and connected properly.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
Set Up and Operation
Follow the directions below, as they pertain to your preferred operation mode.
Before plugging the unit in, always make sure that the power supply matches the product specification
voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa.
Connect the device to the main power supply.

10
Ordercode: 41394
Expression 550S
Control Modes
There are 4 modes: • Auto
•Manual (Custom)
•Master/Slave
•DMX-512 (17CH, 17CH, 18CH, 23CH)
One Expression (Auto and Manual)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Plug the end of the electric mains power cord into a proper electric power supply socket.
03) When the Expression is not connected with a DMX cable, it functions as a stand-alone device.
Please see page 19 for more information about the Auto mode (AUTO1, AUTO2) and Manual mode
(CUSTOM).
Multiple Expressions (Master/Slave control)
01) Fasten the effect light onto firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Use a 3-pin/5-pin XLR cable to connect the Expression.
The pins:
01) Earth
02) Signal -
03) Signal +
03) Link the units as shown in fig. 03. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
You can use the same functions on the master device as described on page 19 (Auto or Custom).
This means that you can set your desired operation mode on the master device and all slave
devices will react the same as the master device.
Multiple Expressions (Master/Slave control)
Fig. 03

11
Ordercode: 41394
Expression 550S
Multiple Expressions (DMX Control)
01) Fasten the effect light to a firm trussing. Leave at least 0,5 meter on all sides for air circulation.
02) Always use a safety cable (ordercode 70140 / 70141).
03) Use a 3-pin/5-pin XLR cable to connect the Expressions and other devices.
04) Link the units as shown in fig. 04. Connect the first unit's DMX "out" socket with the second unit's "in"
socket, using a DMX-signal cable. Repeat this process to link the second, third, and fourth units.
05) Supply electric power: Plug electric mains power cords into each unit's PowerCON socket, then plug
the other end of the mains power cord into proper electric power supply sockets, starting with the
first unit. Do not supply power before the whole system is set up and connected properly.
Multiple Expressions DMX Set Up
Fig. 04
Note : Link all cables before connecting electric power

12
Ordercode: 41394
Expression 550S
Fixture Linking
You will need a serial data link to run light shows of one or more fixtures using a DMX-512 controller or to
run synchronized shows of two or more fixtures set to a master/slave operating mode. The combined
number of channels required by all the fixtures on a serial data link determines the number of fixtures the
data link can support.
Important: Fixtures on a serial data link must be daisy-chained in a single line. To comply with the
EIA-485 standard, no more than 30 devices should be connected on one data link.
Connecting more than 30 fixtures on one serial data link without the use of a DMX
optically isolated splitter may result in deterioration of the digital DMX signal.
Maximum recommended DMX data link distance: 100 meters
Maximum recommended number of fixtures on a DMX data link: 30 fixtures
Maximum recommended number of fixtures on a power link @ 110V: 7 fixtures
Maximum recommended number of fixtures on a power link @ 240V: 13 fixtures
Data Cabling
To link fixtures together, you must obtain data cables. You can purchase DAP Audio certified DMX cables
directly from a dealer/distributor or construct your own cable. If you choose to create your own cable,
please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic
interference.
DAP Audio DMX Data Cables
•DAP Audio Basic microphone cable for allround use. bal. XLR/M 3-pin > XLR/F 3-pin.
Ordercode FL01150 (1,5 m), FL013 (3 m), FL016 (6 m), FL0110 (10 m), FL0115 (15 m), FL0120 (20 m).
•DAP Audio X-type data cable XLR/M 3-pin > XLR/F 3-pin. Ordercode FLX0175 (0,75 m),
FLX01150 (1,5 m), FLX013 (3 m), FLX016 (6 m), FLX0110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL71150 (1,5 m), FL713 (3 m), FL716 (6 m), FL7110 (10 m).
•DAP Audio cable for the demanding user with exceptional audio-qualities and connector made by
Neutrik®. Ordercode FL7275 (0,75 m), FL72150 (1,5 m), FL723 (3 m), FL726 (6 m), FL7210 (10 m).
•DAP Audio 110 Ohm cable with digital signal transmission. Ordercode FL0975 (0,75 m),
FL09150 (1,5 m), FL093 (3 m), FL096 (6 m), FL0910 (10 m), FL0915 (15 m), FL0920 (20 m).

13
Ordercode: 41394
Expression 550S
The Expression 550S can be operated with a controller in control mode or without the controller in
stand-alone mode.
Control Panel
A) MENU button
B) ENTER button
C) DOWN button
D) UP button
E) LCD display
Fig. 05
Control Mode
The fixtures are individually addressed on a data-link and connected to the controller.
The fixtures respond to the DMX signal from the controller. (When you select the DMX address and save it,
the controller will display the saved DMX address, next time.)
DMX Addressing
The control panel on the front side of the base allows you to assign DMX fixture addresses, which is the first
channel with which the Expression will respond to the controller.
Please note, when you use the controller, the unit has 23 channels.
When using multiple Expressions, make sure you set the DMX addresses right.
Therefore, the DMX address of the first Expression should be 1(001); the DMX address of the second
Expression should be 1+23=24 (024); the DMX address of the third Expression should be 24+23=47 (047),
etc. Please, be sure that you do not have any overlapping channels in order to control each Expression
correctly. If two or more Expressions are addressed similarly, they will work similarly.
Controlling:
After having addressed all Expression fixtures, you may now start operating these via your lighting
controller.
Note: After switching on, the Expression will automatically detect whether DMX 512 data is received or
not. If there is no data received at the DMX-input, the “LED “ on the control panel will not flash.
If not, the problem may be:
•The XLR cable from the controller is not connected with the input of the Expression 550S.
•The controller is switched off or defective, the cable or connector is detective, or the signal wires are
swapped in the input connector.
Note: It is necessary to insert an XLR termination plug (with 120 Ohm) in the last fixture in order to ensure
proper transmission on the DMX data link.
Display Off after 30 seconds
When no button is pressed for 30 seconds, the display will turn off.
To light up the display, you have to press the MENU, ENTER, UP or DOWN button.
Once you have pressed the button, the display will light up.

14
Ordercode: 41394
Expression 550S
Menu Overview

15
Ordercode: 41394
Expression 550S
Main Menu Options
01) On start-up, the device will display information about the device’s current temperature, DMX
address, current channel mode and the software version.
02) Press the ENTER button to open the main menu.
03) Press the UP/DOWN buttons to toggle through the main menu options.
04) Press the ENTER button to open the desired submenu.
1. Address
With this menu you can set the desired DMX starting address.
01) Press the UP/DOWN buttons to set the desired DMX starting address. The adjustment range is
between 001-512.
02) Press the ENTER button to save settings.

16
Ordercode: 41394
Expression 550S
2. Personality
With this menu you can set the desired DMX channel mode/personality.
01) Press the UP/DOWN buttons to choose one of the 4 channel modes HSIC (17 channels), PERSON1 (18
channels), PERSON2 (23 channels) or CMY (17 channels):
02) Press the ENTER button to confirm your choice.
3. Perform
With this menu you can adjust various settings, crucial for the performance of the device.
01) Press the UP/DOWN buttons to toggle through the menu.
02) Press the ENTER button to open the desired submenu. The submenus are:
3.1. Fans
01) Press the UP/DOWN buttons to choose one of the available fan speed modes: SLOW, NORMAL, FAST
and AUTO.
02) If you have chosen AUTO, the fan speed will depend on the device’s current temperature and will
be adjusted automatically.
3.2. Pan/Tilt
01) Press the UP/DOWN buttons to choose between PAN INVERT (pan inversion), TILT INVERT (tilt inversion)
or P/T SPEED (pan/tilt speed).
02) If you have chosen PAN INVERT or TILT INVERT, press the ENTER button to open the menu. Press the
UP/DOWN buttons to choose between NORMAL and INVERT and press the ENTER button to confirm
your choice and perform pan/tilt inversion.
03) If you have chosen P/T SPEED, press the ENTER button to open the menu. Press the UP/DOWN buttons
to choose between FAST and SLOW and press the ENTER button to confirm your choice.

17
Ordercode: 41394
Expression 550S
3.3. Blackout
01) Press the UP/DOWN buttons to choose between OFF and ON.
02) Press the ENTER button to confirm your choice.
03) If you have chosen ON, the light output will be blacked out during pan/tilt movement.
3.4. Dimmer
01) Press the UP/DOWN buttons to choose one of the 4 dimming curves (DIM1-4) or OFF.
02) Press the ENTER button to confirm your choice.
3.5. Color
01) Press the UP/DOWN buttons to choose one of the color options: UC, RGB to W or OFF.
02) Press the ENTER button to confirm your choice.
3.6. DMX Error
01) Press the UP/DOWN buttons to choose between SAVE and BLACK.
02) Press the ENTER button to confirm your choice.
03) If you have chosen SAVE, the device will use the last working DMX input.
04) If you have chosen BLACK, the device will black out its output.
3.7. DMX Reset
01) Press the UP/DOWN buttons to choose between DMX and DISPLAY.
02) Press the ENTER button to confirm your choice.
03) Press the UP/DOWN buttons to choose YES or NO.
04) If you have chosen YES, press the ENTER button to reset DMX/display.
3.8. Display On
01) Press the UP/DOWN buttons to choose between SHORT and LONG.
02) Press the ENTER button to confirm your choice.
03) If you have chosen SHORT, the display will turn off if no button is pressed for 30 seconds.
04) If you have chosen LONG, the display will remain continuously on.
3.9. Display Lock
01) Press the UP/DOWN buttons to choose between ON and OFF.
02) Press the ENTER button to confirm your choice.
03) If you have chosen ON, the display will be locked and, in order to gain access to the menu, it will be
necessary to insert the password. The password can be inserted by pressing the buttons in the
following order: UP, DOWN, UP, DOWN and ENTER to confirm.
3.10. Upload
01) Press the UP/DOWN buttons to choose one of the 2 options:
LOAD PARA (the device will send the following parameters to the connected slave devices:
Fans, Pan/Tilt, Blackout, Dimmer, Color, Display On, Display Lock, Setting Lock, Service Lock and
Calib.M Pan/Tilt)
LOAD EDIT (the device will send the settings from Edit menu to the connected slave devices).
02) Press the ENTER button to confirm.
03) Press the UP/DOWN buttons to choose between YES or NO and press the ENTER button to confirm
your choice.

18
Ordercode: 41394
Expression 550S
3.11. Settings
01) Press the UP/DOWN buttons to choose between the following options:
02) Press the ENTER button to open the desired menu.
3.11.1. Settings Lock
01) Press the UP/DOWN buttons to choose between ON and OFF.
02) Press the ENTER button to confirm your choice.
03) If you have chosen ON, the display will be locked and in order to gain access to the settings menu, it
will be necessary to insert the password. The password can be inserted by pressing the buttons in the
following order: UP, DOWN, UP, DOWN and ENTER to confirm.
3.11.2. Service Lock
01) Press the UP/DOWN buttons to choose between ON and OFF.
02) Press the ENTER button to confirm your choice.
03) If you have chosen ON, the display will be locked and in order to gain access to Service menu, it will
be necessary to insert the password. The password can be inserted by pressing the buttons in the
following order: UP, DOWN, UP, DOWN and ENTER to confirm.
3.11.3. Recovery
01) In order to restore the factory settings, it will be necessary to insert the password. The password can
be inserted by pressing the buttons in the following order: UP, DOWN, UP, DOWN and ENTER to
confirm.
3.11.4. Wireless DMX Hide
01) Press the UP/DOWN buttons to choose between YES and NO.
02) Press the ENTER button to confirm your choice.
03) If you have chosen YES, you will not see WDMX menu in Perform section (3.12.).
3.12. Wireless DMX
01) Press the UP/DOWN buttons to select WDMX and press the ENTER button to enter the submenu. The
display will show:
02) Press the ENTER button to open.
03) Press the UP/DOWN buttons to choose between OFF and ON.
04) Press the ENTER button to confirm your choice.
05) If you have chosen ON, the wireless DMX will be reset.
06) If you have chosen OFF, the wireless DMX will remain active.

19
Ordercode: 41394
Expression 550S
4. Stand-alone
With this menu you can set the desired operation mode.
01) Press the UP/DOWN buttons to toggle between RUN and EDIT.
02) Press the ENTER button to open the desired menu.
4.1. Run
01) Press the UP/DOWN buttons to choose one of the following 6 operation modes:
DMX512 (The device will react to user’s DMX input.)
AUTO1 and AUTO2 (The device will run the desired built-in program.)
CUSTOM (The device’s behavior depends on the adjustments made in EDIT menu, see page 19.)
TEST (The device will test all its functions and features.)
SLAVE (The device will react the same as the master device.)
02) Press the ENTER button to confirm your choice.
4.2. Edit
With this menu you can create your own custom show, consisting of a maximum of 50 steps.
01) Once you have entered EDIT menu, the display will show:
02) Press the UP/DOWN buttons to select the number of the step which you want to edit. It is possible to
add/edit a maximum of 50 steps.
03) Once you have chosen the step, press the ENTER button to proceed to edition mode. The display will
show:
