Show Tec Performer Profile 700 Q6 User manual

Performer Profile 700 Q6
Highlite International B.V. –Vestastraat 2 –6468 EX –Kerkrade –the Netherlands
Product code: 33067
USER MANUAL
ENGLISH
V1

1
Performer Profile 700 Q6
Product code: 33067
Preface
Thank you for purchasing this Showtec product.
The purpose of this user manual is to provide instructions for the correct and safe use of this product.
Keep the user manual for future reference as it is an integral part of the product. The user manual shall be
stored at an easily accessible location.
This user manual contains information concerning:
●Safety instructions
●Installation and operation of the device
●Intended and non-intended use of the device
●Maintenance procedures
●Troubleshooting
●Transport, storage and disposal of the device
Non-observance of the instructions in this user manual may result in serious injuries and damage of
property.
©2023 Showtec. All rights reserved.
No part of this document may be copied, published or otherwise reproduced without the prior written
consent of Highlite International.
Design and product specifications are subject to change without prior notice.
For the latest version of this document or other language versions, please visit our website
www.highlite.com or contact us at [e-mail].
Highlite International and its authorized service providers are not liable for any injury, damage, direct or
indirect loss, consequential or economic loss or any other loss arising from the use of, or inability to use or
reliance on the information contained in this document.

2
Performer Profile 700 Q6
Product code: 33067
Table of contents
1. Introduction..........................................................................................................................................................4
Before Using the Product ..................................................................................................................................4
Intended Use .......................................................................................................................................................4
Product Lifespan.................................................................................................................................................4
LEDs Lifespan .......................................................................................................................................................4
Text Conventions ................................................................................................................................................4
Symbols and Signal Words................................................................................................................................5
Symbols on the Information Label ..................................................................................................................5
2. Safety ....................................................................................................................................................................6
Warnings and Safety Instructions ....................................................................................................................6
Requirements for the User.................................................................................................................................8
3. Description of the Device ...................................................................................................................................9
Front View ............................................................................................................................................................9
Back View ............................................................................................................................................................9
Product Specifications ....................................................................................................................................10
Optional Accessories.......................................................................................................................................11
Dimensions.........................................................................................................................................................11
4. Installation ..........................................................................................................................................................12
Safety Instructions for Installation ..................................................................................................................12
Installation Site Requirements ........................................................................................................................12
Rigging ...............................................................................................................................................................13
Angle Adjustment ............................................................................................................................................14
Connecting to Power Supply.........................................................................................................................15
Power Linking of Multiple Devices.................................................................................................................15
5. Setup ...................................................................................................................................................................16
Warnings and Precautions .............................................................................................................................16
Stand-alone Setup ...........................................................................................................................................16
DMX Connection..............................................................................................................................................16
DMX-512 Protocol...................................................................................................................................16
DMX Cables.............................................................................................................................................17
Master/Slave Setup ................................................................................................................................18
DMX Linking .............................................................................................................................................19
DMX Addressing......................................................................................................................................19
Beam Shaping with Shutters...........................................................................................................................20
Gobo Installation..............................................................................................................................................21
Iris Installation.....................................................................................................................................................22
Lens Installation.................................................................................................................................................23
Fixed-angle Lens Installation ................................................................................................................23
Zoom Lens Installation............................................................................................................................24
6. Operation ...........................................................................................................................................................25
Safety Instructions for Operation...................................................................................................................25
Control Modes ..................................................................................................................................................25
Control Panel ....................................................................................................................................................26
Start-up...............................................................................................................................................................26
Menu Overview ................................................................................................................................................27
Main Menu Options .........................................................................................................................................31
Static Colors.............................................................................................................................................31
DMX Address ...........................................................................................................................................32
Run Mode ................................................................................................................................................32
Personality................................................................................................................................................32
Auto Programs ........................................................................................................................................33
Edit.............................................................................................................................................................34
Setting.......................................................................................................................................................36

3
Performer Profile 700 Q6
Product code: 33067
Reset .....................................................................................................................................................37
DMX Error..............................................................................................................................................37
Disp Key................................................................................................................................................37
Information ..............................................................................................................................................38
Correlated Color Temperature (CCT) ................................................................................................38
Preset Color .............................................................................................................................................38
DMX Channels ..................................................................................................................................................39
DMX Channels Overview ......................................................................................................................39
BASIC (3 channels), SSP (8 channels), TOUR (13 channels), TR16 (20 channels)........................40
HSIC (7 channels) ...................................................................................................................................43
CMY (10 channels) .................................................................................................................................44
RDM Information...............................................................................................................................................47
RDM Details..............................................................................................................................................47
Supported RDM PIDs (Parameter IDs) ................................................................................................48
7. Troubleshooting .................................................................................................................................................49
8. Maintenance .....................................................................................................................................................50
Safety Instructions for Maintenance.............................................................................................................50
Preventive Maintenance................................................................................................................................50
Basic Cleaning Instructions ...................................................................................................................50
Corrective Maintenance................................................................................................................................51
Replacing the Fuse ................................................................................................................................51
9. Deinstallation, Transportation and Storage ....................................................................................................52
Instructions for Transportation ........................................................................................................................52
Instructions for Deinstallation..........................................................................................................................52
Storage...............................................................................................................................................................52
10. Disposal ..............................................................................................................................................................52
11. Approval.............................................................................................................................................................52

4
Performer Profile 700 Q6
Product code: 33067
1. Introduction
Before Using the Product
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
After unpacking, check the contents of the box. If any parts are missing or damaged, contact your
Highlite International dealer.
Your shipment includes:
●Showtec Performer Profile 700 Q6
●Schuko to power pro cable (1,5 m)
●Safety cable
●User manual
Fig. 01
Intended Use
This device is intended for use as a professional stage luminaire and is suitable for indoor installation only.
It is not suitable for households or for general lighting.
Any other use, not mentioned under intended use, is regarded as non-intended and incorrect use.
Product Lifespan
This device is not designed for permanent operation. Disconnect the device from the electrical power
supply when it is not in use. This will reduce wear and improve the device’s lifespan.
LEDs Lifespan
The light output of LEDs gradually decrease over time (lumen depreciation). High operating temperatures
contribute to this process. The lifespan of LEDs can be extended by ensuring adequate ventilation and
operating the LEDs at the lowest possible brightness.
Text Conventions
Throughout the user manual the following text conventions are used:
●Buttons: All buttons are in bold lettering, for example “Press the UP/DOWN buttons”
●References: References to chapters and parts of the device are in bold lettering, for example:
“Refer to 2. Safety”, “turn the adjustment handle (05)”
●0–255: Defines a range of values
●Notes: Note: (in bold lettering) is followed by useful information or tips

5
Performer Profile 700 Q6
Product code: 33067
Symbols and Signal Words
Safety notes and warnings are indicated throughout the user manual by safety signs.
Always follow the instructions provided in this user manual.
DANGER
Indicates an imminently hazardous situation which, if not avoided, will result in
serious injury or death.
WARNING
Indicates an imminently hazardous situation which, if not avoided, could result
in serious injury or death.
CAUTION
Indicates a potentially hazardous situation, which, if not avoided, may result in
minor or moderate injury.
Attention
Indicates important information for the correct operation and use of the
product.
Important
Read and observe the instructions in this document.
Provides important information about the disposal of this product.
Symbols on the Information Label
This product is provided with an information label. The information label is located on the mounting
bracket of the device.
The information label contains the following symbols:
This device is designed for indoor use.
This device falls under IEC protection class I.
This device shall not be treated as household waste.

6
Performer Profile 700 Q6
Product code: 33067
2. Safety
Important
Read and follow the instructions in this user manual before installing, operating or
servicing this product.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of
this manual.
Warnings and Safety Instructions
DANGER
Danger for children
For adult use only. The device must be installed beyond the reach of children.
●Do not leave various parts of the packaging (plastic bags, polystyrene foam, nails, etc.) within
children’s reach. Packaging material is a potential source of danger for children.
DANGER
Electric shock caused by dangerous voltage inside
There are areas within the device where dangerous touch voltage (> 120 V DC) may be present.
●Do not open the device or remove any covers.
●Do not operate the device if the covers or the housing are open. Before operation, check if the
housing is firmly closed and all screws are tightly fastened.
●Disconnect the device from the electrical power supply before service and maintenance, and when
the device is not in use.
DANGER
Electric shock caused by short-circuit
This device falls under IEC protection Class I.
●Make sure that the device is electrically connected to ground (earth). Connect the device only to a
socket-outlet with ground (earth) connection.
●Do not cover the ground (earth) connection.
●Do not bypass the thermostatic switch or fuses.
●For replacement use fuses of the same type and rating only.
●Do not let the power cable come into contact with other cables. Handle the power cable and all
connections with the mains with caution.
●Do not modify, bend, mechanically strain, put pressure on, pull or heat up the power cable.
●Make sure that the power cable is not crimped or damaged. Examine the power cable periodically
for any defects.
●Do not immerse the device in water or other liquids. Do not install the device in a location where
flooding may occur.
●Do not use the device during thunderstorms. Disconnect the device from the electrical power supply
immediately.

7
Performer Profile 700 Q6
Product code: 33067
WARNING
Possible eye damage caused by high light intensity
Possibly hazardous optical radiation emitted from this device.
●Do not look at the operating light source. May be harmful to the eye.
●Do not look at the light source with optical instruments that may concentrate the light output.
●Make sure that persons are not looking directly into the light source when the device lights up
suddenly. This can happen when the device is powered or when it receives DMX signal, or when
certain menu items are selected.
●Disconnect power supply before servicing.
●Wear protective goggles if looking into light source during service or maintenance.
WARNING
Risk of epileptic shock
Strobe lighting can trigger seizures in photosensitive epilepsy. Sensitive persons should avoid looking at
strobe lights.
Attention
Power supply
●Before connecting the device to the power supply, make sure that the current, voltage and
frequency match the input voltage, current and frequency specified on the information label on the
device.
●Make sure that the cross-sectional area of the extension cords and power cables is sufficient for the
required power consumption of the device.
Attention
General safety
●Do not connect this device to a dimmer pack.
●Do not switch the device on and off in short intervals. This reduces the device’s life.
●Do not shake the device. Avoid brute force when installing or operating the device.
●Change the lens or the LEDs if they are visibly damaged to such an extent that their effectiveness is
impaired, for example by cracks or deep scratches. Contact your Highlite International dealer for
more information, as servicing can be performed only by instructed or skilled persons.
●If the device is dropped or struck, disconnect the device from the electrical power supply
immediately.
●If the device fails to work properly, discontinue use immediately.

8
Performer Profile 700 Q6
Product code: 33067
Attention
For professional use only
This device shall be used only for the purposes it is designed for.
This device is designed to be used as a professional stage luminaire. Any incorrect use may lead to
hazardous situations and result in injuries and material damage.
●This device is not suitable for households and for general lighting.
●This device is not designed for permanent operation.
●This device does not contain user-serviceable parts. Unauthorized modifications to the device will
render the warranty void. Such modifications may result in injuries and material damage.
Attention
Before each use, examine the device visually for any defects.
Make sure that:
●All screws used for installing the device or parts of the device are tightly fastened and are not
corroded.
●The safety devices are not damaged.
●There are no deformations on housings, fixations and installation points.
●The lens is not cracked or damaged.
●The power cables are not damaged and do not show any material fatigue.
Attention
Do not expose the device to conditions that exceed the rated IP class conditions.
This device is IP20 rated. IP (Ingress Protection) 20 class provides protection against solid objects greater
than 12 mm, such as fingers, and no protection against harmful ingress of water.
Requirements for the User
This product may be used by ordinary persons. Installation, service and maintenance shall be carried out
only by instructed or skilled persons. Contact your Highlite International dealer for more information.
Instructed persons have been instructed and trained by a skilled person, or are supervised by a skilled
person, for specific tasks and work activities associated with the service of this product, so that they can
identify risks and take precautions to avoid them.
Skilled persons have training or experience, which enables them to recognize risks and to avoid hazards
associated with the installation, service and maintenance of this product.
Ordinary persons are all persons other than instructed persons and skilled persons. Ordinary persons
include not only users of the product but also any other persons that may have access to the device or
who may be in the vicinity of the device.

9
Performer Profile 700 Q6
Product code: 33067
3. Description of the Device
The Showtec Performer Profile 700 Q6 is a professional stage luminaire with an iris slot and a gobo slot. It is
equipped with four shutters.
Front View
01) Barrel screw (x2)
02) Safety eye 1
03) Safety eye 2
04) Mounting bracket
05) Adjustment handle
06) Barrel
07) Iris slot screw
08) Iris slot cover
09) Iris slot
10) Gobo slot
11) Shutter (x4)
Fig. 02
Back View
12) Control panel: OLED display and control
buttons
13) Power-pro connector OUT 100–240 V
14) 5-pin DMX signal connector OUT
15) Fuse T 6.3 A
16) 5-pin DMX signal connector IN
17) Power-pro connector IN 100–240 V
Fig. 03

10
Performer Profile 700 Q6
Product code: 33067
Product Specifications
Model:
Performer Profile 700 Q6
Electrical:
Input voltage:
100–240 V AC, 50/60 Hz
Power consumption:
300 W
Fuse:
T 6,3 A / 250 V
Physical:
Dimensions:
685 x 238 x 499 mm (L x W x H) (without accessories)
Weight:
8 kg (without accessories)
Optics:
Light source:
1 x 300 W RGBACL LED
Dimmer:
0–100 %
Strobe:
0–25 Hz
Output:
23862 lx @ 2 m, 10605 lx @ 3 m, 3818 lx @ 5 m
CRI:
95
CCT:
1800–10000 K
Luminous flux (Total):
10276 lm
Luminous flux (Red):
1289 lm
Luminous flux (Green):
2119 lm
Luminous flux (Blue):
295 lm
Luminous flux (Amber):
1720 lm
Luminous flux (Lime):
3756 lm
Luminous flux (Cyan):
857 lm
Refresh rate:
1200 Hz–25 kHz
Operation and control:
Control:
Stand-alone (manual), master/slave, DMX-512
DMX channels:
BASIC (3 channels), HSIC (7 channels), SSP (8 channels), CMY (10
channels), TOUR (13 channels), TR16 (20 channels)
Control panel:
OLED display and buttons
Connections:
Power connections:
Power Pro True connectors IN/OUT
Data connections:
5-pin DMX signal connectors IN/OUT
Signal pinouts:
Pin 1 (ground), pin 2 (-), pin 3 (+), pin 4 (N/C), pin 5 (N/C)
Construction:
Housing:
Aluminum
Color:
Black
IP rating:
IP20
Cooling:
Convection/Axial fan
Thermal:
Maximum ambient temperature ta:
45 °C
Minimum ambient temperature ta:
0 °C
Minimum distance:
Minimum distance from flammable surfaces:
0,5 m

11
Performer Profile 700 Q6
Product code: 33067
Optional Accessories
●Product code: 33070 (Zoom Lens for Performer Profile)
●Product code: 33071 (Zoom Lens for Performer Profile)
●Product code: 33072 (19°Lens for Performer Profile)
●Product code: 33073 (36° Lens for Performer Profile)
●Product code: 33074 (50° Lens for Performer Profile)
●Product code: 33075 (26° Lens for Performer Profile)
●Product code: 33076 (Iris for Performer)
●Product code: 33077 (Gobo Holder with Soft Edge for Performer Profile)
●Product code: 33078 (Metal Gobo Holder for Performer Profile)
●Product code: 33079 (Glass Gobo Holder for Performer Profile)
Dimensions
Fig. 04
Fig. 05

12
Performer Profile 700 Q6
Product code: 33067
4. Installation
Safety Instructions for Installation
WARNING
Incorrect installation can cause serious injuries and damage of property.
If trussing systems are used, installation must be carried out only by instructed or skilled persons.
Follow all applicable European, national and local safety regulations concerning rigging and trussing.
Installation Site Requirements
●The device can be used indoors only.
●The device can be mounted to a truss or another rigging structure in any orientation.
●The minimum distance to other objects must be bigger than 0,5 m.
●The maximum ambient temperature ta= 45 °C must never be exceeded.
●The relative humidity must not exceed 50 % with an ambient temperature of 45 °C.

13
Performer Profile 700 Q6
Product code: 33067
Rigging
The device can be mounted to a truss or other rigging structure in any orientation. Make sure that all
loads are within the pre-determined limits of the supporting structure.
CAUTION
Restrict the access under the work area during rigging and/or derigging.
To mount the device, follow the steps below:
Use a clamp to attach the device to the supporting structure, as shown in Fig. 06. Make sure that the
device cannot move freely.
02) Secure the device with a secondary suspension, for example a safety cable. Make sure that the
secondary suspension can hold 10 times the weight of the device. If possible, the secondary
suspension should be attached to a supporting structure independent of the primary suspension. Put
the safety cable through one of the safety eyes (02 or 03), as shown in Fig. 06.
Fig. 06

14
Performer Profile 700 Q6
Product code: 33067
Angle Adjustment
You can adjust the angle of the device with the adjustment handle (05).
Turn the adjustment handle (05) counterclockwise to loosen it (see Fig. 07).
02) Tilt the device to the desired angle.
03) Turn the adjustment handle (05) clockwise to tighten it. Make sure that the device cannot move
freely after the adjustment handle (05) is tightened.
Fig. 07

15
Performer Profile 700 Q6
Product code: 33067
Connecting to Power Supply
DANGER
Electric shock caused by short-circuit
The device can be powered by 100–240 V 50/60 Hz AC mains power. Do not supply mains power at any
other voltage or frequency to the device.
This device falls under IEC protection class 1. Make sure that the device is always electrically connected
to the ground (earth).
Before connecting the device to the socket-outlet:
●Make sure that the power supply matches the input voltage specified on the information label on
the device.
●Make sure that the socket-outlet has a ground (earth) connection.
Connect the device to the socket outlet with the power plug. Do not connect the device to a dimmer
circuit, as this may damage the device.
Power Linking of Multiple Devices
This device supports power linking. Power can be relayed to another device via the power OUT
connector. Note that the input and the output connectors have different designs: one type cannot be
connected to the other.
Power linking of multiple devices must be carried out only by instructed or skilled persons.
WARNING
Incorrect power linking may lead to overload of the electrical circuit and result in serious
injuries and damage of property.
To prevent overload of the electrical circuit, when power linking multiple devices:
●Use cables with sufficient current-carrying capacity. The power cable supplied with the device is not
suitable for power linking of multiple devices.
●Make sure that the total current draw of the device and all connected devices does not exceed the
rated capacity of the power cables and the circuit breaker.
●Do not link more devices on one power link than the maximum recommended number.
Maximum recommended number of devices:
●at 100–120 V: 3 devices Performer Profile 700 Q6
●at 200–240 V: 6 devices Performer Profile 700 Q6

16
Performer Profile 700 Q6
Product code: 33067
5. Setup
Warnings and Precautions
Attention
Connect all data cables before supplying power.
Disconnect power supply before connecting or disconnecting data cables.
Stand-alone Setup
When the Performer Profile 700 Q6 is not connected to a controller or to other devices, it functions as a
stand-alone device. It can be operated manually via the control panel.
For more information about the control modes, refer to 6.2. Control Modes on page 25.
DMX Connection
DMX-512 Protocol
You need a DMX serial data link to run light shows of one or more devices using a DMX-512 controller.
The Performer Profile 700 Q6 has 5-pin DMX signal IN and OUT connectors.
The pin assignment is as follows: pin 1 (ground), pin 2 (-), pin 3 (+), pin 4 (N/C), pin 5 (N/C).
Devices on a serial data link must be daisy-chained in a single line. The number of devices that you can
control on one data link is limited by the combined number of the DMX channels of the connected
devices and the 512 channels available in one DMX universe.
To comply with the TIA-485 standard, no more than 32 devices should be connected on one data link.
In order to connect more than 32 devices on one data link, you must use a DMX optically isolated
splitter/booster, otherwise this may result in deterioration of the DMX signal.
Notes:
●Maximum recommended DMX data link distance: 300 m
●Maximum recommended number of devices on a DMX data link: 32 devices

17
Performer Profile 700 Q6
Product code: 33067
DMX Cables
Shielded twisted-pair cables with 5-pin XLR connectors must be used for a reliable DMX connection.
You can purchase DMX cables directly from your Highlite International dealer or make your own cables.
If you use XLR audio cables for DMX data transmission, this may lead to signal degradation and unreliable
operation of the DMX network.
When you make your own DMX cables, make sure that you connect the pins and wires correctly as
shown in Fig. 08.
Fig. 08

18
Performer Profile 700 Q6
Product code: 33067
Master/Slave Setup
The Performer Profile 700 Q6 supports master/slave control mode. To connect multiple devices in a
master/slave setup, follow the steps below:
Connect the DMX OUT connector on the first device to the DMX IN connector on the second device
with a 5-pin DMX cable. The first connected device in the setup will be automatically recognized as
the master device.
Repeat step 1 to connect all devices as shown in Fig. 09.
Set all subsequent devices in the setup as slave devices. See 6.6.3 Run Mode on page 32 for more
information.
Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device in the setup.
Fig. 09

19
Performer Profile 700 Q6
Product code: 33067
DMX Linking
To connect multiple devices on one DMX data link, follow the steps below:
Connect the DMX OUT connector on the lighting controller to the DMX IN connector on the first
device with a 5-pin DMX cable.
02) Connect the DMX OUT connector on the first device to the DMX IN connector on the second device
with a 5-pin DMX cable.
03) Repeat step 2 to connect all devices in a daisy-chain as shown in Fig. 10.
04) Connect a DMX terminator (120 Ω resistor) to the DMX OUT connector of the last device on the data
link.
Fig. 10
DMX Addressing
In a setup with multiple devices, make sure that you set the DMX starting address of each device
correctly. The Performer Profile 700 Q6 has 6 personalities: 3, 7, 8, 10, 13 and 20 channels.
If you want to connect multiple devices on one data link and use them in 20-channel mode, for
example, follow the steps below:
Set the starting address of the 1st device on the data link to 1 (001).
02) Set the starting address of the 2nd device on the data link to 21 (021), as 1 + 20 = 21.
03) Set the starting address of the 3rd device on the data link to 41 (041) as 21 + 20 = 41.
04) Continue assigning the starting addresses of the remaining devices by adding 20 to the previous
number each time.
Make sure that you do not have any overlapping channels in order to control each Performer Profile 700
Q6 correctly. If two or more devices are addressed similarly, they will work similarly.
