Shure MXW Specification sheet

MXW
Quick Setup
Quick start guide for Shure Microflex Wireless (MXW)
Version: 3 (2020-E)

Shure Incorporated
2/14
Table of Contents
MXWQuick Setup 3
MXW Wireless System 3
Connect the System 3
Power On the Devices 4
Charge the Microphones 4
Download the Shure Discovery Application 4
View Devices on the Network 5
Open the APT Web Interface 6
Select Devices for the Group 7
Link Microphones to the Group 8
Remove the Microphones 9
Test the Audio 10
MXW Help Links 11
Safety Information 11
WARNING 11
SAFETY PRECAUTIONS 12
WARNING 12
Important Product Information 13
Information to the user 13
Certifications 13
Trademarks 14

Shure Incorporated
3/14
MXW
Quick Setup
MXW Wireless System
①Wireless Microphones
②System processor and wireless transceiver
③Microphone linking and charging station
④Analog output device with gigabit network switch
⑤Shielded Cat5e cables (not included)

Shure Incorporated
4/14
Connect the System
Power On the Devices
Charge the Microphones
Note: the MXWNCS2 does not operate with gooseneck microphones.

Shure Incorporated
5/14
Download the Shure Discovery Application
To discover and access Shure devices on the network, download the Shure Web Device Discovery application from the Shure
website.

Shure Incorporated
6/14
View Devices on the Network
The Discovery app displays Shure devices networked to the computer.

Shure Incorporated
7/14
Open the APT Web Interface

Shure Incorporated
8/14
Select Devices for the Group
The group channel count is determined by the access point (APT) model: 2, 4 or 8 channels.

Shure Incorporated
9/14
Link Microphones to the Group

Shure Incorporated
10/14
Remove the Microphones
Microphone LEDs stop flashing when it is ready to use.

Shure Incorporated
11/14
•
•
•
Test the Audio
MXW Help Links
Use the information at the following links to ensure the successful configuration and use of Microflex Wireless:
How-To Videos
Training
User Guide
